OPERATION MANUAL
Revision #1 (05/08/06)
SERIES
MODEL HHN-34TVDTCSL4MODEL HHN-34TVDTCSL4
MODEL HHN-34TVDTCSL4MODEL HHN-34TVDTCSL4
MODEL HHN-34TVDTCSL4
MODEL HHN-34TVDTCSL5MODEL HHN-34TVDTCSL5
MODEL HHN-34TVDTCSL5MODEL HHN-34TVDTCSL5
MODEL HHN-34TVDTCSL5
RIDE ON TROWEL
(VANGUARD DIESEL ENGINE)
P/N 21729
THIS MANUAL MUST ACCOMPANYTHE EQUIPMENT AT ALLTIMES.
To order go to Discount-Equipment.com

We sell worldwide for the brands: Genie, Terex, JLG, MultiQuip, Mikasa, Essick, Whiteman,
Mayco, Toro Stone, Diamond Products, Generac Magnum, Airman, Haulotte, Barreto, Power
Blanket, Nifty Lift, Atlas Copco, Chicago Pneumatic, Allmand, Miller Curber, Skyjack, Lull,
Skytrak, Tsurumi, Husquvarna Target, Stow, Wacker, Sakai, Mi-T-M, Sullair, Basic, Dynapac,
MBW, Weber, Bartell, Bennar Newman, Haulotte, Ditch Runner, Menegotti, Morrison, Contec,
Buddy, Crown, Edco, Wyco, Bomag, Laymor, EZ Trench, Bil-Jax, F.S. Curtis, Gehl Pavers, Heli,
Honda, ICS/PowerGrit, IHI, Partner, Imer, Clipper, MMD, Koshin, Rice, CH&E, General Equip-
ment ,Amida, Coleman, NAC, Gradall, Square Shooter, Kent, Stanley, Tamco, Toku, Hatz,
Kohler, Robin, Wisconsin, Northrock, Oztec, Toker TK, Rol-Air, APT, Wylie, Ingersoll Rand /
Doosan, Innovatech, Con X, Ammann, Mecalac, Makinex, Smith Surface Prep,Small Line,
Wanco, Yanmar
Discount-Equipment.com is your online resource for
commercial and industrial quality parts and equipment sales.
561-964-4949
visit us on line @ www.discount-equipment.com
TO PURCHASE THIS PRODUCT PLEASE CONTACT US
Select an option below to find your Equipment
Equipment Financing and
Extended Warranties Available

To order go to Discount-Equipment.com

Grinding/cutting/drillingofmasonry,concrete,metaland
other materials with silica in their composition may give
off dust or mists containing crystalline silica. Silica is a
basic component of sand, quartz, brick clay, granite and
numerous other minerals and rocks. Repeated and/or
substantial inhalation of airborne crystalline silica can
cause serious or fatal respiratory diseases, including
silicosis. In addition, California and some other
authorities have listed respirable crystalline silica as a
substance known to cause cancer. When cutting such
materials, always follow the respiratory precautions
mentionedabove.
WARNING
Grinding/cutting/drillingofmasonry,concrete,metaland
other materials can generate dust, mists and fumes
containing chemicals known to cause serious or fatal
injury or illness, such as respiratory disease, cancer,
birth defects or other reproductive harm. If you are
unfamiliar with the risks associated with the particular
process and/or material being cut or the composition of
the tool being used, review the material safety data
sheet and/or consult your employer, the material
manufacturer/supplier, governmental agencies such as
OSHA and NIOSH and other sources on hazardous
materials. California and some other authorities, for
instance, have published lists of substances known to
cause cancer, reproductive toxicity, or other harmful
effects.
Control dust, mist and fumes at the source where
possible. In this regard use good work practices and
follow the recommendations of the manufacturers or
suppliers, OSHA/NIOSH, and occupational and trade
associations. Water should be used for dust
suppression when wet cutting is feasible. When the
hazardsfrominhalation of dust, mists andfumescannot
be eliminated, the operator and any bystanders should
always wear a respirator approved by NIOSH/MSHAfor
thematerialsbeingused.
WARNING
SILICOSISWARNING RESPIRATORY HAZARDS
To order go to Discount-Equipment.com

PAGE 6 — HHN 31V
HHN-34TVD • RIDE-ON POWER TROWEL — OPERATION MANUAL — REV. #1 (05/08/06) — PAGE 6
HHN-34TVD —TABLE OF CONTENTS
Here's How to Get Help ............................................ 5
Table of Contents ...................................................... 6
Parts Ordering Procedures ....................................... 7
Training Checklist ...................................................... 8
Daily Pre-Operation Checklist................................... 9
Safety Message Alert Symbols..........................10-11
Rules For Safe Operation ..................................12-15
MQ WHITEMAN — HHN-34TVD
RIDE-ON POWER TROWEL
Operation And Safety Decals.................................. 16
Specifications (Trowel) ............................................ 17
Specifications (Engine) ........................................... 18
General Information................................................ 19
Controls and Indicators......................................20-21
New Machine Setup Instructions ............................ 22
Basic Engine-Diesel ................................................ 23
Initial Start-Up ......................................................... 24
Operation ...........................................................25-26
Maintenance ......................................................27-41
Troubleshooting .................................................42-43
Terms And Conditions of Sale-Parts ....................... 45
NOTE
Specifications and
part numbers are
subject to change
without notice.
To order go to Discount-Equipment.com

