MTS Systems Exceed 22 Series User manual

Manual Title
Additional Information
be certain.
Operation Guide;
100-301-882 B
MTS Exceed®22 Series

MTS Exceed®22 Series
2
© 2014 MTS Systems Corporation. All Rights Reserved.
Trademark information
MTS is a registered trademark while Exceed is a trademark of MTS Systems Corporation in the United States. These trademarks
are also protected in other nations.
Translation information
Original Chinese: 100-302-291 C
Ownership information
Software usage and licensing are managed via MTS End Customer Licensing Agreement. It regulates all rights reserved by MTS
and granted to end users. All software is proprietary properties and classified information of MTS Systems Corporation, and
therefore should not be otherwise reproduced, copied, dissembled, decompiled, reverse engineered, or distributed without prior
written consent of MTS.
Software Authentication and Certification
MTS software is developed according to already established quality systems and hence up to ISO 9001 standards. As MTS
software is provided in binary format, users cannot make modifications. The software does not change over time. Many releases
are backward compatible, resulting in other authentication forms.
The operating status and authentication of MTS software will also be checked during system verification and hardware
calibration. These verification processes will compare the final testing results after statistical analysis with expected responses
based on verification standards. By relying on these proven methods, MTS can guarantee to its customers that MTS products are
in compliance with strict MTS quality standards at initial installation, and will continue to run with excellent performances with
the passing of time.
Serial No. Publication Date
100-302-291 A Jan 2015
100-302-291 B Oct2015
100-302-291 C Jan 2016

3
MTS Exceed®22 Series
Table of Contents
Technical Support
How to Get Technical Support - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 5
Before Contacting MTS Service Representative - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 5
Calling MTS - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 7
Preface
Before getting started - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 9
Document Conventions - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 9
Safety
General Safety Measures - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 12
Safety Practices Before Operating the System - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 13
Safety Practices During System Operations - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 16
Danger Labels - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 18
Introduction
About This Manual - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 20
Overview - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 21
Overview of mainframe and shield - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 22
Electric Coupling Plate - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 27
Control panel - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 29
Shield - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 30
Examples of Running Charpy Notch Impact Test
Overview - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 32
Safety Introduction - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 33
Mounting the Pendulum - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 35
Mounting the Support - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 36
Connecting Compressed Air - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 37
Power on the Mainframe - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 38
Reset Angle - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 39
Setting the parameters - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 41
Collecting Pendulum - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 44
Placing Sample - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 45
Impact - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 46
Release the pendulum - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 47

MTS Exceed®22 Series
4
Print or Export Data - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 48
Sample Loading on the Sample Holder- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 49
Placing the Sample Holder - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 51
Automatic Sample Transporting - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 53
Temperature Control - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 54
Test Running - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 58
Commissioning Status- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 59
Calibration
Overview - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 62
Measuring of energy loss due to bearing friction and air resistance - - - - - - - - - - - - - - - - - - - - - - 63
Measuring of energy loss due to pointer friction - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 64
Calibration of Temperature Sensor - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 66
Maintenance
Routine Maintenance List - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 68
Troubleshooting
Troubleshooting - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 72
Stopping Use
Stopping Use - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 76

Technical Support
MTS Exceed®22 Series 5
Technical Support
How to Get Technical Support
Getting Started Using the Guide
The Guide contains most of the information required for the use and maintenance of the equipment. If your
equipment includes software, please check On-line Help and README files that contain additional
product information.
If you cannot get an answer to your technical question from those resources, you may contact MTS for help
by using Internet, E-mail, telephone, or fax.
Methods for Getting Technical Support
After the system is installed, MTS will offer a full range of support services. If you have any doubts about
the system or product, please feel free to contact our technical support engineers via any of the following
channel.
Technical Support outside the United States
To get technical support outside the United States, please contact local sales and service offices. For the list
of global sales and service locations plus contact information, please click Global MTS on MTS website:
www.mts.com > Global MTS > (Choose your region in the right column) > (Choose the closest site)
Before Contacting MTS Service Representative
If you can learn about the following information before contacting us, then MTS can provide supports to
you more efficiently.
Your Location Number and System Number
The location number includes your company number and marks the type of your equipment (material
testing, simulation, etc.). Before the system is shipped out of MTS, the location number is usually written
on a label and placed on the equipment. If you do not know the location number, please contact our sales
engineer.
If you have more than one MTS system, the system number is used to mark each system. You can check the
system number in your order file.
Learn about previous technical support information
If you have contacted MTS about this issue, please provide the following files so that we can find your
archives:
•MTS Service Code
•Service Engineer's Name

