MULTIQUIP QP3TZ Guide

OPERATION AND PARTS MANUAL
THIS MANUAL MUST ACCOMPANY THE EQUIPMENT AT ALL TIMES.
To find the latest revision of this
publication, visit our website at:
www.multiquip.com
MODEL QP3TZ
TRASH PUMP
(HATZ 1B30 DIESEL ENGINE)
Revision #4 (05/15/14)

PAGE 2 — QP3TZ TRASH PUMP • OPERATION AND PARTS MANUAL — REV. #4 (05/15/14)
PROPOSITION 65 WARNING

QP3TZ TRASH PUMP • OPERATION AND PARTS MANUAL — REV. #4 (05/15/14) — PAGE 3
NOTES

PAGE 4 — QP3TZ TRASH PUMP • OPERATION AND PARTS MANUAL — REV. #4 (05/15/14)
TABLE OF CONTENTS
QP3TZ Trash Pump
Proposition 65 Warning ........................................... 2
Table Of Contents.................................................... 4
Parts Ordering Procedures...................................... 5
Safety Information .............................................. 6-10
Specifications (Pump)............................................ 11
Specifications (Engine).......................................... 12
General Information............................................... 13
Pump Components................................................ 14
Basic Engine.......................................................... 15
Inspection (Engine)................................................ 16
Setup ..................................................................... 17
Operation............................................................... 18
Maintenance (Pump) ........................................ 19-20
Maintenance (Engine) ...................................... 21-22
Storage.................................................................. 23
Troubleshooting (Engine)....................................... 24
Troubleshooting (Engine/Pump) ............................ 25
Explanation Of Code In Remarks Column............. 26
Suggested Spare Parts ......................................... 27
Component Drawings
Pump Assembly................................................ 28-31
Engine Service Parts........................................ 32-33
Terms And Conditions of Sale — Parts ................. 34
NOTICE
Specifications and part numbers are subject to change
without notice.

QP3TZ TRASH PUMP • OPERATION AND PARTS MANUAL — REV. #4 (05/15/14) — PAGE 5
PARTS ORDERING PROCEDURES
www.multiquip.com
Ordering parts has never been easier!
Choose from three easy options:
WE ACCEPT ALL MAJOR CREDIT CARDS!
When ordering parts, please supply:
❒Dealer Account Number
❒Dealer Name and Address
❒Shipping Address (if different than billing address)
❒Return Fax Number
❒Applicable Model Number
❒Quantity, Part Number and Description of Each Part
❒Specify Preferred Method of Shipment:
✓ UPS/Fed Ex ✓DHL
■Priority One ✓Tr u c k
■Ground
■Next Day
■Second/Third Day
If you have an MQ Account, to obtain a Username
and Password, E-mail us at:
parts@multiquip.
com.
To obtain an MQ Account, contact your
District Sales Manager for more information.
Order via Internet (Dealers Only):
Order parts on-line using Multiquip’s SmartEquip website!
■View Parts Diagrams
■Order Parts
■Print Specification Information
Note: Discounts Are Subject To Change
Goto www.multiquip.com and click on
Order Parts to log in and save!
Use the internet and qualify for a 5% Discount
on Standard orders for all orders which include
complete part numbers.*
Order via Fax (Dealers Only):
All customers are welcome to order parts via Fax.
Domestic (US) Customers dial:
1-800-6-PARTS-7 (800-672-7877)
Fax your order in and qualify for a 2% Discount
on Standard orders for all orders which include
complete part numbers.*
Order via Phone: Domestic (US) Dealers Call:
1-800-427-1244
Best Deal!
International Customers should contact
their local Multiquip Representatives for
Parts Ordering information.
Non-Dealer Customers:
Contact your local Multiquip Dealer for
parts or call 800-427-1244 for help in
locating a dealer near you.
Note: Discounts Are Subject To Change
Effective:
January 1st
, 2006
NOTICE
All orders are treated as Standard Orders and will
ship the same day if received prior to 3PM PST.