PAGE 8 — HHN 31V
HHN-34TVD • RIDE-ON POWER TROWEL — OPERATION MANUAL — REV. #1 (05/08/06) — PAGE 8
Operator _________________________________________ Trainee __________________________________________
COMMENTS:
HHN-34TVD —TRAINING CHECKLIST
TRAINING CHECKLIST
Thischecklistlistssome ofthe minimumrequirementsfor machineoperation. Pleasefeelfree tomake copiesfordaily use.Use this
checklistwhentraininganewoperatororuse as a review for more experienced operators.
TSILKCEHCGNINIART
.ON NOITPIRCSED ?KO ETAD
1 .yletelpmoclaunaMs’rotarepOdaeR
2dnaenignefognikcehc,stnenopmocfonoitacol,tuoyalenihcaM .sleveldiulf
3 .erudecorpgnileufer,metsysleuF
4 .sthgildnayarpsfonoitarepO
5 .)gninnurtonenihcam(slortnocfonoitarepO
6 .noitarepohctiwSpotSytefaS,slortnocytefaS
7 .serudecorppotsycnegremE
8 .enihcamfoputratS
9 .revohagniniatniaM
01 .gnirevuenaM
11 .gnihctiP
21 ehtgnigagnesid,™hctiPniwTsrewotneewtebhctipedalbgnihctaM .egaknil
31 .seuqinhcetgnihsinifetercnoC
41 .enihcamfonwodtuhS
51 .)spooltfil(enihcamfognitfiL
61 .egarotsdnatropsnartenihcaM
To order go to Discount-Equipment.com

HHN-34TVD • RIDE-ON POWER TROWEL — OPERATION MANUAL — REV. #1 (05/08/06) — PAGE 9
DAILY PRE-OPERATION CHECKLIST
COMMENTS:
DAILY PRE-OPERATION CHECKLIST
TSILKCEHCNOITAREPO-ERPYLIAD
1
.leveLliOenignE
2
diulFxobraeGleveL .
3 .leveLtnalooCrotaidaR
4 sedalBfonoitidnoC .
5 .noitarepOhctiPedalB
6 .noitarepOhctiwSpotS-ytefaS
7 .noitarepOlortnoCgnireetS
8 .stleBfonoitidnoC
To order go to Discount-Equipment.com

PAGE 10 — HHN 31V
HHN-34TVD • RIDE-ON POWER TROWEL — OPERATION MANUAL — REV. #1 (05/08/06) — PAGE 10
HAZARD SYMBOLS
Engine exhaust gases contain harmful toxins
and will displace oxygen when running in an
enclosed or confined space. NEVER operate
this equipment in a confined area or enclosed
structure that does not provide ample free
flow air.
Engine fuel is flammable, and its vapors can
cause an explosion if ignited. DO NOT start
the engine near spilled fuel or combustible
fluids. DO NOT fill the fuel tank while the
engine is running or hot. DO NOT overfill
tank, since spilled fuel could ignite if it comes
into contact with hot engine parts or sparks
from the ignition system. Store fuel in
approved containers, in well-ventilated areas
and away from sparks and flames. NEVER
use fuel as a cleaning agent.
Explosive Fuel
Lethal Exhaust Gases
Burn Hazards
Enginecomponentscangenerateextreme heat.
To prevent burns, DO NOT touch these areas
while the engine is running or immediately after
operations. NEVER operate the engine with
heat shields or heat guards removed.
Rotating Parts
NEVER operate equipment with covers or
guards removed. Keep
fingers , hands , hair
and clothing away from all moving parts to
prevent injury.
Safety precautions should be followed at all times when
operating this equipment. Failure to read, understand and
comply with the Safety Messages and Operating Instructions
could result in injury to yourself and others.
FORYOUR SAFETY ANDTHE SAFETY OF OTHERS!
This Operation Manual has been
developedto provide instructions for the
safeand efficient operation of the HHN -
34TVD Ride-OnTrowel. For engine
maintenanceinformation, please refer to the
enginemanufacturer's instructions fordata
relativeto its safe operation.
Before using this Ride-OnTrowel, ensure that the operating
individual has read, understands, and complies with all
instructions in this manual.
SAFETY MESSAGE ALERT SYMBOLS
The three (3) Safety Messages shown below will inform you
about potential hazards that could injure you or others. The
Safety Messages specifically address the level of exposure to
theoperator,andarepreceded byoneof three words: DANGER,
WARNING, or CAUTION.
You WILL be
KILLED or SERIOUSLY INJURED
if you DO NOT follow these directions.
You CAN be KILLED or
SERIOUSLY INJURED if
you DO NOT follow these directions.
You CAN be
INJURED if you DO NOT follow
these directions.
CAUTICAUTI
CAUTICAUTI
CAUTION
DANGERDANGER
DANGERDANGER
DANGER
WARNINGWARNING
WARNINGWARNING
WARNING
Potential hazards associated with trowel operation will be
referenced with Hazard Symbols which appear throughout this
manual, and will be referenced in conjunction with Safety
Message Alert Symbols.
HHN-34TVD — SAFETY MESSAGE ALERT SYMBOLS
NEVER useyour hand to find hydraulic leaks.
Use a piece of wood or cardboard. Hydraulic
fluid injected into the skin must be treated by
a knowledgable physician immediately or
severe injury or death can occur.
Skin Injection Hazard
To order go to Discount-Equipment.com

