MPFiltri LPA2 Manual

Operators Guide LPA2
Portable Particle Counter

PRODUCT OVERVIEW
• LPA2 saves time: online/realtime monitoring
• Immediate hydraulic health check
• Predictive maintenance procedures can be employed
• Reduced downtime for industrial and mobile plants
• Reduced costs associated with downtime
• Fully portable
• Precision Instrument
• Full Calibration using ISO Medium Dust Test (MTD) based on ISO11171 on test equipment certied to ISO 11943
• Measures and displays the following international standard formats; ISO 4406, NAS 1638, AS 4059E Tables 1 & 2
• Moisture and temperature sensing
• Data logging and 600 test result memory
• Manual and remote control exibility
• LPA View software (included)
• Full size QWERTY keyboard
• Various test programme settings
• Full accessories kit included
• Internal rechargeable battery capable of performing 100 tests between charges
The LPA2 is a highly precise, lightweight & fully portable instrument suitable for on-site and laboratory applications. It can automatically
measure and display particulate contamination, moisture and temperature levels in various hydraulic uids. The LPA2 can be connected
to the MP range of bottle sampler products to enable laboratory based particle counting.
The LPA2 is a solution for online monitoring of contamination in your hydraulic uid, providing an immediate hydraulic health check. It
employs predictive maintenance procedures to help reduce downtime and in turn costs.
LPA2 - Portable Particle Counter
Features & Benets
Automatic Particle Counters
1

Product Presentation
The LPA2 is designed to measure and quantify the numbers of solid contaminants in Hydraulic, Lubrication and Transmission
applications. The LPA2 is designed to be a laboratory accurate instrument suitable for “on-site’’ applications utilising hydraulic uid
as the operating medium. Please contact your local sales ofce for other operating uid options.
The instrument uses the light extinction principle whereby two laser light systems shine through the uid and land on photodiodes.
When a particle passes through the beam it reduces the amount of light received by the photodiode, and from this change in
condition, the size of the particle can be deduced.
Hydraulic and Lubricating Systems consists of sets of continuously moving metal parts, which use hydraulic uid as the power
medium. Hydraulic uid is also used to create a lubrication lm to keep the precision parts separated and it is also used as a
cooling medium. The very nature of a hydraulic system is that it produces solid particulate contamination and these are ever
present in all hydraulic systems. There are various standards that quantify/ arrange/tabulate the amount of particle contamination
in specic volumes of uids and it is these levels that the particle counter is designed to measure.
Product features
Moisture sensor
LPA2-W models measure water content using a capacitive RH (relative humidity) sensor. The result is expressed as percentage
saturation. 100% RH corresponds to the point at which free water exists in the uid, i.e. the uid is no longer able to hold the water
in a dissolved solution. This is also normally the point at which signicant damage occurs in a hydraulic system, so is an ideal
measurement scale that is independent of the uid characteristics.
The water saturation point (100% RH) is temperature dependent, so the temperature is measured at the same time. This enables
results to be compared meaningfully.
The temperature measured is that of the uid passing through the unit.
Note: this may differ from that of the hydraulic system, depending on ow rate, pipe length and ambient temperature.
It is not intended to be an accurate indication of system temperature, but to provide a reference for the RH measurement at the
point of sample. Nevertheless, experience has shown the temperature measured is within a few degrees of that of the hydraulic
system, in most applications.
Automatic Particle Counters
2

Data logger
The LPA2 includes a built-in data logger, which adds the facility to log and timestamp test results locally within an internal
memory, even when not connected to a computer.
• Test logging is determined by the log settings
• Each log entry is time-stamped and contains the LPA2 serial number, so that it can be identied later.
• The LPA2 memory has space for around 600 log entries. When full, the oldest log entry is overwritten.
Optional built-in pressure transducer
LPA20P & LPA2WP models measure system pressure at inlet of the unit via a built in 0-600 bar pressure transducer with a sensor
accuracy of +/-0.5% Full scale.
Optional on-board thermal printer
All LPA2 products come with an on-board printer.
Fluid compatibility product versions
Options within the product code allow for a tailored product to suit and be compatible for a range of uids.
M and MW version: Mineral and synthetic oils, plus diesel uids *
N version: Offshore/Subsea and water-based uids *
S version: Phosphate ester and aggressive uids. Contact local MP Filtri branch or distributor.
* Please note: a suitable ushing procedure should be followed when switch from mineral based to water based uids and vice
versa. See document # 200.093 on supplied USB data stick.
Please note: a bottle sampling unit will be required to carry out the ushing procedure.
https://www.mpltri.co.uk/particle-counters/bs110-bs500/
Disclaimer
As a policy of continual improvement, MP Filtri reserves the right to alter the specication without prior notice.
PRODUCT OVERVIEW
Automatic Particle Counters
3

