MSI Wind Top AE2210 User manual
Wind Top AE2210
All-in-One (AIO) PC
G52-AC711XD
ii
MS-AC71
iii
iv
MS-AC71
v
vi
MS-AC71
vii
廢電池請回收
viii
MS-AC71
ix
x
MS-AC71
xi
xii
Packing contents
MS-AC71
system overview
MS-AC71
MS-AC71
1-8
Overview
▍
5USB 3.0 Port (Optional)
The USB 3.0 port is backward-compatible with USB 2.0 devices. It supports up
to 5Gbit/s (SuperSpeed) data transfer rate.
6USB 3.0 Port (with MSI Super Charger Technology) (Optional)
The USB 3.0 port is backward-compatible with USB 2.0 devices. It supports up
to 5Gbit/s (SuperSpeed) data transfer rate.
With MSI Super Charger Technology, not only does it function as normal USB
3.0 port, but it also enables users to charge USB devices even when the sys-
tem is turned o. Users will no longer need to power on the system just to
charge USB devices. Better yet, it can reduce the charge time up to 40%,
making life more ecient than ever.
7Card Reader Drive
The built-in card reader may support various types of memory cards.
8Power Jack
The AC/DC adapter converts AC power to DC power for this jack. Power sup-
plied through this jack supplies power to the PC. To prevent damage to the PC,
always use the supplied power adapter.
9Optical Disk Drive
A DVD Super-Multi drive is integrated for your home entertainment (Blu-ray
is optional).
10 Eject Hole
Insert a thin, straight object (such as a paper clip) into the eject hole to open the
optical disk drive manually if the eject button does not work.
11 Eject Button
Press the eject button to open the optical disk drive.
12 ODD LED
If the ODD LED is on, it means the system is reading data from, or writing to,
a CD or DVD.
13 Ventilator
The ventilator on the enclosure is used for air convection and to prevent the
equipment from overheating. Do not cover the ventilator.
Important
High-speed devices are recommended for USB 3.0 ports whereas low-speed
devices, such as mouse or keyboard, are suggested to be plugged into the USB
2.0 ports on the rear panel.
