Multitech Multi-Tech RouteFinder SOHO RF820 User manual

RouteFinder®
SOHO Internet Security Appliance
RF820 / RF830
IPSec VPN Setup Examples
Reference Guide

Copyright and Technical Support
Multi-Tech Systems, Inc. RF820/830 IPSec VPN Setup Examples – A Reference Guide 2
IPSec VPN Setup Examples
Reference Guide
RouteFinder SOHO Internet Security Appliance
RF820 and RF830
PN S000412E, Revision E
Copyright © 2006-2007
This publication may not be reproduced, in whole or in part, without prior expressed written permission from Multi-
Tech Systems, Inc. All rights reserved.
Multi-Tech Systems, Inc. makes no representations or warranties with respect to the contents hereof and specifically
disclaims any implied warranties of merchantability or fitness for any particular purpose. Furthermore, Multi-Tech
Systems, Inc. reserves the right to revise this publication and to make changes from time to time in the content hereof
without obligation of Multi-Tech Systems, Inc. to notify any person or organization of such revisions or changes.
Revision Date Description
A 06/20/06 Initial release. To accompany software version 1.00
B 07/17/06 Changed the example setup drawings for Non-NAT Example 2, NAT Example 1,
NAT Example 2, and NAT Example 3.
C 08/10/06 Added a table of commonly supported subnet addresses.
D 04/05/07 Updated the Technical Support contact list.
E 10/25/07 Changed the screens on pages 10 and 14. Add notes about not checking the
Status box on the Packet Filter Rules screen when entering a new Packet Filter
rule. Changed the Packet Filter screen shot on page 22. Change the Save &
Restart screens and text.
Trademarks
The Multi-Tech logo and RouteFinder are registered trademarks of Multi-Tech System, Inc.
World Headquarters
Multi-Tech Systems, Inc.
2205 Woodale Drive
Mounds View, Minnesota 55112
Phone: [phone] or 800-328-9717
Fax: [phone]
Internet Address: http://www.multitech.com
Technical Support
Country By Email By Phone
Europe, Middle East, Africa [email protected] +(44) 118 959 7774
U.S., Canada, all others [e-mail] [phone] or 763-717-5863

Chapter 1 – Non-NAT Setup Examples
Multi-Tech Systems, Inc. RF820/830 IPSec VPN Setup Examples – A Reference Guide 3
Contents
Chapter 1 – Non-NAT Setup Examples ......................................................................................................................4
Prerequisite Step – Set Up VPN Client Using IPSec VPN Client Software .....................................................4
Prerequisite Step 1 – VPN Client Phase 1 Set Up....................................................................................4
Prerequisite Step 2 – Phase 2 Setup........................................................................................................5
Example 1 – Set Up a RouteFinder and a VPN Client Behind a Non-NAT Device..........................................6
Example 2 – A Setup Using Two RouteFinders Behind a Non-NAT Device.................................................10
Chapter 2 – NAT Setup Examples.............................................................................................................................18
Prerequisite Steps – Set Up VPN Client Using IPSec VPN Client Software .................................................18
Prerequisite Step 1 – VPN Client Phase 1 Setup (Behind NAT).............................................................18
Prerequisite Step 2 – Client Phase 1 Advanced Setup (Behind NAT) ....................................................19
Prerequisite Step 3 – Client Phase 2 Setup (Behind NAT) .....................................................................20
Example 1 – Set Up a RouteFinder with a Tunnel to a Client Behind a NAT Device ...................................21
Step 1 – Network Setup..........................................................................................................................21
Step 2 – Packet Filters............................................................................................................................22
Step 3 – VPN Setup................................................................................................................................22
Example 2 – Set Up Two RouteFinders Behind a NAT Device ......................................................................25
Step 1 -- Network Setup .........................................................................................................................25
Step 2 – Packet Filters............................................................................................................................26
Step 3 -- VPN Setup ...............................................................................................................................27
Example 3 – Set Up the RouteFinder Going to a VPN behind a NAT Device ...............................................28
Step 1 -- Network Setup .........................................................................................................................28
Step 2 – Packet Filters............................................................................................................................29
Step 3 – VPN Setup................................................................................................................................29
Chapter 3 – A Reference Table of Commonly Supported Subnets........................................................................32

