Muratec MFX-1330 Installation and operation manual

Muratec
MFX-1330 / F-300
FACSIMILE SYSTEM
FIELD ENGINEERING MANUAL
U.S.A. version 2.0
Muratec America, Inc.
3301 East Plano Parkway, Ste. 100
Plano, Tx 75074
[phone] (Tel)
[phone] (Fax)
www.muratec.com

Safety Information
LED Safety Label
A LED safety label is attached to the outside of the machine as shown below.
Battery Precautions
CAUTION
Danger of explosion if battery is incorrectly replaced.
Replace only with the same or equivalent type recommended by the manufacturer.
Dispose of used batteries according to the manufacturer’s instructions.
Important: Muratec does not recommend the independent replacement of this battery.
The battery is sold only as a component part of the main control PCB and Battery
PCB, and cannot be purchased separately from Muratec.
Il y a un danger d'explosion s'il y a un remplacement incorrect de la batterie.
Remplacer uniquement avec une batterie du même type ou d'un type recommandé par le
constructeur. Mettre au rebut les batteries usagées conformement aux instructions du fabricant.
Germany only
VORSICHT!
Explosinsgefahr bei unsachgemäßen austausch der batterie.
Ersatz nur durch denselben oder einen vom hersteller empfohlenen ähnlichen typ. Entsorgung
gebrauchter batterien nach angaben des herstellers.
Denmark only
ADVARSEL!
Lithiumbatteri - Eksplosionsfare ved fejlagtig håndtering
Udskiftning må kun ske med batteri af samme fabrikat og type.
Levér det brugte batteri tilbage til leverandøren.
Norway only
ADVARSEL
Eksplosjonsfare ved feilaktig skifte av batteri.
Benytt samme batteritype eller en tilsvarende type anbefalt av apparatfabrikanten.
Brukte batterier kasseres i henhold til fabrikantens instruksjoner.

Sweden only
VARNING
Explosionsfara vid felaktigt batteribyte.
Använd samma batterityp eller en ekvivalent typ som rekommenderas av apparattillverkaren.
Kassera använt batteri enligt fabrikantens instruktion.
Finland only
VAROlTUS
Paristo voi räjähtää, los se on virheellisesti asennettu.
Vaihda paristo ainoastaan laitevalmistajan suosittelemaan tyyppiin.
Hävitä Käytetty paristo valmistajan ohjeiden mukaisesti.
ALL Areas
CAUTION
“Replace only with the same or equivalent type recommended by the manufacturer.
Dispose of used IC Package according to the manufacturer’s instructions.”
Germany only
VORSICHT!
”Austausch nur durch denselben oder einen vom Hersteller empfohlenen,
gleichwertigen typ. Entsorgung gebrauchter Batterien nach Angaben des Herstellers.

i
Table of Contents
Section 1 General Description ................................................ 1-1
1.1 Product Description..............................................................................................................................1-1
1.2 Specifications .......................................................................................................................................1-2
Section2 Machine Composition.............................................. 2-1
2.1 Interconnect Block Diagram ................................................................................................................2-1
2.2 Main Control PCB ................................................................................................................................2-3
2.3 Network Control Unit (NCU) PCB ........................................................................................................ 2-4
2.4 Power Supply Unit (PSU).....................................................................................................................2-5
2.5 Sensors ................................................................................................................................................2-6
2.5.1 Sensor Locations .......................................................................................................................... 2-6
2.5.2 Sensor Descriptions......................................................................................................................2-7
2.6 Document Scanning Sequence ........................................................................................................... 2-8
2.6.1 ADF Detection ..............................................................................................................................2-8
2.6.2 FBS section (MFX-1330 only) ......................................................................................................2-9
2.7 Recording Section..............................................................................................................................2-11
2.7.1 Recording Paper Feed Path ....................................................................................................... 2-11
2.8 Image Processing .............................................................................................................................. 2-12
2.8.1 Drum Charge .............................................................................................................................. 2-12
2.8.2 Drum Exposure...........................................................................................................................2-12
2.8.3 Development...............................................................................................................................2-13
2.8.4 Image Transfer ...........................................................................................................................2-13
2.8.5 Erasing........................................................................................................................................ 2-14
2.8.6 Cleaning...................................................................................................................................... 2-14
2.8.7 Fusing .........................................................................................................................................2-15
Section3 Adjustment Procedures........................................... 3-1
3.1 Field Service Program Modes.............................................................................................................. 3-1
3.2 Machine Parameter Adjustment........................................................................................................... 3-3
3.2.1 Setting the Machine Parameters ..................................................................................................3-3
3.2.2 Clearing the Machine Parameters ................................................................................................ 3-3
3.3 Memory Switch Adjustment ...............................................................................................................3-48
3.3.1 Setting the Memory Switches .....................................................................................................3-48
3.3.2 Clearing the Memory Switches...................................................................................................3-48
3.4 Clear Programmed Data / User Settings ........................................................................................... 3-68
3.5 All RAM Clear.....................................................................................................................................3-69
3.6 Setting Individual Autodialer Attributes .............................................................................................. 3-69
3.7 Unique Switch Adjustment .................................................................................................................3-74
3.7.1 Setting the Unique Switches.......................................................................................................3-74
3.7.2 Clearing the Unique Switches ....................................................................................................3-74
3.8 Printer maintenance mode.................................................................................................................3-97
3.9 Monitor speaker .................................................................................................................................3-98
3.10 Test Modes ...................................................................................................................................... 3-98
3.10.1 Life Monitor ...............................................................................................................................3-99
3.10.2 Printer Test .............................................................................................................................3-100
3.10.3 Feeder test..............................................................................................................................3-101
3.10.4 Port Status ..............................................................................................................................3-101
3.10.5 Set Background Level ............................................................................................................3-101
3.11 Print Machine Parameters, Memory Switch and Unique Switch Settings .....................................3-102
3.12 Factory Functions ..........................................................................................................................3-102
3.12.1 Function List ...........................................................................................................................3-102
