Introduction
1-1
Introduction
TheMS6395 MICROATXmainboard isahigh-performance computer
mainboard based on Intel®810M/Echipset. TheIntel®810M/Echipseten-
hancestheperformance ofthefirstgeneration Integrated Graphicschipset
designed fortheIntel®CeleronTMprocessorand Intel®Pentium III processor.
TheIntel®810M/Echipset’sarchitecturealso enablesanewsecurityand
manageabilityinfrastructurethrough aFirmwareHub Flash BIOScomponent.
TheIntel®810M/Echipsetcontainstwo corecomponents:
-Intel®82810EGraphicsandMemoryControllerHub (GMCH)
-Intel®82801BAI/OControllerHub2 (ICH2)
TheGMCHintegrates66/100/133MHz,P6familysystembuscontroller,
integrated 2D/3Dgraphicsaccelerator, 100MhzSDRAMcontrollerand ahigh-
speed hub interface forcommunication within theI/OControllerHub (ICH2).
TheICH2 integratesan UltraATA/100 controller, 2 USBhostcontrollerwith a
totalof4 ports, LPCinterface controller, FWHFlash BIOSinterface controller,
PCIinterface controller,AC’97digitalcontrollerand ahubinterface forcommu-
nication with theGMCH.
Thischaptercontainsthefollowing topics:
Mainboard Specifications1-2
Mainboard Layout1-4
Quick ComponentsGuide1-5
KeyFeatures1-6
MSISpecialFeatures1-6
1

Chapter1
1-2
CPU
●
SupportIntel®CeleronTMand Pentium III processorin FC-PGApackage
(Socket370)
●
Support533MHz,550MHz...1GHz,and1.13GHz(Coppermine-D)
Chipset
●
Intel®810M/E(GMCH)chipset(421BGA)
-Integrated GraphicsController
-IntelDDM+Architecture
-SDRAMmemoryIndependentofSystem Bus
●
Intel®ICH2 chipset.(241BGA)
-AC’97 ControllerIntegrated
-2 full IDEchannels, up to ATA100
-Lowpin countinterface forSIO
FrontSideBus(FSB)
●
66/100/133MHzclocksaresupported
MainMemory
●
Supporttwo 168-pinDIMM sockets
●
Supportamaximum memorysize of512MBSDRAM
Slots
●
OneCNR(Communication andNetwork Riser) slot
●
Three 32-bit MasterPCIBusslotsand one16-bit ISAbusslot
●
Support3.3v/5v PCIbusInterface
On-BoardIDE
●
An IDEcontrolleron theICH2 chipsetprovidesIDEHDD/CD-ROMwith
PIO, BusMasterand UltraDMA/100 operation modes
●
Can connectup to fourIDEdevicess
MainboardSpecifications

Introduction
1-3
Video
●
GMCHchip integrated
●
2D/3DGraphics
●
Onboard 4MBDisplayCache(optional)
On-BoardPeripherals
●
On-Board Peripheralsinclude:
-1 floppyportsupports2 FDD with 360K, 720K, 1.2M, 1.44Mand
2.88Mbytes
-2 serialports(COMA+COMBpin header)
-1 parallelportsupportsSPP/EPP/ECPmode
-2 USBports(2 rearports+2 frontconnectors)
-1 IrDAconnectorforSIR
-1VGAport
-1 Audio/Gameport
Audio
●
AC97 Codec
●
ICH2 chip integrated
BIOS
●
Themainboard BIOSprovides“Plug &Play”BIOSwhich detectsthe
peripheraldevicesand expansion cardsoftheboard automatically
●
Themainboard providesaDesktop ManagementInterface(DMI) function
which recordsyourmainboard specifications
Dimension
●
MicroATXFormFactor:24cm x 20cm
Mounting
●
6 mounting holes

