MULTIBETON Airbreze User manual
1. Safety instructions
Carefully read the instructions for use before using the air puri-
fier for the first time, and always store them in the immediate
vicinity of the appliance. MULTIBETON GmbH does not assume
liability in case of accidents or damage caused by non-complian-
ce with the instructions. Keep children under 5 years of age away
from the appliance. Children between the age of 5 and 8 may
switch the product on and off under supervision. Do not allow
children between the age of 5 and 8 years to plug the appliance
into the outlet or adjust the appliance settings, clean the appli-
ance and/or perform user maintenance.
· Pull the plug from the outlet while cleaning the appliance or
changing the filter. Also observe this step for repair work.
· Always keep air inlets and outlets clear. The immediate envi-
ronment should be free of loose objects and contamination.
· Never insert objects or body parts (e.g. fingers) into the air
purifier.
· Do not allow liquids to enter the interior of the appliance.
· Do not place any objects and drinks on the air purifier.
· Do not stand on the appliance; Risk of injury!
· Do not sit on the appliance. The air purifier is not a piece of
exercise equipment and must be kept out of the reach of pets
and children. Only use the product under adult supervision.
· Never allow the appliance to come into contact with flammable
liquids/gases (explosion hazard).
· Do not cover or transport the appliance while operating it.
· Do not operate the device with wet or damp hands.
· Check the appliance for damages and filter condition before
each use (see control element/filter replacement display).
Do not use the appliance if it is defective or if the filter has
reached the end of its life. Do not use the device if the power
adapter or plug are damaged. Contact your retailer for the fast
replacement of damaged parts.
· Never replace damaged parts yourself, have this done by the
manufacturer, sales representative, or a similarly qualified
person.
· Before use, check whether your available mains supply corre-
sponds to the mains supply indicated in the technical data
sheet and ensure that the outlet used is faultless and secured.
· If you wish to stop using the appliance temporarily, switch it
off and remove the cable from the outlet.
· The device may only be used in closed rooms.
· Do not set up the device in front of or near heaters or radiators.
· For optimum performance, observe the minimum distances to
walls and objects outlined in the section on initial use.
· Do not remove any labels, safety instructions, or stickers from
the air purifier and ensure they are legible.
· Appropriately dispose of used filters.
· The air purifier is an appliance intended for the purification of
air. We recommend using normal ventilation cycles.
Warranty
The functionality of the appliances is tested before delivery. If
any defects occur on the appliance, contact your trusted retailer.
A warranty claim requires the filled out proof of purchase and
submission within 12 months after the purchase date. A dirty fil-
ter is not a reason to file a warranty claim. Please note the
General Terms & Conditions (https://www.multibeton.com).
We reserve the right to make technical modifications to the
Airbreze air purifier’s design and technology.
Disclaimer (German Civil Code [BGB] BGB § 444)
The retailer may not invoke an agreement, which excludes or
limits the customer’s rights, if the retailer has fraudulently con-
cealed damage or assumed guarantee for the properties of the
product.
2. Application examples
Airbreze is an air purifier that exclusively serves the purpose of
purifying atmospheric air. Do not use it as a dehumidifier. The
device should only be used in dry rooms. Always observe all ope-
rating instructions and ensure proper use under consideration of
the safety instructions and technical data.
The air purifier is ideally suitable for use in:
· Schools and seminar rooms
· Supermarkets and hardware stores
· Speciality retail stores
· Retail stores
· Gyms
· Reception areas and waiting rooms
· Trade show booths
· Restaurants and cafeterias
· Production facilities
· Retirement homes
· Conference rooms
· Offices & apartments
MULTIBETON GmbH, Heuserweg 23, 53842 Troisdorf-Spich, Phone +49224125200-0, Fax +49224125200-99
08/2021
Updates and additions reserved without notice.
Airbreze - Air Purifier
Operation manual
01
06
3. Operating modes and Appliance Description
The larger the number of people in a room, the faster the increa-
se in the concentration of harmful aerosols. Air can absorb humi-
dity in addition to small particles and dust and transport viruses,
bacteria and germs in this manner. The warmer the air, the more
humidity it can absorb. Airbreze was developed to remove these
suspended particles from the air. In closed rooms, the viral load
is particularly high on the floor, since heavy and moist particles
quickly sink with the room air. Airbreze suctions air close to the
ground and emits it at the top after it is purified. This achieves
continuous purification and clean room and respiratory air is
ensured in closed rooms. The process is facilitated by the ther-
mal conditions in the room. Purification is achieved by multiple
filters. A G4 filter serves as the pre-filter. It filters particles with
a size of up to 10μm. The primary filter used is a HEPA H-14 high-
performance filter. It achieves filtration of particles with a size
of 0.1 to 0.3 μm to 99.995%. This ensures that even the smallest
pollutants are removed from the room air. The Bulpren post-fil-
ter ensures the optimum distribution of the air inside the room.
The air is transported toward the ceiling of the room to ensure
optimum airflow. This compact all-in-one device changes indoor
air in closed rooms up to 6 times per hour in its entirety.
