Muji MJ-AP1GL User manual

Air Purifier
Model MJ-AP1GL
User's Manual
Index Page
Household Use
• Thank you for purchasing this product.
• Please read this manual before use.
• Please keep this manual in a safe place for future reference.
Do not dispose of electrical appliances as
unsorted municipal waste, use separate
collection facilities. Contact you local
government for information regarding the
collection systems available. If electrical
appliances are disposed of in landlls or
dumps, hazardous substances can leak into
the groundwater and get into the food chain,
damaging your health and well-being.
Manufacturer: TechnoPLAS(SHENZHEN)CO,.LTD
Manufacturer A Building TechnoPLAS Ind., Sheng Bao Road,Kangle community,
Address: Nanwan Sreet,Longgang District,Shenzhen,China. 518112
Package Contents 1
Parts Names 2
Safety Advice 3-4
Warnings 5-7
Cautions 7
Before Use 8-10
How to Set Up 11
Specifications 12
How to Use/Explanation of Indicators 13-14
Operating Modes 15-16
Sensors 17
How to Clean the Dust Sensor 18
Air Purifier 360° Deodorizing Dust Collector Filter 19
How to Clean the Filter 20
How to Reset the Filter Cleaning Sign 21
Changing Filters 21
Care & Maintenance 22
FAQs 23-25
M空清_Manual Size:148.5x210 BALMUDA Inc. 2015/03/20

Package Contents
Body
Power Cord
User's Manual
(this document)
1Package Contents
★Points to follow for long term use
Discontinue
Use
360° Deodorizing
Dust Collector Filter
* At time of purchase, the filter is
in a plastic bag, stored inside
the body.
Filter Start Date Use Label
* The label is packed with the filter.
* Write the date of first use
and stick onto the filter.
Have you
noticed
any of the
following?
• The purifier doesn't work, even if the
power is turned on.
• Power supply is interrupted when the
cord is twisted.
• Unusual sounds during operation.
• Warped or unusually hot product
housing.
• Other irregularities or malfunctions.
In any of these
cases, immediately
discontinue use.
Unplug the power
plug from the
socket and consult
your retailer.
M空清_Manual Size:148.5x210 BALMUDA Inc. 2015/03/20

Fan guard
Sensor cover
Filter cover hinge
Power cord slot
Parts Names
2
Parts Names
Filter cover
Operational Panel
· Operating Mode Indicator
· Filter Cleaning Sign
· Child Lock Button
· Jet Cleaning Mode Button
· Change Modes Button
· Power Switch
Warning/Caution label
Product label
Plug
(product end)
Power plug
(socket end)
Body
Back of Body
Power Cord
25
P.13
P. 8
P.21
P. 9
P.13-14
P.14
FAQs
FAQs
SolutionProblem Page
□It is powder from the active carbon inside the filter.
▶It is not harmful to humans but when cleaning the
filter, please lay newspaper on the ground.
□Select Manual mode and change the air volume.
Is there a change in the noise when the operating
mode changes?
▶Please check "How to Use" and "Operating Modes". It is
possible there is a rotating sound when fan mode is in
operation, so please check the specified sound levels.
Please consult the store where it was purchased from.
□When nothing is pressed for more than 1 second,
the indicator light will dim.
▶Please check "How to Use".
□Is child lock on?
▶Please check "How to Use".
□The deodorizer can remove smells to a certain
extent.
* It is possible that not all smells can be removed
depending on the environment.
▶ Remove the 360° Deodorizing Dust Collector Filter and dry it
out in the sun where there is good wind flow, for half a day.
□It does not necessarily remove smells that are
always present (smells from pets, building
materials etc).
▶If these smells are not removed completely, please use
the product as well as ventilate the room.
□Is the filter cover inserted correctly?
▶Please check how to insert the filter cover.
□The product has detected an error and has stopped
functioning.
▶Please check "How to Use" and press the power
button following the steps below.
<1st step> →Turn the power OFF.
<
2nd step > →Turn the power ON and operate normally.
If it still does not function even after following the 2nd
step, please consult the store where this was purchased.
□Turn the machine off and unplug the power cord.
▶Remove the filter, and then take out the foreign object.
Black powder
leaking from
the filter.
During operation,
there is a noise
other than that of
the air blowing.
The indicator light
dimmed suddenly.
Ican't change
operating modes.
Foreign object
enters the fin guard.
The smell won't
go away.
The child lock
indicator is
flashing and the
product stopped
functioning.
* The fan is below the fan guard.
Do not insert your finger or small
objects into the fan guard.
* Do not remove the fan and
wash. Impure air flows
through the filter and
becomes clean, so it is
difficult for the fan to
become dirty.
Fan (inside the body)
Air Filter
M空清_Manual Size:148.5x210 BALMUDA Inc. 2015/03/20