Chapter 1 – Non-NAT Setup Examples
Multi-Tech Systems, Inc. RF820/830 IPSec VPN Setup Examples – A Reference Guide 4
Chapter 1 – Non-NAT Setup
Examples
Prerequisite Step – Set Up VPN Client Using
IPSec VPN Client Software
The Non-NAT setup requires the VPN client to be set up first in the IPSec VPN Client software, and then
the VPN tunnel for the RouteFinder can be set up using the RouteFinder software.
Prerequisite Step 1 – VPN Client Phase 1 Set Up
1. Open the IPSec VPN Client software.
2. Right click on RouteFinder Client VPN Configuration and select New Phase 1.
3. Enter a name for your connection in the Name field.
4. Choose Any for the client Interface if your IP address is dynamic or the IP address
provided by your ISP if Static (e.g., 65.126.90.250).
5. In the Remote Gateway field, enter the IP address of the VPN WAN for your Remote
Gateway (e.g., 65.126.90.248).
6. Enter the Shared Secret in Preshared Key for your network (the Secret has to match
on both ends). Then Confirm the shared secret by retyping the shared secret.
7. For IKE Authentication choose MD5.

Chapter 1 – Non-NAT Setup Examples
Multi-Tech Systems, Inc. RF820/830 IPSec VPN Setup Examples – A Reference Guide 5
Prerequisite Step 2 – Phase 2 Setup
1. Start Phase 2 by right clicking on the name of your VPN Client you created in Phase 1.
2. The VPN Client address will be set to 0.0.0.0 unless you have a Static IP address (e.g.,
65.126.90.250).
3. The Address type is the type of setup on the host side. If it’s a network, then choose
Subnet address from the drop down list box and enter in the Remote LAN address
(e.g., 192.168.25.0) and the Subnet Mask (e.g., 255.255.255.0). If it’s a single IP
address, change it to that address.
4. For ESP Authentication choose MD5.

Chapter 1 – Non-NAT Setup Examples
Multi-Tech Systems, Inc. RF820/830 IPSec VPN Setup Examples – A Reference Guide 6
Example 1 – Set Up a RouteFinder and a VPN
Client Behind a Non-NAT Device
Note: Prerequisite Steps must be completed before you start this setup.
Step 1 – Network Setup
1. Log in to your RF820 or RF830 and go to the Networks & Services screen.
2. Enter the Name of the network that you want to create for this connection.
Example: vpn-client.
3. Enter the IP Address of this new network. Example: 65.126.90.250
4. Enter the Subnet Mask for this network. The same address/mask pair should not be present
in the current list displayed on the screen.
5. Click the ADD button to add the new network
Note: Pictured below is an RF820 screen with the single WAN ports. The RF830 screen is the
same except for the addition of WAN2 and WAN2Interface Names.

Chapter 1 – Non-NAT Setup Examples
Multi-Tech Systems, Inc. RF820/830 IPSec VPN Setup Examples – A Reference Guide 7
Step 2 – Packet Filters
1. Go to the Packet Filters screen to set the VPN client rights. These rights give the client
access across the tunnel to your host network.
2. Click on From (Host/Networks) and select the network you are allowing.
Example: vpn-client.
3. If you are not restricting the type of service, select Any for the To (Host/Network).
4. If the client is dynamic (unknown), set up an Any Any Any ACCEPT filter to allow any
network to come in.
5. Click the Add button to add this Packet Filter rule.
Important Note: Do not check the Status box. When adding a user-defined rule, leave the Status
box unchecked.

