MSA MPC-127 User manual

Limited Liability Company
«NPK MORSVYAZAVTOMATICA»
26E, Kibalchicha str., 192174, St
Petersburg, Russia
[email protected]
www.unicont.com
Phone.: [phone]
Fax: [phone]
COMPUTER SYSTEM UNIT
OF TYPES MPC-127, MPC-19-4
Operating Manual

Version 0.12
Computer system unit of types
MPC-127, MPC-19-4
TABLE OF CONTENT
INTRODUCTION.........................................................................................................................3
1DESCRIPTION AND OPERATION OF THE DEVICE ...................................................4
1.1 Description ...............................................................................................................................4
1.2 Technical specifications ...........................................................................................................4
1.3 The Product’s structure and operation......................................................................................6
1.4 Measurement tools, instruments and appliances....................................................................10
1.5 Marking and sealing...............................................................................................................10
1.6 Packaging ...............................................................................................................................10
2INTENDED USE...................................................................................................................11
2.1 Operational constraints...........................................................................................................11
2.2 Preparation for the Product operation.....................................................................................11
2.1 Usage of the Product ..............................................................................................................12
3TECHNICAL SERVICE OF THE PRODUCT.................................................................13
3.1 General instructions................................................................................................................13
3.2 Safety features........................................................................................................................13
3.3 Maintenance routine...............................................................................................................13
3.4 Preservation............................................................................................................................15
4INSTALLATION AND DISASSEMBLY OF THE PRODUCT......................................16
4.1 General description.................................................................................................................16
4.2 Safety features........................................................................................................................16
4.3 Сurrent repair..........................................................................................................................16
5STORAGE.............................................................................................................................17
6TRANSPORTATION...........................................................................................................18
7DISPOSAL.............................................................................................................................19
8WARRANTY.........................................................................................................................20

3 Version 0.1
Operating Manual
INTRODUCTION
This operating manual (hereinafter referred to as the OM) covers structure,
construction, specifications of Computer system unit of types MPC-127, MPC-19-4
(hereinafter referred to as the Product), its components and instructions required for the
Product’s correct and safe operation (intended use, technical service, current repair), as
well as disposal information for its components.
Only those who have read operational documentation shall be permitted to
operate with the Product.
Only those who have had general education in the area of electronic devices and
read operational documentation shall be permitted to provide the Product’s service.

Version 0.14
Computer system unit of types
MPC-127, MPC-19-4
1DESCRIPTION AND OPERATION OF THE DEVICE
1.1 DESCRIPTION
The Product is designed to be applied as a control computer, component of
shipborne automation, navigation and surveillance devices, etc.
1.2 TECHNICAL SPECIFICATIONS
1.2.1 Main parameters and technical specifications of the Product
are represented in Table 1.
Table 1 –Technical specifications of the Product
Parameter
MPC-127
MPC-19-4
Значение
CPU
Intel Core i3, Intel Core i5, Intel Core i7, Intel Pentium
Graphics, MB
included, 1024, 2048, 4096, 8192
RAM, GB
4, 8, 16, 32
Type and capacity of HDD, GB1)
480, 960, 2 ТБ, 4 ТБ
Software2)
Windows 7x86, Windows 7x64, Windows 10x64
Astra Linux Special Edition
Supported interfaces, pcs.
1 x Audio input, audio output, microphone
8 хUSB 2.0, 2 хUSB 3.0
1 хVGA, 1 x DVI
1 хEthernet 10/100/1000 Base-T
1 хCOM (RS-232)
2 x PS/2 (keyboard and manipulator)
Supply voltage
220 VAC, 110 VAC, 24 VDC, 12 VDC
Max. Power consumption, W3)
550
Protection degree
IP22
Operating temperature, °С
–60 … +70
Temperature limit, °С
–15 … +55
Монтаж
desk top
19'' rack
Type of connectors
standard
1) Specify HDD type at order (HDD or SSD).
2) Another OS may be installed on request.
3) Standard power characteristics.
1.2.2 The Product ensures:
–data processing, reception and transmission with connected devices via
interfaces; installed software control;
–display of computing processes on the screen according to the installed
software;
–automatic configuration control and software load under Basic Input and
Output System (BIOS) when the Product is switched on and setup initially;
–continuous operation mode;
–performing autonomous operations in all operating conditions including
emergency ones.

5 Version 0.1
Operating Manual
1.2.3 Products’ overall dimensions depending on the diagonal are represented in
Figures 1 и2.
Note –Overall dimensions in Figures 1 and 2 are informative and may differ
from particular Product design depending on the order. Inquire the manufacturer for
overall dimensions of particular Product design
Figure 1 –Overall dimensions of the Product MPC-127
Figure 2 –Overall dimensions of the Product MPC-19-4