3FAQs 24
P.15,16
P.15,16
P.11
P.17
P.19
P.18
P. 2 1
P.20
P. 2 1
SolutionProblem Page
The air volume
changes without
any manual
operation.
Astrong volume
of air started
blowing.
Even though it is
in Auto mode, it
doesn't respond
to dust or smell.
There is a smell
coming from the
filter.
How often should
the filter be
changed?
The filter cleaning
sign won't turn off.
□Check the current operating mode. If it is in auto
mode, it will automatically change if dust or smell
is detected.
▶Please check "Operating Modes".
□Did you select the Jet Cleaning Mode?
This mode cleans the air on a high level in a short time.
▶Please check "Operating Modes".
Please be sure a suitable operating mode is selected.
□Is the sensor obstructed by the wall or other objects?
▶Please check "How to Set Up".
If it is obstructed, please remove the obstruction. If
there is no obstruction, please clean the sensor at the
back of the body.
□What level of sensitivity is the sensor set to?
▶Please check "Changing the sensor's sensitivity". You
can choose from Mild or Sensitive.
□Is the filter new? There may be a faint sweet smell
from the active carbon in the filter.
▶As high range active carbon is used, it may emit a
sweet smell when it is first used. Usually it will take
about 1 week for the smell to gradually lessen.
□Did you use the product when there were many
different smells emitted temporarily from many
people smoking, cooking BBQ etc?
▶As the filter absorbs smells, it will temporarily store it
up. It will gradually reduce as the product is in
operation.
□Did you move it from another room?
▶It is possible it smell like the room it was used in before.
The smell will gradually reduce as the product is in operation.
□It is recommended the filter is changed every year.
▶Please check the date when the filter was first used.
It it has been a year, please change to a new filter.
□Did you reset the filter change sign?
▶Please reset the filter change sign.
M空清_Manual Size:148.5x210 BALMUDA Inc. 2015/03/20
Safety Advice
Safety Advice
Explanation of Signs
Warning
Explanation of Symbols
This symbol indicates never to do this.
This symbol indicates you must do this.
Prohibited
Must follow
Caution
Please be sure to follow the Safety Advice.
Please read the Safety Advice carefully before usage and use correctly. This manual contains
points for caution so that the product can be used correctly in order to prevent causing
accidental injuries or harm to the user of this product and others.
Indicates a hazard with a medium level of risk
which, if not avoided, could result in death or
serious injury.
Indicates a hazard with a low level of risk which,
if not avoided, could result in minor or moderate
injury or damage to property or furniture.