Chapter1
1-4
MainboardLayout
MS-6395 MICROATXMainboard
B
A
T
T
+
I
n
t
e
l
G
M
C
H
c
h
i
p
s
e
t
ICH2
ATX
Power Supply
FWH
PCI Slot 1
PCI Slot 2
PCI Slot 3
IDE1
IDE2
DIMM 1 DIMM 2
CNR
ISA Slot
Top : mouse
Bottom: keyboard
CD_IN
MODEM_INAUX_IN
SOCKET370
COMB
FDD
Top : Parallel Port
Bottom:
COM Port &
VGA Port
Top :
Game port
Bottom:
Line-Out
Line-In
Mic
D-LED
W209
VGA
CACHE
W836275
F-AW
JSCD1
JP1
J1
PWRSWITCH
POWER_FAN
JBAT1
JP2
JGS1
SYSFAN
JP3
JIR1
JMDM1
JFP1
J10
JGLED1
JWOL1
JGL1
ExternalUSB
CPUFAN

Introduction
1-5
Thetablebelowprovidesyou thequick guideforsetting up thesystem.
QuickComponentsGuide
Socket370 Installing CPUp. 2-2
DIMM1~2Installing memorymodulep. 2-4
ATXPowerSupplyInstalling powersupplyp. 2-6
FDD Connecting to floppydisk drivep.2-12
USBConnectorConnecting to USBinterface p.2-12
IDE1&IDE2Connecting to HDD drivep.2-13
JFP1Connecting to casep.2-16
JMDM1Connecting to modem card p.2-15
JWOL1Connecting to LANcard p.2-15
POWER_FANConnecting to powersupplyfan p.2-18
SYSFANConnecting to system fan p.2-18
JIR1Connecting to IRmodulep.2-19
JBAT1Setting clearCMOSp.2-22
JP1Setting BIOSFlash p.2-23
JP3Setting FrontAudio p.2-24
PCISlotInstalling expansion cardsp.2-25
CNRSlotInstalling CNRcardsp.2-25
ISASlotInstalling expansion cardsp.2-25
ComponentFunctionReference
JP2Setting Onboard Audio p.2-23
CPUFANConnecting to CPUfan p.2-18
J1ChassisIntrusion function p.2-14

Chapter1
1-6
●
PC99 Color Connector
●
MicroATX Form Factor
●
Audio/Video Chip Integrated
●
PCAlert System Hardware Monitor
●
Support DMI (Desktop Management Interface) through BIOS
●
TOP Tech. (Thermal Overheat Protection Technology) III (optional)
●
Wake Up On LAN function
●
Modem (Internal/External) Ring Wake Up function
●
Suspend to RAM (optional)
KeyFeatures
MSISpecialFeatures
TheMSIspecialfeaturesaredesigned byMSIR&Dwhich areonly
availablein MSImainboards. TheMS-6395 mainboard isequipped with PC
AlertTMIII and T.O.PTechTMIII.
T.O.PTechIII™
TheT.O.PTechTMisaextended sensing device thatcan 100%accu-
ratelydetecttheCPU’stemperature. You can see thetemperatureon BIOS
setup menu. ThePCAlertTMalso can providetheinformation.

Introduction
1-7
PCAlert™III
ThePCAlertTMIII isautilityyou can find in theCD-ROM. Theutility
isjustlikeyourPCdoctorthatcan detectthefollowing PChardwarestatus
during realtimeoperation:
●
monitorCPU&system temperature
●
monitorfan speed
●
monitorsystem voltage
●
monitorchassisintrusion
Ifoneoftheitemsaboveisabnormal, theprogram main screen will beimmedi-
atelyshown on thescreen, with theabnormalitem highlighted in red. Thiswill
continueto beshown until userdisableswarning.