This significantly reduces the concentration of viruses and
bacteria in enclosed rooms, such as offices, at the workplace, in
schools or restaurants.
Front
Rear
Rear with open inspection door
MULTIBETON GmbH, Heuserweg 23, 53842 Troisdorf-Spich, Phone +49224125200-0, Fax +49224125200-99
08/2021
Updates and additions reserved without notice.
Airbreze - Air Purifier
Operation manual
02
06
1. Control
panel
4. Air inlet
2. Top inspection
door wirth air outlet
8. Cylinder lock
6. Mains connection,
Main switch,
Fuse
9. Bulpren filter
10. HEPA filter
11. G4 filter
7. Bottom
inspection door
3. Handle
5. Casters
MULTIBETON GmbH, Heuserweg 23, 53842 Troisdorf-Spich, Phone +49224125200-0, Fax +49224125200-99
08/2021
Updates and additions reserved without notice.
4. Initial use
· Remove the packaging.
· Place the air purifier on a stable and level surface.
· Position the appliance so that it is stable and lock the casters.
· Before initial use, check the air purifier for visible damage.
· Never operate the appliance when it is damaged.
· Contact your retailer in case of damage.
· Position the appliance with a minimum distance of 1 m to walls
and objects and keep air inlets and outlets uncovered.
· Ensure that cables that are lying around do not become a
hazard to you or other people.
· If you have ordered your HEPA filter separately, read the sec-
tion on “changing the filter” to learn how correctly to install
the filter in the Airbreze.
· If you ordered the Airbreze including the HEPA filter, the filter
is pre-installed. Remove the protective hygiene cover before
initial use.
· Never use the air purifier without the filter, because this may
lead to a contamination of and damages to the interior techno-
logy.
· Before switching the appliance on, please ensure that all filters
are installed.
· Connect the air purifier to a shockproof socket on the mains
supply using the included mains cable.
· Avoid operating the appliance using a multi-plug connection.
· Use the ON switch after inserting the mains plug into a shock-
proof outlet to start up the product.
· Select your desired ventilation setting (an exact description
can be found in the “control panel” section).
· Please note that the fan has a brief lead time of 2-5 seconds,
before it achieves the output performance of the corresponding
setting. For optimum performance, we recommend setting up
the product at the centre of the room. If this is not possible,
the air purifier can also be placed somewhere else in the room.
In this case, observe a minimum distance of one meter on each
side.
5. Control panel
The Airbreze air purifier is operated using buttons (arrow but-
tons) on an electronic control panel. A LED display (green) indi-
cates which of the five settings the appliance is currently set to.
After pushing the Power Button [A] once, the air purifier runs for
10 minutes at the highest setting and afterwards returns to the
previous setting. After repeatedly pushing the button within
these 10 minutes, the air purifier immediately returns to the pre-
vious setting. If the Power Button is pushed before the fan runs,
the air purifier will run for 10 minutes at the highest setting and
shut off afterwards.
The Power Button makes it possible for the air purifier to purify
the air quickly, for example, between two classes or before the
start of school at max. capacity. The filter change indicator indi-
cates when it is time to change the filter. If the indicator is not
illuminated, no filter replacement is required. However, if the
display lights up in orange, the filter must be replaced. You can
find a description in “Section 6” on Filter Replacement. The error
indicator helps to warn you, if errors occur in the appliance. In
this case, the LED display lights up red. In this case, read
“Section 10” on Trouble-shooting. If this still does not remedy
your problem, please contact your retailer.
Power setting LED display Fan output Power
120 % 12 W
240 % 24 W
360 % 86 W
480 % 111 W
5100 % 167 W
Airbreze - Air Purifier
Operation manual
03
06
Power Button (10 minutes of maximum
or normal power) Green LED display for
fan settings (5 settings)
Buttons for adjusting
the fan output
Orange LED filter
replacement
Red LED for electrical error indicator
MULTIBETON GmbH, Heuserweg 23, 53842 Troisdorf-Spich, Phone +49224125200-0, Fax +49224125200-99
08/2021
Updates and additions reserved without notice.
6. Maintenance/Filter replacement
Only use accessories and spare parts indicated in the operating
instructions. The use of other accessories or spare parts can limit
optimum operation or cause damages to the appliance. MULTIBE-
TON GmbH does not assume liability for damages caused by the
use of third-party filters or spare parts. Please observe the
necessary, regular filter replacement indicated by the filter
change indicator for optimum and hygienic operation. Imminent
filter replacement is signaled when the orange LED lights up.
MULTIBETON GmbH recommends replacing the HEPA filter after
6 months of use
Replacing the HEPA filter and G4 filter
1. Switch the appliance off and disconnect it from the power
supply!
2. Open the filter inspection door (7) using the included key.
3. Remove the PE conductor and remove the used filter (10, 11).
It is a bit difficult to remove because of the seal. (Note: If
necessary, wear protective clothing and gloves included with
the replacement filter. The airtight cover of the HEPA filter on
the bracket can be difficult to remove.)
