MSA FireHawk 10025120 Quick start guide

TAL 307 (L) Rev. 2 © MSA 2003 Prnt. Spec. 10000005389(A) Mat. 10028156
Doc. 10000010260
We encourage our customers to call or write for a demonstration of this
equipment prior to use, or for any additional information relative to this
upgrade or the SCBA use or repairs. During regular working hours, call
1-800-MSA-2222.
THIS MANUAL MUST BE CAREFULLY READ AND FOLLOWED BY ALL
PERSONS WHO HAVE OR WILL HAVE THE RESPONSIBILITY FOR
UPGRADING THE AIR MASK. THIS AIR MASK WILL PERFORM AS
DESIGNED ONLY IF UPGRADING ACCORDING TO THE INSTRUCTIONS.
OTHERWISE IT COULD FAIL TO PERFORM AS DESIGNED, AND PER-
SONS WHO RELY ON THE AIR MASK COULD SUSTAIN SERIOUS PER-
SONAL INJURY OR DEATH.
WARNING
Quick-Connect Hose
UPGRADE INSTRUCTIONS
MMR Air Mask With

BEFORE USE
BEFORE USE
• Read and understand these instructions before
attempting to use this equipment.
• This air mask is to be used only by trained and quali-
fied personnel.
UPGRADING FIRST STAGE REGULATOR
Do not tighten fittings or connectors when the system
is pressurized. Close the cylinder valve. Be sure noth-
ing blocks the regulator outlet. Relieve pressure from
the system by slowly opening the bypass valve. Failure
to follow this precaution may cause fittings or connec-
tors to rupture, resulting in serious personal injury or
death.
All repair procedures require that the regulator and Audi-
Larm is disassembled from the apparatus carrier. To do
this:
Wear eye protection throughout maintenance proce-
dures to avoid eye injury.
DISCONNECT AUDI-LARM FROM THE APPARATUS
CYLINDER
1. Be sure the cylinder valve is completely closed.
2. Be sure that nothing blocks the regulator outlet. Open
the bypass valve to relieve pressure in the system.
3. Close the bypass valve fully.
Do not disconnect the Audi-Larm coupling nut when
pressure is shown on the harness gauge. Always be
sure that you have released all pressure from the reg-
ulator. Removing the coupling nut with the regulator
pressurized may result in serious personal injury or
death.
4. Unscrew the Audi-Larm coupling nut from the cylinder
valve.
5. Leak-test after each repair.
REMOVING THE INTERMEDIATE PRESSURE HOSE
FROM THE FIRST STAGE REGULATOR CAP
Note: All procedures require that the Second Stage regu-
lator is disconnected from the First Stage Regulator.
1. Disconnect the Second Stage Regulator Hose from
the First Stage Regulator intermediate hose.
Note: The First Stage Regulator Cap must be removed
before the intermediate pressure hose and adapter is
removed from the regulator cap, this will ensure that no
debris will enter the first stage regulator.
2. Removing the First Stage Regulator Cap.
• Use an open-end wrench to unthread (counter-
clockwise) regulator cap.
• Secure the regulator cap.
3. Disconnect the First Stage Regulator intermediate
hose from the regulator cap.
2
TAL 307 (L) Rev. 2 - 10028156
WARNING
CAUTION
CAUTION
Kit — P/N 10025120
10024739 Intermediate Hose Assy. Quick-Connect
with Washer
805051 First Stage Regulator Cap
10023685 Firehawk MMR Regulator
10022245 Belt mount
630493 O-ring
635037 O-ring
Kit — P/N 10038666
10024739 Intermediate Hose Assy. Quick-Connect
with Washer
805051 First Stage Regulator Cap
10033113 Firehawk MMR Regulator
10022245 Belt mount
630493 O-ring
635037 O-ring
Table of Contents
Before Use ...............................................................................................................................................................................2
Upgrade Instructions ...............................................................................................................................................................5
Donning the Apparatus............................................................................................................................................................7
Removing the Apparatus .......................................................................................................................................................11