HHN-34TVD • RIDE-ON POWER TROWEL — OPERATION MANUAL — REV. #1 (05/08/06) — PAGE 11
Accidental Starting Respiratory Hazard
ALWAYS wear approved respiratory protection.
ALWAYS wear approved eye and
hearing protection.
Sight and Hearing hazard
Equipment Damage Messages
Other important messages are provided throughout this manual
to help prevent damage to your trowel, other property, or the
surrounding environment.
HHN-34TVD — SAFETY MESSAGE ALERT SYMBOLS
Over Speed Conditions
NEVER tamperwith thefactory settings of the
engine governor or settings. Personal injury
and damage to the engine or equipment can
result if operating in speed ranges above
maximum allowable.
ALWAYS place the ON/OFF switch in the
OFF position. Disconnect and ground spark
plug lead and disconnect negative battery
cable from battery before servicing.
Accidental starts can
cause severe injury or
death.
This Ride-On Trowel, other property, or the
surrounding environment could be damaged
if you do not follow instructions.
CAUTICAUTI
CAUTICAUTI
CAUTION
To order go to Discount-Equipment.com

PAGE 12 — HHN 31V
HHN-34TVD • RIDE-ON POWER TROWEL — OPERATION MANUAL — REV. #1 (05/08/06) — PAGE 12
HHN-34TVD — RULES FOR SAFE OPERATION
The following safety guidelines should always be used when
operatingthe HHN-34TVD Ride-OnTrowel.
SAFETY
■ DONOT operateorservicethisequipment
beforeyouread,understand,andcomply
with all safety messages in this manual.
The manual must be kept available and
accessibletotheoperator.
■ Thisequipmentshouldnot beoperated bypersonsunder the
minimumstatutory agelimit.
■ ALWAYS use extremecautionwhenworkingwith flammable
liquids. When refueling, STOP the engine. Allow the engine
to cool before adding fuel or performing service and
maintenancefunctions.
■ NEVERtouchthehotexhaustmanifold,muffler
or cylinder. Allow these parts to cool before
servicing the trowel. Contact with
hot!
componentscan cause serious burns.
■ The engine of this trowel requires an adequate free flow of
cooling air. NEVER operate the trowel in any enclosed or
narrowarea where free flow of
theairisrestricted.Iftheairflow
isrestricteditwill causeserious
damagetothe engineandmay
cause injury to people.
Remembertheenginecangive
off harmful toxins and will
displaceoxygen.
■ ALWAYS refuel in a well-ventilated area, away from sparks
andopen flames.
RULES FOR SAFE OPERATION
■ ALWAYS check the trowel for loosened hardware such as
nutsand bolts before starting.
■ Replace nameplate, operation and safety decals when they
becomedifficult toread.
■ NEVER use accessories or attachments which are not
recommended by Multiquip for this equipment. Damage to
theequipment and/or injury to user may result.
■ Manufacturerdoesnotassumeresponsibilityfor anyaccident
due to equipment modifications. Unauthorized equipment
modification will void all warranties. Any modification which
could lead to a change in the original characteristics of the
machineshould bemadeonly bythemanufacturer whoshall
confirm that the machine is in conformity with appropriate
safetyregulations.
WARNINGWARNING
WARNINGWARNING
WARNING
Failuretofollowinstructionsinthismanualmayleadtoserious
injury or even death! This equipment is to be operated by
trained and qualified personnel only! This equipment is for
industrial use only.
■ NEVER smoke aroundornearthemachine.
Fire or explosion could result from
fuel
vapors
,or if fuel is spilledon a hot! engine.
■ Topping-off to filler port is dangerous,as it tends to spill fuel.
■ NEVER usefuelasacleaningagent.
■ NEVER operate this equipment when not feeling well due to
fatigue, illnessor takingmedicine.
■ NEVER operate the trowel under the influence or drugs or
alcohol.
■ NEVERoperatethetrowel without proper protective clothing,
shatterproof glasses, steel-toed boots and other protective
devicesrequiredforthejob.
■ NEVER use this machine for any purpose other than those
describedinthismanual.
■ NEVER operate the trowel in an
explosive atmosphere where fumes
are present, or near combustible
materials. An explosion or fire could
result in severe
bodily harm or even
death.
To order go to Discount-Equipment.com