PAGE 6 — QP3TZ TRASH PUMP • OPERATION AND PARTS MANUAL — REV. #4 (05/15/14)
SAFETY INFORMATION
Do not operate or service the equipment before reading
the entire manual. Safety precautions should be followed
at all times when operating this equipment.
Failure to read and understand the safety
messages and operating instructions could
result in injury to yourself and others.
SAFETY MESSAGES
The four safety messages shown below will inform you
about potential hazards that could injure you or others.The
safety messages specifically address the level of exposure
to the operator and are preceded by one of four words:
DANGER, WARNING, CAUTION
or NOTICE.
SAFETY SYMBOLS
DANGER
Indicates a hazardous situation which, if not avoided,
WILL result in DEATH or SERIOUS INJURY.
WARNING
Indicates a hazardous situation which, if not avoided,
COULD result in DEATH or SERIOUS INJURY.
CAUTION
Indicates a hazardous situation which, if not avoided,
COULD result in MINOR or MODERATE INJURY.
NOTICE
Addresses practices not related to personal injury.
Potential hazards associated with the operation of this
equipment will be referenced with hazard symbols which
may appear throughout this manual in conjunction with
safety messages.

QP3TZ TRASH PUMP • OPERATION AND PARTS MANUAL — REV. #4 (05/15/14) — PAGE 7
SAFETY INFORMATION
GENERAL SAFETY
CAUTION

NEVER operate this equipment without proper protective
clothing, shatterproof glasses, respiratory protection,
hearing protection, steel-toed boots and other protective
devices required by the job or city and state regulations.

NEVER operate this equipment when not
feeling well due to fatigue, illness or when
under medication.

NEVER operate this equipment under the influence of
drugs or alcohol.
NOTICE

This equipment should only be operated by trained and
qualified personnel 18 years of age and older.

Whenever necessary, replace nameplate, operation and
safety decals when they become difficult read.

Manufacturer does not assume responsibility for any
accident due to equipment modifications. Unauthorized
equipment modification will void all warranties.

NEVER use accessories or attachments that are not
recommended by Multiquip for this equipment. Damage
to the equipment and/or injury to user may result.

ALWAYS know the location of the nearest
fire extinguisher.

ALWAYS know the location of the nearest
first aid kit.

ALWAYS know the location of the nearest phone or keep
a phone on the job site. Also, know the phone numbers
of the nearest ambulance, doctor and fire department.
This information will be invaluable in the case of an
emergency.
PUMP SAFETY
DANGER
NEVER
pump volatile, explosive, flammable or low flash
point fluids. These fluids could ignite or explode.

The engine fuel exhaust gases contain poisonous carbon
monoxide. This gas is colorless and odorless, and can
cause death if inhaled.

The engine of this equipment requires an adequate free
flow of cooling air. NEVER
operate this equipment in any
enclosed or narrow area
where free flow of the air is
restricted. If the air flow is
restricted it will cause injury
to people and property and
serious damage to the
equipment or engine.
NEVER operate the equipment in an explosive
atmosphere or near combustible materials.An
explosion or fire could result causing severe
bodily harm or even death.
WARNING
NEVER
pump corrosive chemicals or water containing
toxic substances. These fluids could create serious
health and environmental hazards. Contact local
authorities for assistance.
NEVER open the priming plug when pump
is hot. Hot water inside could be pressurized
much like the radiator of an automobile.
Allow pump to cool to the touch before
loosening plug. The possibility exists of
scalding, resulting in severe bodily harm.
NEVER disconnect any
emergency or safety devices.
These devices are intended for operator safety.
Disconnection of these devices can cause severe injury,
bodily harm or even death. Disconnection of any of these
devices will void all warranties.
DANGEROUS
GAS FUMES

PAGE 8 — QP3TZ TRASH PUMP • OPERATION AND PARTS MANUAL — REV. #4 (05/15/14)
SAFETY INFORMATION
CAUTION

NEVER lubricate components or attempt service on a
running machine.

NEVER block or restrict flow from discharge hose.
Remove kinks from discharge line before starting pump.
Operation with a blocked discharge line can cause water
inside pump to overheat.
NOTICE

ALWAYS fill the pump casing with water before starting
the engine. Failure to maintain water inside the pump
housing will cause severe damage to the pump and
mechanical seal.

In winter drain water from pump housing to prevent
freezing.

NEVER start the pump with the clean-out cover removed.
The rotating impeller inside the pump can cut or sever
objects caught in it. Before starting the pump, check that
the clean-out cover is securely fastened.