3.12.2 LED Test.................................................................................................................................3-102
3.12.3 LCD Test................................................................................................................................. 3-103
3.12.4 Key Panel Test .......................................................................................................................3-103
3.12.5 SRAM Check ..........................................................................................................................3-104

ii
3.12.6 DRAM Check ..........................................................................................................................3-104
3.12.7 RTC(real time clock) Test.......................................................................................................3-105
3.12.8 Page memory check...............................................................................................................3-105
3.12.9 Generate bell test ...................................................................................................................3-105
3.13 Line Tests.......................................................................................................................................3-106
3.13.1 Relay Test...............................................................................................................................3-106
3.13.2 Tonal Signal Test....................................................................................................................3-106
3.13.3 DTMF Output Test .................................................................................................................. 3-108
3.14 Mirror Carriage Transfer Mode ......................................................................................................3-109
3.15 Consumable order sheet................................................................................................................3-110
3.15.1 Set consumable order sheet...................................................................................................3-111
3.15.2 Clear consumable order sheet ...............................................................................................3-112
3.15.3 Print consumable order sheet................................................................................................. 3-112
3.16 DRAM Clear ...................................................................................................................................3-113
3.17 Clear Life Monitor........................................................................................................................... 3-113
3.18 Clear Optional Data .......................................................................................................................3-114
3.19 Set Service Code ...........................................................................................................................3-114
3.20 Life monitor maintenance...............................................................................................................3-115
3.21 Sensor input test ............................................................................................................................ 3-116
3.22 Printer diagnostic mode .................................................................................................................3-117
3.23 Network service mode ...................................................................................................................3-117
3.23.1 Display the server sum-check ................................................................................................3-117
3.23.2 Clear the Administrator’s information .....................................................................................3-117
3.23.3 All clear the registered parameters of the network board ......................................................3-117
3.24 Multi Line Settings..........................................................................................................................3-118
3.25 Flash Rom Sum Check ..................................................................................................................3-119
3.26 Printer registration adjustment.......................................................................................................3-119
3.27 Set Service Report.........................................................................................................................3-119
3.27.1 Set the service report..............................................................................................................3-119
3.27.2 Clear service report ................................................................................................................3-120
3.28 Quick Initial settings .......................................................................................................................3-121
3.28 Update the software.......................................................................................................................3-127
3.28.1 Install the update application on PC .......................................................................................3-127
3.28.2 Installing the USB driver on the PC ........................................................................................ 3-128
3.28.3 Updating the software using the PC.......................................................................................3-131
Error code ..........................................................................................................................................3-133
Section4 Troubleshooting Procedures ..................................4-1
4.1 Troubleshooting Outline.......................................................................................................................4-1
4.2 Recording Paper Jam ..........................................................................................................................4-2
4.3 Document Feeder Jam ........................................................................................................................ 4-2
4.4 Document Feeder Multi-feeding or Skew ............................................................................................ 4-3
4.5 Mirror Carriage Error (MFX-1330 only)................................................................................................4-3
4.6 Transmit Error ......................................................................................................................................4-3
4.7 Transmit Black Lines............................................................................................................................ 4-3
4.8 Cannot transmit.................................................................................................................................... 4-4
4.9 Receive Errors ..................................................................................................................................... 4-4
4.10 Will not Auto-Answer.......................................................................................................................... 4-4
4.11 Clearing Jammed Paper ....................................................................................................................4-5
If the original document jams................................................................................................................. 4-5
To remove the document:......................................................................................................................4-6
If a printout jams inside your machine ................................................................................................... 4-8
4.12. The Image Quality Problems ..........................................................................................................4-11
4.12.1 Blank pages ..............................................................................................................................4-11
4.12.2 Black pages ..............................................................................................................................4-11
4.12.3 Printout too light........................................................................................................................4-12
4.12.4 Printout too dark .......................................................................................................................4-12
4.12.5 Blurred background .................................................................................................................. 4-12

iii
4.12.6 Uneven print density................................................................................................................. 4-13
4.12.7 Irregularities ..............................................................................................................................4-13
4.12.8 White (Black) Line.....................................................................................................................4-14
4.12.9 Toner Smudges ........................................................................................................................4-14