FAQs
23
FAQs
SolutionProblem Page
P.10
P.10
P.14
P.13
P.9
P.9
P.8
P.9
P.20
P.15,16
4
□Is the power plug plugged in correctly?
Please check the following that it is plugged in
correctly.
▶Connection between power code slot (of the body) and
the plug (product end).
▶Connection between the power plug and socket.
□Are the indicators on the operating panel on?
Be sure to press the power button to operate.
▶After reading and checking the section "How to Use",
turn the ON/OFF button if necessary.
□Is the child lock on?
Turn off the child lock.
□Is the filter cover on correctly?
Check how to re-attach the filter cover.
□Is the filter inserted correctly?
Check how to insert the filter.
□Is there are a power outage in your area?
▶Wait until the power supply returns.
□Is the power breaker on?
▶Turn on the breaker.
□Did you remove the filter from the plastic bag and
inserted it in?
▶At the time of purchase, the filter is in a plastic bag.
Remove from plastic bag and use.
□Is the filter inserted properly?
▶Check if it is inserted properly.
□Is the filter dirty?
The amount of dirt will affect the air volume.
▶Please clean the filter. If there is no improvement, the
filter needs to be changed.
□Is the operating mode in Auto mode?
▶Please check the "Operating Modes".
▶Press the Change Modes button to check that it is
possible to change operating modes.
Power doesn't
turn on.
There is no air
blowing.
There is no
change in air
volume.
The air volume
has decreased
from when it was
first purchased.
Safety Advice
In order to use safely:
If any of the following occurs, stop usage immediately and contact the store where it was
purchased from.
Stop usage immediately if there are any
irregularities such as unusual sounds,
smell or heat.
Not doing so may cause malfunction or fire.
Do not insert foreign objects or
your nger inside the guard or
moving parts.
This may cause injury.
Do not use on unstable locations or
next to dangerous objects.
This may cause injury if it falls over.
Stop usage immediately if the fan is
rotating abnormally or if there are other
abnormalities.
Not doing so may cause malfunction or fire.
Do not use near objects such as
curtains that will block the wind ow.
It may get caught in the curtain, or the
filter or air diffuser may become blocked
causing an accident or injury.
M空清_Manual Size:148.5x210 BALMUDA Inc. 2015/03/20

522
Warnings
Warnings
Do not damage the power cord or plug.
Damaging, altering, forcefully twisting, pulling or placing heavy objects on the cord
can cause electric shock or fire due to short circuit.
Do not use if the power plug or cord becomes damaged, hot or loosely
plugged into the socket.
This may cause fire, electric shock, injury or short circuit.
Do not use on voltages over 220-240V or over the specified ratings for
the socket or wiring appliances.
Using on multiple sockets over the specified ratings can cause it to heat up and lead to fire.
Do not unplug with wet hands.
Wet hands on the electric plug can cause electric shock.
Insert the plug fully until the base.
If it is not plugged in fully, electric shock or heat can cause a fire.
Stop usage immediately and unplug if there are any abnormalities or malfunction.
Not doing so may lead to smoke, fire or electric shock. Please consult the store where
it was purchased.
<Abnormalities/Malfunction>
・Moving the electric cord causes it to stop operating.
・During operation, there are unusually large sounds or it moves violently.
・The product is unusually hot or there is a burnt smell.
Unplug from socket if not used for long periods.
Deterioration of insulation can cause a fire.
Regularly clean the dust from the electric plug.
When dust accumulates, it can deteriorate insulation due to moisture, causing a fire.
When cleaning, inspecting or moving the product, be sure to turn off
the power and unplug.
Sudden movements can lead to electric shock or injury.
Do not insert foreign objects such as your finger or metal objects into
the air outlet, filter or openings inside the body.
Touching the inside can cause electric shock or injury.
Please see on how to clean the inside and the filter.
Care & Maintenance
Care & Maintenance
1
2
* Be careful not to damage the surface.
Remove the plug from the socket.
(Benzine, thinners, other solvents or polishing powder)
* This can cause scratches, discoloration or cracks.
Do not use the following to clean the product.
P.20
Turn off the power and remove the plug from the socket. Vacuum the dust around the body of
the product with a vacuum cleaner nozzle. Gently wipe with a soft cloth.
* Be sure to unplug from the socket
before starting.
Vacuum the dust around the body of the product. Gently wipe
with a soft cloth.
M空清_Manual Size:148.5x210 BALMUDA Inc. 2015/03/20