Chapter1
1-8
Features:
●
Network Management
-Monitoring &remotecontrol
●
BasicSystem Utilities
-Scandisk &Defragmentto maintain yourHDD
●
3DGraphicsDesign
-Enablesamorefriendlyuserinterface
●
SoftwareUtilities
-SoftCoolerOptimizedCooling
-DoctorY2KdiagnosesY2Kproblems
-BusRacing function adjustsF.S.BunderWindows95/98
-MoSpeed speedsup yourmodem transmission

Introduction
1-9
D-LED Description
System Power ON
-The D-
LED will hang here if the processor is damaged or not
installed properly.
Early Chipset Initialization
Memory Detection Test
-Testing onboard memory size. The D-LED will hang if the
memory module is damaged or not installed properly.
Decompressing BIOS image to RAM for fast booting.
Initializing Keyboard Controller.
Testing VGA BIOS
-This will start writing VGA sign-on message to the screen.
RedGreen
D-LED™(optional)
TheD-LED™usesgraphicsignaldisplayto help
usersunderstand theirsystem. FourLEDsembedded in
themainboard provideup to 16 combinationsofsignalsto
debug thesystem. The4 LEDscan debug all problemsthat
fail thesystem, such asVGA, RAMorotherfailures. This
specialfeatureisveryusefulfortheoverclocking users.
Theseuserscan usethefeatureto detectifthereareany
problemsorfailures.
1
2
3
4
DiagnosticLED
1 2 3 4

Chapter1
1-10
Processor Initialization
-
This will show information regarding the processor (like brand
name, system bus, etc…)
Testing RTC (Real Time Clock)
Initializing Video Interface
-This will start detecting CPU clock, checking type of video
onboard. Then, detect and initialize the video adapter.
BIOS Sign On
-This will start showing information about logo, processor
brand name, etc….
Testing Base and Extended Memory
-Testing base memory from 240K to 640K and extended
memory above 1MB using various patterns.
Assign Resources to all ISA.
Initializing Hard Drive Controller
-This will initialize IDE drive and controller.
Initializing Floppy Drive Controller
-This will initializing Floppy Drive and controller.
Boot Attempt
-This will set low stack and boot via INT 19h.
Operating System Booting

Hardware Setup
2-1
2
HardwareSetup
Thischapterprovidesyou with theinformation abouthardwaresetup
procedures. Whiledoing theinstallation, becarefulin holding thecompo-
nentsand followtheinstallation procedures. Forsomecomponents, ifyou
install in thewrong orientation, thecomponentswill notwork properly.
Besides, pleaseuseagrounded wriststrap beforehandling computer
components. Staticelectricitymaydamagethecomponents.
Thischaptercontainsthefollowing topics:
Central Processing Unit: CPU 2-2
MemoryInstallation 2-4
PowerSupply2-6
Back Panel2-7
Connectors2-12
Jumpers2-22
Slots2-25

Chapter 2
2-2
Central Processing Unit: CPU
The mainboard supports Intel®CeleronTM / Pentium III (FC-PGA)
processors. The mainboard uses a CPU socket called Socket 370 for easy CPU
installation. Make sure that the CPU has a Heat Sink and a cooling fan at-
tached to prevent overheating. If you do not find the Heat Sink and cooling
fan, contact your dealer or purchase them before turning on the computer.
CPU Installation Procedures
1. Pull the lever sideways away
from the socket. Then, raise
the lever up to a 90-degree angle.
2. Look for the white dot or cut edge
in the CPU. Insert the CPU.
It should insert easily.
3. Press the lever down to complete
the installation.
Open Lever
Mark
Sliding
Plate
Close
Lever
OpenLever
White dot/
Cut edge
Close
Lever
Sliding
Plate
Overheating will seriously damage the CPU and system.
Always make sure the cooling fan can work properly to
protect the CPU.
!
WARNING!

Hardware Setup
2-3
CPU Core Speed Derivation Procedure
The mainboard can automatically set the CPU Host Bus Frequency Clock.
If CPUClock = 100MHz
Core/Bus ratio = 7
then CPU core speed = Host Clock x Core/Bus ratio
= 100MHzx7
= 700MHz
OVERCLOCKING
This motherboard are designed to support overclocking.
However, please make sure your components are able to
tolerate such abnormal setting, while doing overclocking.
Any attempt to operate beyond product specifications are
not recommended. We do not guarantee the damages or
risks caused by inadequate operation or beyond product
specifications.
!
WARNING!