Chapter 1 – Non-NAT Setup Examples
Multi-Tech Systems, Inc. RF820/830 IPSec VPN Setup Examples – A Reference Guide 8
Step 3 – VPN Setup
1. Go to the VPN > IPSec screen.
2. Click the VPN Status check box to enable IPSec. Then click the Save button.
3. Select Add an IKE Connection by clicking the corresponding Add button.
The Add an IKE Connection screen displays. All settings can be left at the default unless
otherwise indicated:
1. Connection Name: Enter in the name of the VPN tunnel you want to create. Example: vpn-
client.
2. Secret: Enter in the Secret (which has to match on both ends of the tunnel)
3. Local WAN IP: Select WAN1
4. Local LAN: Select LAN
5. Remote LAN: Select vpn-client. Note that you select Any if the Remote Client is dynamic.
6. Click the Save button to save your tunnel.

Chapter 1 – Non-NAT Setup Examples
Multi-Tech Systems, Inc. RF820/830 IPSec VPN Setup Examples – A Reference Guide 9
Note:
Make sure to check the Status box at the bottom of the screen on the left side to activate the
newly created tunnel.
Step 4 – Save and Restart
Click the Save & Restart button located just under the menu bar. The Save and Restart screen
displays.
Save to Flash Memory
If a connection is established, then the settings have been entered correctly and your basic
configuration is now complete. Now, you must save your settings to the Flash Memory; this saves
the current settings in the flash prom and prevents settings from getting lost at the next power up.
Restart
This is optional. You do not have to restart the RouteFinder after saving to the flash memory.
Step 5 – Checking the Tunnel
To see if the tunnel is up you can click on Statistics & Logs and go to the IPSec Live Log. You
will see whether or not the connection is up. You will also see information about the data, if any,
that is being sent across the tunnel.

Chapter 1 – Non-NAT Setup Examples
Multi-Tech Systems, Inc. RF820/830 IPSec VPN Setup Examples – A Reference Guide 10
Example 2 – A Setup Using Two RouteFinders
Behind a Non-NAT Device
Side A Side B
Note: Prerequisite Steps must be completed before you start this setup.
The Following Directions Apply to Side A of Example 2
Step 1 for Side A – Network Setup
1. Log in to your RF830 or RF820 and go to the Networks & Services screen.
2. Enter a Name for the remote WAN IP address. Example: Remote-WAN
3. Enter the remote WAN IP Address (Ex. 65.126.90.250) with a single Subnet Mask of
255.255.255.255
4. Click Add to add the network to the list
5. Enter a Name for the remote LAN IP Address. Example: Remote-LAN
6. Enter the remote LAN IP Address (Ex. 192.168.2.0) with a network Subnet Mask for the
255.255.255.0.
Note: Pictured below is an RF820 screen with the single WAN ports. The RF830 screen is
the same except for the addition of WAN2 and WAN2Interface Names.
Remote-WAN 65.126.90.248 255.255.255.255 Edit | Delete
Remote-LAN 192.168.25.0 255.255.255.0 Edit | Delete
Once the network configuration is complete, the information about that network displays at the
bottom of the screen.

Chapter 1 – Non-NAT Setup Examples
Multi-Tech Systems, Inc. RF820/830 IPSec VPN Setup Examples – A Reference Guide 11
Step 2 for Side A – Packet Filters
1. Go to the Packet Filters screen to setup another network across the VPN tunnel with the
rights to access across the tunnel
2. Click on From (Host/Networks) and select the network you are allowing. Example: ANY.
Note that you should already have the LAN Any Any Accept listed.
3. If you are not restricting the type of service, select Any for the To (Host/Network).
4. Click the Add button to add the Packet Filter rule.
Important Note: Do not check the Status box. When adding a user-defined rule, leave the
Status box unchecked.
Step 3 for Side A –VPN Setup
1. Go to the VPN > IPSec screen.
2. Click the VPN Status check box to enable IPSec. Then click the Save button.
3. Select Add an IKE Connection by clicking the corresponding Add button.