21 6
Warnings
Do not disassemble, repair or alter the product.
Heat or irregular operation may lead to electric shock or fire.
Do not wet or run water over the product.
This may lead to electric shock or fire due to a short circuit.
Do not let children use it alone or place in an area where young
children can reach.
This may lead to electric shock or injury. Be especially careful with babies and infants.
Do not use chlorine or acidic detergents.
Detergents emit poisonous gases which may be harmful to your health.
Do not use near combustibles, lighted cigarettes or incense.
It may cause it to ignite and catch on fire.
Do not operate when using pesticides that emit smoke.
Chemical substances that have accumulated is released through the air diffuser which
may be harmful to health.
After the use of pesticides, be sure to ventilate the room sufficiently before operating
the product.
Ventilate the room when using the product together with combustible appliances.
Not doing so may lead to carbon monoxide poisoning.
Even if the product is in operation, it will not remove carbon monoxide.
Do not use in the following locations.
This may lead to electric shock, fire or other damages.
・Unstable or high places.
・In the bathroom or where there is water, high temperatures or high humidity.
・In the kitchen or places where there is oil.
・Places where there might be leakage or use of oil or burnable gases.
・Places where there are corrosive gases or dust from metallic objects.
・Places where there is direct wind on plants or animals.
・Places with direct heat such as a heater.
Do not wipe with benzine or thinners or use pesticides.
This may cause cracks leading to injury, or short circuit causing electric shock or fire.
To buy a replacement filter, please go to the store where you bought the product.
(Product Name: 360° Deodorizing Dust Collector Filter Model: MJ-AP1-FL)
How to Reset the Filter Cleaning Sign/Changing Filters
How to Reset the Filter Cleaning Sign
Changing Filters (Ideally once a year)*1
About changing filters
When to change filters
*1 When using Jet Cleaning mode once per day.
Turn off the power and press the Jet Cleaning Mode button for more than 2 seconds until it
beeps. The filter cleaning sign will turn off and the timer will be reset.
②Check that the filter
cleaning sign is off.
①Press the Jet Cleaning button
for more than 2 seconds when
the power is off.
The time to change filters depends on how and where you use the product. You should aim to
change it every year.
If it is being used in areas where the air is not clean, you may need to change it earlier.
・When changing filters, lay newspaper underneath so that dust does not spread around.
・Dispose of the old filter according to your local area's disposal rules.
Main materials of the filter .....Polypropylene non-woven fabric, polyester non-woven
fabric, rayon, active carbon, pulp etc
・Depending on the environment in which it is used in, the filter may start to emit a smell within
a few weeks or months, so you may need to change the filter.
・The filter is a consumable item so it will incur a cost even if it is within the warranty period.
M空清_Manual Size:148.5x210 BALMUDA Inc. 2015/03/20

207
Cautions
Warnings/Cautions
Warnings
This appliance can be used by children aged from 8 years and above and persons with
reduced physical, sensory or mental capabilities or lack of experience and knowledge if
they have been given supervision or instruction concerning use of the appliance in a safe
way and understand the hazards involved. Children shall not play with the appliance.
Cleaning and user maintenance shall not be made by children without supervision.
Do not sit or lean on the product.
It may cause the product to fall over and lead to injury. In case it falls over, unplug
from socket.
Be especially careful when using it in homes where there are young children.
Do not turn the product on its side.
This may lead to injury or damage.
When moving the product, turn off the power and carry it tightly.
Dropping the product or letting it slip and fall can lead to injury.
Do not use for special purposes such as preserving artwork or
technical documents or commercial purposes.
This may lead to deterioration of the quality of preservation items.
During operation, do not move the product.
This may lead to injury or malfunction.
Keep hair away from the fan guard.
This may lead to hair getting caught or malfunction.
If using near pets, be careful that they don't urinate on the product or
chew on the power cord.
This may lead to electric shock or fire.
When unplugging from the socket, pull from the plug.
Not doing so may lead to electric shock or fire due to damage or short circuit.
Do not obstruct the air outlet and filter with laundry, cloths or curtains.
This may lead to poor air circulation causing heat or fire.
How to Clean the Filter
How to Clean the Filter
1
2
Remove the filter following the steps on P.8.
3Insert the filter following the steps on P.9.
Vacuum dust inside the body and around the filter.
The Filter Cleaning Sign and How to Clean the Filter
Filter Cleaning Sign
light on
NO
Inside Filter
Based on the timer located inside the body, when the period of operation reaches 500 hours
(approx. 3 weeks), the orange Filter Cleaning Sign will light up. When this lights up, please
clean the area surrounding the filter in order to maintain the product's functions.
* Lay newspaper underneath so the dirt from the filter doesn't spread to other areas.
* Be careful not to damage the surface of the filter.
* Vacuum dirt inside and gently
wipe with a soft cloth.
* Do not wash with water.
(This will impair the functions.)
M空清_Manual Size:148.5x210 BALMUDA Inc. 2015/03/20

