MSE Audio Phase SOLARIS OUTDOOR User manual

SAFETY INSTRUCTIONS 2
GETTING STARTED AND PRECAUTIONARY NOTES 3
INSTALLING YOUR SOLARIS SPEAKER 3
CARING FOR YOUR SOLARIS SPEAKER 3
MAINTENANCE AND SERVICE 3
WARRANTY 4
SPECIFICATIONS 4
[BOX CONTENTS]
1 IN-GROUND SPEAKER
1 ANTI-THEFT DEVICE (2 PEICES)
1 LIQUID-TIGHT COMPRESSION FITTING
1 SQUARE DRIVE BIT
2 WIRE NUTS
6 #8 STAINLESS-STEEL SQUARE-DRIVE SCREWS
2 .75” 1/4-20 STAINLESS STEEL BOLTS
SOLARIS OUTDOOR
OWNER’S MANUAL: SPF-55 & SPF-85
SPEAKER ENCLOSURE
#8 STAINLESS-STEEL
SQUARE-DRIVE
SCREW (X6)
IN-GROUND/
SECURITY BRACKET
.75” 1/4-20 STAINLESS
STEEL BOLT
LIQUID-TIGHT
STRAIN RELIEF
WIRE LEADS
Thank you for choosing Phase Technology®speakers. We know
there are a wide variety of choices available today, and we sincerely
appreciate your purchase of our product. Phase Technology
speakers are built to exacting standards and will provide many
years of listening enjoyment.
Our speakers are the result of over ve decades of designing
and manufacturing. We hold many key patents in loudspeaker
technology including the soft-dome tweeter. Our mission, our
passion is to constantly advance the art and science of accurate
audio reproduction. Our dedication insures your new speakers will
accurately reproduce all the impact, detail and delicacy of today’s
digital technology.
Regardless of application, serious audiophile listening or home
theater, we recommend that you take the time to read this manual
thoroughly before connecting speakers to your amplier or receiver.
In the highly unlikely event that you should experience a problem
with set-up or operation, please contact one of our authorized
dealers for assistance, or contact us directly.
Phase Technology Corporation
8005 W. 110th St., Suite 208
Overland Park, KS 66210
855.663.5600 (Domestic)
+1.913.663.5600 (International)
913.663.3200 (Fax)

2
1. Read Instructions - All the safety and operating instructions
should be read before the appliance is operated.
2. Retain Instructions - The safety and operating instructions
should be retained for future reference.
3. Heed Warnings - All warnings on the appliance and in the
operating instructions should be adhered to.
4. Follow Instructions - All operating and other instructions
should be followed.
5. Water and Moisture - The appliance should not be used near
water - for example, near a bathtub, washbowl, kitchen sink,
laundry tub, in a wet basement, or near a swimming pool, etc.
6. Carts and Stands - The appliance should be used only with a
cart or stand that is recommended by the manufacturer.
PORTABLE CART WARNING
7. Wall or Ceiling Mounting - The appliance should be mounted
to a wall or ceiling only as recommended by the manufacturer.
8. Ventilation - The appliance should be situated so that its
location or position does not interfere with its proper ventilation.
For example, the appliance should not be situated on a bed, sofa,
rug, or similar surface that may block the ventilation openings;
or placed in a built-in installation, such as a bookcase or cabinet
[SAFETY INSTRUCTIONS] that may impede the ow of air through the ventilation openings.
9. Heat - The appliance should be situated away from heat sources
such as radiators, stoves, or other appliances that produce heat.
10. Power Source - The appliance should be connected to
a power supply only of the type described in the operating
instructions or as marked on the appliance.
11. Power Cord Protection - Power supply cords should be
routed so that they are not likely to be walked on or pinched by
items placed up or against them, paying particular attention to
cords at plugs, convenience receptacles, and the point where they
exit from the appliance.
12. Cleaning - The appliance should be cleaned only as
recommended by the manufacturer.
13. Nonuse Periods - The power cord of the appliance should
be unplugged from the outlet when left unused for a long period
of time.
14. Object and Liquid Entry - Care should be taken so that
neither objects fall nor liquids spill into the inside of the appliance.
15. Damage Requiring Service - The application should be
serviced by qualied service personnel when:
a. the power supply cord or the plug has been damaged,
b. objects have fallen onto or liquid has been spilled into the
appliance,
c. the appliance has been exposed to rain,
d. the appliance does not appear to operate normally or exhibits a
marked change in performance, or
e. the appliance has been dropped or the cabinet damaged.
16. Servicing - The user should not attempt to service the
appliance beyond those means described in the operating
instructions. All other servicing should be referred to qualied
service personnel.
17. Grounding or Polarization - Precautions should be taken so
that the grounding or polarization means of an appliance is not
defeated.
Explanation of Graphical Symbols
The lightning ash with arrowhead symbol, within an
equilateral triangle, is intended to alert you to the presence
of un-insulated “dangerous voltage: within the product’s
enclosure that may be off sufcient magnitude to constitute
a risk of electric shock to persons.
The exclamation point within an equilateral triangle is
intended to alert you to the presence of important operating
and maintenance (servicing) instructions in the literature
accompanying the appliance.
APPLICABLE FOR USA, CANADA OR WHERE APPROVED FOR
USAGE
CAUTION: TO PREVENT ELECTRIC SHOCK, MATCH WIDE BLADE
PLUG TO WIDE SLOT, INSERT FULLY.
ATTENTION: POUR EVITER LES CHOCS ELECTRIQUES, INTRODUIRE
LA LAME LA PLUS LARGE DE LA FICHE DANS LA BORNE
CORRESPONDANTE DE LA PRESE ET POUSSER JUSQU AU FOND.
CAUTION: To reduce the risk of electric shock, do not remove cover
(or back). No user-serviceable parts inside. Refer servicing to qualied
service personnel.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN

[GETTING STARTED AND PRECAUTIONARY NOTES]
For proper connection and therefore full enjoyment of your new Phase Technology®speakers, we encourage you to read this owners’ manual
thoroughly, even if you are very familiar with installing speakers.
The Solaris®speaker is designed for indoor and outdoor playback of music and home theater sources. These omnidirectional speakers feature
powder-coated aluminum grilles and stainless steel fasteners that weather the elements and includes theft-resistant mounting hardware.
Speaker placement is very subjective. Each speaker should be positioned properly, relative to the listening area for good coverage.
[CARING FOR YOUR SOLARIS®SPEAKER]
Your Solaris®speakers are engineered for both indoor and outdoor use and operations. Random water hitting the speaker will not damage
your Solaris®speakers making it ideally suited for placement in close proximity to swimming pools and spas. The Solaris®speaker is not
intended for use underwater.
Ordinary dust and dirt accumulation will not harm the Solaris®speaker. If you wish to clean the Solaris®speaker, household glass cleaning
solution sprayed on a paper towel may be used for light cleanup. For heavier stains, a soap and water solution applied with a rag or sponge
should remove the dirt and stains. Avoid spraying the Solaris®speaker with a high-pressure hose.
[MAINTENANCE AND SERVICE]
Because of Phase Technology’s uncompromising quality control programs, it’s unlikely that your speakers will ever need service if connected
and used as outlined in this Owners’ Manual. In the unlikely event that a problem does occur, please contact your Phase Technology dealer.
Your dealer has the necessary factory-authorized parts and trained technicians to quickly restore your speaker to its original performance
specications.
3
1. If needed for daisy chaining,
drill speaker base and install
second liquid-tight strain relief
(not included).
5. Attach signal wire to wire
leads. Use wire nuts provided.
For added water-proong,
grease caps are recommended.
2. Attach in-ground/security
brackets to speaker base using
stainless steel bolts.
6. Set speaker enclosure on
speaker base. Use tamper-
resistant stainless steel screws
to attach speaker to base
(driver tip and screws provided).
3. Thread signal wire thru
liquid-tight strain relief and
tighten seal.
7. DO N E !
4. Place speaker base into hole
in ground with the top rim of
the base at ground level. Back-
ll dirt into hole, packing rmly.
For added security, cement
security brackets into ground.
[INSTALLING YOUR SOLARIS OMNIDIRECTIONAL OUTDOOR SPEAKER]

4
Copyright © 2016 MS Electronics, LLC. All rights reserved. MSE Audio, Phase Technology and PhaseTech are registered trademarks and
“Speakers for your Life” is a trademark of MSE Audio, Overland Park, Kansas USA. Phase Technology is part of MSE Audio®. www.phasetech.com.
[WARRANTY]
LIMITED WARRANTY: Phase Technology®warrants its loudspeakers to be free from defects in material and workmanship for a period of ten
(10) years for speaker product, limited lifetime for CI speakers, and three (3) years for the electronic components to the original purchaser.
Purchase must be made from an authorized Phase Technology®dealer.
This warranty does not cover service or parts to repair damage caused by misuse, abuse, damage while in transit, alterations, unauthorized
repairs, failure to follow instructions, re, ood or any other cause beyond the reasonable control of Phase Technology®. Defects in speaker
cabinets or grilles must be brought to the attention of your dealer immediately after purchase. This warranty will be void if the products’ serial
number has been altered or removed.
Should your Phase Technology®product require service, please call the MSE Audio®customer service department for a return authorization.
All merchandise returned to Phase Technology without prior authorization will be refused. For your return authorization number, please call
855.663.5600 or email [e-mail].
[SPECIFICATIONS]
5.25” Coaxial Omnidirectional Outdoor w/ 25/70.7/100 Volt Transformer
4Ω
86 dB
49 Hz - 22 kHz
15 - 60 Watts
1” Aluminum Dome
N/A
5.25” Mineral-Filled Polypropylene w/ NBR Surround
18-Gauge Wire Lead
Corrosion-Resistant, Powder-Coated Aluminum
Green or Sandstone
14.17” Diameter x 15.51” H
13 lbs
Anti-Theft Brackets, Water-Tight Strain Relief
N/A
8” Coaxial Omnidirectional Outdoor w/ 25/70.7/100 Volt Transformer
4Ω
88 dB
38 Hz - 22 kHz
15 - 100 Watts
1” Aluminum Dome
N/A
8” Mineral-Filled Polypropylene w/ NBR Surround
18-Gauge Wire Lead
Corrosion-Resistant, Powder-Coated Aluminum
Green or Sandstone
14.17” Diameter x 16.42” H
16.7 lbs
Anti-Theft Brackets, Water-Tight Strain Relief
N/A
Description:
Nominal Impedance:
Sensitivity:
Frequency Response:
Recommended Power:
Tweeter(s):
Midrange:
Woofer(s):
Inputs:
Grille:
Color Options:
Dimensions:
Weight:
Included Accessories:
Optional Accessories:
SPF-55 SPF-85