BEFORE USE
• Using a 5/8 wrench, unthread the hose and adapter
counter-clockwise. Remove hose and adapter from
regulator cap.
4. Using the O-ring removal tool, remove the O-ring from
adapter. Discard old O-ring. Clean the thread of the
adapter to ensure the threads are free of debris.
5. Using the O-ring removal tool, remove the O-ring from
the regulator body. Discard old O-ring. Clean the
threads of the adapter port to ensure the threads are
free of debris.
6. Pull the hose out from the shoulder strap.
3
TAL 206 (L) Rev. 1 - 10028156 TAL 307 (L) Rev. 2 - 10028156

NOTES
4
TAL 307 (L) Rev. 2 - 10028156

UPGRADE INSTRUCTIONS
INSTALLATIONS OF QUICK-CONNECT SECOND
STAGE INTERMEDIATE HOSE WITH RUBBER WASH-
ER AND MALE QUICK CONNECT
Note: All procedures require that the Second Stage
Regulator Intermediate hose is disconnected from First
Stage Intermediate Hose.
1. Thread the end with O-ring of the Intermediate Hose
up through the shoulder strap tunnel.
INSTALLING THE RELIEF VALVE
1. To protect the O-ring, wrap paper or tape around the
Relief Valve threads Apply Christo-Lube lubricant to
the new O-ring.
2. Install a new O-ring (P/N 635037) on the relief valve.
3. Thread the relief valve into the First Stage Cap clock-
wise by hand. Torque to 90+/-10 IN. LB. with a 5/8"
socket.
INSTALLING THE FIRST STAGE REGULATOR CAP
AND RELIEF VALVE
1. Wrap paper or tape around the regulator body exter-
nal threads, protecting the O-rings. Apply Christo-
Lube lubricant to the new O-ring (P/N 630493) and
install it on the regulator body. Remove the paper or
tape.
2. Thread the First Stage Regulator cap and relief valve
assembly on the First Stage Regulator. Using a torque
wrench, torque to 180+/-10 IN LB.
INSTALLING THE QUICK-CONNECT INTERMEDIATE
HOSE
1. Thread the Intermediate Hose into the First Stage Cap
clockwise hand tighten. Using a torque wrench, torque
to 125+/- 5 IN. LB.
INSTALL THE SECOND STAGE QUICK-CONNECT
HOSE REGULATOR
1. Quick-Connect Hose.
a. Insert Intermediate Hose from First Stage Regulator
into Intermediate Hose from Second Stage
Regulator.
b.Ensure the Connection is tight.
SYSTEM CHECK
1. Perform the Leak-Test procedures
2. Perform the Donning procedure for SCBA Operation
and Instructions Manual supplied with the apparatus.
3. Ensure there are no leaks and the apparatus performs
properly. If the unit fails to meet any of the tests, the
condition(s) must be corrected before using the appa-
ratus.
Leak Testing should be performed if the SCBA fails any of
the inspection steps; following disassembly; or, as part of
a regularly scheduled maintenance procedure. The SCBA
must hold system pressure without leaks to provide ade-
quate protection. The component leak test procedure is
the first step in trouble-shooting. These tests ensure that
you do not have a leak. Leak testing quickly identifies
components which need repair or replacement.
INSTALL BELT CLIP (P/N 10022245)
1. Black Rhino and Classic Harness
a. Remove the two tee-nuts and screws that secure
the waist-belt buckle. Set the waist-belt buckle
aside.
b.Note the location of the old standby belt clip. Slide
the old standby belt clip off of the waist-belt and
discard.
c. Slide the new standby belt clip onto the waist belt
to the approximate location of the old belt clip.
d.Place one drop of Loctite #222* on each screw.
Secure the waist-belt buckle to the waist belt by
reusing two tee-nuts and screws.
2. Install Belt Clip for Vulcan
a. Cut Old Belt Clip from waist strap and discard.
b.Thread waist strap through new Belt Clip and slide
Belt Clip to the approximate location.
CHANGING IDENTIFICATION NUMBER OF CARRIER
AND HARNESS
1. Apply New Identification Number decal over Original
Identification Disc.
2. See the following description of New Carrier and
Harness for new Part Number decal:
5TAL 307 (L) Rev. 2 - 10028156
Washer
(P/N 10047742)
Adapter