19 8
Air Purifier 360° Deodorizing Dust Collector Filter
Protective mesh
* Filter cross-section
Air Purifier 360° Deodorizing Dust Collector Filter
All-in-one dust collector and deodorizing filter
Non-woven fabric filter
+
Granulated active carbon
When the deodorizer becomes less effective...
* Filter cross-section in detail
Protective mesh
Non-woven fabric filter
Non-woven fabric filter
Granulated
active carbon
Granulated active carbon (deodorizer) is placed in between non-woven fabric filters
(dust collector) and pleated into a all-in-one dust collector and deodorizing filter.
Revive the deodorizer by drying it out in the sun where there is good wind flow, for half a day.
Do not wash with water.
*The above does not guarantee that the deodorizer will return to its original new state.
M空清_Manual Size:148.5x210 BALMUDA Inc. 2015/03/20
Before Use ①Removing/Inserting the filter
Open the filter cover
Before Use ①
1
a
b
c
2
* Top of Filter
Stick the Filter Start Date Use Label on here.
Press and hold down
the filter cover hinge.
Pull the cover in the
direction of the
arrow shown.
Remove the cover in
the direction of the
arrow shown.
Take the Filter and Filter Start Date Use Label out from the plastic
bag. Stick the Filter Start Date Use Label on the side as shown.
* Cut the plastic bag with scissors.

18
9
* side should be facing up and push the filter
all the way back.
Insert the filter into the body with the pull tab facing the front.
Insert the filter into the body.
d
e
4
3
* If the filter or filter cover is not inserted correctly, the product will not function.
Replacing the filter cover.
Pull tab
(Top & bottom)
Filter cover
▲▲
Body
360° Deodorizing
Dust Collector
Filter
Insert the bottom tab of
the filter cover into the
tab slot of the body.
* Match the ▲mark of the filter cover with the same
mark on the body.
Push the filter cover hinge down in the
direction of the arrow shown to close.
* There is a top and bottom to the filter. Insert the filter with facing the top, and
push all the way in.
Before Use ①How to Clean the Dust Sensor
How to Clean the Dust Sensor
Remove the sensor cover.
ab
cd
When the lens that detects dust becomes dirty with moisture, nicotine from cigarettes etc, it
reduces the level of sensitivity. Please clean it regularly as shown below, vacuum the
surrounding dust with a vacuum cleaner, remove dirt with a dry cotton bud.
* Recommended cleaning every 3 months.
Use a vacuum cleaner to remove the
surrounding dirt that is covering it.
Re-attach the sensor cover
after cleaning.
Wipe the top left side of the lens with a
dry cotton bud.
* Keep the cover in a safe
place so you don't lose it.
* Firmly attach all the way
until you hear it click.
M空清_Manual Size:148.5x210 BALMUDA Inc. 2015/03/20