Automatic Particle Counters
4

DECLARATION OF CONFORMITY
EC Declaration of Conformity
The products included in this Declaration are all variants of the following:
• With or without moisture sensor
• Compatible with mineral oil/ synthetic uids, offshore uids and phosphate esters.
• With printer
• With/without pressure transducer
For part codes see the Designation & Ordering Code (section 4.7 on page 20).
Product Manufacturer:
MP Filtri UK
Bourton Industrial Estate
Bourton on the Water
Cheltenham
Gloucestershire
GL54 2HQ
[phone]
sales@mpltri.co.uk
The products described are in conformity with the following directives:
2014/30/EU Electromagnetic Conformity
Certication Testing that has been carried out is in accordance with:
• DEF STAN 00-35 Part 3 issue 4 Environmental Test Methods
• BS EN 60068 range of standards covering environmental conditions
• BS EN 60529: 1992 + A2:2013 Degrees of Protection provided by enclosures (IP Code)
• BS EN 62262:2002 Degrees of Protection Provided for Electrical Equipment against External Mechanical Impacts (IK Code)
• BS EN 60721-3-4: 1995 Part 3: Classication of Groups of Environmental Parameters and their severities, Section 3.4
Date: July 2020
Signed:
Phil Keep (Managing Director) on behalf of MP Filtri UK Ltd
Automatic Particle Counters
5

Product overview 1
EC Declaration of Conformity 5
Table of Contents 6
What this guide is for 8
1 General warnings and information for the Operator 10
1.1 General safety warnings 10
1.2 Operator position and dangerous areas 12
1.3 Dangers and Hazards that cannot be eliminated 12
1.4 Personal Protective Equipment 12
1.5 Precautions related to product handling of the Liquid Crystal Touchscreen display
2 Transportation and Storage 14
2.1 Transportation and Handling Conditions 14
2.2 Storage 14
3 Warranty, Limitations and Disclaimers 16
4. Technical Specication 18
4.1 Performance 18
4.2 Electrical Interface 18
4.3 Physical Attributes 19
4.4 Fluid Characteristics 19
4.5 Environment 19
4.6 Dimensions 20
4.7 Designation & Ordering code 20
5 Product Installation and General Operation 21
5.1 Installation 21
5.2 Online Operation 22
5.3 Main Test / Progress Screen 23
5.4 Analyser Settings 24
5.4.1 Test Reference 24
5.4.2 Test Number 24
5.4.3 Time and Date 24
5.4.4 Result Presentation Options 24
5.4.5 Test Type 25
5.4.6 Test Options 26
5.5 Preparing Analyser for Test 26
5.6 Interpreting Results 26
5.7 Further Results 28
5.7.1 Same Sampling Point 28
5.7.2 Different Sampling Point / Same System 28
5.7.3 New System 28
5.8 Shutting Down 29
5.9 Continuous Sampling 29
5.10 Continuous Sampling Basic Operation 30
5.11 Continuous Sampling with Clean Alarm Levels (Alarm Mode 1) 31
Pg.
13
Automatic Particle Counters
6

5.12 Moisture Sensor
5.13 Alarms
5.14 Wiring
5.15 Bottle Sampling
5.16 Battery Charging
5.17 Printer Paper
5.18 Computer Analysis
5.18.1 Software Installation
5.18.2 Results Download
6 Troubleshooting / FAQ
6.1 Misuse of Product
6.2 Fault Finding
6.3 Warranty
6.4 Calibration
6.5 Clean Working Practices
7 Reference
7.1 Spare Product / Part numbers
7.2 Com Ports
7.2.1 Connection Using a USB Port
7.2.2 Determining the Com Port
34
34
36
37
38
39
40
40
40
42
42
42
43
43
44
46
46
46
46
46
TABLE OF CONTENTS
Pg.
Automatic Particle Counters
7