ALWAYS keep the machine in proper running condition.

ALWAYS ensure pump is on level ground before use.

Fix damage to machine and replace any broken parts
immediately.

ALWAYS store equipment properly when it is not being
used. Equipment should be stored in a clean, dry location
out of the reach of children and unauthorized personnel.
ENGINE SAFETY
WARNING

NEVER operate the engine with heat shields or
guards removed.

DO NOT remove the engine oil drain plug
while the engine is hot. Hot oil will gush
out of the oil tank and severely scald any
persons in the general area of the pump.
CAUTION

NEVER touch the hot exhaust manifold,
muffler or cylinder. Allow these parts to cool
before servicing equipment.
NOTICE
NEVER
run engine without an air filter or with a dirty air
filter. Severe engine damage may occur. Service air filter
frequently to prevent engine malfunction.
NEVER tamper with the factory settings
of the engine or engine governor. Damage
to the engine or equipment can result
if operating in speed ranges above the
maximum allowable.
FUEL SAFETY
DANGER
DO NOT
add fuel to equipment if it is placed inside truck
bed with plastic liner. Possibility exists of explosion or
fire due to static electricity.
DO NOT
start the engine near spilled fuel or combustible
fluids. Fuel is extremely flammable and its vapors can
cause an explosion if ignited.
ALWAYS
refuel in a well-ventilated area, away from
sparks and open flames.
ALWAYS
use extreme caution when working with
flammable liquids.
DO NOT
fill the fuel tank while the engine is running
or hot.
DO NOT
overfill tank, since spilled fuel could ignite if it
comes into contact with hot engine parts or sparks from
the ignition system.

QP3TZ TRASH PUMP • OPERATION AND PARTS MANUAL — REV. #4 (05/15/14) — PAGE 9
SAFETY INFORMATION
Store fuel in appropriate containers, in well-ventilated
areas and away from sparks and flames.

NEVER use fuel as a cleaning agent.

DO NOT smoke around or near the
equipment. Fire or explosion could result
from fuel vapors or if fuel is spilled on a
hot engine.
BATTERY SAFETY (ELECTRIC START ONLY)
DANGER

DO NOT drop the battery. There is a possibility that the
battery will explode.

DO NOT expose the battery to open flames,
sparks, cigarettes, etc.The battery contains
combustible gases and liquids. If these
gases and liquids come into contact with a
flame or spark, an explosion could occur.
WARNING

ALWAYS wear safety glasses when
handling the battery to avoid eye irritation.
The battery contains acids that can cause
injury to the eyes and skin.

Use well-insulated gloves when picking up
the battery.

ALWAYS keep the battery charged. If the battery is not
charged, combustible gas will build up.

DO NOT charge battery if frozen. Battery can explode.
When frozen, warm the battery to at least 61°F (16°C).

ALWAYS recharge the battery in a well-ventilated
environment to avoid the risk of a dangerous concentration
of combustible gases.

If the battery liquid (dilute sulfuric acid)
comes into contact with clothing or skin,
rinse skin or clothing immediately with
plenty of water.

If the battery liquid (dilute sulfuric acid) comes into
contact with eyes, rinse eyes immediately with plenty
of water and contact the nearest doctor or hospital to
seek medical attention.
CAUTION
ALWAYS disconnect the
NEGATIVE battery terminal
before performing service on the equipment.
ALWAYS
keep battery cables in good working condition.
Repair or replace all worn cables.
TRANSPORTING SAFETY
CAUTION
NEVER
allow any person or animal to stand underneath
the equipment while lifting.
NOTICE

Before lifting, make sure that the equipment parts (hook
and vibration insulator) are not damaged and screws are
not loose or missing.

Always make sure crane or lifting device has been
properly secured to the lifting bail (hook) of the
equipment.
ALWAYS shutdown engine before transporting.
NEVER lift the equipment while the engine is running.

Tighten fuel tank cap securely and close fuel cock to
prevent fuel from spilling.

Use adequate lifting cable (wire or rope) of sufficient
strength.
Use one point suspension hook and lift straight upwards.
DO NOT lift machine to unnecessary heights.
ALWAYS
tie down equipment during transport by
securing the equipment with rope.