17 10
Before Use ②
Before Use ②Connecting the power cord
Connect the power plug to the socket.
1
2
Insert the power cord into the slot of the body.
Connect the power cord.
Insert power plug into socket.
* Please insert fully to the end.
* The product will beep.
ab
Power cord
Power cord
slot
Up
Down
Plug
(product end)
Power plug
(socket end)
After inserting into socket as
shown, it will be ready to use.
Changing the sensor's sensitivity (Set on Mild at time of purchase)
Sensors
Easily detectable by the dust sensor
When changing to Sensitive
The buzzer will sound "Beeeep, Beep"
*Unplugging the product will reset the sensor to Mild
P.16
Easily detectable by the smell sensor
When changing to Mild
The buzzer will sound "Beeeep, Beep Beep"
Dust Sensor
Smell Sensor
Sensors
This product is equipped with a dust sensor which detects dirt in the air and a smell
sensor which detects smells in the room.
In Auto mode, when the sensors detect dust or smell, it will control the air volume accordingly.
* The sensors only operate in Auto Mode. Please refer to
House dust (dust, corpse and faeces of ticks,
pollen, spores of mold), cigarette or incense
smoke, pet hair
Cigarette, incense, make-up, alcohol,
sprays, pets, cooking/food odours
When in Auto mode, the rotation of the fan is finely controlled depending on the monitoring
status of the 2 sensors. The sensitivity level of the sensor can be chosen from the normal
setting of Mild, or a higher sensitivity level of Sensitive. When you want to change the
sensitivity level higher during Auto mode, use the Sensitive setting. To change the sensor's
sensitivity level, press the Jet Cleaning Mode button and Change Modes button at the same
time for more than 2 seconds, while the power is turned off.
*Please refer to the diagram below to change the sensor's sensitivity level.
To change the sensor's sensitivity
Press these 2 buttons at the same time for over 2
seconds while the power is OFF.
M空清_Manual Size:148.5x210 BALMUDA Inc. 2015/03/20

11 16
How to Set Up
How to Set Up
To utilise the functions of the product at its optimum, please set up at a suitable
distance from the wall.
* Do not place under a table or where the air
outlet will be blocked.
* Do not place next to furniture or where the
filter will be blocked.
* Do not place in high areas as this will
reduce the efficiency of absorbing the air
around the ground.
Placing in the following locations will
not enable the product to function at
its optimum.
Set up the product in a place where there is
good air circulation in the room.
More than 120cm from ceiling.
Operating panel
facing the front.
M
ore than 30cm
from the wall.
More than 30cm
from the wall.
[Back]
More than 10cm
from the wall.
More than 120cm from ceiling.
Operating panel
facing the front.
M
ore than 30cm
from the wall.
More than 30cm
from the wall.
[Back]
More than 10cm
from the wall.
Operating Modes
Manual Mode Indicator
Auto Mode
Idling Mode during Auto Mode Operation
[Air Volume 1] [Air Volume 2] [Air Volume 3]
Idling
Once the air becomes clean
This mode automatically controls the air volume depending on the condition of the air in the
room. The 2 sensors which detects dust and smell regularly monitors the air condition .
When dirt (dust or smell) is detected, it will clean the air accordingly. When it doesn't detect
any dirt in the air, it will repeat the cycle of <Idling > Manual Mode [Air Volume 1]>.
The Idling mode which operates only in Auto mode stops the air purifier fan from
rotating, while keeping the upper fan rotating slowly in order to circulate air that is
required for the sensor detectors. This mode operates at the lowest energy consumption
level at approximately 4W.
Auto Mode Operation
Regularly monitoring dirt in the air
Detects dirt
Selects cleaning mode
depending on cleanliness of air
Manual
[Air Volume 1]
Manual
[Air Volume 2]
Manual
[Air Volume 3]
If dirt is detected during
operation, the air volume
will be adjusted.
P.17
M空清_Manual Size:148.5x210 BALMUDA Inc. 2015/03/20