MTS Exceed®22 Series
6
Technical Support
Problem Verification
Before calling us for help, you should be able to describe the problem you are experiencing and know
answers to the following questions:
•How long has the problem been persisting? How often does it occur?
•Can you reproduce the problem?
•Did you make any changes to system hardware or software prior to the occurrence of the problem?
•What is the model of the equipment?
•What is the type of the controller?
•What are system configurations?
Your PC Information
Please provide the following information about your PC:
•Name of the manufacturer and PC model
•OS type and service patches
•System RAM Capacity
•Available space on the hard disk drive where applications are located
•Current state of hard drive fragments
•How the equipment is connected to corporate network
Your Software Information
Please provide the following information about your software applications:
•Name, version number, and build number of the software as well as software patch number; This information is
usually accessible via Help & About.
•Names of other applications installed on the PC, such as:
– Anti-virus software
– Screen saver
– Keyboard accelerator
– Keyboard accelerator
– Communication application

Technical Support
MTS Exceed®22 Series 7
Calling MTS
Before connecting you to the technical support experts, the call centre representative will record your call
and ask you about the following information:
•Location number
•Your name
•Company name
•Company address
•Phone number to reach you
Each new problem will be assigned with a unique notification number. If the question already has a
notification number, please provide the notification number.
Identifying System Type
In order for the call centre representative to connect you to the most suitable technical support expert,
please identify the type of your system as which of the following:
•Pendulum impact system
•Electromechanical material testing system
•Hydraulic material testing system
•Vehicle testing system
•Vehicle component testing system
•Aviation testing system
Preparing for Troubleshooting
Preparations before troubleshooting by phone call:
•Use a phone near to the system so that you can carry out operations step by step conveniently based on
our suggestions
•Have in hand the initial operating and application software.
•If you are not familiar with equipment operations, ask an experienced user to company at your side.
Recording Related Information
Please perform the following operations in case our technical support engineer calls you back:
•Confirm the notification number
•Record the name of your technical support engineer
•Record any special guidance.
After Your Call
MTS will log your call and track all calls to ensure that you have received the help necessary to address
your problems and issues. If you have any doubts regarding the status of the problem or have additional
information to report, please contact our technical support engineers again while providing your initial
notification number.

MTS Exceed®22 Series
8
Technical Support

Preface
MTS Exceed®22 Series 9
Preface
Before getting started
Safety First!
Before using MTS products or systems, please carefully read the safety information attached to the product
or system. Improper installation, operations, or maintenance may cause serious personal injuries and
equipment damages. So, please once again remember to carefully read and understand the attached safety
information for the system before proceeding to next chapters.
Other MTS Manuals
Except for this Manual, you may receive other manuals, in paper or via email.
You may also receive MTS system documentation CD-ROM that contains the electronic manuals relating
to the testing system.
The software CD-RO Musually includes manuals for controllers and application software.
Document Conventions
This section introduces conventions used in MTS manuals.
Conventions on Hazards
This Guide may contain hazard prompts, which cover safety information specific to operations to be
executed. Such prompts will appear right before steps or procedures that might lead to such hazards. Please
carefully read all hazard prompts and follow all instructions and recommendations. There are three levels of
hazard prompts in this Manual. The following gives some examples of each level.
DANGER:
DANGER indicates high risks, if neglected, that may cause serious personal injury or
property loss, even death.
WARNING:
WARNING indicates intermediate risks, if neglected, that may cause serious personal
injury or property loss, even death.

MTS Exceed®22 Series
10
Preface
NOTE:
NOTE indicates low risks, if neglected, that may cause intermediate or slight personal
injury or equipment damage, mayalso influence test integrity and accuracy.
Special Terms
Special terms will be presented in italics when appearing for the first time.
Illustrations
Illustrations in the manual are a description of the text. They are only examples only and do not necessarily
represent actual configurations of your system, applications.
Conventions on Electronic Version
This Manual is provisioned in PDF-based electronic version and can be viewed on any PC that has installed
the Adobe Acrobat Reader.
Hypertext Links
The electronic version contains a host of hypertext links displayed in blue. All words marked in blue in the
text, all items in the table of contents, and all index page numbers are hypertext links. If you click on a
hypertext link, the application will jump to the corresponding topic.

Safety
MTS Exceed®22 Series 11
Safety
* General Safety Measures - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 12
* Safety Practices Before Operating the System - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 13
* Safety Practices During System Operations - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 16
* Danger Labels - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 18