NOTES
6
TAL 307 (L) Rev. 2 - 10028156

DONNING THE APPARATUS
RECONNECT AUDI-LARM AND CHECK AIR MASK
FUNCTION
DONNING THE APPARATUS
1. Remove the facepiece from the case.
Do not use a cover lens in a high-temperature environ-
ment, such as firefighting. High temperatures may dis-
tort the cover lens. Or, moisture trapped between a
cover lens and the facepiece lens may condense and
distort vision. Always remove the cover lens before
donning the facepiece.
2. Check that the cylinder is fully pressurized.
If the cylinder is not full, the service time is reduced
accordingly & should not be used.
3. Reach inside the right shoulder straps and grasp the
redundant alarm and pressure gauge, slide left arm
through left shoulder straps.
4. Bend forward slightly, rest it on your back.
5. Attach the chest strap (optional).
6. Fasten the waist-strap and pull it tight for a snug fit.
7. As you straighten up, pull the shoulder strap tabs out.
Hike the unit up for a comfortable fit.
8. The shoulder straps and waist-strap ends must be
tucked in and lay flat across the body.
TESTING AND USING THE REDUNDANT ALARM, ICM
& AUDI-ALARM
1. Grasp the mask-mounted regulator and push the slide
button (top release button).
2. Check that the red
bypass knob is fully
closed (clockwise).
Note: To test the redundant alarm or ICM, see the
Redundant Alarm or ICM donning instruction. The alarm
should enter Test Mode.
3. Reach behind and
open the cylinder valve
fully. Listen for the
audible alarm to ring
briefly and redundant
alarm tones as pres-
sure in the system
increases.
4. As the pressure rises from 50 to 200 psig, both visible
and audible alarms activate automatically, indicating
that the alarms are functional and "cocked." When the
system is fully pressurized, the alarms enter the
Monitor (normal) mode.
If the alarm fails to ring, ICM or Redundant Alarm fails
to light and tone, do not use the apparatus. The SCBA
must be checked and corrected for proper operation
by an MSA trained or certified repairperson before
using. Failure to follow this precaution may result in
serious personal injury or death.
5. No air should flow from
the regulator. If it does,
repeat steps 1 and 2.
6. Check the Pressure Gauge, Redundant Alarm, ICM and
Cylinder Gauges. It should be within 110 psig for 2216
psig; 150 psig for 3000 psig; 225 psig for 4500 psig.
If your readings do not agree with these cylinder val-
ues, return the SCBA to an MSA trained or certified
repairperson.
7. Check for bypass oper-
ation. Grasp the red
knob and turn it
counter-clockwise.
Listen for airflow, then
turn it OFF. Close cylin-
der valve fully.
7TAL 307 (L) Rev. 2 - 10028156
WARNING
CAUTION
WARNING WARNING