PAGE 10 — QP3TZ TRASH PUMP • OPERATION AND PARTS MANUAL — REV. #4 (05/15/14)
ENVIRONMENTAL SAFETY/DECOMMISSIONING
NOTICE
Decommissioning is a controlled process used to safely
retire a piece of equipment that is no longer serviceable.
If the equipment poses an unacceptable and unrepairable
safety risk due to wear or damage or is no longer cost
effective to maintain (beyond life-cycle reliability) and is to
be decommissioned (demolition and dismantlement),be
sure to follow rules below.

DO NOT pour waste or oil directly onto the ground, down
a drain or into any water source.

Contact your country's Department of
Public Works or recycling agency in your
area and arrange for proper disposal of
any electrical components, waste or oil
associated with this equipment.

When the life cycle of this equipment is over, remove
battery and bring to appropriate facility for lead
reclamation. Use safety precautions when handling
batteries that contain sulfuric acid.

When the life cycle of this equipment is over, it is
recommended that the trowel frame and all other metal
parts be sent to a recycling center.
Metal recycling involves the collection of metal from
discarded products and its transformation into raw
materials to use in manufacturing a new product.
Recyclers and manufacturers alike promote the process
of recycling metal. Using a metal recycling center
promotes energy cost savings.
EMISSIONS INFORMATION
NOTICE
The diesel engine used in this equipment has been
designed to reduce harmful levels of carbon monoxide
(CO), hydrocarbons (HC) and nitrogen oxides (NOx)
contained in diesel exhaust emissions.
This engine has been certified to meet US EPA Evaporative
emissions requirements in the installed configuration.
Attempting to modify or make adjustments to the engine
emmission system by unauthorized personnel without
proper training could damage the equipment or create an
unsafe condition.
Additionally, modifying the fuel system may adversely affect
evaporative emissions, resulting in fines or other penalties.
Emission Control Label
The emission control label is an integral part of the emission
system and is strictly controlled by regulation(s).
The label must remain with the engine for its entire life.
If a replacement emission label is needed, please contact
your authorized engine distributor.
SAFETY INFORMATION

QP3TZ TRASH PUMP • OPERATION AND PARTS MANUAL — REV. #4 (05/15/14) — PAGE 11
Table 1. Specifications (Pump)
Pump
Model QP3TZ
Type Trash Pump
Suction 3.0 in. (76 mm.)
Discharge Size 3.0 in. (76 mm.)
Maximum Pumping
Capacity
383 gallons/minute
(1,450 liters/minute)
Max. Solids Diameter 1.0 in. (25.4 mm)
Max. Head 90 ft. (27.0 m)
Max. Lift 25 ft. (7.62 m)
Max. Pressure 38.9 psi (268 kPa)
Dry Net Weight 163 lbs. (74 Kg.)
SPECIFICATIONS (PUMP)
Figure 1. QP3TZ Dimensions
23.6 IN.
(59.9 CM.)
19.0 IN.
(48.2 CM.)
26.9 IN.
(68.3 CM.)

PAGE 12 — QP3TZ TRASH PUMP • OPERATION AND PARTS MANUAL — REV. #4 (05/15/14)
SPECIFICATIONS (ENGINE)
Table 2. Specifications (Engine)
Model HATZ 1B30
Type Air-Cooled Diesel
Engine
Displacement 21.2 in3(0.347 liters)
Idle Speed 1,000 R.P.M.
Fuel Type EN 590 - DIN 51601 BS 2869 A1/A2-
ASTM D 975-1D/2D
Lube Oil Capacity 1.16 quarts (1.10 liters)
Engine Oil Type CCMC - D4 - D5 - PD@ or API - CD-
CE- CF -CG or SHPD
Starting Method Recoil Start
Air Cleaner Type Dry Element
Weight 77.1 lbs (35 Kg.)
Figure 2. QP3TZ Performance Curve
3.3 FT
23.3 FT
16.7 FT
10 FT