What this guide is for
This guide will take you through the installation and instructions for making the most out of your LPA2.
It contains detailed information to enable you to master the full functionality of the device, as well as key information on safety,
waranty, maintenance and accessories.
At MP Filtri we are commited to customer service and hope this manual will help you to fully master the LPA2.
Disclaimer
As a policy of continual improvement, MP Filtri reserves the right to alter the specication without prior notice.
Automatic Particle Counters
8

OPERATOR’S GUIDE
Automatic Particle Counters
9

It means that failure to comply with the relevant safety regulations may result in mild injury or property damage.
It relates to important information concerning the product, its use or part of this documentation
to which special attention must be paid
It means that failure to comply with the relevant safety regulations may result in death, serious injury
or serious property damage.
CAUTION
NOTE
DANGER
!
!
!
1 General warnings and information for the Operator
1.1 General Safety Warnings
Do not operate, maintain or carry out any procedure before reading this manual. Any individual operating the unit shall wear the
following Personal Protective Equipment:
- Protective eyewear
- Safety shoes
- Gloves
- Overalls (or other suitable protective clothing)
Before carrying out any machine installation procedures and/or before use, one should scrupulously follow the in- structions listed
in this manual. Moreover, it is necessary to comply with the current regulations related to occupational accident prevention and
safety in the workplace.
Notices aimed at the prevention of health hazards for personnel operating the machine are highlighted in this document with signs
having the following meaning:
Failure to comply with the relevant safety regulations may result in death, serious injury or serious property damage.
Automatic Particle Counters
10

GENERAL WARNINGS
To allow rapid identication of the employees who must read this manual, denitions have been used with the following meaning:
This is any individual whose task is to use the machine for production purposes. The operator is
aware of all the measures taken by the machine manufacturer in order to eliminate any source
of injury risk in the workplace and takes into account the operational constraints.
This is any individual whose task is to carry out maintenance activities on the machine.
The maintenance technician is aware of the possible danger situations that may arise and takes
the appropriate precautions in order to eliminate the risks of accidents in the workplace.
This is any individual whose task is to carry out maintenance activities on the electrical wiring of
the machine. The electrician is aware of the possible danger situations that may arise and takes
the appropriate precautions in order to eliminate the risks of accidents in the workplace.
This is any individual whose task is to handle the machine or parts of it. Personnel involved in
slinging and hoisting operations are aware of the issues regarding the safe transfer of machinery
or parts of it and, therefore, uses appropriate lifting equipment, following the instructions provided
by the product manufacturer.
This is any individual whose task is to set up the machine for its operation. The machine setter
is aware of the measures taken to eliminate all sources of injury risks in the workplace and
takes into account the operational constraints. The machine setter takes all the appropriate
precautions in order to operate in utmost safety conditions.
OPERATOR
MAINTENANCE
TECHNICIAN
ELECTRICIAN
PERSONNEL INVOLVED
IN SLINGING AND
HOISTING OPERATIONS
MACHINE SETTER
Automatic Particle Counters
11

1.2 Operator Position and Dangerous Areas
The operator should be trained to use this equipment. Care should be taken when connecting to live systems. Always
connect to the LPA2 unit rst then connect to a system. The waste should always be to atmosphere, failure to do so may
result in damage to the unit and leakage of uid.
1.3 Dangers and Hazards that cannot be eliminated
- Burn risk because of high temperatures
- Accidental oil leaks with consequent risk of slipping
- Hose breakage and resulting lubricant loss
- With oil temperatures exceeding 40/45°C, it is vital to be extremely careful when connecting to live systems and when
moving the unit. Avoid direct contact with hot oil.
ALL EQUIPMENT SHOULD BE ALLOWED TO COOL PRIOR TO HANDLING, AFTER IT HAS BEEN IN USE
1.4 Personal Protective Equipment
When operating the unit, personnel must be wearing safety shoes, gloves and goggles. In general, the PPEs to be used according
to the activities on the machinery are listed in the following table:
ACTIVITY
Ordinary operation
Planned maintenance
Shoes, gloves, goggles, overall
Shoes, gloves, goggles, overall
PPE
The unit shall be taken out of service and/or dismantled in accordance with the current regulations in force
in the country where the machinery is installed
The machinery is not suitable for outdoor use and all the electrical devices have a protection class
starting from IP 55 upwards.
NOTE
!
CAUTION
!
Automatic Particle Counters
12