HHN-34TVD • RIDE-ON POWER TROWEL — OPERATION MANUAL — REV. #1 (05/08/06) — PAGE 13
■ NEVER run engine without air filter. Severe engine damage
may occur. Service air filter frequently to prevent carburetor
malfunction.
■ NEVER place your feet or hands inside the guard rings
whilestarting or operating this equipment.
■ AVOID wearingjewelryorloosefitting clothingthatmaysnag
on the controls or moving parts as this can cause a serious
injury.
■ ALWAYS keep clear of rotating or moving parts while
operatingthe trowel.
■ Moving Parts – Shut down the engine before performing
serviceormaintenance functions.Contact withmoving parts
cancause seriousinjury.
■ ALWAYS checktomakesurethattheoperatingareaisclear
beforestarting the engine.
■ NEVER leave the machine unattended while running.
■ ALWAYS be sure the operator is familiar with proper safety
precautions and operations techniques before using trowel.
■ ALWAYS keep the work area well organized.
■ ALWAYS clear the work area of any debris, tools, etc. that
would constitute a hazard while the trowel is in operation.
■ ALWAYS store equipment properly when it is not being used.
Equipment should be stored in a clean, dry location out of the
reach of children.
■ No one other than the operator is to be in the working area
whenthe trowel is in operation.
■ NEVER allow passengers or riders on the trowel during
operation.
■ Always observe all applicable compulsory regulations
relevantto environmentalprotection,especially,fuelstorage,
the handling of hazardous substances, and the wearing of
protective clothing and equipment. Instruct the user as
necessary, or, as the user, request this information and
training.
ALWAYS check to make sure that the operating area is
clearbeforestartingthe engine.
WARNINGWARNING
WARNINGWARNING
WARNING
HHN-34TVD — RULES FOR SAFE OPERATION
NEVERstandunderorallowanyone
elsetostandunderthetrowelwhileit
isbeing lifted.
Pay close attention to ventilation when
operating the trowel in confined spaces
suchastunnels,buildings orsimilarareas.
The engine exhaust contains harmful
elements. Ensureproperairflowtomove
engineexhaustaway from the operator.
Lifting the Ride-OnTrowel
This ride-on trowel is very
heavy and awkward to move
around. Use proper heavy lifting procedures and DO NOT
attemptto lift the ride-on trowel by the guard rings.
The HHN-34TVD Ride-On Power Trowel is designed to be
movedand handled several ways.
Theeasiest waytolift the trowelisto utilize thelift loops thatare
welded to the frame.These lift loops are located to the left and
right sides oftheoperator’sseat.
A strap or chain can be attached to these lift loops, allowing a
forkliftorcranetoliftthetrowelupontoandoffofaslabofconcrete.
Thestrapor chainshould havea minimum2,000 pounds(1000-
kg)liftingcapacityandtheliftinggearmustbecapableoflifting
atleast this amount.
DANGERDANGER
DANGERDANGER
DANGER
CAUTIONCAUTION
CAUTIONCAUTION
CAUTION
DANGERDANGER
DANGERDANGER
DANGER
To order go to Discount-Equipment.com

PAGE 14 — HHN 31V
HHN-34TVD • RIDE-ON POWER TROWEL — OPERATION MANUAL — REV. #1 (05/08/06) — PAGE 14
Battery
■ In case the battery electrolyte liquid, (dilute sulfuric acid),
comesincontact with
clothingor skin ,rinseskin orclothing
immediatelywith plenty of water.
■ In case the battery electrolyte liquid, (dilute sulfuric acid),
comes in contact with your
eyes , rinse eyes immediately
withplentyofwater,thencontactthenearestdoctororhospital
andseek medical attention.
Thebatterycontainsacidthat can cause injury to the eyes and
skin. Toavoideye irritation,
always wear safetyglassesor face
shielding. Usewell insulated gloves whenhandlingthe battery.
Use the following guidelines when handling the battery.
■ Use chock-blocks underneath each wheel when parked to
preventtrailer from rolling.
■ Use the trailer's swivel jack to adjust the trailer height to a
level position while parked.
■ Avoidsuddenstopsandstarts. Thiscancausethe trailer to
skid or jack-knife. Smooth, gradual starts and stops will
improvetowing.
■ Avoidsharp turns.
■ Trailer should be adjusted to a level position at all times
whentowing.
■ Raiseand lock trailer wheelstandin the "UP"positionwhen
transporting.
■ DOTrequirementsinclude the following:
Connectand test electric brake operation.
Secureportablepowercablesincable tray with tie wraps.
■ DO NOT drop the battery. Any impact to
thebattery may cause it toexplode.
■ DONOTexposethebatterytoopenflames,
sparks, lit cigarettes etc. The battery
containscombustible gasesandliquids. If
these gases and liquids come in contact
withaflameorsparkanexplosioncanoccur.
■ ALWAYS keepthebattery charged. If the
batteryisnotchargedabuildupofcombustiblegaswilloccur.
■ ALWAYS keep battery cables in good working condition.
Repair or replace all worn cables.
■ ALWAYS disconnect the negative battery terminal before
performingservice on the trowel.
■ ALWAYS recharge the battery in a vented air environment
to avoid risk of a dangerous concentration of combustible
gases.
HHN-34TVD — RULES FOR SAFE OPERATION
Towing Safety Precautions
Conform to
Department ofTransportation (DOT) Safety
Towing Regulations
before transporting trowel on public
roads.
To reduce the possibility of an accident while transporting the
trowelonpublicroads,alwaysmakesurethetrailerthatsupports
thetroweland thetowingvehicleareingoodoperating condition
andbothunitsaremechanicallysound.
Transporting
■ ALWAYS shutdown engine before transporting.
■ Tightenfueltankcapsecurelyand closefuel cockto prevent
fuelfrom spilling.
■ Drainfuelwhentransportingtrowelfor longdistancesorover
badroads.
■ Whenplacingthe trowelona truck-bedfortransport, always
tie-downthe trowel.
■ Ifthetrowelis being transportedvia a trailer, makesure the
trailercomplies with all local and state safety transportation
laws. Refer to the following "
Towing Safety Precautions"
forbasic towingtechniques.
The following list of suggestions should be used when towing
yourtrowel:
■ Make sure the hitch and coupling of the towing vehicle are
ratedequalto,orgreaterthanthetrailer"grossvehicleweight
rating"(GVWR) of 6,000 lbs.
■ ALWAYS inspect the hitch and coupling for wear. NEVER
towa trailer with defective hitches,couplings,chains,etc.
■ Checkthetireairpressureonboth towingvehicleand trailer.
Trailer tires should be inflated to 50 psi cold . Alsocheck
thetire tread wear on both vehicles.
■ ALWAYS make sure the trailer is equipped with "Safety
Chains ".
■ ALWAYS attach trailer's safety chains to towing vehicle
properly.
■ ALWAYS make sure the vehicle and trailer directional,
backup,brake, andtrailerlights areconnectedand working.
■ DO NOT exceed the recommended highway speed when
towing.
CAUTIONCAUTION
CAUTIONCAUTION
CAUTION
To order go to Discount-Equipment.com