DONNING THE APPARATUS
8. Check for air leaks. Open cylinder valve fully to pres-
surize system, then close the cylinder valve and watch
the pressure gauge, Redundant alarm or ICM.
If the needle drops more than 100 psi in 10 seconds,
do not use the SCBA.
9. Crack the bypass valve slowly to bleed off pressure
until the Redundant alarm or ICM drops below:
530 psig - approximately (low-pressure system)
750 psig. approximately ( 3000psi System)
1175 psig – approximately (high-pressure system)
The Redundant alarm, ICM and audi-alarm will sound
and the gauge will illuminate until you turn the redun-
dant alarm OFF.
10. When the pressure falls below 200 psig, turn the alarm
off.
If the audi-alarm fails to ring, ICM or Redundant alarm
fails to light and tone, or fails to continuously ring to
200 psig, do not use the apparatus. The SCBA must be
checked and corrected for proper operation by an
MSA trained or certified repairperson before using.
Failure to follow this precaution may result in serious
personal injury or death.
Note: Before donning, check that the regulator sealing
ring is seated properly in its groove, and that it is not torn,
gouged, or nicked.
THE SPEED-ON HARNESS
Do not wear eye glasses under the facepiece. The
temples or sidebars on eye glasses will prevent an air-
tight seal. if you must wear glasses, install the specta-
cle kit. Failure to follow this precaution may cause
inhalation of contaminated air, resulting in serious res-
piratory injury or death.
1. Extend the facepiece
straps fully place neck-
strap around your neck
and don the facepiece
by inserting your chin
first.
2. Pull the head harness
completely over your
head and tighten the
lower (neck) straps.
3. Tighten the lower (neck) harness straps first, by pulling
them straight back, not out. Tighten the temple straps
the same way. Tuck in the ends of the straps so that
they lay flat across the head.
4. Push headband pad towards neck, tighten the front
strap for best visibility and fit. Tuck in the ends of the
straps so they flat across the head.
FACEPIECE FIT CHECK
Check the inhalation valve, inhale. If you do not
receive sufficient flow of air, do not use facepiece. The
facepiece must be repaired or replaced.
1. To check for facepiece
fit, hold the palm of
your hand over the inlet
facepiece adapter and
inhale. Hold your
breath at least 10 sec-
onds. The facepiece
should collapse and
stay collapsed against
your face. If it does
not, readjust the face-
piece and test again. If
this does not correct the leak, do not use the face-
piece.
2. Test the exhalation
valve, take a deep
breath and hold it.
Block the inlet face-
piece adapter with the
palm of your hand and
exhale. If the exhalation
valve is stuck, you may
feel a heavy rush of air
around the facepiece.
Note: You may need to exhale sharply to open the valve.
If this does not release the valve, do not use the face-
piece.
8
TAL 307 (L) Rev. 2 - 10028156
WARNING
WARNING
WARNING
CAUTION

DONNING THE APPARATUS
This device may not seal properly with your face if you
have a beard, gross sideburns or similar physical
characteristics (see NFPA-1500 and ANSI Z88.2). An
improper facial seal may allow contaminants to leak
into the facepiece, reducing or eliminating respiratory
protection. Do not use this device if such conditions
exist. The face-to-facepiece seal must be tested
before each use. Never remove the facepiece except
in a safe, non-hazardous non-toxic atmosphere.
3. Open the cylinder valve
fully. Push in on the
slide button to stop air
flow.
INSTALLING SLIDE MASK MOUNTED REGULATOR
1. Grasp regulator and
orient regulator so that
red bypass knob is
pointing to the right
and slide button is on
top.
2. Slide regulator onto rail
(fast track) of facepiece
cover. Slide regulator
down the rail cover
until regulator stops.
3. Insert regulator into
facepiece adapter by
pushing inward.
4. Listen for the buttons to "click" as the regulator locks
into the facepiece.
5. Check proper engagement by pulling on the regulator
to ensure regulator is securely attached to facepiece
adapter.
INSTALLING FIREHAWK PUSH TO CONNECT MASK
MOUNTED REGULATOR
1. Grasp regulator and insert regulator into facepiece
adapter by pushing inward. Listen for the buttons to
"click" as regulator locks into the facepiece. Check
proper engagement by pulling on the regulator to
ensure regulator is securely attached to facepiece
adapter.
Do not use the respirator unless the regulator is con-
nected properly. A regulator that is not installed cor-
rectly can separate from the facepiece unexpectedly.
Return the respirator to an MSA trained or certified
repairperson to correct the condition. Failure to follow
this precaution can result in serious personal injury or
death.
2. Inhale sharply to start the airflow.
3. Check the bypass again by turning the red knob
counter-clockwise until you feel increased air flow.
Close the bypass.
There must be a continuous flow of air when the
bypass knob is opened. if not, do not use the appara-
tus. The SCBA must be checked and corrected for
proper operation by an MSA trained or certified repair-
person before using it. Failure to follow this precaution
may result in serious personal injury or death.
Note: If the apparatus passes all tests, the unit is ready to
use. Remember, you must perform these tests every time
before you enter the hazardous atmosphere. If the unit
fails to meet any of the tests, the condition(s) must be
corrected before using the apparatus.
9TAL 307 (L) Rev. 2 - 10028156
WARNING
WARNING
WARNING
Slide Button