4.13 LCD Error Messages .......................................................................................................................4-15
LCD error messages (Alphabetic list)..................................................................................................4-15
4.14 Error Codes......................................................................................................................................4-20
Dialing errors .......................................................................................................................................4-20
Reception errors ..................................................................................................................................4-20
Transmission errors .............................................................................................................................4-21
Communication Error Messages .........................................................................................................4-22
4.15 Service Call Error .............................................................................................................................4-23
4.15.1 Call For Service ........................................................................................................................4-23
4.15.2 Please Call Service...................................................................................................................4-23
4.16 LCD Failure ......................................................................................................................................4-26
4.17 General Power Failure ..................................................................................................................... 4-26
4.18 Cleaning the Unit..............................................................................................................................4-27
Curing frequent jams in the ADF ......................................................................................................... 4-27
Cleaning the Document glass, ADF glass and Document pad ...........................................................4-28
Cleaning the drum chare wire and LED print head .............................................................................4-28
Section5 Maintenance & Adjustment ..................................... 5-1
5.1 Maintenance schedule ......................................................................................................................... 5-2
5.2 Re/Disassemble...................................................................................................................................5-3
5.2.1 COVERS.......................................................................................................................................5-5
5.2.2 PCBS .......................................................................................................................................... 5-15
5.2.3 SCANNING SECTION................................................................................................................5-24
5.2.4 PRINTER SECTION ................................................................................................................... 5-42
5.3 Adjustment ......................................................................................................................................... 5-72
5.3.1 Outline of printer registration adjustment ...................................................................................5-72
5.3.2 Printer registration mode ............................................................................................................5-72
5.3.3 Printer registration (top).............................................................................................................. 5-73
5.3.4 Printer registration (side) ............................................................................................................5-74
5.3.5 FBS zoom adjustment (Vertical).................................................................................................5-75
5.3.6 FBS zoom adjustment (Horizontal).............................................................................................5-76
5.3.7 ADF zoom adjustment (Vertical).................................................................................................5-77
5.3.8 ADF zoom adjustment (Horizontal) ............................................................................................5-78
5.3.9 FBS registration (top).................................................................................................................. 5-79
5.3.10 FBS registration (side)..............................................................................................................5-80
5.3.11 ADF registration (top) ...............................................................................................................5-81
5.3.12 ADF registration (side)..............................................................................................................5-82
5.3.13 SEPARATION PRESSURE ADJUSTMENT ............................................................................ 5-83
5.3.14 Cleaning the MIRRORS A, B and C .........................................................................................5-84
5.3.15 Applying the SHEET DOCUMENT PRESS (MFX-1330 only)..................................................5-85
Section 6 Options..................................................................... 6-1
6.1 Memory Upgrade ................................................................................................................................. 6-1
Packaging contents: ..............................................................................................................................6-1
Installation..............................................................................................................................................6-1
6.2 Second paper cassette ........................................................................................................................6-3
Packaging contents: ..............................................................................................................................6-3
Installation..............................................................................................................................................6-3
6.3 Page Counter .......................................................................................................................................6-5
Packaging contents: ..............................................................................................................................6-5
Installation..............................................................................................................................................6-5
6.4 PCL printer controller ...........................................................................................................................6-7
Packaging contents: ..............................................................................................................................6-7
Installation..............................................................................................................................................6-7
6.5 Network interface board.......................................................................................................................6-8
Packaging contents: ..............................................................................................................................6-8
Installation..............................................................................................................................................6-8

iv
6.6 Second phone line kit.........................................................................................................................6-11
Packaging contents: ............................................................................................................................6-11
Installation............................................................................................................................................6-11

1-1
Section 1
General Description
1.1 Product Description
The MFX-1330 and F-300 are Multi-function products with flat bed scanner (MFX-1330) and Group 3 and
V.34 HDX modem facsimile machine. Documents are printed on plain paper using dry
electrophotographic printing.
Bypass Tray
Automatic
Document Feeder
Control Panel
Paper Cassette
2nd Paper Cassette
(Option)
1st Side Cover
2nd Side Cover
Front Cover
Paper Level
Indicator
Document
Guides
Document
Tray Document
Exit Tray
LINE
PHONE1
PHONE2
Document Glass
Power Switch
AC Power Jack
Telephone
Connectors
Platen Cover
Paper Exit Tray
Second phone line kit (Option)
Network Connector (Option)
USB Connector
LINE
PHONE1
PHONE2
Note: F-300 has no document glass.

1-2
1.2 Specifications
Item MFX-1330 F-300
Type Desktop type
Telephone network PSTN (Public Switched Telephone Network) or equivalent.
Compatibility ITU-T T.4 and T.30
Coding method ITU-T-standard MH, MR, MMR and JBIG
Modem speed 33600, 31200, 28800, 26400, 24000, 21600, 19200, 16800, 14400,
12000, 9600, 7200, 4800 and 2400 bps
Dual Access Allows up to three simultaneous operations.
LCD 2 lines, 20 characters per line.