QP3TZ TRASH PUMP • OPERATION AND PARTS MANUAL — REV. #4 (05/15/14) — PAGE 13
ELEVATION
Higher elevations will effect the performance of the pump.
Due to less atmospheric pressure at higher altitudes,
pumps DO NOT have the priming ability that they have at
sea level. This is due to the “thinner air” or lack of oxygen
at higher altitudes.
A general rule of thumb is that for every 1,000 feet of
elevation above sea level a pump will lose one foot of
priming ability.
For example, in Flagstaff, Arizona where the elevation is
approximately 7,000 feet, the pump would have a suction
lift of only 18 feet rather than the 25 feet at sea level.
Table 3 shows suction lift at various elevations.
Table 3. Suction Lift at Various Elevations
Altitude
Feet
(Meters)
Suction Lift in Feet (Meters)
Sea Level 10.0 (3.048) 15.0 (4.572) 20.0 (6.096) 25.0 (7.620)
2,000 (610) 8.80 (2.680) 13.2 (4.023) 17.6 (5.364) 22.0 (6.705)
4,000 (1,219) 7.80 (2.377) 11.7 (3.566) 15.6 (4.754) 19.5 (5.943)
6,000 (1,829) 6.90 (2.103) 10.4 (3.169) 13.8 (4.206) 17.3 (5.273)
8,000 (2,438) 6.20 (1.889) 9.30 (2.834) 12.4 (3.779) 15.5 (4.724)
10,000 (3,048) 5.70 (1.737) 8.60 (2.621) 11.4 (3.474) 14.3 (4.358)
Table 4 shows percentage drops in performance as
elevation increases.
Table 4. Performance Loss at Various Elevations
Altitude
Feet (Meters) Discharge Flow Discharge Head
Sea Level 100% 100%
2,000 (610) 97% 95%
4,000 (1,219) 95% 91%
6,000 (1,829) 93% 87%
8,000 (2,438) 91% 83%
10,000 (3,048) 88% 78%
GENERAL INFORMATION
APPLICATION
The QP3TZ Trash Pump is designed to be used for
dewatering applications. Both the suction and discharge
ports on the QP3TZ trash pump use a 3-inch diameter
opening, which allows the pump to pump at a rate of
approximately 383 gallons/minute (gpm) or 1,450 liters/
minute (lpm).
Trash or self-priming pumps are designed to purge air from
the suction line and create a partial vacuum in the pump
body. The reduced atmospheric pressure inside the pump
allows water to flow through the suction line and into the
pump body. The centrifugal force created by the rotating
impeller pressurizes the water and expels it from the pump.
ENGINE
This trash pump is powered by a 6.8 horsepower, air-
cooled, HATZ 1B30 diesel engine.
TRASH PUMP
Trash pumps derive their name from their ability to handle
a greater amount of debris and solids than standard
centrifugal pumps. This pump generally handle solids up
to 1/2 the size of the discharge opening making them less
likely to clog. Also,trash pumps are capable of handling
water with 25% solids by weight.
The advantage of using a trash pump is that it can be quickly
and easily disassembled in the field “without tools” and
easily cleaned when clogged.
SUCTION LIFT
This pump is intended to be used for dewatering applications
and is capable of suction lifts up to 25 feet at sea level. For
optimal suction lift performance, keep the suction hose or
line as short as possible. In general, always place the pump
as close to the water as possible.
PUMP SUPPORT
The pump should always be placed on solid stationary
ground in a level position.
NEVER place the pump on soft soil. The suction hose or
pipe connection should always be checked for tightness
and leaks. A small suction leak in the hose or fittings could
prevent the pump from priming.

