PackingChecklist.................................................................................................1-5
Chapter2HardwareSetup...................................................................................2-1
Quick ComponentsGuide....................................................................................2-2
CPU(CentralProcessingUnit)............................................................................2-3
Memory.................................................................................................................2-6
PowerSupply......................................................................................................2-8
BackPanel..........................................................................................................2-10
Connectors........................................................................................................2-12
Jumper................................................................................................................2-20
Slots....................................................................................................................2-21
Chapter3BIOSSetup.............................................................................................3-1
EnteringSetup.....................................................................................................3-2
TheMainMenu.....................................................................................................3-4
StandardCMOSFeatures...................................................................................3-6
AdvancedBIOSFeatures...................................................................................3-8
IntegratedPeripherals........................................................................................3-11
PowerManagementSetup...............................................................................3-13
PNP/PCIConfigurations.....................................................................................3-16
H/WMonitor........................................................................................................3-18
Cell Menu............................................................................................................3-19
LoadFail-Safe/Optimized Defaults.................................................................3-23
BIOSSetting Password.....................................................................................3-24
AppendixARealtekALC888Audio....................................................................A-1
Installing theRealtekAudioDriver......................................................................A-2
SoftwareConfiguration......................................................................................A-4
HardwareSetup................................................................................................A-19

ix
AppendixBnVidiaRAID.........................................................................................B-1
Introduction..........................................................................................................B-2
RAIDConfiguration..............................................................................................B-3
NVIDIARAIDUtilityInstallation.............................................................................B-9
RAIDDrivesManagement..................................................................................B-12
AppendixCnVidiaSystemDriver......................................................................C-1
nVidia SystemDriverInstallation........................................................................C-2
nVidiaUtilityInstallaion........................................................................................C-5
AppendixDDualCoreCenter..............................................................................D-1
Activating DualCoreCenter...............................................................................D-2
Main......................................................................................................................D-3
DOT (DynamicOverClocking).............................................................................D-5
Clock.....................................................................................................................D-6
Voltage.................................................................................................................D-7
FANSpeed...........................................................................................................D-8
Temperature.........................................................................................................D-9
UserProfile........................................................................................................D-10
AppendixETV-OutFunction.................................................................................E-1
Installingthe TV-OutBracket..............................................................................E-2
Connecting S-Video&HDTVCables.................................................................E-3
DisplaySetup.......................................................................................................E-5

1-1
Getting Started
Getting Started
Chapter1
Thankyouforchoosing the K9NGM3Series(MS-7349
v1.X)ATXmainboard.TheK9NGM3Seriesmainboards
arebasedon nVidia MCP68PV singlechipsetfor
optimal systemefficiency.Designedtofittheadvanced
AMD Athlon64X2/Athlon 64 &Sempron
processor,theK9NGM3Seriesdeliverahighperfor-
manceandprofessionaldesktopplatformsolution.

MS-7349Mainboard
1-2
ProcessorSupport
-AMD Athlon 64/ 64X2&Sempron inthesocketAM2package
(ForthelatestinformationaboutCPU,pleasevisit http://global.msi.
com.tw/index.php?func=cpuform)
SupportedFSB
-HyperTransportsupportingspeedup to1GHz(2000MT/s)
Chipset
-nVidia MCP68PV chipset
MemorySupport
-DDR2533/667/800SDRAM(240pin/ non-ECC)
-4DDR2DIMMs(8GB Max)
(Formoreinformationoncompatiblecomponents,pleasevisit http:/
/global.msi.com.tw/index.php?func=testreport)
LAN
-SupportsGigaLAN10/100/1000 FastEthernetbyRealtek
RTL8211BL
IEEE 1394(optional)
-Chipintegratedby6308P
-Transferrateisup to400Mbps
Audio
-ControlledbyRealtekALC888
-Supports7.1channelsaudioout
-CompliantwithAzaliaSpec
IDE
-1IDE port
-SupportsUltraDMA66/100/133,PIO& BusMasteroperation
mode
SATA
-4SATAportssupport 4SATAdevices
-Supportsstorageanddatatransfersatupto300MB/s
RAID
-SATA1~4supportRAID0/1/0+1/5orJBODmode
MainboardSpecifications