Language: English, French, Spanish
Scanning method B/W and Color CCD
Recording method Dry electrophotographic (LED) printer
<ADF>
Single sheet Two or more sheets
Max: 216 (W) 900 (L) mm 216 (W) 356 (L) mm
8.5 (W) 35.4 (L) inches 8.5 (W) 14.0 (L) inches
Min: 120 (W) 100 (L) mm 216 (W) 139.5m (L) mm
4.7 (W) 25.4 (L) inches 8.5 (W) 55.0 (L) inches
Paper weight: 35 – 128 g/m252 – 105 g/m2
Thickness: 0.05 – 0.15 mm 0.07 – 0.12 mm
Acceptable document
size
<FBS glass>
Max: 216mm (W) 356 (L)
Min: No limit
—
ADF capacity Letter, Legal, Half-letter : 80 sheets (Paper weight: 75.0 g/m2)
<Transmission>
horizontal vertical
(in dots/inch in lines/inch)
Normal: 203 98
Fine: 203 196
Super fine: 406 392* or 600dpi 600lpi
Grayscale: 203 196
*: In the case that the remote fax has the ability of “406 392”. If not, the
superfine resolution is “203 392“, and the grayscale resolution is “203
196”.
<Copy>
600 300 dpi (600 600 dpi for ultra fine)
Scanning resolution
<Scanner (TWAIN)>
200 dpi 200 dpi 200 lpi
300 dpi 300 dpi 300 lpi
600 dpi 600 dpi 600 lpi
Effective Scanning width 208 mm (Fax), 216 mm (Copy)
Transmission speed Under 3 seconds (Super G3)
Based on transmission of ITU-T Test Document 1 to a Muratec fax
machine.
Document Memory Standard: 8 MB (650 pages)
Upgrade option: plus 32MB (2720 pages)
Document memory
backup
(Total memory capacity: Backup time)
8 MB: 72 hour
40 MB: 24 hours
The backup battery requires about 24 hours to reach full charge after
power to the fax unit is restored.
Printing resolution 600 dpi

1-3
Item MFX-1330 F-300
Printing speed
Simplex printing: 13 ppm
Duplex printing : 5 ppm
(When loading Letter-sized paper
from 1st paper cassette.)
13 ppm (When loading Letter-
sized paper from 1st paper
cassette.)
Toner yield Approx. 5,000 pages
(Letter, 6 % document coverage
under 2-pages interval printing.)
Approx. 7,500 pages
(Letter, 6 % document coverage
under 2-pages interval printing.)
Drum yield Approx. 20,000 pages
(Letter, 6 % document coverage under 2-pages interval printing.)
Print margin Reading edge, Trailing edge, Left edge and Right edge:
0.12 ± 0.08 inch (3 ± 2 mm)
Simplex printing
<Paper cassette>
Plain paper: Letter(SEF), Legal(SEF), Half letter (LEF),
Paper weight: 60 – 90g/m2, 20 – 24 lb
<Bypass tray>
Plain paper: Letter(SEF), Legal(SEF), Half letter(LEF),
A4(SEF), A5(LEF)(SEF), A6(SEF), F4(SEF),
Executive(SEF)
Envelopes: DL(SEF), COM10(SEF), Monarch(SEF)
Postcard: 100 mm (W) 148 mm (L) (3.9 5.8 inch)
Transparency: Letter (SEF)
Custom size: (3.8 – 8.5 inch) (5.5 – 14 inch) (Width Length)
*The paper except Letter, Legal Half-letter are available only when the
optional printer controller kit has been installed.
Acceptable recording
paper
Duplex printing
<Paper cassette>
Plain paper: Letter(SEF),
Legal(SEF)
<Bypass tray>
Plain paper: Letter(SEF),
Legal(SEF)
—
Recording paper capacity <Paper cassette>
1st cassette: 500 sheets
2nd cassette (option): 500 sheets
<Bypass tray>
Plain paper: 50 sheet
Postcard/Transparency: 20 sheets
Envelopes 1 sheet
Receive paper tray
capacity
Approx. 250 sheets
Printouts exit Face down
Environmental conditions Ambient temperature: 10 C to 32 C (50 F to 89.6 F)
Relative humidity: 20 % to 80 % with no condensation
Power requirements 120 VAC ± 10 %; 50/60 Hz
Power consumption Sleep mode: 10.0 W
Standby: 40 Wh
Memory Transmission: 28 W
Reception: 1030 W
Copying: 1030 W
Maximum: 1040 W

1-4
Item MFX-1330 F-300
Dimensions Standard: 520mm (W) 450 mm (D) 446 mm (H)
With optional cassette: 520mm (W) 450 mm (D) 566 mm (H)
520 mm
446 mm
450 mm
350 mm
520 mm
120 mm
Weight Approx. 21.1 Kg (46.5 lbs) without
consumables and trays.
Approx. 19.0 Kg (41.9 lbs) without
consumables and trays.