GENERAL WARNINGS
1.5 Precautions related to product handling of the LPA2
Battery
• It is recommended that the LPA2 be charged for a minimum of 24 hours prior to rst use, to fully charge the internal battery
Internal Cleaning
• Do NOT clean the LPA2 or Bottle Sampler with Acetone or similar solvents that are not compatible with the seals in the LPA2.
The recommended cleaning uid for internal ushing is Petroleum Ether
• The use of a 500μm coarse screen lter, screwed onto the HP connector, is recommended for heavily contaminated systems.
LCD Visibility
• If the LCD screen remains blank then refer to page 38 for recharging instruction. To improve the LCD screen visibility, the
Analyser can be inclined by unlatching the two extension feet tted to the bottom of the case.
Automatic Particle Counters
13

Automatic Particle Counters
14

TRANSPORT / STORAGE
2 Transportation and Storage
2.1 Transportation and handling Conditions
The unit is shipped in a cardboard box with appropriate protective packaging and these should be recycled accordingly
where possible.
The packed weight of the LPA2 and accessories is 14 kg, the box dimensions are 60 x 50 x 40 cm.
2.2 Storage
The unit should be stored in a suitable location away from the production area when not in use. The unit should be stored with
the caps provided on the ports. This location should not impede any other production or personnel.
Automatic Particle Counters
15

3 Warranty, Limitations and Disclaimers
MP Filtri warrants that the products that it manufactures and sells will be free from defects in material, workmanship & performance
for a period of 12 months from the date of shipment.
Hardware/Firmware
Should the hardware prove defective during the warranty period, MP Filtri, at its discretion, will either repair the defective product
or replace it with an equivalent product in exchange for the defective unit without charge for parts, labour, carriage and insurance.
Software
MP Filtri warrants that software will operate substantially in accordance with its functional specication for 12 months from date
of shipment provided that the integrity of the operating environment has not been compromised through misuse, inappropriate
handling, abnormal operating conditions, neglect or damage (unintentional or otherwise) or the introduction of third party product
(software or hardware) that in any way conicts with the MP Filtri product.
Eligibility
This warranty extends to the original purchaser only or to the end-user client of a MP Filtri authorised afliate.
How to obtain service?
To obtain service under the terms of this warranty, the customer is required to notify MP Filtri before the expiration of the warranty
period and to return the item in accordance with MP Filtri product return policy. Any product returned for warranty repair must be
accompanied by a full fault report specifying the symptoms and the conditions under which the fault occurs. Should MP Filtri incur
additional cost as a result of a failure to complete the appropriate paperwork, an administrative charge may be levied.
Exclusions
This warranty shall not apply to any defect, failure or damage caused by improper use or improper or inadequate care. MP Filtri
shall not be obligated to provide service under this warranty if:
a) Damage has been caused by a failure to make a full and proper inspection of the product (as described by the
documentation enclosed with the product at the time of shipment) on initial receipt of the product following shipment;
b) Damage has been caused by the attempts of individuals, other than MP Filtri staff to repair or service the product;
c) Damage has been caused by the improper use or a connection with incompatible equipment or product including software
applications.
Charges
Under cover of this warranty, MP Filtri will pay the carriage and insurance charges for the shipment of defective product back to
site of manufacture and for its return to the client’s original site of despatch except when:
a) MP Filtri product return policy has not been followed.
b) Product failure is caused by any of the exclusions described above, when the customer will be liable for the full cost of the repair
(parts and labour) plus all carriage and insurance costs to and from MP Filtri premises.
c) The product is damaged in transit and a contributory cause is inadequate packaging. It is the customer’s responsibility to ensure
that the packaging used to return equipment to MP Filtri is the same, or has equivalent protective qualities, to that used to ship
the product to the customer in the rst instance. Any damage resulting from the use of inadequate packaging will nullify MP Filtri
Automatic Particle Counters
16