15 12
Specifications
Specifications
*1For use in Hong Kong and Europe.
*2Suitable Floor Area and Cleaning Time is based on "JEM1467" (during Jet Cleaning Mode).
*3Idling mode only functions during Auto mode.
Body*1
Model MJ-AP1GL
Power Source AC 220-240VAC 50Hz
Suitable Floor Area (Ideal) ~49m2 *2
Cleaning Time 10min/32m3 *2
Operating Mode Jet Cleaning 3 2 1 Idling*3
Total Air Volume 6.7m3/min 3.1m3/min 1.9m3/min 1.1m 3/min —
Energy Consumption 32W 10W 7W 4W 4W
Operating Noise Level 60dB 43dB 34dB 27dB 19dB
Product Measurement W250×D250×H498
（mm）
Product Weight Approx. 6.0kg (Including filter)
Power Plug*1
Cord Length Approx. 2.0m (Power cord is for AC 220-240VAC.)
* This product uses an original "dual counter fan" to effectively clean the air of the entire room.
"Total air volume" refers to the amount of air that flows through the 360° Deodorizing Dust
Collector Filter that becomes purified and is released through the top air outlet.
* The energy consumption value during Idling mode is measured when the indicator brightness is halved.
Operating Modes
Operating Modes
Jet Cleaning Mode
Manual Mode
30 minutes 20 minutes 10 minutes
20 minutes
5minutes
5minutes
10 minutes
5minutes
5minutes
5minutes
2.5 minutes
2.5 minutes
Remaining time indicator during Jet Cleaning Mode
Remaining time:
Over 20 minutes
Remaining time:
20 minutes or less
Remaining time:
10 minutes or less
When the jet cleaning mode finishes, it will return to the previous operating mode.
This mode provides the optimum level of air flow at the highest speed, efficiently purifying the
air in the room. It is especially effective to use before/after cleaning, after ventilation, before
leaving the room, after cooking to remove strong odors such as from a BBQ. Also, you can
choose from continuous operating time of 10, 20 or 30 minutes. When the jet cleaning mode
finishes, it will return to the previous operating mode.
* To cancel the jet cleaning mode, press the Change Modes Button .
Display at the
start of Jet
Cleaning Mode
Jet Cleaning
Manual Mode Air
Volume 3
Manual Mode Air
Volume 2
You can choose from 3 levels of "Air Volume 1, 2, 3" providing a specific level of air
purification. Also, manual mode can be used as an air circulator to improve the efficiency of air
conditioners/heaters whilst purifying the air.
M空清_Manual Size:148.5x210 BALMUDA Inc. 2015/03/20

14
13
Pressing this will begin the jet
cleaning mode.
How to Use/Explanation of IndicatorsHow to Use/Explanation of Indicators
How to Use/Explanation of Indicators
Press this to turn on child lock.
Filter Cleaning Sign
P.20
Child Lock Button
Turning child lock on and off.
Jet Cleaning Indicator
Child Lock Indicator
Select 10, 20 or 30 minutes.
The remaining time is shown
by the flashing LED.
Please clean the filter if this light is on.
This will light up when the child lock is on.
This will also blink when the filter cover is
not inserted correctly or when there is
something wrong.
To prevent young children from operating the product, pressing the Child Lock Button for
about 2 seconds will turn it on/off. When the child lock is on, the indicator will light up.
* When child lock is on, no other functions will work except for turning off the child lock. Also,
child lock can be turned on while the product is switched off.
P.15 P.15,16
Power Switch
When power has been reconnected
This will change the operating mode.
Change Modes Button
Cycle of Changing Modes
Air volume 3
Air volume 2 AUTO
Air volume 1
Jet Cleaning Mode Button
Air volume 1, 2, 3
AUTO Mode Indicator
Power
Indicator
Jet Cleaning Operation
Turns the power ON/OFF.
* When nothing is pressed for more than 1
second, the LED will dim.
Operation will start in the mode that
was set before the power was turned
off. If it was unplugged after the
previous time it was used, it will start
from Low Manual Mode.
Pressing this button during operation will
begin the Jet Cleaning Mode, the
optimum air purification function. Every
time the button is pressed, it will change
the operation time from 10 minutes →
20 minutes →30 minutes →10 minutes
etc. When the time ends, it will return to
the operation mode that was set before
the jet cleaning mode began.
The LED will light up on the
selected mode.
M空清_Manual Size:148.5x210 BALMUDA Inc. 2015/03/20
