MRC DW-6160 User manual

WATT/Leakage METER
Model : DW-6160 Your purchase of this
WATT/Leakage METER
marks a step forward for
you into the field of
precision measurement.
Although this
WATT/Leakage METER
is a complex and
delicate instrument, its
durable structure will
allow many years of use
if proper operating
techniques are
developed. Please read
the following
instructions carefully
and always keep this
manual within easy
reach.
OPERATION MANUAL

Caution Symbol
Caution :
* Risk of electric shock !
Caution :
* Do not apply the overload
voltage, current to the input
terminal !
* Remove test leads before open
the battery cover !
* Cleaning - Only use the dry
cloth to clean the plastic case !
Environment Conditions
*
Installation Categories II 600V.
*
Pollution Degree 2.
*
Altitude up to 2000 meters.
*
Indoor use.
*
Relative humidity 80% max.
Equipment protected throughout
by double insulation or reinforced
insulation.

TABLE OF CONTENTS
1. FEATURES................................................................. 1
2. SPECIFICATIONS.................................................... 2
2-1 General Specifications............................................ 2
2-2 Electrical specifications...........................................3
3. FRONT PANEL DESCRIPTION..................................... 6
3-1 Display..................................................................6
3-2 Backlight button................................................. 6
3-3 Record button ( MAX. / MIN. )............................... 6
3-4 Data hold button.................................................. 6
3-5 Power & function rotary switch .......................... 6
3-6 ACV / DCV & Ωinput terminal.............................. 6
3-7 Load terminal....................................................... 6
3-8 Power source terminal......................................... 6
3-9 Battery Cover / Compartment.................................6
3-10 Stand................................................................ 6
3-11 RS-232 output terminal........................................ 6
3-12 DC 9V power adapter input socket........................ 6
4. MEASURING PROCEDURES.......................................... 7
5. MAINTENANCE........................................................... 8
6. RS232 PC SERIAL INTERFACE.................................... 9
7. BATTERY REPLACEMENT........................................... 10
8. THE ADDRESS OF AFTER SERVICE CENTER..................11

1. FEATURES
* Professional WATT meter with Leakage current tester
digital display , battery operated .
* LSI - circuit provides high reliability and durability .
*Measurement
WATT ( AC ) : 2500W x 0.1 W / 1 W.
Leakage current ( AC mA ) : 80.00 mA x 0.01 mA.
ACV : 600.0 V x 0.01 V / 0.1 V.
ACA : 10.00 A x 0.001 A / 0.01 A.
DCV : 600.0 V x 0.01 V / 0.1 V.
Ω: 20 kΩx 0.01 kΩ/ 0.001 kΩ/ 1 Ω.
* Low Watt measurement , 999.9 Watt x 0.1 W.
* True Power and Wide range 0 to 2500 Watt.
* True RMS measurement of ACV / ACA.
* Leakage detect ( AC mA ) detection.
* Continuity beeper.
* Super large LCD , Dual display at same time.
* Full function Auto range.
* Memory Record ( Max. , Min. ) , Data Hold.
* RS232 / USB Computer interface.
* Built-in low battery indicator.
* Built-in backlight easy to readout .
* Power : DC 1.5V (UM-3 , AA ) x 8 PCs or DC 9V
adapter in.
1

2. SPECIFICATIONS
2-1 General Specifications
Circuit Custom one-chip of microprocessor
LSI circuit.
Display Large LCD display Max. reading 9999.
LCD size :90.5 x 64.5 mm.
Dual value display with backlight.
Measurement ACV 0 to 600.0 V
DCV 0 to 600.0 V
Ω0 Ωto 20.00 kΩ
WATT 0.1 W to 2500 W
Leakage 0.01 m A to 80.00 m A
current
ACA 0.01 A to 10.00 A
Over input " - - - - " mark indication .
Polarity Automatic switching , "-" indicates
reverse polarity.
Zero Adjustment Automatic adjustment.
Sampling Time Approx. 1.5 second.
Data Hold Freeze the display reading.
Memory Recall Maximum & Minimum value.
Data output RS232 / USB PC Computer interface .
* Connect the optional RS232 cable
UPCB - 02 will get the RS232 plug .
*Connect the optional USB cable
USB - 01 will get the USB plug .
Operation 0 to 50 (32 to 122 ) .℃℃℉ ℉
Temperature
Operation Less than 80% RH.
Humidity
2