PAGE 14 — QP3TZ TRASH PUMP • OPERATION AND PARTS MANUAL — REV. #4 (05/15/14)
PUMP COMPONENTS
Figure 3 shows a typical application using the QP3TZ centrifugal pump. Please note that this pump is intended for the
removal of clean water.
Figure 3. QP3TZ Pump Application
NOTE:
CONTACT YOUR NEAREST
MULTIQUIP DEALER FOR
QUICK DISCONNECT HOSES
AND FITTINGS.
5
5
4
4
4
7
89
10 11
12
4
3
21
6
1. Pump — The model QP3TZ is a 3-inch trash pump
used in general dewatering applications. Typical
dewatering applications consist of manholes, septic
tanks, fast and slow seepage ditch water, silt water,
mud water and muck water.
2. Fill Cap — Prior to operation, the pump casing should
be filled with water. Remove this cap to add water to
the pump. After the initial prime, a sufficient amount of
water will be retained in the casing so that the operator
will not need to re-prime later.
3. Discharge Port — Connect a 3-inch discharge hose
to this port.
4. Worm Clamp — Used to secure the hose to the inlet
and outlet ports on the pump. Use two clamps to secure
the hose on the inlet side of the pump.
5. Discharge Hose — Connect a flexible rubber
hose to the discharge port on the pump. Make sure
that the hose lays flat and is not kinked. Use only
recommended type discharge hose. Contact Multiquip
Parts Department for ordering information.
6. Suction Port — Connect a 3-inch inlet hose to this port
Use two worm clamps to secure the hose.
7. Suction Hose — Connect this flexible rubber hose to
the suction port on the pump. Make sure that the hose
lays flat and is not kinked. Use only recommended type
suction hose. Contact Multiquip parts department for
ordering information.
8. Clean-out Cover Handles — To gain access to the
pump's clean-out area, grip both handles, then pull to
remove cover. Make sure both locking knobs have been
released before attempting to remove clean-out cover.
9. Drain Plug — Remove this plug to drain water from
the pump.
10. Clean-out Cover — Remove cover to gain access to
the clean-out area.
11. Locking Knobs —Turn both knobs clockwise to secure
clean-out cover. Turn both knobs counterclockwise to
release cover.
12. Strainer — Always attach a strainer to bottom side of
the suction hose to prevent large objects and debris
from entering the pump. Strainer should be positioned
so that it will remain completely under water. Running
the pump with the strainer above water for long periods
can damage pump.

QP3TZ TRASH PUMP • OPERATION AND PARTS MANUAL — REV. #4 (05/15/14) — PAGE 15
6. Engine Motor Mounts — Attach these engine mounts
to the pump frame. Tighten securely.
7. Oil Filter — Remove this bolt to gain access
(internal) to the engine oil filter. Service the oil filter
as recommended in the maintenance section of this
manual.
8. Oil Drain Plugs —There are two oil drain plugs, one
is underneath the flywheel, the other on the side of the
engine. Remove these plugs to drain engine oil from
the engine crankcase.
9. Crankshaft — Connect this shaft to the input of the
transmission.
10. Muffler — Used to reduce noise and emissions.
11. Nameplate — Contains information about the engine.
NOTICE
Operating the engine without an air filter, with a
damaged air filter, or a filter in need of replacement
will allow dirt to enter the engine, causing rapid engine
wear.
WARNING
Engine components can generate
extreme heat. To prevent burns,
DO NOT touch these areas while the
engine is running or immediately after
operating. NEVER operate the engine
with the muffler removed.
Figure 4. Engine Controls and Components
INITIAL SERVICING
The engine (Figure 4) must be checked for proper lubrication
and filled with fuel prior to operation. Refer to the manufac-
turer’s Engine manual for operating and servicing information.
1. Fuel Filler Cap/Fuel Tank — Pull this latch to add
diesel fuel to the tank. After refueling, always make
sure the fuel cap is latched properly. DO NOT over
fill. For additional information refer to engine owner’s
manual.
.
2. Engine Lifting Straps/Cover — Remove the air
cleaner cover, then lift this cover (the one with decals
on it) to gain access to the engine lifting straps.
3. Air Cleaner/Cover — Prevents dirt and other debris
from entering the fuel system. Remove wing-nut on
side of air filter cover to gain access to filter element.
4. Speed Control Lever — This lever is connected to
the throttle control which is located on the side of the
engine compartment cover. Use this lever to control
engine speed.
5. Dipstick — Remove dipstick to determine if the engine
oil level is low. If low, add oil as specified.
DANGER
Adding fuel to the tank should be done
only when the engine is stopped and has
had an opportunity to cool down. In the
event of a fuel spill, DO NOT attempt to
start the engine until the fuel residue has
been completely wiped up, and the area
surrounding the engine is dry.
BASIC ENGINE