HHN-34TVD • RIDE-ON POWER TROWEL — OPERATION MANUAL — REV. #1 (05/08/06) — PAGE 15
Emergencies
■ ALWAYS know the location of the
nearest
first aid kit .
■ Know the phone numbers of the nearest
ambulance , doctor and fire department .Ensure
that a phone or radio is readily available at the
jobsite. If this is not possible, know the location of
the nearest phone. This information will be
invaluable in the event of an emergency.
HHN-34TVD — RULES FOR SAFE OPERATION
■ DON'TPOLLUTE! Wasteoilsand otherchemicals mustbe
disposed of in a manner consistent with local and state
environmentalprotectionregulations. Examplesofpotentially
hazardouswaste are used motor oil, fuel and fuel filters.
■ DONOT use plasticfoodcontainerstodisposeofhazardous
waste.
■ DO NOT pour waste, oil or fuel directly onto the ground,
downa drain or into any water source.
Maintenance Safety
■ ALWAYS knowthe location of
thenearest
fireextinguisher .
■ Orientationof the Battery
Thepositivecable,normallyred,isassociatedwiththe"+"symbol
onthebattery. Thenegativecable,normallyblack,isassociated
withthe"-"symbolonthebattery. Thepositivecableisconnected
tothepositiveterminal on the battery and the negative cable is
connectedto the negativeterminal.
■ Replace batteries that have cracked or broken cases or
batteriesthat are otherwise leaking electrolyte.
■ Always replace with battery of equivalent type and rating.
Neverreplace with a non-rechargeablebattery.
■ Alwaysdisposeofbatteryproperly.Bringtoappropriatefacility
for lead reclamation.Thesefacilitiescangenerallybefound
inthelocalphonelistingsunder"RecyclingServices".
■ Agood practiceis toisolatethe machinewhen removing the
battery.
■ ALWAYS shutdowntheengineanddisconnectbatterybefore
performing service or maintenance functions. Contact with
movingpartscan cause seriousinjury.
■ Securelysupportanytrowelcomponentsthatmustberaised.
■ NEVERlubricatecomponentsorattemptserviceonarunning
trowel.
■ ALWAYS allow the trowel a proper amount of time to cool
beforeservicing.
■ Keepthetrowel in proper running condition.
■ Makesure thatthereis no buildupofconcrete, grease, oilor
debrison the machine.
■ Fix damage to the trowel immediately and always replace
brokenparts.
2
1
1. Negative Cable (BLACK)
2. Positive Cable (RED)
To order go to Discount-Equipment.com

PAGE 16 — HHN 31V
HHN-34TVD • RIDE-ON POWER TROWEL — OPERATION MANUAL — REV. #1 (05/08/06) — PAGE 16
HHN-34TVD— OPERATION AND SAFETY DECALS
Machine Safety Decals
TheHHN-34TVDRide-OnPowerTrowelisequippedwitha number of operationand safetydecals.Thesedecals are providedfor
operator safetyand maintenanceinformation. Should anyof these decals becomeunreadable,replacements canbe obtained from
your dealer.
Figure 1. HHN-34TVD Decals & Safety Labels
P/N 20926
P/N 11811
SERIES
WHITEMAN
P/N 2634
DO NOT DISASSEMBLE
SPRING INSIDE IS
UNDER COMPRESSION
2634
DANGER
P/N 10818 WHITE TEXT 24” x 3”
P/N 1499 RED TEXT
P/N: 11246
P/N: 13118
P/N: 21455
P/N 35137
To avoid injury,
you MUST read
and understand
operator’s manual
before using this
machine.
Ask for training
as needed.
This machine to
be operated by
qualified
personnel only.
P/N 35137
WARNING
MODEL
SERIAL NO.
P/N 36099 (ISO Blue)
P/N 21517 (WHITE TEXT)
P/N 2814 (WHITE)
OIL WATER CHG
FUEL
FILTER GLOW
PLUGS
Engine exhaust and some of
itsconstituents,andsome dust created
of California to cause cancer, birth
defects and other reproductive harm.
by power sanding, sawing, grinding,
drillingandotherconstructionactivities
contains chemicals known to the State
Someexamplesof these chemicalsare:
Leadfromlead-basedpaints.
Crystallinesilicafrombricks.
Cementandothermasonryproducts.
Arsenicandchromiumfromchemically
treatedlumber.
Your risk from these exposures varies,
dependingonhowoftenyoudothistype
of work.To reduce your exposure to
these chemicals: work in aALWAYS
well ventilated area, and work with
approved safety equipment, such as
dust masks that are specially designed
to filter out microscopic particles.
CONTACT
SERVICE
DEPARTMENT
P/N 20525
P/N 35168
WARNING
ROTATING BLADE
HAZARD
Keep hands
and feet clear
of guard rings.
Stop engine
before servicing.
P/N 35168
P/N 35168
CHECK
GEAR DRIVE
GEAR DRIVE
CHECK
HOT
BELT DRIVE CLOCKWISE
COUNTER
CLOCKWISE
LUBRICATION
LUBRICATION
LIFTING POINTLIFTING POINT
LUBRICATION
LUBRICATION
To order go to Discount-Equipment.com