Power Supply Alkaline or heavy duty DC 1.5 V battery
( UM3, AA ) x 8 PCs, or equivalent.
*
A
DC 9V adapter input. ( AC/DC power
adapter is optional ).
Power Approx. DC 33 mA
Consumption
Weight 883 g / 1.95 LB
Dimension 224 x 125 x 65 mm
( 8.8x 4.8 x 2.5 inch )
Standard Instruction manual................
.
1 PC
Accessories
T
est lead ( Red & Black ).......
.
1 pair
Included
Optional * AC/DC 9V adapter, AP-9VA.
Accessories * USB cable , USB - 01.
* RS232 cable , UPCB - 02.
* Data Acquisition software,
SW-U801-WIN.
* Hard carrying case , CA-08.
2-2 Electrical specifications (23±5 )℃
AC / DC VOLTAGE
Range Range 1 0.01V to 99.99V
Range 2 100 V to 600V
Resolution Range 1 0.01 V
Range 2 0.1 V
Accuracy ACV ± (1 %+5d)
DCV ± (0.8 %+5d)
* Measuring Signals come from the front panel terminals.
* Auto range.
* Max. input voltage : AC 600 V, DC 600 V.
* ACV accuracy is test under input signal is sine wave,
50/60 Hz
*ACV frequency response is from 40 to 400 Hz.
* ACV is true rms measurement..
3

OHMS ( Resistance )
Range Resolution Accuracy
0 to 999 Ω1 Ω± (1 % + 1d )
1.000 to 9.999 KΩ0.001 KΩ± (1 % + 1d )
10 to 20 KΩ0.01 KΩ± (1 % + 1d )
* Auto range.
* Continuity beeper : < 4 Ω.
* Overload Rating : AC / DC 600V at 20 second Max
WATT ( true power )
Range Resolution Accuracy
1000 W 0.1 W ± (1.5 % + 5d )
1001 to 2500 W 1 W ± (1.5 % + 5d )
* 0.1 W resolution : Input voltage < 120 AVC or
Input current < 1 ACA.
Beyond above input, the resolution will still be 1 W.
*Measuring Signals come from the top power plug input..
* Accuracy is test under input signal is sine wave, 50/60 Hz
* ACV, ACA frequency response is from 40 to 400 Hz.
* Max. input voltage : AC voltage 250 V, AC current : 10 A.
Leakage ( AC mA )
Range Resolution Accuracy
0 to 80 mA 0.01 mA ± (1 % + 5d )
*The leakage current that sense between the " Hot line " and the "
Earth " of the measuring installation that connect to the output "
Power plug "
4

V, A ( true rms )
Range Resolution Accuracy
ACV 250 V 0.01 V/0.1 V ± (1 % + 5d )
ACA 10 A 0.001 A/0.01A ± (1 % + 3d )
* ACV, 0.01 V resolution is valid from 0.01 V to 99.99 V.
ACV, 0.1 V resolution is valid from > 100.0 V.
* ACA, 0.001 A resolution is valid from 0.001 A to 1.200 A.
ACA, 0.01 A resolution is valid from > 1.2 A.
* Measuring signals come from the top power plug input
( power source ).
* Auto range.
* ACV, ACA accuracy is test under input signal is sine wave,
50/60 Hz
*ACV, ACA frequency response is from 40 to 400 Hz.
* ACV, ACA is true rms measurement..
* Max. input voltage : AC voltage 250 V, AC current : 10 A.
5

3. FRONT PANEL DESCRIPTION
Fig. 1
3-1 Display
3-2 Backlight button
3-3 Record button ( MAX. / MIN. )
3-4 Data hold button
3-5 Power & function rotary switch
3-6 ACV / DCV & Ωinput terminal
3-7 Load terminal
3-8 Power source terminal
3-9 Battery Cover / Compartment
3-10 Stand
3-11 RS-232 output terminal
3-12 DC 9V power adapter input socket
6