MTS Exceed®22 Series
12
Safety
General Safety Measures
If you are relevant to the system (that is, you are an operator, service engineer, or maintenance engineer),
you need to carefully learn relevant safety information before trying to perform any operations on the
system.
You should receive training on this system or similar systems, to ensure that you have fully understood
safety precautions relating to your equipment and the use of the equipment. In addition, you should also
read other Guides delivered alongside the system, to further learn about system functions. For details on
training courses, such as contents and dates, please contact MTS.
It is important for you to read the following safety information, to assure that your operations and system
working environment will not contribute to or cause hazards. Keep in mind that you cannot eliminate all
hazards of the system, so you should understand and remember all applicable hazards at all times. These
safety guidelines can help you understand and identify hazards such that you can develop appropriate
training and operating procedures and acquire proper safety gears (such as gloves, goggles, and hearing
protections, etc.).
Each test system is run in a particular operating environment, which includes the following known
variables:
•factors of the site (such as architectural structure, environment, and its functions);
•the customer's unauthorized modification of equipment;
•experience and professionalism of operators.
•Test Sample.
Because of the above variables and other possible factors, your system may work under unforeseen
circumstances that might contain unknown hazards. Incorrect system installation, operation, or
maintenance may lead to death, personal injuries or equipment/Sample damages. Common sense and
thorough knowledge of the system's performances may help you develop proper and safe operating
methods.

Safety
MTS Exceed®22 Series 13
Safety Practices Before Operating the System
Check all safety practices applicable to the system before powering on the system. The purpose of this is to improve the
safety awareness of all personnel relating to the system and observe and maintain the integrity of specific system
components through naked eye.
Read All the Guides
Prior to your first attempt to perform any system operations, you should read this Guide and all other Guides companying
the system. This will help you get a general idea of the system, so as to avoid possible hazards.
Locating Close/Switch Points
You should learn about the close/switch positions corresponding to each energy source of the system, including
hydraulic, gas, electricity, and water sources, to make sure these energy sources can be isolated from the system when
necessary.
Knowing Plant's Safety Processes
Most facilities have their own internal procedures and regulations as safety practices. You should learn about these safety
practices and apply them in daily system operations.
Learning Controls
When operating the system for the first time, you should run the system according to operating procedures without
powering the system on. Check all hardware and software controls, and understand their functions and what adjustments
should be made. If you feel fuzzy about any control functions or adjustment methods, please consult relevant information
until you have a pretty clear mind.
Getting First Aid Supplies Ready
Accidents may occur even if you are very careful. Please properly arrange the schedule of operators, to ensure that there
will always be properly trained personnel in the vicinity who can carry out first aids. Also, post the local emergency
contact information within the sight of system operators.
Knowing Potential Crush Positions
Know potential crush positions on the system, and keep personnel and equipment away from these areas.
Understanding Electrical Hazards
Minimize risks of electrical shocks after the system is powered on. Wear insulated coveralls and use fully insulated tools
for any electrical operations, and avoid touching bare wires or switch contacts. Turn off the power if possible before
operating or approaching any electrical system components. Abide by precautions for other high-voltage machinery.
Safe Distance of Irrelevant Personnel
Irrelevant personnel should be kept a safe distance from the equipment. When conducting tests, do not let any irrelevant
person to touch the Sample or equipment.

MTS Exceed®22 Series
14
Safety
Wearing Appropriate Outfits
Do not wear a tie, shop aprons, loose clothing, or jewellery, or let the long hair loose, to avoid them being
stuck into equipment, thereby causing personal injuries. Take off your loose clothing or jewellery, or tie
your hair up.
Emptying Combustible Liquids in Sample
Before installing the container or component, empty combustible liquids inside the container or component.
Where necessary, replace combustible liquids with non-flammable ones, to maintain an appropriate
proportion of weight and balance.
Check the bolt classifications and torques
In order to ensure product reliability, the torque of fasteners (such as bolts and connecting rods) in MTS
systems must comply with requirements specified. Due to high strengths and high pressures of MTS testing
equipment, the actual torque higher than or lower than the ratings could lead to dangers..
In rare cases, failures may occur even when fasteners are correctly installed. Faults often occur during
tightening, and may even occur several days later. Such faults may result in fasteners springing off at high
speed. As a result, on-site personnel are better to avoid being on a straight line with or under assemblies that
contain large or long fasteners.
Keeping Indoor Area Clean
Keep the floor of the work area clean. Do not leave any tools, facilities, or other items unrelated to the test
on the floor, system or accessories.
Protecting Hoses and Cables
Avoid cables to be overheated, as they can cause the hardening and, ultimately, failures of cables. Ensure
that appropriate strain relief apparatus is installed near cables and plugs of connectors. Do not use plugs of
connectors to release strain.
Avoid all system hoses and cables to get in touch with sharp or rough objects, as they may cause damages to
hoses or cables. It is forbidden to stampede or use heavy objects to press against hoses or cables. During
considerations of system layout and cabling, cables and hoses should be placed away from areas that may
cause damages to them.
Recording Changes Made
In the event that you make any changes to any operating procedures, record all changes made and the dates
when they are made in the Guide.
Test Area Protection
When testing hazardous Samples (such as crisp or fragile materials, or internally-pressurized materials), use
protective shells, such as cages, shields and special laboratory layout.
Do Not Disable Safety Apparatus
Your system may be equipped with active or passive safety apparatus. Do not disable such apparatus to
avoid unexpected system actions.

