P/N: 1802051501010
NPort P5250A Series Quick
Installation Guide
First Edition, August 2011
Overview
NPort P5250A series device servers are compact, palm-sized data
communication devices that allow you to control RS-232/422/485
serial devices over a TCP/IP-based Ethernet.
Note: “-T” indicates an extended temperature model.
Package Checklist
Before installing the NPort P5250A series device server, verify that
the package contains the following items:
•1 NPort P5250A serial device server
•4 stick-on pads
•Document & Software CD
•Quick Installation Guide
•Product Warranty Statement
Optional Accessory
•DK-35A: DIN-Rail Mounting Kit (35 mm)
Notify your sales representative if any of the above items are
missing or damaged.
Hardware Introduction
As shown in the following figures, NPort P5250A series device
servers have one male DB9 port for transmitting RS-232/422/485
serial data.
Reset Button—Press and hold the Reset button for 5 seconds to
load factory defaults: Use a pointed object, such as a straightened
paper clip or toothpick, to depress the reset button. This will cause
the Ready LED to blink on and off. Once the Ready LED stops
blinking (after about 5 seconds), release the reset button and the
device server will start to load the factory defaults.
WARNING
1. T
he equipment is designed for in-building
installation only and is not intended to be connected
to exposed (outside plant) networks.
2. This equipment is intended to be used in a
Restricted Access Location.
3. This product is intended to be supplied by an
UL60950
-1 and IEC60950-1 certified Power Unit
marked “LPS” and rated output rating: 12 to 48 VDC,
0.18 A minimum, 75°C.
LED Indicators—NPort P5250A’s top panel has three LED
indicators, which are described in the following table.
LED
Name
LED
Color
LED Function
Ready
Red
Steady on:
Power is on and the NPort is booting
up.
Blinking:
Indicates an IP conflict, or DHCP or
BOOTP server is not responding
properly.
Green
Steady on:
Power is on and the NPort is
functioning normally.
Blinking: The NPort has been located by the
NPort Administrator’s Location
function.
Off
Power is off, or a power error..
Link Orange
10 Mbps Ethernet connection.
Green 100 Mbps Ethernet connection.
Off Ethernet cable is disconnected.
Tx/Rx Orange
Serial port is receiving data.
Green
Serial port is transmitting data.
Off No data is being transmitted or received through
the serial port.
Adjustable pull high/low resistor and terminator for RS-485
Remove the NPort P5250A’s top cover
and you will find DIP switches to adjust
each serial
port’s pull-high, pull-low,
and terminator.
Do not use the 1 KΩ
setting with RS
-232 mode, as
doing so
will degrade the RS
-232 signals and
shorten the communication
s range.
SW
1
2
3
Pull-high resistor
Pull-low resistor
Terminator
ON
1 K
Ω
1 K
Ω
120
Ω
OFF
*150 K
Ω
*150 K
Ω
*---
*Default

– 4 – – 5 – – 6 –
www.moxa.com/support
The Americas:
[phone] (toll-free: 1-888-669-2872)
Europe:
[phone]
Asia-Pacific:
[phone]
China:
[phone] (toll-free: 800-820-5036)
2011 Moxa Inc. All rights reserved.
Hardware Installation Information
STEP 1: After removing the NPort P5250A series device server
from the box, if you are not using a PoE switch, the first thing you
should do is connect the power adaptor.
STEP 2: Connect the NPort P5250A series device server to a
network. Use a standard straight-through Ethernet cable to
connect to a PoE switch.
STEP 3: Connect the NPort P5250A series device server’s serial
port to a serial device.
STEP 4: Placement options.
In addition to placing the NPort P5250A on a desktop or other
horizontal surface, you may also make use of the DIN-Rail or Wall
Mount options, as illustrated below.
Software Installation Information
To install NPort Administration Suite, insert the NPort
Document & Software CD into your computer’s CD-ROM drive.
Once the NPort Installation CD window opens, click on the
Software folder, and then follow the instructions on the screen.
To view detailed information about NPort Administration Suite,
click on the Documents folder, and then select “NPort P5250A
Series User’s Manual” to open the pdf version of the user’s guide.
Pin Assignments
Ethernet Port Pinouts
Pin Number Ethernet
1
Tx+
2
Tx-
3 Rx+
6
Rx-
NPort P5250A—DB9 male (RS-232/422/485) port pinouts
Pin
Number
RS-232
RS-422/
485 (4W)
RS-485
(2W)
1
DCD
TxD-(A)
---
2
RxD
TxD+(B)
---
3
TxD
RxD+(B)
Data+(B)
4
DTR
RxD-(A)
Data-(A)
5 GND GND GND
6
DSR
---
---
7
RTS
---
---
8 CTS --- ---
9
---
---
---
Specifications
Power Requirements
Power Input
12 to 48 VDC (Supplied by power adapter)
or 48 VDC (Supplied by PoE.)
Power Output
12 VDC, 5W (Supplied from PoE)
Power Consumption
125 mA @ 12V, 40 mA @ 48 VDC (Supplied
by power adapter)
180 mA @ 48V (Supplied by PoE.)
Operating
Temperature
0 to 60°C (32 to 140°F), for standard
models
-40 to 75°C (-40 to 167°F), for -T models
Operating Humidity
5 to 95% RH
Dimensions
100 x 111 x 26 mm
(
3.94 x 4.37 x 1.02 in)
with ears
77 x
111 x 26 mm
(3.03 x 4.37 x 1.02 in)

without ears
Serial Line Protection
15 KV ESD for s
erial port
Level 2 Surge, EN61000-4-5
Magnetic Isolation
1.5 KV for Ethernet
Power Line
Protection
Level 2 Burst (EFT), EN61000
-4-4
Level 3 Surge, EN61000-4-5
Regulatory
Approvals
FCC Class A, CE Class A, UL 60950-1, EN
60950-1