Optional
products
Optional telephone handset
Second paper cassette
Upgrade memory
PCL printer controller
Network interface board
Second phone line kit
Mechanical page counter

Section2
Machine Composition
2.1 Interconnect Block Diagram (1/2)
1T(flat)
2T
DA7-08320-50B
H/L
HC1
HC2
+5VP
+5VP
GND
GND
+3.3VP
+3.3VP
GND
GND
+24VP
+24VP
GND
GND
DCB-21556-50A
VDD
VSS
VDD
VSS
VDD3
SO
SCK
/STROBE
DATA1
DATA2
DATA3
DATA4
/HSYNC
LOAD
GNDL
CLKN
CLKP
GNDL
DCB-51854-50A
DA7-08380-50B
DA7-08390-50B
DA7-08410-50B
DA7-08420-50A
DA7-08370-50A
DA7-08360-50A
DA7-08430-50B
PFCL2
Z90-48683-00
COUNTER
Z90-35223-50
PCB
MAIN
DA7-08010-50
184 x 184
(4 layers)
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
P3
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
1
2
3
4
5
6
7
8
9
10
11
12
1
2
3
4
5
6
7
8
9
10
11
12
P9A
P9B
PCB
CONNECT
A
DA7-08050-50
84 x 116
(simplex side)
NEWDRUM
FCUTDR
/DRUMSET
NEWDVLP
/FMLOCK
FCUTDV
FANMC
DVLPTYPE
+24V
+24V
NC
+24V
GND
NC
GND
GND
MDUP_A
/PSAVE2
MDUP_B
/PSAVE1
/MDUP_A
+5V
/MDUP_B
+5VA
OPDUP
/DUPS
/PDS
+3V
/JAMC1
THTMP
DCB-53008-50A
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
P8C
P8A
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
LED HEAD
Z90-49754-00
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
P7 PHD
EH
EH
PHD PHD P80C
P80A
PCB
CONNECT
B
DA7-08060-50
78 x 85
(simplex side)
/TRAYS
GND
+5VC
1
2
3
4
5
6
1
2
3
4
5
6
7
8
9
10
11
12
1
2
3
4
5
6
7
8
9
10
11
12
/PSS
GND
+5VC
1
2
3
4
5
6
7
8
9
10
11
12
13
14
1
2
3
4
5
6
7
8
9
10
11
12
13
14
+24V
/RESCL
1
2
3
4
5
6
7
8
9
10
11
1
2
3
4
5
6
7
8
9
10
11
PH
PH
PH
PH
P90A
P90B
1
2
1
2
P91
P92
P93
P94
PCB
PSU-100
DA7-08080-50
or
PSU-200
DA7-08070-50
160 x 163
(simplex side)
5T(large)
AC switch
DA7-08330-50B
3P
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
1 2
1 2
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
TRAYS
Z90-37777-50
PFCL
Z90-48683-00
1
2
3
1
2
3
PSS
Z90-37777-50
1
2
3
1
2
3
PES1
Z90-37777-50
OPEN1
Z90-37777-50
1
2
3
1
2
3
TS1
D88-09060-50
1
2
3
1
2
3
1
2
3
4
1
2
3
4
TS2
D88-09060-50
1
2
3
4
1
2
3
4
RESCL
Z90-47516-00
OPEN2
Z90-37777-50
PES2
Z90-37777-50
JAMC2
Z90-37777-50
1
2
3
1
2
3
1
2
3
1
2
3
1
2
3
1
2
3
+24V
/COUNT
DCB-D0224-50A
/OPEN1
GND
+5V
+5VC
TS1
GND
NC
+5VC
TS2
GND
NC
/PES1
GND
+5VC
/PES2
GND
+5VC
/OPEN2
GND
+5V
/JAMC2
GND
+5V
CBL ASSY PRINTER(DA7-08210-50E)
CBL ASSY CASSETTE(DA7-08220-50G)
CBL ASSY 2ND CASSETTE(DA7-08280-50C)
PHN
PH
PH
PH
PH
PH
PH
PH
PH
PH
1
2
3
4
5
6
1
2
3
4
5
6
COVER-SW
Interlock 24V
DA7-08310-40A
6
7
8
6
7
8
+24V
/FMLOCK
GND
FAN 80mm
ZA1-02364-40
1
2
3
1
2
3
1
2
3
1
2
3
4
5
6
1
2
3
4
5
6
1
2
3
1
2
1
2
3
4
5
3
4
5
Fusing thermistor
Z90-48783-00
/FCUTDR
LFCUTDR
DVTYPE2
/FCUTDV
PH
EH
EH
EH
PH
EH
PH
PH
PH
P88A
P90
P89
P86
P87
RX MOTER
Z90-48681-00
1
2
3
4
5
6
DUPE MOTOR
(Factory option)
Z90-48576-00
1
2
3
4
5
6
DUPS
Z90-37777-50
1
2
3
JAMC1
Z90-37777-50
1
2
3
1
2
3
PDS
Z90-37777-50
1
2
3
/DUPS
GND
+5VB
DCB-70338-50A
1
2
3
MOUP_A
MOUP_B
/MDUP_A
/MDUP_B
+24V
+24V
1
2
3
4
5
6
1
2
3
/JAMC1
GND
+5VA
/PDS
GND
+5VA
+24V
+24VA