WARRANTY
obligations under this warranty. Should the customer’s product be damaged in transit following a repair at MP Filtri site, a full
photographic record of the damage must be obtained (packaging and the product) to support any claim for recompense. Failure to
present this evidence may limit MP Filtri obligations under this warranty.
THIS WARRANTY IS GIVEN BY MP FILTRI IN LIEU OF ANY OTHER WARRANTIES, EXPRESS OR IMPLIED, INCLUDING BUT NOT LIMITED
TO ANY IMPLIED WARRANTY OF MERCHANTABILITY, NON INFRINGEMENT OR FITNESS FOR A PARTICULAR PURPOSE. MP FILTRI LTD
SHALL NOT BE LIABLE FOR ANY SPECIAL, INDIRECT, INCIDENTAL OR CONSEQUENTIAL DAMAGES OR LOSSES ( INCLUDING LOSS
OF DATA), WE SPECIFICALLY DISCLAIM ANY AND ALL WARRANTIES TO CUSTOMERS OF THE CUSTOMER. THE CUSTOMER’S SOLE
REMEDY FOR ANY BREACH OF WARRANTY IS THE REPAIR OR REPLACEMENT, AT MP FILTRI DISCRETION, OF THE FAILED PRODUCT.
MP Filtri Ltd maintains a policy of product improvement and reserves the right to modify the specications without prior notice.
It is requested that only the LPA2, not the support case or any other ancilliaries, be returned for recalibration.
MP Filtri will not be held responsible for any items returned as such.
Ensure that the LPA2 is packed appropriately for transportation.
3.1 Warranty on Recalibration
The LPA2 is guaranteed for 12 months upon receipt of the LPA2, subject to it being used for the purpose intended and operated in
accordance with this User Guide.
MP Filtri will only verify the accuracy of the LPA2 if the unit is recalibrated every 12 months.
Please ensure that the test results in the Log are downloaded to LPA-View before the LPA2 is despatched,
in case action taken by MP Filtri during the service / recalibration causes the Log to be cleared. NOTE
!
Automatic Particle Counters
17

4.2 Electrical interface
Supply Voltage 9-36V DC
Supply Current 2A Max
Power Consumption Charging state: ~40W max
Idle State: 3W max
Note: Power consumption level can vary dependant on uid properties
Test Time 8 ml. (short): 2:50
15 ml. (normal): 5:00
30 ml. (dynamic): 10:00
24 ml. (bottle sampler): 8:00
15 ml. (continuous): 5:00
Data Storage Approximately 600 timestamped tests in the integral LPA2 memory
Keypad & LCD Full size QWERTY keyboard and backlit graphical LCD
Communication Options 9 pin D type RS232 serial port for direct connection to PC and software
4.Technical Specication
4.1 Performance
Technology Twin laser and twin optical diode detectors Based Light Extinction Automatic
Optical Particle Analyser
Particle Sizing >4, 6,14, 21, 25, 38, 50, 70 μm(c) to ISO 4406 Standard
Analysis range ISO 4406 Code 8 to 24
NAS 1638 Class 2 to 12
AS4059 Rev.E. Table 1 Size Codes 2-12
AS4059 Rev.E, Table 2 Size Codes, A:000 to 12, B:00 to 12, C:00 to 12, D:2to12,
E:4to12, F:7to12
Calibration Each unit individually calibrated with ISO Medium Test Dust (MTD) based on ISO
11171, on equipment certied by I.F.T.S. To ISO 11943
Moisture Sensing % RH (Relative Humidity) ±3%
Temperature Measurement ±3%°C
Accuracy ±1 ISO code for 4, 6, 14, 21, 25, 38, 50, 70 μm
±3°C (± 5.4F)
±3%RH
Automatic Particle Counters
18