HHN-34TVD • RIDE-ON POWER TROWEL — OPERATION MANUAL — REV. #1 (05/08/06) — PAGE 17
HHN-34TVD — SPECIFICATIONS
NOTE:
1. This value does not include seat height.To obtain total
height(seat ) add 4 inches (10.2 cm.).
2. Soundpressureis"A"weighted.Measuredattheoperators
ear position while the ride-on trowel is operating at full
throttleonconcretein amannermost oftenexperienced in
“
normal ” circumstances. Sound pressure may vary
depending upon the condition of the concrete. Hearing
protectionis always recommended.
3. The vibration level indicated is the maximum RMS (Root
Mean Square) value obtained at the handle grip while
operating the ride-on trowel on curing concrete in a
manner most often experienced in “
normal ”
circumstances. Values were obtained from all three axes
ofmotion.The valuesshownrepresentthemaximumRMS
valuefrom thesemeasurements.
Figure 2. HHN-34TVD Dimension Specifications
snoitacificepSDVT43-NHH.1elbaT s
)mc(.ni–htgneL–A )4.642(0.79
)mc(.ni–htdiW–B )721(0.05
)mc(.ni–thgieH–C
1
)711(0.64
gnitarepO).sgk(.sbl–thgieW )005(290,1
gnippihS).sgk(.sbl–thgieW )875(472,1
ABd–erusserPdnuoS
2
DBT
s/tf–noitarbiV
2
s/m(
2
)
3
DBT
.P.H–enignE 43
)sretil(snollag–knaTleuF )91(5
MPR–rotoR 061ot06
)mc(.ni–htdiWhtaP )132(19
liOnoitacirbuL PE5RG022OSI
yticapaCliOxoBraeG .ZO441
)daoLlluF(noitpmusnoCleuF RH-PHB/BL45.0
yticapaCrotaidaR .LAG0.1
To order go to Discount-Equipment.com

PAGE 18 — HHN 31V
HHN-34TVD • RIDE-ON POWER TROWEL — OPERATION MANUAL — REV. #1 (05/08/06) — PAGE 18
HHN-34TVD— SPECIFICATIONS (ENGINE)
snoitacificepSenignEDVT43-NHH.2elbaT
ledoM LSCTDVT43NHH enignEPH43sggirB
epyT .enigneobrutleseiddraugnaV,nottartS&sggirB TD459MD
srednilyC3
tnemecalpsiDnotsiP)cc259(.ni.uc1.85
ekortSdnaeroB )mm87xmm27(.ni70.3x.ni38.2
tuptuO.xaM)wK53.52(mpr0063/phb43
euqroT.xaMmpr0032ta)gK4.62(tf-fbl3.85
metsySgnilooCdelooc-retawdetekcajylluf
yticapaCliOenignE )sretil3(.tq2.3 )tnemecalperretliflio/wsretil3.3(.tq5.3
metsySgnitacirbuL retlifno-nipshtiwdeeferusserP
knaTleuF)sretil9.81(.lag5
metsySyrevileDleuFdetcejnIleuF
yticapaCdnuopmoCraeGxobraeGlacileH )sretil62.4(.zo441 PE5RGAMGAO22OSI
leuF gnitarenatec04fomuminim-leuFleseiD
metsySgnitratSgulPwolG-retratScirtcelE
thgieWyrD)gK98(.sbl691
)HxWxL(snoisnemiD .ni47.91x.ni28.71x.ni72.71 )mm4.105xmm5.744xmm7.834(
To order go to Discount-Equipment.com