+3.3V
THTMP
1
2
1
2
SM
CBL ASSY FUSE
(DA7-08260-50G)
CBL ASSY INTERLOCK24V
(DA7-08240-50E)
LDS1
/DS1
GND
DS1
D88-08190-50A
DS2
D88-08190-50A
/MADF_B
MADF_B
/MADF_A
MADF_A
TXIL
GND
APS
Z90-37777-50
MFBS_A
/MFBS_A
MFBS_B
/MFBS_B
FBS MOTOR
Z90-48578-00
1
2
3
4
1
2
3
4
1
2
3
1
2
3
LDS2A
/DS2
GND
1
2
3
1
2
3
TXIL
DA7-08340-40A
1
2
3
1
2
3
1
2
1
2
3
4
5
3
4
5
6
7
8
6
7
8
9
10
11
12
9
10
11
12
13
14
15
13
14
15
ASSY ADF(DA7-08230-40F)
EH
PHN
PH
PH
PH
P82
P83
/APS
GND
+5V
1
2
3
4
1
2
PCB
PSU HV
Z90-48829-00
(simplex side)
1
2
3
4
5
6
7
8
9
10
11
12
1
2
3
4
5
6
7
8
9
10
11
12
HVTR
HVTS
HVTN
HVTP
HVBS
HVBN
HVRLR
HVSFT
HVCP
GND
GND
+24V
(B to B)
1
2
3
P88B PH
CZ
BATT
ERS
+24V
+24V
COUNT
PFCL2
RESCL
PFCL1
TRYCL
GND
GND
TS2
(B to B)
TS1
+5V
PES
/OPEN1
/PSS
/TRAYS
+5VC
/JAMC2
/PES2
/OPEN2
/OPCSST2
GND
(B to B)
1
2
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
P18
Z90-28246-50A(USA/angle)
Inlet
DEVELOPER1(HV)
DEVELOPER2(HV)
CHARGER(HV)
GRID(HV)
TRANSFER(HV)
CLEANING2(HV)
CLEANING1(HV)
1
2
1
2
+24V
/PFCL2
+24V
/PFCL
11
12
9
10
CZ +24V
/TRYCL
TRYCL
Z90-47516-00
7
8
1
2
3
4
5
6
9
10
7
8
PHN
1
2
1
2
PHN
1
2
1
2
PHN
1
2
1
2
PCB
CONNECT
C
DA7-08100-50
35 x 55
(Duplex)
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
PHD
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
GND
CLK-P
CLK-N
GND
LOAD
HSYNC
DATA3
DATA2
DATA1
DATA0
STROBE
SCK
SO
+3.3V
LED_GND
VDD
LED_GND
VDD
LED_GND
VDD
LED_GND
VDD
LED_GND
VDD
(FFC)
ZA1-02462-40
135mm
FMN FMN
+24VB
/MLOCK
MTDIR
MTCLK
/MTEN
GND
GND
/COVER
/MADF_B
MADF_B
/MADF_A
MADF_A
/MFBS_B
MFBS_B
/MFBS_A
MFBS_A
/APS
/DS2
/DS1
/TXIL
(B to B)
9
10
11
9
10
11
1 1
2 2
3 3
4 4
5 5
6 6
7 7
1 2
GND
BATT
BATTERY
1 1
2 2
3 3
1 1
2 2
3 3
P95
1 2
/DRUMSET
LFCUTDV
DVTYPE1
PHN 1
2
1
2
1
2
DA1-08570-50A
DA1-08570-50A
PH
1
2
51006(molex)
51006(molex)
GND
+24VB
/MTEN
MLOCK
MTDIR
MTCLK
DCB-20622-50A
2T
3T(large)
CASSETTE(2ND) / DA71101010 CASSETTE / DA71100010 PRINTER FRAME/COVER / DA71050010
PRINTER FRAME/COVER / DA71050010
PRINTER FRAME/COVER / DA71050010
FBS/SCANNER
/ DA71010010 ADF / DA71000010
FAX FRAME/PCB MAIN / DA71030010
PHD PHD
PCB
NCU
(EUR)
DA7-Y8040-50
or
(USA)
DA7-08040-50
75 x 140
(simplex side)
TEL1
TEL2
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
LINE
Core
P4
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
+24VN
DP
+24VN
CML
GND
L
GND
H
+5V
S
+5V
RI
RXA
CONT24
+12V
OH1
TXA
OH2
GND
CI
AREF
DSE2
CNG
DSE1
-12V
NC
DCB-52634-50A
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
Option
P2
USB
DCB-xyyzz-50A
x : connector name / kind
1 : KR8M / UL1061 #28
2 : EHR / UL1007 #22
5 : PHDR / UL1061 #28
7 : PHR / UL1061 #28
D : PHNR / UL1061 #28
y : numbers
z : harness length (cm)
FUSER
HEATER (100V)
ZA1-02362-00
HEATER (200V)
ZA1-02363-20
Thermostat
Z07-47096-00
Temperature fuse
Z90-48827-00
3T(small)
OPTION(OTHER)
(Bracket)
PCB
DC/DC
DA7-08130-50
80x50
(simplex side)
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
+3.3DP
+3.3DP
GND
GND
+24V
+24V
GND
GND
DA7-08450-50A
P17
EH
EH
2T
OPTION(OTHER)
13
14
15
11
12