Version 0.16
Computer system unit of types
MPC-127, MPC-19-4
1.3 THE PRODUCT’S STRUCTURE AND OPERATION
1.3.1 General description
The Product is manufactured in metal casing, where a power connector, audio
ports, video ports, peripheral interfaces, local network ports are generally located.
Connectors are standard, see Figure 2 (the Product’s connector layout may differ from
the given ones). For the description of connectors, see Table 2. Electrical connector’s
pinouts are represented in Tables 3 –9.
Figure 3 –Connectors layout
Caution! Provide 160 mm free space from the detachable connection to connect
the Product at mounting
Table 2 –Description of the Product’s connectors
N.
Name
Description
Type
1
XPn.8
To connect AC voltage 220 V, 50 Hz
C13
XPn.9
To connect AC voltage 110 V, 50 Hz
C13
XSn.10
To connect DC voltage 24 V
C14
XSn.11
To connect DC voltage 12 V
C14
2.1
ХSn.27
To connect manipulator
mini DIN-6
2.2
ХSn.27
To connect keyboard
mini DIN-6
3
XSn.20
To connect universal serial interface COM (RS-232)
DB-9M
4
XSn.1
To connect VGA
DB-15F
5
XSn.2
To connect DVI
DVI-D
6.1
XSn.25
To connect USB 2.0 devices
USB type А
6.2
XSn.25
To connect USB 3.0 devices
USB type А
7
XSn.17
To connect Ethernet 10/100/1000 Base-T
RJ-45
8
XSn.12
To connect audio input
3,5 jack
XSn.13
To connect audio output (speaker)
3,5 jack
XSn.14
To connect microphone
3,5 jack
Note –«n» – ordinal number of same-type connectors. For example, if the device has 2 USB interfaces, they
are marked as: XS1.25, XS2.25.

7 Version 0.1
Operating Manual
Table 3 –Description of XPn.8, XPn.9 connector pins
Type
Pin №
Description
1 2
(view from soldering side)
1
L
E (PE)
2
N
Table 4 –Description of XSn.10, XSn.11 connector pins
Type
Pin №
Description
12
(view from soldering side)
E (PE)
1
+ 24 V
2
0 V
Table 5 –Description of ХSn.27 connector pins
Type
Pin №
Description
1
Data key / Data mouse
2
‒
3
Gnd
4
Vcc
5
Clock key / Clock mouse
6
‒
Table 6 –Description of XSn.20 connector pins
Тип разъема
№ контакта
Назначение
5 4 3 2 1
9876
(view from soldering side)
1
‒
2
RxD
3
TxD
4
‒
5
GND
6
‒
7
RTS
8
CTS
9
‒
‒
Screen
Table 7 –Description of XSn.25 connector pins
Тип
№ контакта
Назначение
(view from connection side)
1
+ 5 V (VCC)
2
data –(D –)
3
data + (D +)
4
GND
Table 8 –Description of XSn.12, XSn.13, XSn.14 connectors pins
Type
Pin №
XSn.12, XSn.13
XSn.14
Description
1
GND
GND
2
LINE_R
MIC_VCC
3
LINE_L
MIC_IN

Version 0.18
Computer system unit of types
MPC-127, MPC-19-4
Table 9 –Description of XSn.17 connector pins
Type
Pin №
Description
(view from connection side)
1
MDI 0 + (white orange)
2
MDI 0 ‒ (orange)
3
MDI 1 + (white green)
4
MDI 2 + (blue)
5
MDI 2 ‒ (white blue)
6
MDI 1 ‒ (green)
7
MDI 3 + (white brown)
8
MDI 3 ‒ (brown)
Table 10 –Description of XSn.1 connector pins
Type
Pin №
Description
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
(pinout of unit from side of
cable connection)
1
Red
2
Green
3
Blue
4
Not used
5
Common (GND)
6
GND_Red
7
GND_Green
8
GND_Blue
9
+ 5 В
10
GND
11
GND
12
data (SDA)
13
HSYNC
14
VSYNC
15
Data synch (SCL)
Table 11 –Description of XSn.4 connector pins
Type
Pin №
Description
(pinout of unit from side
of cable connection)
1
TMDS 2 ˗
2
TMDS 2 +
3
TMDS 2 Sh
4
Not used
5
Not used
6
SCL
7
SDA
8
Not used
9
TMDS 1 ˗
10
TMDS 1 +
11
TMDS 1 Sh
12
Not used
13
Not used
14
+ 5 V
15
GND
16
HPD
17
TMDS 0 ˗
18
TMDS 0 +
19
TMDS 0 Sh
20
Not used
21
Not used
22
TMDS Cl Sh
23
TMDS Cl +
24
TMDS Cl ˗

9 Version 0.1
Operating Manual
1.3.2 Controls and indication
Controls, indication (LEDs) and speakers are also located on the front panel, see
Figures 4 и5. Description of the controls and indication (LEDs) are represented in
Tables 12 и13.
Рисунок 4 –Layout of controls, indication (LEDs) of the Products MPC-127 type
Table 12 –Control and indication description of the Products MPC-127 type
N
Name
Description
1
«O/ǀ»
Switch to turn power on/off
2
DVD-RW
DVD-RW drive
3
Provides connection of external USB devices
4
Button switches on/off the product
5
Reset button
6
Power indicator
7
HDD activity indicator
Рисунок 5 –Layout of controls, indication (LEDs) of the Products MPC-19-4 type
