mr. steam AudioSteam User manual

AudioSteam®
Installation, Operation, and Maintenance Manual
mr
.steam®Feel Good Inc.
®
Installation, Operation and Maintenance Manual

READ ME FIRST:
1. Read and follow all instructions within this technical manual.
2. Heed all warnings, cautions, notices, and important notes.
3. Save this technical manual and leave with the homeowner.
ABOUT WARNINGS, CAUTIONS, NOTICES, AND IMPORTANT NOTES:
As you follow the instructions in this technical manual, you will see four types of callouts: WARNINGS, CAUTIONS,
NOTICES, and IMPORTANT NOTES. This blocked information is important for the safe and efficient installation, mainte-
nance, and operation of the AudioSteam. These callouts are described as follows:
SAFETY INSTRUCTIONS:
To prevent personal injury and or product damage, please read the following important safety instructions carefully before
installing the AudioSteam:
• Do not install the AudioSteam near any heat sources.
• Clearance and minimum distance between the AudioSteam and the surrounding structure are not specified as long as
they are sufficient so that the ambient temperature around the apparatus does not exceed 140 °F (60 °C).
• Do not defeat the safety purpose of the polarized and/or grounding type plug. A polarized plug has two blades, with
one wider than the other. A grounding type plug has two blades and a third grounding prong. The wide blade or the
third prong are provided for your safety. If the provided plug does not fit into your outlet, consult an electrician for
replacement of the obsolete outlet.
• Protect the power cord from being walked on or pinched, particularly at plugs, convenience receptacles, and at the point
where the cord exits from the apparatus.
• Only use attachments/accessories specified by the manufacturer.
• All servicing to be performed by qualified service personnel. Servicing is required when the AudioSteam is damaged
in any way, including when the power-supply cord or plug is damaged, liquid is spilled into or objects fall into the
AudioSteam, AudioSteam is exposed to rain or moisture, the AudioSteam does not operate normally, or the AudioSteam
dropped.
• Do not disassemble or alter the AudioSteam in any way.
• Clean the AudioSteam with a dry cloth only. Beware of the application of some products commonly used against cor-
rosion (such as WD-40
®
family products), as some industrial oils can have negative chemical reactions and damage the
housing materials of the AudioSteam. Any other materials that may come in contact with the AudioSteam must be care-
fully evaluated under end-use conditions for compatibility.
2
Indicates a potentially hazardous situation,
which, if not avoided, may result in death
or serious injury.
These instructions are for use by qualified service personnel
only. To reduce the risk of electric shock, do not perform any
servicing, other than that contained in these instructions.
Indicates a potentially hazardous situation,
which, if not avoided, may result in minor
or moderate injury.
Indicates a situation, which, if not avoided,
may result in property damage.
IMPORTANT SAFETY INFORMATION
NOTE: All information in this technical manual is based on the latest product information available at the time of
publication. Sussman-Automatic Corporation reserves the right to make changes at any time without notice.
IMPORTANT NOTE
Indicates information that is especially
relevant to a problem-free installation.
NOTICE
WARNING
!
WARNING
!
CAUTION
!

3
Before installing or connecting the AudioSteam, please read the following:
• To prevent a shock hazard, do not disassemble or alter the AudioSteam.
• To prevent overtemperature shutoff and equipment damage, do not use foam to insulate the
AudioSteam.
• To prevent a shock hazard, turn power off before servicing or changing any cable connections
in the AudioSteam.
• To prevent electric shock hazard and/or water damage to the AudioSteam, all conduits must
be plugged with the included foam blocks.
• To prevent a shock hazard do not install the AudioSteam in a location where it can get wet.
Audiosteam must be installed in a dry, indoor location.
• AudioSteam must be disposed of separately in accordance with local waste disposal legislation.
• Risk of electric shock. Do not leave compartment door open.
• Risk of electric shock. Replace components only with identical components.
• Prevent electrocution. Do not connect any auxiliary components (for example cable, additional
speakers, headphones, additional audio/video components, etc.) to the system.
• These units are not provided or intended to be connected to an outdoor antennae; to prevent
electrocution only use the supplied antennae and install it in accordance with these instructions.
• Opening or removing covers may expose you to dangerous voltage or other risk of injury.
All servicing to be performed by qualified service personnel.
• When the power supply connections or power supply cord(s) are damaged; if water is entering
the audio/video compartment or any electrical equipment compartment area; if the protective
shields or barriers are showing signs of deterioration; or if there are signs of other potential
damage to the unit, turn off the unit and refer servicing to a qualified service personnel.
• This unit should be subjected to periodic routine maintenance (for example, once every 3
months) to make sure that the unit is operating properly.
• Product must be disposed of separately in accordance with local waste disposal legislation.
IMPORTANT SAFETY INFORMATION (cont.)
WARNING
!
WARNING
!

pur 100516 rev 1.18
mr.steam®
Sussman-Automatic Corporation® • www.mrsteam.com • [email protected]
43-20 34th Street, Long Island City NY 11101 1 800 76 STEAM fax: [phone]
9410 S. La Cienega Blvd., Inglewood CA 90301 1 800 72 STEAM fax:[phone]
4
mr.steam® INSTALLATION, OPERATION, AND MAINTENANCE AudioSteam®
TABLE OF CONTENTS
INSTALLER INSTRUCTIONS
1. General information................................................ 5
Box Contents................................................................5
AudioSteamJ2 General installation............................5-6
2. Installing AudioSteam............................................. 7
AudioSteam Dimensions..............................................7
Locating and Installing AudioSteam ............................7
3. Connecting AudioSteam ......................................... 8
Connecting AudioSteam..............................................8
Removing the AudioSteam Cover ...............................8
Connecting the FM Antenna and Auxiliary Cord.........9
Connecting Speakers and Subwoofer..........................9
Connecting AudioSteam to the Steam Generator ....10
Pairing a Bluetooth-Enabled Device..........................11
4. AudioSteam Specifications ................................... 12
5. Regulatory Statements ......................................... 13
HOMEOWNER/END-USER INSTRUCTIONS
6. About AudioSteam ............................................... 14
7. Operating AudioSteam .................................... 14-15
8. AudioSteam Warranty........................................... 15

5
Box Contents
AudioSteam General Installation
Figure 1 shows how the AudioSteam interconnects with the
steam generator, iSteam3, and audio speakers.
Figure 2 shows how to use the AudioSteam as a standalone
system within your steam room (i.e., if your steam room does
not use iSteam3).
All drawings are for illustrative purposes only.
1. General Information
AudioSteam FM antenna Control cable
INSTALLER INSTRUCTIONS
mr.steam® INSTALLATION, OPERATION, AND MAINTENANCE AudioSteam®
IMPORTANT NOTE
AudioSteam only integrates with iSteam3.