13
14
15
2T
2T
2T
2T
2T
PCB ERS LAMP
DA7-08170-50
+24V
/ERS
1
2
1
2
PHN 1
2
1
2
PHN
DCB-D0224-50A
ADF MOTOR
Z90-48577-00
1
2
3
4
1
2
3
4
PH
1
2
3
4
SM
1
2
3
4
*ASSY ADF EXTENSION (DA7-08500-50B) + core
(only added when PCL equip ed between P82 and ASSY ADF)
2-1

Interconnect Block Diagram (2/2)
FG wires
[ADF]
DFG-S3S3B-530
[ADF to REAR COVER]
DFG-S3S3B-520
[FBS]
DFG-S3S3B-527
[LEDHEAD]
DA7-08480-50A
[PRINTER]
DFG-S3S3B-509
DFG-S3S3B-512 x 3
DFG-S3S3B-518
[2ND CASSETTE]
DFG-S3S3B-527
Cores
Core (standard)
ZA1-00921-00
Core (large)
ZA1-02490-A0
Core (small)
ZA1-01031-50
Core (flat)
ZA1-01943-40
Core (flat A)
Z07-15820-80
Core (dividable)
ZA1-02491-00
+12V
+12V
BW/COL
+5V
+5V
+5V
GND
SH
GND
P1
GND
P2
GND
RS
GND
CP
PSAVE
CLM1
CLM0
GND
VIDEO
GND
HS
GND
GND24
GND24
GND24
+24V
+24V
+24V
(FFC)
(NGP only)
SCLKP
SCLKN
TXDP
TXDN
DCB-70488-50A
PCB
MAIN
DA7-08010-50
184 x 184
(4 layers)
PCB
PCL
DA5-08010-50
176 x 110
(4 layers)
1
2
3
4
5
6
7
8
9
11
10
12
13
15
14
16
17
19
18
20
21
23
22
24
25
27
26
28
29
31
30
32
33
35
34
36
37
39
38
40
41
43
42
44
45
47
46
48
49
50
1
2
3
4
5
6
7
8
9
10
11
12
13
15
14
16
17
19
18
20
21
23
22
24
25
27
26
28
29
31
30
32
33
35
34
36
37
39
38
40
41
43
42
44
45
47
46
48
49
50
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
PCB
PANEL
DA7-08020-50
330 x 87
(simplex side)
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
P5
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
P6
PCB
EX.MEMORY
DA1-08120-50
60 x 40
t=10
(4 layers)
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
P1
VSS
A3
A4
A2
A5
A1
A6
A0
A7
VDD
PD1
VSS
VDD
VSS
A8
A10
A9
BS1
A11
/BS0
A12
VDD
VSS
/CS0
/CKE
/CS1
/CS2
/CS3
/VDD
RAS
VSS
/CAS
VSS
VSS
CLK
VSS
VSS
WE
N.C
VDD
VDD
VDD
VDD
DQML
DQMU
DQ7
DQ8
DQ6
DQ9
DQ5
DQ10
DQ4
DQ11
DQ3
DQ12
DQ2
DQ13
VSS
VDD
VSS
VDD
DQ1
DQ14
DQ0
DQ15
PD2
PD3
PD4
PD5
PD6
PD7
VSS
(B to B)
PCB
LIME2
DA5-08020-50
176 x 136
(4 layers)
or
PCB
NETWORK
DA4-0801*-50
176 x 90
(4 layers)
1
2
3
4
5
6
7
8
9
11
10
12
13
15
14
16
17
19
18
20
21
23
22
24
25
27
26
28
29
31
30
32
33
35
34
36
37
39
38
40
41
43
42
44
45
47
46
48
49
50
1
2
3
4
5
6
7
8
9
10
11
12
13
15
14
16
17
19
18
20
21
23
22
24
25
27
26
28
29
31
30
32
33
35
34
36
37
39
38
40
41
43
42
44
45
47
46
48
49
50
PCB
EXT LINE
DA5-08020-50
114 x 74
(4 layers)
or
PARALLEL
DA7-08140-50
122.5 x 90
(4 layers)
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
PCB
NCU
(EUR)
DA7-Y8040-50
or
(USA)
DA7-08040-50
75 x 140
(simplex side)
TEL1
TEL2
LINE
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
P10
A8
A7
GND
A6
D15
D14
GND
D13
D12
D11
GND
D10
D9
D8
GND
D7
D6
D5
GND
D4
D3
D2
GND
D1
D0
A5
GND
A4
A3
A2
GND
A1
+5V
+5V
GND
/RD
/WR
/CSPORT
/CSHDD
/CSCDC
/CSMDM
REQENC
/RESET
REQDEC
+3.3V
+3.3V
GND
/ACKENC
/ACKDEC
/INTCI
IO0
/INTCDC
/IMTMDM
REQTX
GND
REQRX
BUSY
+12V
GND
RXSIG
-12V
+24V
GND
GND
HI/MID
IO1
GND
NC
(B to B)
KR KR
PHD PHD
P12
P11
PCB
CCD
DA7-08030-50
35 x 176
(4 layers)
+24V
GND
DCB-20210-50A
1
2
1
2
HS
Z90-37777-50
1
2
3
1
2
3
1
2
3
1
2
3
30
29
28
27
26
25
24
23
22
21
20
19
18
17
15
