MSI AE2410 User manual
Wind Top AE2410 Series
All-in-One (AIO) PC
MS-AE32 (V1.X) System
G52-AE321X7
ii
iii
MS-AE32
iv
v
MS-AE32
vi
廢電池請回收
vii
MS-AE32
廢電池請回收
viii
ix
MS-AE32
x
xi
MS-AE32
xii
Chapter 1
Overview
The Wind Top AE2410 Series is integrated in design, selecting a
stylish appearance with a mirror screen, which displays the sim-
plicity of modern individualism and the comfort of home. With a
touchscreen display, awless audio/video capabilities, and intui-
tive user interface, it blends technology with life, making comput-
ers easier and more fun to use — suitable for the whole family.
1-2
Overview
▍
Packing contents
* Please contact us immediately if any of the items is
damaged or missing.
* The illustrations are for reference only and your
packing contents may slightly vary depending on
the model you purchased.
Wind Top Series
User Manual &
Quick Guide
Driver/Utility Disk
Stylus (Optional)
Mouse (Optional)
Keyboard (Optional)
LCD Display Wiper
AC/DC Adapter
AC Power Cord
system overview
Front View
12
4
3
1
11 10 9 8 7 6 5
4
2
1-3
MS-AE32
Packing contents
* Please contact us immediately if any of the items is
damaged or missing.
* The illustrations are for reference only and your
packing contents may slightly vary depending on
the model you purchased.
Wind Top Series
User Manual &
Quick Guide
Driver/Utility Disk
Stylus (Optional)
Mouse (Optional)
Keyboard (Optional)
LCD Display Wiper
AC/DC Adapter
AC Power Cord
system overview
Front View
12
4
3
1
11 10 9 8 7 6 5
4
2
1-4
Overview
▍
1Microphone
- The built-in microphone can be used for video chatting online.
2Webcam
- The built-in webcam with the microphone can be used for picture
taking, video recoding, online conferencing and any other interac-
tive applications.
3LCD Display
- 23.6-inch full-HD display with 1920 x 1080 resolution, 16:9 wide-
screen, and Multi-Touch function
4
IR Transmitter
- The IR transmitter is provided for 3D glasses to synchronize with
the display to achieve 3D visualization.
5System Power Button
- Touch this button to power on, power o, or suspend the system
(up to the OS settings).
6Display Power Button
- Touch this button to power on/o the monitor.
7ECO Button
- Touch this button to turn on/o the ECO power saving mode. Work-
ing under ECO mode contributes to energy eciency.
8Video / Auto Button
- In Menu mode, touching this button enables auto adjustment of
the image quality. Out of Menu mode, it works as the signal input
switch between PC & HDMI.
9TV / Exit Button
- In Menu mode, touching this button escapes to the previous OSD
level. Out of Menu mode, it activates the application programs for
TV function.
10 Menu / Enter Button
- Touch this button to view the OSD menu or enter into the sub-
menu.
11 Right / Volume Up Button
- In Menu mode, this button indicates the cursor movement or OSD
manual selection in incremental values. Out of Menu mode, it works
as Volume Up button.
12 Left / Volume Down Button
- In Menu mode, this button indicates the cursor movement or OSD
manual selection in decremental values. Out of Menu mode, it
works as Volume Down button.
1-5
MS-AE32
1Microphone
- The built-in microphone can be used for video chatting online.
2Webcam
- The built-in webcam with the microphone can be used for picture
taking, video recoding, online conferencing and any other interac-
tive applications.
3LCD Display
- 23.6-inch full-HD display with 1920 x 1080 resolution, 16:9 wide-
screen, and Multi-Touch function
4
IR Transmitter
- The IR transmitter is provided for 3D glasses to synchronize with
the display to achieve 3D visualization.
5System Power Button
- Touch this button to power on, power o, or suspend the system
(up to the OS settings).
6Display Power Button
- Touch this button to power on/o the monitor.
7ECO Button
- Touch this button to turn on/o the ECO power saving mode. Work-
ing under ECO mode contributes to energy eciency.
8Video / Auto Button
- In Menu mode, touching this button enables auto adjustment of
the image quality. Out of Menu mode, it works as the signal input
switch between PC & HDMI.
9TV / Exit Button
- In Menu mode, touching this button escapes to the previous OSD
level. Out of Menu mode, it activates the application programs for
TV function.
10 Menu / Enter Button
- Touch this button to view the OSD menu or enter into the sub-
menu.
11 Right / Volume Up Button
- In Menu mode, this button indicates the cursor movement or OSD
manual selection in incremental values. Out of Menu mode, it works
as Volume Up button.
12 Left / Volume Down Button
- In Menu mode, this button indicates the cursor movement or OSD
manual selection in decremental values. Out of Menu mode, it
works as Volume Down button.
1-6
Overview
▍
Rear View
Important
We suggest that you connect the AC/DC adapter to your AIO PC rst and then con-
nect the AC power cord to the socket-outlet for safety concerns.
