1. Introduction
The Mueller Systems Mueller Cellular Node is intended for indoor and outdoor use
as an unattended Automatic Metering Infrastructure (AMI) and control device. The
Mueller Cellular Node is fully self-contained and battery powered device with no user
accessible controls.
The Mueller Cellular Node for Residential Metering (“Mueller
Cellular Node”) is a device that incorporates a microcontroller, a
LTE MODEM , and battery (DC power supply) for the purpose of
logging and forwarding water meter readings to the Mueller
Systems servers. The Mueller Cellular Node comprises 2
primary communication and processing modules, the SIERRA
HL7800 LTE MODEM, and the Silicon Labs BlueGecko
EFR32BG12. The Mueller Cellular Node provides a direct
connection to all Mueller water meters equipped with a
Mueller encoder register. The primary function of the Mueller
Cellular Node is to provide full, two way reliable and secure data
communications via the existing cellular networks. The Mueller Cellular Node will also
autonomously send messages to the server when various events or alert conditions are
detected, such as potential leak or theft of service.
Meter reading interval is remotely settable. Information retrieved from a water meter is
stored temporarily within the Mueller Cellular Node unit's internal memory. As a default,
the Mueller Cellular Node will transmit hourly meter data at a predetermined time once
per day, via the cellular network to the Sentryx system host server for analysis and
storage. On demand reads to the Mueller Cellular Node can be requested at any point in
time.
The contents of this installation manual are intended for technically qualified personnel
of water and energy distribution utilities who have been trained and are technically
qualified in local safety procedures for installation of the device.
2. Construction
The Mueller Cellular Node product consists of a printed circuit board which is encapsulated
to provide complete protection against shock and water intrusion. The enclosure is made of
UV stable, high- density thermoplastic and is completely waterproof. The UV stable,
thermoplastic housing design provides a compact, waterproof enclosure that is lightweight
and easy to handle and install. The Mueller Cellular Node has integral mounting brackets
for both pit and wall installations. One D size lithium battery provides plenty of power
for reading the register and sending RF data.
• To protect the AMI device electronics from moisture ingress the design
incorporates the use of thermoplastic injection molded housings, rubber seals,
a potting compound that completely incases the internal electronics and a
coated circuit board which combine to provide a formidable barrier of
protection against water intrusion.
• Internal wire strain relief has been built into the housing to protect the wire
connections against damage. Please note that meters or registers should never
be carried while supported only by the Mueller Cellular Node transmitter or wiring.

Mueller Cellular Node Installation
Manual
Mueller Systems –Proprietary
Page 5
• A LTE PCB antenna is located in the upper housing to provide RF communication.
• A single D cell long life Lithium battery is located in the lower housing which
provides power for register interrogation and data transmission for a calculated
battery life of up to 10 years.
• There are no customer serviceable parts inside the Mueller Cellular Node housing.
Batteries are not replaceable.
• The electronic design utilizes the latest RF microchip technology which
increases reliability when compared to older RF designs.
3. Installation
Mueller Cellular Node modules support two mounting options, either mounting to a ½”
PVC pipe for pit set installations or affixed to the side of a building. Pit set
installations require no drilled holes through the lid and are mounted beneath the
polymer meter box lid for security and ease of installation on PVC pipe. Surface
mounts are easily accomplished with the integral mounting brackets and two screws
(not included).
3.1 Pit Set Installation
Please note that meters or registers should never be carried while supported only
by the AMR transmitter or wiring.
Tools Required: Length of ½” PVC pipe for pit depth, hammer
1. PVC pipe should be cut to the proper length and installed deep
enough in the floor of each meter box that subsequent flooding
will not allow the stake and Mueller Cellular Node to change
position. The Mueller Cellular Node includes a ½” female PVC
pipe fitting for easy pit installation.
2. For maximum radio performance, once installed, the top
of the transmitter should be located approximately ½” inch
below the pit lid in the center of the meter box to maximize RF
performance.
3. Once the PVC stake is installed, the Mueller Cellular Node
should be pushed down onto the stake by hand until the
interference fit engages securely. Two solid stops are molded
into the PVC Installation Slot to prevent the wire from
being pinched when installed.
Never hammer Mueller Cellular Node onto the stake since this may result
in damage to the electronic components inside the unit.
4. Always mount the Mueller Cellular Node in a vertical orientation, with the
antenna compartment on top and the battery compartment on the bottom.

Mueller Cellular Node Installation
Manual
Mueller Systems –Proprietary
Page 6
3.2 Exterior Wall Mounting
Tools required: 1 –1 1/2 inch galvanized, or stainless wood or sheet
metal screws (2 per), Phillips screwdriver
1. The open-ended wire from the device permits routing through
interior walls for external wall mounting when required or
direct mounting to exposed floor joists above grade level.
2. Mueller Cellular Node can be directly mounted to almost any
flat surface by using the holes shown and common screws in
most instances.
3. Vertical orientation of the device is required to maximize RF
performance.
3.3 Wiring
Tools Required: 3M-2Y connectors, splitting tube, and a 3M Crimping Tool
Mueller Cellular Node
Red
Green/White
Black
TranslatorRegister
Red
Green/White
Black
Badger ADE Register
Red
Green
Black
Sensus ECR and ICE Registers
Red
Green
Black
Neptune PRORead, AUTORead, E-Coder Registers
Black
Red
Green
Table 1. Mueller Cellular Node Meter Interconnect
3.4 Verification- Activation [Bluetooth]
The EFR32 Bluetooth subsystem is primarily responsible for one time device activation and
verification. Device activation must be in close proximity of Mobile Bluetooth Hand-Held [<
5ft]
Device Bluetooth activation is initiated by a magnet swipe located in a pre-determined area
on the device.
After magnet swipe, device initiates Bluetooth communication and is configured in discovery
mode. For one time activation the Bluetooth Hand-held should be used to verify proper
installation and operation. Verify device operates per customer settings and is starting with
the default profile.
Bluetooth subsystem is deactivated after verification/activation and device enters normal
mode and supports the profiles based on situational logic.
Bluetooth subsystem will be shut down and non-functional until new activation is initiated
by local magnet swipe.
Please refer to the Bluetooth Mobile Hand-held application manual for more app. details.
Shipping mode -- How the device leaves the factory and shipped to a warehouse or
distribution center

Mueller Cellular Node Installation
Manual
Mueller Systems –Proprietary
Page 7
Operational mode -- device operates per customer settings and is starting with the default
profile.
4. Maintenance
There are no user serviceable items within a Mueller Cellular Node. The battery is sealed
within the module and is not replaceable. No cleaning is required.
5. ProductLabeling
5.1 Product and FCC/IC Identification
This label is affixed to the face of the Mueller Cellular Node unit. This allows the
installer to easily scan the label with the Bluetooth handheld device during the
installation process. This label includes the Date of Manufacture, the Hardware Version
and the Mueller Cellular Node/Serial Number (Node ID) that is used to uniquely address
the device and assembled in USA. The FCC ID is SM6-CELLNODE.
Figure 1. Sample Product Identification Label
5.2 IC Information
This AMI t r a n s m i t t e r , model Mueller Cellular Node, contains FCC ID:N7NHL78M/
IC:2417C-HL78M, MODEM that operates in LTE bands and is also certified for operation
in Canada. The device IC ID is 9235A-CELLNODE. Information pertaining to the
certification can be found on the web at http://www.ic.gc.ca/eic/site/ceb-
bhst.nsf/eng/home.