HHN-34TVD • RIDE-ON POWER TROWEL — OPERATION MANUAL — REV. #1 (05/08/06) — PAGE 19
HHN 34TVD — GENERAL INFORMATION
HHN -34TVD Ride-On PowerTrowel Familiarization
The HHN-34TVD Ride-On Power Trowel is designed for the
floatingand finishing of concrete slabs.
Take a walk around your trowel. Take notice of all the major
components (see Figures 3 and 4, pages 20 and 21) like the
engine, blades, air cleaner, fuel system, fuel shut-off valve,
ignitionswitch etc. Ensure engine and gearbox lubricant levels
arewithinproperoperating range.
Readall the safetyinstructions carefully.Safetyinstructionswill
befoundthroughout this manual and on the machine. Keep all
safetyinformationingood,readablecondition.Operatorsshould
bewell trained on the operationandmaintenance of the trowel.
Lookattheoperator controllevers. Graspthecontrolleversand
movethemaroundabit.Observehowmovingthecontrollevers
causethe gearboxes and frame to move.
Noticethefootpedalwhichcontrolstheengine andbladespeed.
Also take a look at the main driveline of the trowel.Take note
andreferencehow thebelts look,this isthe waythe beltsshould
lookwhenadjustedproperly.
Beforeusingyour trowel,test itonaflatwatereddownsectionof
finishedconcrete.Thistrial testrunwillincreaseyourconfidence
in using the trowel and at the same time it will familiarize you
with the trowel’s controls and indicators. In addition you will
understandhowthetrowelwillhandleunder actual conditions.
Engine
ThisTrowelisequippedwithaliquidcooled 34HPdieselengine.
Refer to the engine owner’s manual for specific instructions
regarding engine operation.This manual is included with the
trowel at the time of shipping. Please contact your nearest
MultiquipDealer should a replacement manualbe required.
Blades
The blades of the HHN-34-TVD Ride-On Power Trowel finish
theconcrete astheyare swirled aroundthesurface. Blades are
classified as combination (10 or 8 inches wide) and finish (6
inches wide). The HHN-34TVD Ride-On Power Trowels are
equipped with four or five blades (depending on model), per
rotorequallyspacedinaradialpatternandattachedto avertical
rotatingshaft bymeans of a
spider assembly.
Figures3 and4 showthelocation ofthecontrols, indicatorsand
generalmaintenanceparts.Eachcontrolmayperformmorethan
one function. The functions of each control or indicator is on
pages 20 and 21.
Gearboxes
TheHHN-34TVD Ride-OnPowerTrowelconsistoftwoseparate
gearboxassemblies thatareenclosed inruggedcast aluminum
gearcases.
The gearbox casing holds 50% more oil capacity than
competitors, which allows more lubrication to be provided to
criticalpoints.
Steering
Dual control levers located in front of the operator's seat are
providedforsteering this trowel.Thecontrol leversarelinkedto
twospringloadedcylinders.
Pushthe leftcontrollever forwardandpull therightcontrol lever
backwardand the trowel will rotateclockwiseonapproximately
a center axis. Pull the left control lever backward and push the
right control lever forward and the trowel will rotate
counterclockwise. See Table 3 on page 26 for a complete
descriptiononthecontrolleversdirectionalpositioning.
Constant Velocity Joints (CV-Joints)
Constant velocity joints insure the efficient transfer of power to
thedrive shaft andmaintainthe timing ofthegearboxes without
anychanceofslippage.
Training
For training, please use the “TRAINING CHECKLIST”located
inthefrontof thismanual(Page9).Thischecklistisnotintended
to be a substitute for proper training but will provide an outline
foranexperiencedoperatortoprovidetrainingtoanewoperator.
To order go to Discount-Equipment.com

PAGE 20 — HHN 31V
HHN-34TVD • RIDE-ON POWER TROWEL — OPERATION MANUAL — REV. #1 (05/08/06) — PAGE 20
HHN 34TVD — CONTROLS AND INDICATORS
Figure 3. HHN-34TVD Controls and Indicators (Front)
12. Hour Meter - Indicates number of hours the key switch is
inthe "ON" position.
13. Preheat Light - Lights blue when glow plugs are
energized.
14. Fuel Gauge/Filler Cap - Indicates the amount of fuel in
thefuel tank. Remove thiscaptoadd fuel.
15. FuelTank - Holds 5 gallons of fuel.
16. Spare Belt Carrier - Containsasparebelt. Beltisused on
the drive pulley.
17. Left Foot Riser – Operator foot rest pedal.
18. Spray Nozzles – Spraynozzle for retardant.
19. Right Foot Pedal – Controls blade speed. Slow blade
speedisaccomplishedbyslightlydepressingthefootpedal.
Maximumbladespeedisaccomplishedbyfullydepressing
thefoot pedal.
20. EZ- Mover Boss– Front -sideinsertion pointforEZMover.
Usedwhenthetransportingof the trowel is required.
21. Fuel Filter Light - Lights red when water level risesinthe
Fuel Filter/Separator. See engine manual for draining
instructions.
1. Seat – Provides comfortable position for operation of the
trowel.Enginewillnotstartunless operatoris seated.Seat
isadjustable, fore and aftforoperator comfort.
2. Steering Control Lever (right side) -Allows the unit to
movein either a forward, reverse left or right direction.
3. Retardant Spray Control Buttons – When pressed
allows retardant spray to flow through the spray nozzle
locatedat the front ofthemachine.
4. Twin Pitch Control (Right) – Adjusts the blade pitch for
right side ofthetrowel.Turnthecrank as markedon its top
surfaceto increase or decrease blade pitch.
5. TwinPitchControl (Left)– Adjuststhebladepitchfor left
sideofthetrowel.Turnthecrankasmarkedonitstopsurface
toincreaseordecreasebladepitch.
6. SteeringControlLever(left side) -Allowstheunittomove
ineither a forward, reverse left or right direction.
7. Light Switch – When activated, turns on four halogen
lights.Lights offer better visibility when workingindoors.
8. Ignition Switch – With key inserted turn clockwise to
startengine.
9. Oil Indicator Light - Lights red when oil pressure is low.
10. WaterIndicatorLight-Lightsredwhenwatertemperature
is high.
11. Charge Indicator - Lights red when electrical system is
notcharging properly.
CHG
WATER
OIL
GLOW
PLUGS
FUEL
FILTER
SERIES
3
2
41
8
18
17
16
14
15
18
7
910 11
13
21
6
5
12
19 20
20
To order go to Discount-Equipment.com