1
6
8
10 11 12 16 19
20
1
2
4
5
3
7
9 15 14 17 18
13
1-7
MS-AE32
Rear View
Important
We suggest that you connect the AC/DC adapter to your AIO PC rst and then con-
nect the AC power cord to the socket-outlet for safety concerns.
1Ventilator
- The ventilator on the enclosure is used for air convection and to
prevent the equipment from overheating. Do not cover the ventila-
tor.
2Optical Disk Drive
- A DVD Super-Multi drive is integrated for your home entertain-
ment. (Blu-ray is optional.)
3Card Reader Drive
- The built-in card reader may support various types of memory
card, such as XD (eXtreme Digital), SD (Secure Digital), SDHC
(SD High Capacity), MS (Memory Stick), MS Pro (Memory Stick
Pro) or MMC (Multi-Media Card) cards that usually used in devices
like digital cameras, MP3 players, mobile phones and PDAs. Con-
tact the local dealer for further information and please be noted
that the supported memory cards may vary without notice.
USB 2.0 Port
- The USB (Universal Serial Bus) port is for attaching USB devices
such as keyboard, mouse, or other USB-compatible devices. It
supports up to 480Mbit/s (Hi-Speed) data transfer rate.
4Cable Routing Hole
- Route the cables through the cable routing hole to avoid cable
spaghetti when connecting devices.
5Stand
- Use this stand to position your system on a at and stable sur-
face.
6Mini PCI-E Card Compartment
- This compartment stores mini PCI-E cards, such as WLAN cards
and TV tuner cards.
7Kensington Lock Port
- This AIO PC provides a Kensington lock port, which allows users
to secure the AIO PC in place with a key or some mechanical PIN
device and attached through a rubberised metal cable. The end
of the cable has a small loop which allows the whole cable to be
looped around a permanent object, such as a heavy table or other
similar equipment, thus securing the AIO PC in place.
1
6
8
10 11 12 16 19
20
1
2
4
5
3
7
9 15 14 17 18
13
1-8
Overview
▍
8Subwoofer (Optional)
- A subwoofer (a complete loudspeaker) is provided to reproduce
low-pitched audio frequencies (the bass).
9TV Antenna Connector
- This connector is provided for digital TV antenna.
10 Power Jack
- The AC/DC adapter converts AC power to DC power for this jack.
Power supplied through this jack supplies power to the PC. To pre-
vent damage to the PC, always use the supplied power adapter.
11 VGA-Out Port
- The DB15-pin female connector is provided for VGA-interface de-
vice.
12 USB 2.0 Port
- The USB (Universal Serial Bus) port is for attaching USB devices
such as keyboard, mouse, or other USB-compatible devices. It
supports up to 480Mbit/s (Hi-Speed) data transfer rate.
13 USB 3.0 Port (Optional)
- The USB 3.0 port is backward-compatible with USB 2.0 devices. It
supports up to 5Gbit/s (SuperSpeed) data transfer rate.
14 USB 3.0 Port (with MSI Super Charger Technology) (Optional)
- The USB 3.0 port is backward-compatible with USB 2.0 devices. It
supports up to 5Gbit/s (SuperSpeed) data transfer rate.
With MSI Super Charger Technology, not only does it function as
normal USB 3.0 port, but it also enables users to charge USB
devices even when the system is turned o. Users will no longer
need to power on the system just to charge USB devices. Better
yet, it can reduce the charge time up to 40%, making life more
ecient than ever.
15 HDMI-In Port (Optional)
- The High-Denition Multimedia Interface (HDMI) is an all-digi-
tal audio/video interface capable of transmitting uncompressed
streams. HDMI supports all TV format, including standard, en-
hanced, or high-denition video, plus multi-channel digital audio
on a single cable.
16 eSATA Port (Optional)
- The eSATA (external SATA) port is provided for eSATA hard disk
drives.
17 Line-Out Jack
- This connector is provided for headphones or speakers.
18 Microphone Jack
- This connector is provided for microphones.
19 RJ-45 LAN Jack
- The standard RJ-45 LAN jack is provided for connection to the Lo-
cal Area Network (LAN). You can connect a network cable to it.
Yellow Green/ Orange
LED Color LED State Condition
Left Yellow O LAN link is not established.
On (steady state) LAN link is established.
On (brighter & pulsing) The computer is communicating with
another computer on the LAN.
Right Green O 10 Mbit/sec data rate is selected.
On 100 Mbit/sec data rate is selected.
Orange On 1000 Mbit/sec data rate is selected.
20 Optical S/PDIF-Out Jack (Optional)
- This S/PDIF (Sony & Philips Digital Interconnect Format) jack
is provided for digital audio transmission to external speakers
through an optical ber cable.
Important
High-speed devices are recommended for USB 3.0 ports whereas low-speed de-
vices, such as mouse or keyboard, are suggested to be plugged into the USB 2.0
ports on the rear panel.