PAGE 16 — QP3TZ TRASH PUMP • OPERATION AND PARTS MANUAL — REV. #4 (05/15/14)
INSPECTION (ENGINE)
CAUTION
DO NOT attempt to operate the pump
until the Safety Information, General
Information and Inspection sections
of this manual have been read and
thoroughly understood.
BEFORE STARTING
1. Read safety instructions at the beginning of manual.
2. Clean the pump, removing dirt and dust, particularly
the engine cooling air inlet, carburetor and air cleaner.
3. Check the air filter for dirt and dust. If air filter is dirty,
replace air filter with a new one as required.
4. Check carburetor for external dirt and dust. Clean with
dry compressed air.
5. Check fastening nuts and bolts for tightness.
Engine Oil Check
1. To check the engine oil level, place the pump on secure
level ground with the engine stopped.
2. Remove the filler dipstick from the engine oil filler hole
(See Figure 5) and wipe clean.
Figure 5. Engine Oil Dipstick (Removal
3. Insert and remove the dipstick without screwing it into
the filler neck. Check the oil level shown on the dipstick.
4. If the oil level is low (See Figure 6), fill to the edge
of the oil filler hole with the recommended oil type
(Table 5). Maximum oil capacity is 1.16 quarts
(1.1 liters).
Figure 6. Engine Oil DipStick (Oil Level
Fuel Check
1. Remove the gasoline cap located on top of fuel tank.
2. Visually inspect to see if the fuel level is low. If fuel is
low, replenish with unleaded fuel.
3. When refueling, be sure to use a strainer for filtration.
DO NOT top-off fuel. Wipe up any spilled fuel
immediately!
Table 5. Oil Type
Season Temperature Oil Type
Summer 25°C or Higher SAE 10W-30
Spring/Fall 25°C~10°C SAE 10W-30/20
Winter 0°C or Lower SAE 10W-10
DANGER
Motor fuels are highly flammable and can
be dangerous if mishandled. DO NOT
smoke while refueling. DO NOT attempt
to refuel the pump if the engine is hot!
or running.

QP3TZ TRASH PUMP • OPERATION AND PARTS MANUAL — REV. #4 (05/15/14) — PAGE 17
7. The discharge hose is usually a collapsible
(thin-walled) hose, however if a thin-walled discharge
hose is not available, a rigid suction hose can be
substituted in its place.
8. Make sure the suction strainer (See Figure 3) is
clean and securely attached to the water end of the
suction hose. The strainer is designed to protect the
pump by preventing large objects from being pulled in
to the pump.
CAUTION
The strainer should be positioned so it will remain
completely under water. Running the pump with the
strainer above water for long periods can damage the
pump.
CAUTION
DO NOT pump flammable fluids, corrosive chemicals or
fluids containing toxic substances. These fluids can create
potentially dangerous health and environmental hazards.
Contact local authorities for assistance.
CAUTION
This pump uses a water-cooled mechanical seal to
prevent water from seeping into the engine.The passage
of water through the pump casing lubricates the seal and
prevents it from overheating. NEVER operate the pump
without water in the casing as this will cause damage to
the mechanical seal.
1. Place pump as near to water as possible, on a firm
flat, level surface.
2. To prime pump, remove fill cap (See Figure 3) and fill
pump casing with water. If the pump casing is not filled
with water before starting, it will not begin pumping.
3. Attach suction and discharge hoses to the pump.Check
that all hoses are securely attached to the pump. Make
certain suction hose (See Figure 3) does not have
any air leakage. Tighten hose clamps and couplings
as required.
4. It is recommended that 2 clamps be used when
securing the suction hose to the inlet side (suction)
of the pump.
5. Remember suction hoses must be rigid enough not to
collapse when the pump is in operation.
6. Check that the discharge hose (See Figure 3) is not
restricted. Place hose so that it lays as straight as it is
possible on the ground. Remove any twists or sharp
bends from hose which may block the flow of water.
NOTICE
Suction and discharge hoses are available from
Multiquip. Contact your nearest dealer for more
information.
SETUP