HHN-34TVD • RIDE-ON POWER TROWEL — OPERATION MANUAL — REV. #1 (05/08/06) — PAGE 21
HHN 34TVD — CONTROLS AND INDICATORS
22. Lift Loops – Locatedon boththeleftandright sidesof the
main frame. Used when the trowel must be lifted onto a
concreteslab.
23. Lights – Four 12 volt halogen lights are providedwiththis
unit.
24. Right-Side Spider – Consists (basic) of trowel arms,
blades,wear plate, and thrust collar etc.
25. Left-SideSpider– Consists(basic)oftrowelarms,blades,
wearplate, and thrust collar etc.
26. Radiator/FillerCap – Holds coolantor waternecessaryto
keepengineata safeoperating temperature.Removethis
cap to add water or antifreeze. DO NOT revove this cap
whentheengine is warm.
27. Safety Stop Switch – Shutsdown engine when operator
is not sittingin seat.
28. Overflow Bottle - Supplies coolant to the radiator when
radiatorcoolant level islow.Fill toindicated level asshown
onbottle.
31. Oil Filter – Provides oil filteringfortheengine.
32. Battery – Provides+12VDCpowertotheelectricalsystem
33. Retardant Spray Motors – Used in conjunction with the
leftand right spray controlbuttons.
34. Retardant SprayTank – Holds 5 gallons of retardant.
35. Belt Guard – Enclosesdrivebelt usedinconjunction with
clutch.
36. EZ-MoverBoss – Back- sideinsertion pointforEZ Mover.
Usedwhen the transporting of the trowel is required.
37. Oil Sight Glass -Indicates the level of the hydraulic oil in
thegear box.
Figure 4. HHN-34TVD Controls and Indicators (Rear)
29. Engine Air Filter – Prevents dirt and other debris from
entering the fuel system. Lift locking latch on air filter
cannisterto gain access to filterelement.
30. Engine Dip Stick – Indicates engine oil level. Add oil as
required.
RETARDANT ONLY
DIESEL FUEL
33
28
22
26
22
34
32
31
30
25 35 29
23
24
37
36
36
37
27
To order go to Discount-Equipment.com

PAGE 22 — HHN 31V
HHN-34TVD • RIDE-ON POWER TROWEL — OPERATION MANUAL — REV. #1 (05/08/06) — PAGE 22
HHN 34TVD — NEW MACHINE SETUP INSTRUCTIONS
Trowel Pre-Set-Up Instructions
The purpose of this section is to assist the user in setting up a
NEW trowel.Ifthetrowelis alreadyassembled,(seats,handles,
knobsand battery), this section can be skipped.
Beforepackagingandshipping this Ride-On PowerTrowelwas
run and testedatthe factory.If thereareproblems,please let us
know.
Control Handle Assembly
Thesteeringcontrolhandlesarenot attachedto thetrowel's two
lower handles at the time of shipment.To attach the steering
control handles to the lower handle assemblies perform the
following:
1. Remove theboltsfromtheplasticbagtied to the control
towers.
2. Remove allprotectivewrapping andstrapsfrom thecontrol
handles.
3. Slip the top (loose) control handle piece into the base of
thecorrespondinghandle,making suretolineuptheholes.
4. Install the bolt through the lined up holes and tighten the
acornnut onto the threaded end.
5. Pay close attention to any wires that may be inside the
control handles. DO NOT pinch or cut any wires during
installation.
6. Remove the two knobs from the plastic bag for the pitch
control tower cranks and install the knobs onto the tower
cranklevers.
1. Remove theseatfrom the protective wrapping.
2. Remove theboltsonthebottomofthe seat,and placeseat
on the seat mounting plate, then insert the bolts through
theholesorslotsontheseatmountingplateandtighten.
Seat Assembly
The seat is not installed on the trowel for shipping purposes.
To attach the seat perform the following:
Toinstall the batteryonthe trowel,makesurethat the batteryis
wellseatedin thebatterybox. Thepositivecable,normallyred,
is associated with the "+" symbol on the battery. The negative
cable, normally black, is associated with the "-" symbol on the
battery. Connect the positive cable to the positive terminal on
thebattery first,thenconnect the negativecableto the negative
terminal. Close the plastic battery box cover and secure the
batterybox.
Use all safety precautions specified by the battery
manufacturer when working with the battery. See further
specificsafety information on page 14 & 15 of this manual.
Thenewride-ontrowel cannotbe put
into service until the pre-setup
installation instructions are
completed. These pre-setup
instructionsonlyneedtobeperformed
at the time of unpacking a
NEW
trowel.
NOTE
NOTE
Models equipped with adjustable
height handles are adjusted by
placing the bolt through the set of
holes that bring the handles to a
height most comfortable for the
operator.
NOTE
H-series trowels have a seat that is
mounted on tracks, similar to an
automobile seat. This seat can be
adjusted fore and aft via the control
leverunder the front of the seat.
Thistrowelwasshippedwitha wetchargedbattery.Thisbattery
may need to be charged for a brief period of time as per the
manufacturerinstructions.
Battery Setup
CAUTIONCAUTION
CAUTIONCAUTION
CAUTION
Figure 5. Battery Cable Orientation
2
1
1. Negative Cable (BLACK)
2. Positive Cable (RED)
To order go to Discount-Equipment.com