Safety
MTS Exceed®22 Series 15
Using Fuses up to Specifications
Whenever fuses of the system or power sources are replaced, ensure that a suitable fuse is used and
installed correctly. Fuses thicker or thinner than the prescribed specifications may lead to overheat of cables
and explosion of the fuse. And either case may cause a fire.
Providing Adequate Lighting
Ensure adequate lighting, to minimize the odds of mal-operations, equipment damages, and personal
injuries. Make sure to have a clear vision of all tasks.
Ensuring Equipment Stability
Ensure that the equipment is stable or has been installed with seismic isolation device. Some tests may
cause resonance to the equipment as well as shocks to and movements of the equipment.
Regular Inspection
During impact process, press Scram to check braking torque and respond speed, and check if there is
leakage in air circuit.

MTS Exceed®22 Series
16
Safety
Safety Practices During System Operations
Wearing Appropriate Personal Protective Gears
Wear goggles when operating the pendulum impact testing equipment or performing tests on fragile
Samples or on Samples that contain peculiar fragile parts.
If you may be exposed to liquids, chemicals or powders that irritate or damage the skin, the respiratory
system or eyes, wear personal protective equipment (such as gloves, boots, coveralls or respirators).
Test Area Protection
When testing hazardous Samples (such as crisp or fragile materials, or internally-pressurized materials), use
protective shells, such as cages, shields and special laboratory layout.
Sample Temperature Changes
During cyclic testing, the Sample may catch fire due to overheating. So, you need to wear personal
protective gears, such as gloves, when handling Samples.
Handling chemicals safely
When using or handling chemicals (such as cleaning fluids, hydraulic oil, batteries, contaminated parts,
electro-hydraulic solutions, or maintenance wastes), first consult the MSDS document corresponding to the
concerned material, and then adopt measures and devices suitable for the safe handling and use of the
chemical. Ensure that chemicals are handled appropriately.
Do Not Interfere with Encoder
When the power is switched on, do not crash, swing, adjust, disconnect, or otherwise interfere with the
encoder or its cables.
Ensure cable safety
Do not make any changes to cable connections when the system is powered on. Changing cable
connections during equipment operations may lead to fast, abnormal system responses. In addition, make
sure that all cables are properly connected after you have made any changes to system configurations.
Remaining Vigilant
Avoid working for long time without taking rests. Also, try not to do repetitive, unchanging or monotonous
work over long periods, as this may easily cause accidents or hazards. If you are over familiar with the
work environment, you tend to overlook potential hazards in the environment.
Avoiding Moving Equipment/Crush Points
Keep clear of mechanical linkage devices, connection cables, and moving hoses, as you may be caught,
squeezed, or wrapped therein, or dragged by their movements. Forces generated by the system can pinch,
cut or crack any object by which the system passes, causing serious injuries. So, avoid all potential crush
points. Most test systems can produce sudden, strong movements. Do not think that your reaction is fast
enough to keep you from any dangers in the case of system failures.

Safety
MTS Exceed®22 Series 17
Do Not Use RF Transmitter
Ensure that workstation PCs, remote terminals, and electronic consoles are far away from the radio
frequency (RF) transmitter. Strong RF electromagnetic fields can make sensitive circuits of the system
unstable.

MTS Exceed®22 Series
18
Safety
Danger Labels
The following table lists labels that are affixed on the equipment.
Danger Labels
Label Description
Indicates that you need to read and understand instructions
before starting, operating, or maintaining the equipment.
Indicates the vertical lifting device.
Indicates that the equipment has no maintenance tools that
can be utilized by customer.
Indicates splashes, which may easily injure eyes, so you need
to wear goggles.
Indicates the presence of moving parts. Moving parts may
squeeze or cut objects, so your hands need to keep clear of
them.
Indicates that the equipment may easily tip. When the
equipment is tilted, use support frame.
The Waste Electrical and Electronic Equipment symbol
indicates that controllers and other electronic components
cannot be discarded like unsorted municipal waste. They can
be recycled only by accredited electrical waste recycling
institutions. For EC customers, if you want to return the
scrapped controllers and other electrical components, please
contact the local MTS sales/service office for guidance.

Introduction
MTS Exceed®22 Series 19
Introduction
* About This Manual - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 20
* Overview - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 21
* Overview of mainframe and shield - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 22
* Electric Coupling Plate - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 27
* Control panel - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 29
* Shield - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 30

MTS Exceed®22 Series
20
About This Manual
About This Manual
This guide is an operation guide of E22 metal pendulum impact tester:
•Mainframe Overview
•Detailed instructions showing examples for how to run typical test
•Detailed instructions for measuring power loss
This manual does not involve content relating to installation, calibration, commissioning and adjustment of
the equipment, nor does it involve content related to the on-site service engineer and testing engineer.