4. Insert the new filter and attach the PE conductor on the door.
(Pay attention toe the arrow direction for the airflow).
5. Lock the inspection door (7) with the key.
6. Connect the appliance to the mains supply and switch it on.
7. Check the filter indicator light at the highest setting.
Replacing the Bulpren filter
1. Switch the appliance off and disconnect it from the
power supply!
2. Open the top inspection door (2) with the included key.
3. Remove the filter and holder from the door.
4. The filter can be rinsed in cold, clean water (do not operate
the appliance with a wet filter installed, recommended drying
time: 12 hours; If there is any dirt on the fit that cannot be
rinsed off, it must be replaced.)
5. Do not clean the filter in the dishwasher.
6. Insert the filter into the holder.
7. Attach the PE conductor to the door.
8. Lock the bottom inspection door (2) with the key.
9. Connect the appliance to the mains supply and switch it on.
7. Transport
The appliance was equipped with transport handles for easy
transport (3) and can be moved using the 4 pre-installed casters
(5). Important note: Wear protective shoes! Disconnect the Air-
breze air purifier from the power supply before transporting it.
· Only lift the appliance at the intended parts.
· Gently set it back down. Avoid impacts.
·To push/roll the device, please loosen the locking casters,
since it may be a risk of the appliance tipping over.
· Only roll the appliance on level, firm surfaces.
· Only transport the air purifier slowly and never take your hands
off the appliance while rolling it.
Airbreze - Air Purifier
Operation manual
04
06
7. Inspection
door
10. HEPA filter
11. G4 filter
2. Top inspection
door wirh air outlet
5. Casters
3. Handle
MULTIBETON GmbH, Heuserweg 23, 53842 Troisdorf-Spich, Phone +49224125200-0, Fax +49224125200-99
08/2021
Updates and additions reserved without notice.
8. Maintenance/Cleaning
Airbreze is designed for long-term use and low maintenance. Pull
the plug from the outlet if you want to clean the appliance! Only
use a damp cloth to clean the appliance. Never expose the appli-
ance to direct moisture. Liquids should never penetrate the
appliance’s interior. The exterior of the Airbreze air purifier may
only be cleaned using a soft, clean cloth and a non-aggressive
cleaner. Flammable liquids or gases may not enter the appliance.
9. Disposal
The appliance can be dropped off to any retailer for disposal free
of charge. You can obtain more information about free collection
points from your local authorities and municipality. Please do
not dispose of the appliance with your household waste. The
separate collection of electronic devices and old electronic
appliances can preserve recourses or allow for reuse. Correct dis-
posal makes it possible to prevent negative impacts on the envi-
ronment and humans.
10. Troubleshooting
Problem
· Inadequate airflow
· High noise development
· Device does not function
· The orange LED filter
indicator lights up
· Red LED indicating electrical
errors lights up
· No LED lighting
Possible cause
· Air inlets or outlets
(partially) covered
· Recommended room size
exceeded
· Incorrectly installed filter
· Foreign object inside the
appliance or defective fan
· Faulty connector to the power
supply
· Lid or side door are not fully
closed
· Electrical equipment damage
· Foreign object inside the
· Contaminated HEPA filter
· Clogged air inlet
· Protective film was not remo-
ved from the HEPA filter
· Electrical equipment problem
· Mains plug is inserted
incorrectly
· Defective appliance
· No setting selected
Troubleshooting recommendation
· Check air inlets on the side
· Ensure a distance of approx. 1 m for at least two of the inlet
sides
· Keep the air outlet (at the top) clear
· Use the air purifier in accordance with the technical data
(regarding room size)
· Check pre-filter, main filter, and post-filter for correct
installation - correct if necessary
· Contact retailer
· Ensure that the mains cable is connected to the appliance and
outlet without any pressure or tension
· Tightly close the lid or side flap
· Contact retailer
· Remove foreign object or contact retailer
· Check filter and replace it, if necessary
· Check air inlets for impurities/foreign objects
· Remove protective film
· Contact retailer
· Check mains plug
· Contact retailer
· Select one of the 5 settings
Airbreze - Air Purifier
Operation manual
05
06
Technical Data
Pre-filter: G4
HEPA main filter: H-14
Post-filter: Bulpren
Mass: 25 kg
Circulation: 240 - 1,200 m3/h
Dimensions: 1,110 x 400 x 400 mm
Electrical connector: 230 V @ 50 Hz
Connected load: max. 200 W
Sound pressure level: **28 - 68 dB(A)
Effective virus reduction
Circulation 6 times/h: *50 - 80 m2
Effective air purification
Circulation 2 times/h: *120 - 180 m2
Certificates
The Airbreze is CE certified. The main HEPA filter is certified
according to EN1822-1: 2019.
* for a room height of 2.5 m
** distance of 1 m, depending on purifier setting
MULTIBETON GmbH, Heuserweg 23, 53842 Troisdorf-Spich, Phone +49224125200-0, Fax +49224125200-99
08/2021
Updates and additions reserved without notice.
Airbreze - Air Purifier
Operation manual
06
06
All dimensions in mm
Table of contents