4. MEASURING PROCEDURE
4-1 ACV measurement procedure
1)Rotate the function switch to the " ACV " position and
Power ON the meter.
2)Connect Red test lead to the " V Ω" input terminal and
Black test lead to " COM " input terminal.
3)Use the test lead measurement unknown AC voltage.
4)Read the Display. The show value will correspond to the
position selected. If the Display shows " ---- ", it
indicates an out-of-range measurement.
4-2 DCV measurement procedure
1)Rotate the function switch to the " DCV " position and
Power ON the meter.
2)Connect Red test lead to the " V Ω" input terminal and
Black test lead to " COM " input terminal .
3)Use the test lead measurement unknown DC voltage.
4)Read the display . The show value will correspond to the
position selected. If the Display shows " ---- " it
indicates an out-of-range measurement.
Remark :
* Observe polarity when measuring DC voltage.
4-3 Resistance measurement procedure
1)Rotate the function switch to the Ωposition and Power
ON the meter.
2)Connect red test lead to the " V Ω" input terminal and
black test lead to " COM " input terminal .
Connect test lead to the resistance.
7

3)Read the display . The show value will indicate
correspond to the position selected. If the display
shows " ---- " it indicates an out-of-range measurement.
4)When resistance < 4Ωthe buzzer will continuity beeper .
4-4 Watt measurement procedure
1)Rotate the function switch to the " WATT/Leakage " position.
2)Make sure your equipment work voltage, such as 110 V
or 220 V.
3)Plug in the power source to " AC POWER INPUT " terminal,
it locate the left position of Top Panel.
4)Plug in the equipment power line to the " LOAD " Terminal,
it locate the right position of Top Panel.
5)Turn on the equipment power switch.
6)It can read the Power Consumption value on the top LCD
Display. At the same time. If your equipment exist current
leakage. It will show the leakage current value on the
bottom LCD Display.
4-5 V ( voltage ) A ( current ) measurement procedures
When your equipment is on working. You can rotate the
function switch to V A Position. The upper value will show
working voltage. The bottom value will show the current
consumption value.
5. MAINTENANCE
1)The meter is intended for measuring the TRUE RMS
POWER VALUE, at the same time it also can measure the
leakage current value to verify if the measurement
equipment is under safety condition or not.
2)When measuring POWER VALUE, the working voltage
of measurement equipment must be checked before
turn on the equipment.
8

3)Instruments used in dusty environments should be
stripped and cleaned periodically.
4)Do not leave the instrument exposed to direct heat from
the sun for long periods.
5)Before removing the battery compartment cover, ensure
that the instrument is disconnect from any circuit and
the power switch is on the OFF position.
6. RS232 PC SERIAL INTERFACE
The instrument has RS232 PC serial interface via a 3.5
mm terminal ( 3-11, Fig. 1 ).
The data output is a 16 digit stream which can be
utilized for user's specific application.
A RS232 lead with the following connection will be
required to link the instrument with the PC serial port.
Meter PC
(9W 'D" Connector)
Center Pin..........................Pin 4
(3.5 mm jack plug)
Ground/shield.......................Pin 2
2.2 K
resistor
Pin 5
The 16 digits data stream will be displayed in the
following format :
D15 D14 D13 D12 D11 D10 D9 D8 D7 D6 D5 D4 D3 D2 D1 D0
9

Each digit indicates the following status :
D0 End Word
D1 & D8 Display reading, D1 = LSD, D8 = MSD
For example :
If the display reading is 1234, then D8 to
D1 is : 00001234
D9 Decimal Point(DP), position from right to the
left
0 = No DP, 1= 1 DP, 2 = 2 DP, 3 = 3 DP
D10 Polarity
0 = Positive 1 = Negative
D11 & D12 Annunciator for Display
ACV = 50 DCV = 34 KΩ= 39
Ω= 38 W = 47 m A = 53
ACA = 52
D13 When send the upper display data = 1
When send the lower display data = 2
D14 4
D15 Start Word
RS232 FORMAT : 9600, N, 8, 1
Baud rate 9600
Parity No parity
Data bit no. 8 Data bits
Stop bit 1 Stop bit
7. BATTERY REPLACEMENT
1)
When the left corner of LCD display show " " , it is
necessary to replace the battery, However in -spec.
measurement may still be made for several hours after
Low Battery Indicator appears before the instrument
become inaccurate.
10

2)Open the screw of "Battery Cover "by screwdriver, then
move the batteries.
3)Replace with 1.5V x 8 PCs batteries and reinstate the cover.
8. THE ADDRESS OF AFTER SERVICE
CENTER
11
3, Hagavish st. Israel 58817 Tel: [phone], Fax: [phone]
[email protected]
MRC. 7.18