1-3
Getting Started
TPM(optional)
-SupportsTPM1.2
Floppy
-1floppyport
-Supports1FDD with360KB, 720KB,1.2MB,1.44MBand 2.88MB
Connectors
Back panel
-1PS/2mouseport
-1PS/2keyboardport
-1VGA port
-1HDMIport(optional)
-1DVI-D port(optional)
-1IEEE1394 port(optional)
-4USB 2.0Ports
-1LANjack
-6audiojacks
On-BoardPinheaders
-3USB 2.0pinheaders
-1IEEE1394 pinheader(optional)
-1ChassisIntrusion Switchpinheader
-1Serialportpinheader
-1SPDIF-Outpinheader
-1TV-Outpinheader(optional)
-1FrontPanelAudiopinheader
-1CD-Inpinheader
Slots
-1PCI Expressx16slot
-1PCIExpress x1slot
-2PCI slots,support3.3V/ 5VPCIbusInterface
FormFactor
-Micro-ATX (24.4cmX24.4cm)
Mounting
-8mounting holes

MS-7349Mainboard
1-4
K9NGM3Series
(MS-7349 v1.X)Micro-ATXMainboard
MainboardLayout
PCI 2
PCI 1
PCI _E1
PCI _E2
JAUD1
Codec
LANChip
I/OChip
VIA
VT6308P
JCD1 SPDOUT1
J1394_1 JBAT1
JUSB3
SATA1
SATA4
Nvidia
MCP68
IDE1
DIMM3 DIMM1 DIMM4 DIMM2
ATX1
FDD1
CPUFAN1
SYSFAN1
JTV1(optional)
JCI1
SATA2
SATA3
JUSB1 JUSB2
JFP2 JFP1
BATT
+
Top: mouse
Bottom:
keyboard
Top: LANJack
Bottom:USBports
Top:1394(optional)
Bottom:USBports
T:
M:
B:
Line-In
Line-Out
Mic
T:RS-Out
M:CS-Out
B:SS-Out
JCOM1
JPW1
HDMIPort(optional)
Top:VGAPort
Bottom:DVIPort(optional)
(Optional)

1-5
Getting Started
PackingChecklist
PowerCable SATACable
User’sGuide
MSImotherboard MSIDriver/UtilityCD
*The picturesareforreferenceonlyandmayvaryfromthepackingcontentsofthe
productyoupurchased.
Back IOShield
StandardCablefor
IDEDevices

2-1
HardwareSetup
HardwareSetup
Chapter2
Thischapterprovidesyou withtheinformation about
hardwaresetupprocedures.Whiledoingthe installation,
becarefulinholdingthecomponentsandfollowthe
installationprocedures.Forsomecomponents,ifyou
install inthewrong orientation,thecomponentswillnot
workproperly.
Useagroundedwrist strapbeforehandlingcomputer
components.Staticelectricitymaydamagethe
components.

2-2
MS-7349Mainboard
DDR2DIMMs, p.2-6
JFP1, p.2-18
BackPanel
I/O, p.2-10
JCOM1,p.2-16
IDE1, p.2-12
PCISlots,
p.2-23
SATA1~4,
p.2-13
CPUFAN1,
p.2-14
FDD1, p.2-12
PCIExpress
slots, p.2-20
CPU, p.2-3
Quick ComponentsGuide
JAUD1,
p.2-15
JBAT1,p.2-19 JFP2, p.2-18
JCD1,
p.2-14
JCI1, p.2-14
JPW1,
p.2-8
SPDOUT1,
p.2-17
ATX1, p.2-8
JUSB1~3,
p.2-16
J1394_1,
p.2-17
JTV1,p.2-19
SYSFAN1,
p.2-14