Chapter 1 – Non-NAT Setup Examples
Multi-Tech Systems, Inc. RF820/830 IPSec VPN Setup Examples – A Reference Guide 12
The Add an IKE Connection screen displays. All settings can be left at the default unless
otherwise indicated:
1. Connection Name: Enter in the name of the VPN tunnel you want to create. Example:
test-tunnel
2. Secret: Enter in the Secret (which has to match on both ends of the tunnel)
3. Local WAN IP: Select WAN1
4. Local LAN: Select LAN
5. Remote LAN: Select Remote-LAN. Note that you should select ANY if the network is
unknown or the name you created is for the static IP)
6. Click the Save button to save your tunnel.
Note:
Make sure to check the Status box at the bottom of the screen on the left side to activate the
newly created tunnel.

Chapter 1 – Non-NAT Setup Examples
Multi-Tech Systems, Inc. RF820/830 IPSec VPN Setup Examples – A Reference Guide 13
Step 4 for Side A – Save and Restart
Click the Save & Restart button located just under the menu bar. The Save and Restart screen
displays.
Save to Flash Memory
If a connection is established, then the settings have been entered correctly and your basic
configuration is now complete. Now, you must save your settings to the Flash Memory; this saves the
current settings in the flash prom and prevents settings from getting lost at the next power up.
Restart
This is optional. You do not have to restart the RouteFinder after saving to the flash memory.
Step 5 for Side A – Checking the Tunnel
To see if the tunnel is up you can click on Statistics & logs and go to the IPSec Live Log. You will
see the connection up; and if any data is being sent across, you will see that information here.

Chapter 1 – Non-NAT Setup Examples
Multi-Tech Systems, Inc. RF820/830 IPSec VPN Setup Examples – A Reference Guide 14
The Following Directions Apply to the RF830 (Side B)
Step 1 for Side B – Network Setup
1. Log in to your RF830 or RF820 and go to Networks & Services screen.
2. Enter a Name for the remote WAN IP address. Example: remote-WAN
3. Enter the remote WAN IP Address (Ex. 65.126.90.248) with a single Subnet Mask of
255.255.255.255.
4. Click Add to add the network to the list.
5. Enter a Name for the remote LAN IP address. Example: Remote-LAN
6. Enter the remote LAN IP Address (Ex. 192.168.25.0) with a network Subnet Mask of
255.255.255.0.
Note: Pictured below is an RF820 screen with the one WAN port. The RF830 screen is the same
except for the addition of the WAN2 and WAN2Interface Names.

Chapter 1 – Non-NAT Setup Examples
Multi-Tech Systems, Inc. RF820/830 IPSec VPN Setup Examples – A Reference Guide 15
Step 2 for Side B – Packet Filters
1. Go to the Packet Filters screen to setup the other network across the VPN tunnel with the
rights to access across the tunnel
2. Click on From (Host/Networks) and select the network you are allowing (you should already
have the LAN Any Any Accept listed).
3. If you are not restricting the type of service, select Any for the To (Host/Network).
4. Click the Add button to add the Packet Filter rule.
Important Note: Do not check the Status box. When adding a user-defined rule, leave the
Status box unchecked.
Step 3 for Side B – VPN Setup
1. Go to the VPN > IPSec screen.
2. Click the VPN Status check box to enable IPSec. Then click the Save button.
3. Select Add an IKE Connection by clicking the corresponding Add button.