PAGE 18 — QP3TZ TRASH PUMP • OPERATION AND PARTS MANUAL — REV. #4 (05/15/14)
OPERATION
STARTING THE ENGINE
1. Move the engine speed lever to the START position (See
Figure 7)..
Figure 7. Engine Speed Lever (START Position)
2. Grasp the starter grip (Figure 8) and slowly pull it out until
you feel the strongest resistance then return the starter
grip to the initial position..
Figure 8. Starter Grip
3. Pull the starter grip again, hard and fast, pulling it all
the way out to start engine.
4. If the engine does not start, repeat steps 2 and 3.
CAUTION
DO NOT attempt to operate the pump until the Safety,
General Information and Inspection sections of this
manual have been read and thoroughly understood.
CAUTION
Do not allow the starter grip to snap back against the
engine. Return it gently to prevent damage to the starter.
STOPPING THE ENGINE
Normal Shutdown
1. Move the engine speed lever to the low speed and
run the engine for about three minutes with no load.
2. After the engine cools, move the engine speed lever to
the STOP position (See Figure 9).
Figure 9. Engine Speed Lever (STOP Position)
3. Slowly pull the starter grip (Figure 8) until strong
resistance is felt and leave it in this position. This
prevents rust from forming while the engine is not in
use.
Emergency Shutdown
1. To stop engine immediately, quickly place the engine
speed lever to the STOP position.
CAUTION
ALWAYS run engine at full speed while pumping.
CAUTION
When stopping the engine, reduce the load slowly. Do not
stop engine suddenly since it may cause the temperature
to rise abnormally..

QP3TZ TRASH PUMP • OPERATION AND PARTS MANUAL — REV. #4 (05/15/14) — PAGE 19
PUMP VACUUM TEST
To perform the pump vacuum test do the following:
1. Remove the pump fill cap (See Figure 3), and fill the
pump with water.
2. Start the engine as outlined in the initial start-up
section, and wait for the pump to begin pumping.
3. As shown in Figure 10, place a water hose inside
the discharge opening of the pump, and turn on the
water. This flow of water into the discharge opening
will prevent the pump from running dry.
4. Place the Pump Vacuum Tester (P/N 7000030) over the
pump suction (inlet) opening (See Figure 10) with the
vacuum gauge facing upwards. It may be necessary
to apply a small amount of water around the rubber
seal of the vacuum tester to make a good suction fit.
5. Check and make sure that there are no air leaks
between the vacuum tester and the inlet port on the
pump. If air leaks are present reseat vacuum tester.
6. Run the pump for a few minutes while monitoring the
vacuum gauge. If the gauge indicates a reading
between -25 and -20 in. Hg. (inches of mercury) then
it can be assumed that the pump is working correctly.
7. If the vacuum tester gauge indicates a reading below
-20 in. Hg, it can then be assumed that the pump is
not functioning correctly, and corrective action needs
to be taken.
8. To test the flapper valve, shutdown the engine. The
vacuum tester should remain attached to the pump
suction inlet port by vacuum.This indicates the pump's
flapper valve is seating properly to hold water in the
suction hose when the engine is stopped.This prevents
backflow and allows for faster priming when the engine
is restarted.
NOTICE
25 in. Hg (inches of mercury) translates into 25 feet of
lift at sea level.
MAINTENANCE (PUMP)
CAUTION
DO NOT attempt to start the engine unless the pump
has previously been primed with water. Severe pump
damage will occur if pump has not been primed.
ADJUSTING IMPELLER CLEARANCE
1. If it is necessary to replace impeller or volute, be sure
clearance between impeller and volute is adjusted
2. The impeller should be as close to the volute as
possible without rubbing against it. Clearance is
adjusted by adding or removing shims from behind
the impeller.
3. Check clearance between impeller and insert by slowly
pulling starter rope to turn impeller.
4. Check the impeller every six months for wear, and for
clearance between the impeller face and the volute.
Also check the shaft seal for wear, as well as the shaft
sleeve.
PUMP CLEANING
After pumping water containing large amounts of dirt and
debris, perform the following:
1. Remove the drain plug from the pump housing
(Figure 3) and drain any water left in the pump.
2. Loosen the two locking hand knobs (turn
counterclockwise) and remove clean-out cover.
3. Clean and remove dirt, debris from pump casing.
Inspect impeller and volute for wear. Replace any
damaged or worn parts.
NOTICE
It is important not to remove too many shims or the
clearance between the impeller and volute will become
too wide and pump performance will be reduced.
Remember as the impeller wear down, additional shims
may be required to maintain the clearance between the
impeller and insert.
CAUTION
The impeller may develop sharp edges. Use extreme
care when cleaning around the impeller to prevent
being cut.

PAGE 20 — QP3TZ TRASH PUMP • OPERATION AND PARTS MANUAL — REV. #4 (05/15/14)
MAINTENANCE (PUMP)
Figure 10. Pump Vacuum Tester