2-3
HardwareSetup
ThemainboardsupportsAMD Athlon64/ 64x2& Sempronprocessors.Themainboard
usesaCPUsocketcalledSocketAM2foreasyCPUinstallation.Whenyou are
installingtheCPU, make suretheCPUhas aheatsinkand acooling fan
attachedon thetop topreventoverheating. If youdonothavetheheatsinkand
cooling fan,contactyourdealertopurchaseand installthembeforeturningonthe
computer.
Forthelatest informationaboutCPU,pleasevisithttp://global.msi.com.tw/index.php?
func=cpuform
CPU(CentralProcessingUnit)
Important
Overheating
Overheating will seriouslydamage the CPUand system.Always makesure
thecoolingfancanworkproperlytoprotectthe CPUfromoverheating.Make
surethatyouapplyan even layerofthermalpaste(orthermaltape)between
the CPUand the heatsinktoenhanceheatdissipation.
ReplaceingtheCPU
WhilereplacingtheCPU,alwaysturnofftheATXpowersupplyorunplug the
powersupply spowercordfromthegrounded outlet firsttoensurethe safety
ofCPU.
Overclocking
Wedo notguarantee the damagesorrisks caused byinadequateoperation
orbeyond productspecifications.

2-4
MS-7349Mainboard
CPUInstallation Procedures forSocketAM2
1.Pleaseturnoffthepowerand
unplug thepowercordbefore
installing the CPU.
2.Pulltheleversidewaysaway
fromthe socket.Makesureto
raisetheleverup toa90-de-
greeangle.
3.Lookforthegold arrowofthe
CPU.The goldarrowshould
pointasshownin thepicture.
TheCPUcanonlyfitin the cor-
rectorientation.
4.If theCPUiscorrectlyinstalled,
thepinsshould becompletely
embeddedintothesocketand
cannotbe seen.Pleasenote
thatanyviolation ofthe correct
installationproceduresmay
causepermanentdamagesto
yourmainboard.
5.Press theCPUdownfirmlyinto
thesocketandclosethelever.
AstheCPUislikelytomovewhile
theleverisbeingclosed,al-
waysclosetheleverwithyour
fingerspressingtightlyon top of
the CPUtomakesurethe CPUis
properlyand completelyembed-
dedintothesocket.
OpenLever
90degree
Sliding
Plate
Goldarrow
Goldarrow
Goldarrow
CorrectCPUplacement
Incorrect CPUplacement
O
Close
Lever
Pressdown
theCPU

2-5
HardwareSetup
Installing AMDSocketAM2CPUCooler Set
Whenyouareinstallingthe CPU, make suretheCPUhas aheatsinkanda
cooling fanattachedon thetop topreventoverheating. If youdonothavethe
heatsinkandcoolingfan,contactyourdealertopurchaseandinstallthembefore
turning onthecomputer.
Mainboardphotosshowninthissection arefordemonstrationofthe cooler
installation forSocket AM2CPUsonly.Theappearanceofyourmainboard
mayvarydependingon the modelyou purchase.
Important
2.Thenpress downtheotherendof
thecliptofastenthe cooling seton
the topofthe retentionmechanism.
LocatetheFixLeverand liftup it.
1.Positionthecooling set ontothere-
tentionmechanism.
Hookoneendoftheclip tohook
first.
3.Fastendownthelever. 4.AttachtheCPUFancable tothe CPU
fanconnectoronthemainboard.
Fixed Lever

2-6
MS-7349Mainboard
Memory
DDR2
240-pin,1.8V
1
DIMM1
DIMM2
DIMM3
DIMM4
2
DIMM1
DIMM2
DIMM3
DIMM4
3
DIMM1
DIMM2
DIMM3
DIMM4
64x2=128 pin56x2=112 pin
TheseDIMM slotsareusedforinstalling memorymodules.
Formoreinformationoncompatiblecomponents, pleasevisit http://global.msi.com.
tw/index.php?func=testreport
Dual-Channel modePopulation Rule
InDual-Channelmode,thememorymodulescantransmitand receivedatawithtwo
databuslinessimultaneously.EnablingDual-Channelmodecanenhancethesystem
performance.Pleaserefertothe following illustrationsforpopulationrulesunder
Dual-Channel mode.
Empty
Installed