Chapter 1 – Non-NAT Setup Examples
Multi-Tech Systems, Inc. RF820/830 IPSec VPN Setup Examples – A Reference Guide 16
The Add an IKE Connection screen displays. All settings can be left at the default unless
otherwise indicated:
1. Connection Name: Enter in the name of the VPN tunnel you want to create. Example:
test-tunnel.
2. Secret: Enter in the Secret (which has to match on both ends of the tunnel)
3. Local WAN IP: Select WAN1
4. Local LAN: Select LAN
5. Remote LAN: Select Remote-LAN (Select Any if unknown or the name you created
has a static IP)
6. Click the Save button to save your tunnel.
Note:
Make sure to check the Status box at the bottom of the screen on the left side to activate the
newly created tunnel.

Chapter 1 – Non-NAT Setup Examples
Multi-Tech Systems, Inc. RF820/830 IPSec VPN Setup Examples – A Reference Guide 17
Step 4 for Side B – Save and Restart
Click the Save & Restart button located just under the menu bar. The Save and Restart screen
displays.
Save to Flash Memory
If a connection is established, then the settings have been entered correctly and your basic
configuration is now complete. Now, you must save your settings to the Flash Memory; this saves the
current settings in the flash prom and prevents settings from getting lost at the next power up.
Restart
This is optional. You do not have to restart the RouteFinder after saving to the flash memory.
Step 5 for Side B – Checking the Tunnel
To see if the tunnel is up you can click on Statistics & Logs and go to the IPSec Live Log. You will
see whether or not the connection is up. You will also see the information, if any, about the data being
sent across the tunnel.

Chapter 2 – Behind NAT Setup Examples
Multi-Tech Systems, Inc. RF820/830 IPSec VPN Setup Examples – A Reference Guide 18
Chapter 2 – NAT Setup Examples
Prerequisite Steps – Set Up VPN Client Using
IPSec VPN Client Software
The NAT setup requires the VPN client to be set up first in the IPSec VPN Client software, and then the
VPN tunnel for the RouteFinder can be set up using the RouteFinder software.
Prerequisite Step 1 – VPN Client Phase 1 Setup
(Behind NAT)
1. Open the IPSec VPN Client software.
2. Right click on RouteFinder Client VPN Configuration and select New Phase 1.
3. Enter the name of your connection in the Name field.
4. Choose Any for the client Interface if your IP address is dynamic or the IP address provided
by your ISP is Static. Example: 65.126.90.250.
5. Enter the IP address of the VPN WAN for your Remote Gateway. Example: 65.126.90.248.
6. Enter the Shared Secret in Preshared Key for your network (the secret has to match on both
ends). Then Confirm the shared secret by entering the Shared Secret again.
7. For IKE Authentication choose MD5.
8. Click the P1 Advanced button.

Chapter 2 – Behind NAT Setup Examples
Multi-Tech Systems, Inc. RF820/830 IPSec VPN Setup Examples – A Reference Guide 19
Prerequisite Step 2 – Client Phase 1 Advanced
Setup (Behind NAT)
This screen displays after clicking the P1 Advanced button on the previous screen.
1. Select the IP Address from the drop down list box for the Local ID.
2. Then enter the IP address of the VPN Client in the text box labeled Set the value for the ID
field. Example: 192.168.2.8
3. Select IP Address for the Remote ID.
4. Then enter the IP address of the RouteFinder in the Set the value for the ID field. Example:
65.126.90.248
5. Click OK.

Chapter 2 – Behind NAT Setup Examples
Multi-Tech Systems, Inc. RF820/830 IPSec VPN Setup Examples – A Reference Guide 20
Prerequisite Step 3 – Client Phase 2 Setup (Behind
NAT)
1. Start Phase 2 by right clicking on the name of your VPN Client you created in Phase 1.
2. The VPN Client address will be set to 0.0.0.0 unless you have a Static IP address. Example:
65.126.90.250
3. The Address type is the type of setup on the host side. If it’s a network, then choose
Subnet address and enter the Remote LAN address (Ex. 192.168.25.0) and the Subnet
Mask (Ex. 255.255.255.0). If it’s a single IP address, change it to that address.
4. For ESP Authentication choose MD5.
5. Click OK.