DONNING THE APPARATUS
PRECAUTIONS DURING USE
Periodically check the pressure indicated on the
Redundant alarm or ICM pressure gauge. It continually
displays the cylinder pressure. When the needle reaches
the red zone, the Audi-Larm Alarm will begin ringing and
Redundant alarm or ICM will begin to tone. When the bell
starts ringing or when the pressure reaches approximately
25% of the rated service pressure, return to fresh air.
Redundant alarm, ICM, and Audi-Larm™ activate when
cylinder pressure drops below approximate values:
530 psig approximately for low-pressure
750 psig. approximately ( 3000psi System)
1175 psig approximately for high pressure
when the redundant alarm, ICM or audi-alarm activates,
immediately return to fresh air.
Note: Apparatus service life is reduced greatly when the
bypass is used.
• Reduced air flow: Immediately open the bypass.
Immediately return to fresh air.
• Air mask free-flows: Immediately return to fresh air.
• Audi-Larm Alarm
Rings: Immediately return to fresh air.
• Redundant Alarm
Lights and Flashes: Immediately return to fresh air.
• ICM Lights and
Flashes Immediately return to fresh air.
10
TAL 307 (L) Rev. 2 - 10028156

REMOVING THE APPARATUS
REMOVING THE APPARATUS DISCONNECTING THE
SLIDE REGULATOR
1. Grasp top of regulator.
2. Push the release but-
tons and pull regulator
down and out of face-
piece adapter.
Note: Regulator can hang on cover rail in a stand-by
mode.
3. Slide regulator up cover
rail until regulator slide
button is free of cover
rail.
4. Close the cylinder valve
fully. Open the bypass
to release system pres-
sure. Close the bypass.
5. When the pressure falls below 200 psig, turn the
redundant alarm or ICM off.
6. Stow the regulator with
slide button at bottom
in the STAND-BY belt
mount when it is not in
use.
7. To remove the face-
piece, fully loosen the
harness straps and pull
the facepiece up and
away from your face.
8. To remove the carrier harness, press the belt buckle
release button IN.
9. Disconnect the chest strap (if used).
10. To loosen the shoulder straps, grasp the release
loops. Push them out and away from your body.
11. Slip your right arm out of the shoulder pad first, then
remove the harness.
Note: Be sure to replace the cylinder with a full one.
Complete Inspection and Cleaning and Disinfecting pro-
cedures outlined in this manual. Ensure complete appara-
tus is clean and dry. Ensure that facepiece head harness
straps and harness adjustment straps are fully extended.
Place the complete apparatus in the storage case or suit-
able storage location so it can be reached easily for emer-
gency use. (See storage instructions.)
DISCONNECTING THE FIREHAWK PUSH TO CON-
NECT REGULATOR
1. Grasp top of regulator.
2. Push the release buttons and pull regulator out of
facepiece adapter.
3. Close the cylinder valve fully. Open the bypass to
release system pressure. Close the bypass.
4. When the pressure falls below 200 psig, turn the
redundant alarm off (Sleep Mode) by pressing the
alarm switch 2 times in rapid succession. An extended
single tone will sound indicating the unit has been
turned off.
5. Stow the regulator in the STAND-BY belt mount when
it is not in use.
6. To remove the facepiece, fully loosen the harness
11 TAL 307 (L) Rev. 2 - 10028156

REMOVING THE APPARATUS
straps and pull the facepiece up and away from your
face.
7. To remove the carrier harness, press the belt buckle
release button IN.
8. Disconnect the chest strap (if used).
9. To loosen the shoulder straps, grasp the release
loops. Push them out and away from your body.
10. Slip your right arm out of the shoulder pad first, then
remove the harness.
Note: Be sure to replace the cylinder with a full one.
Complete Inspection and Cleaning and Disinfecting pro-
cedures outlined in this manual. Ensure complete appara-
tus is clean and dry. Ensure that facepiece head harness
straps and harness adjustment straps are fully extended.
Place the complete apparatus in the storage case or suit-
able storage location so it can be reached easily for emer-
gency use. (See storage instructions.)
12
TAL 307 (L) Rev. 2 - 10028156