14
13
12
11
10
9
8
7
6
5
4
3
2
1
30
29
28
27
26
25
24
23
22
21
20
19
18
17
16 16
15
14
13
12
11
10
9
8
7
6
5
4
3
2
1
PH PH
EH
D15
D13
D14
GND
D12
D10
D11
GND
D9
D7
D8
GND
D6
D4
D5
GND
D3
D1
D2
GND
+3.3V
+3.3V
D0
A6
+3.3V
A4
A5
GND
A3
A1
A2
PSAVE
/RD_EFI
/WR_EFI
/CS_EFI
GND
+5V
+5V
BSY_EFI
NC
+5V
REQD_EFI
REQU_EFI
GND
/ACKU_EFI
/INT_EFI
/ACKD_EFI
GND
/RST_EFI
NC
(B to B)
D15
D13
D14
GND
D12
D10
D11
GND
D9
D7
D8
GND
D6
D4
D5
GND
D3
D1
D2
GND
+3.3V
+3.3V
D0
A6
+3.3V
A4
A5
GND
A3
A1
A2
PSAVE
/RD_EFI
/WR_EFI
/CS_EFI
GND
+5V
+5V
BSY_EFI
NC
+5V
REQD_EFI
REQU_EFI
GND
/ACKU_EFI
/INT_EFI
/ACKD_EFI
GND
/RST_EFI
NC
(B to B)
+24VN
DP
+24VN
CML
GND
L
GND
H
AREF
S
AREF(+5V)
RI
RXA
CONT24
+12V
OH1
TXA
OH2
GND
CI1
GND
CI2
CNG
DSE1
-12V
DSE2
DCB-32616-50A
HS
GND
+5V
DCB-70306-50A
SPEAKER
D91-08490-40C
1
2
1
2
PH
1
2
3
4
5
6
7
8
9
10
11
12
13
14
1
2
3
4
5
6
7
8
9
10
11
12
13
14
LCD
ZA1-02394-20
52271
(molex)
VSS
V5
VDD
RS
R/W
E
DB0
DB1
DB2
DB3
DB4
DB5
DB6
DB7
(FFC)
SP1
SP2
FMN FMZ
PCB
INVERTER
DA7-08090-50
35 x 50
1
2
1
2
2
1
2
1
EH
SCAN-LAMP
DA7-08300-40C
N
L
90mm
UL3239(#22) 340mm
BH
Compact
flash
ZA1-02399-10
1
26
2
27
3
28
4
29
5
30
6
31
7
32
8
33
9
34
10
35
11
36
12
37
13
38
14
39
15
40
16
41
17
42
18
43
19
44
20
45
21
46
22
47
23
48
24
49
25
50
1
26
2
27
3
28
4
29
5
30
6
31
7
32
8
33
9
34
10
35
11
36
12
37
13
38
14
39
15
40
16
41
17
42
18
43
19
44
20
45
21
46
22
47
23
48
24
49
25
50
GND
/CD1
D3
D11
D4
D12
D5
D13
D6
D14
D7
D15
/CE1
/CE2
A10
VS1
/ATASEL
/IORD
A9
/IOWR
A8
/WF
A7
INTRO
VCC
VCC
A6
/CSEL
A5
/VS2
A4
/RESET
A3
IORY
A2
/INPAK
A1
/REG
A0
/DASP
D0
/POIAG
D1
D8
D2
D9
/IOIS16
D10
CD2
GND
1
2
3
4
1
2
3
4
1
2
3
4
1
2
3
4
RJ45
P1
P2
P4
ZA1-02336-00/MFP620mm
ZA1-02337-10/PPF380mm
P52 P50
P51
SP2
SP1
PRXD
PLOAD
+5V
GMD
GMD
+5V
+24V
LSCK
LDS
LEDWR1
LEDWR2
LLE
/OTCH1
/OTCH2
DA7-08470-50B
3T 1T(flat) 1T(flatA)
FBS/SCANNER / DA71010010
PANEL / DA71020010
option
OPTION(OTHER) / DA71200010 or NGP / DA71080010
OPTION(OTHER) / DA71200010
2T
3T
2-2

2.2 Main Control PCB
The main control PCB controls the operations of all machine functions.
Jumper JP2 on the main control PCB is used for battery back up of the SDRAM. Removing JP2 will
initialize the SDRAM. If the power is turned off, the battery will provide up to 72 hours (8MB) of back up
when fully charged.
Jumper JP1 on the main control PCB is used for battery back up of the SRAM. All user programmed data
and internal memory switch settings are held in SRAM. Removing JP1 will initialize the SRAM.
If the power is turned off, the battery will provide up to five years of back up when fully charged.
NOTE: JP1, JP2 should remain in the "ON" position at all times.
Memory (FLASH MEMORY, SRAM, SDRAM)
FLASH MEMORY --- T h e F L A S H M E M O R Y c o n t a i n s a l l p r o g r a m i n s t r u c t i o n s f o r u n i t operation.
SRAM ---T h e S R A M , w h i c h i s b a c k e d - u p b y a l i t h i u m b a t t e r y i s u s e d t o s t o r e u s e r p r o g r a m m e d
information.
SDRAM ---T h e S D R A M i s u s e d f o r b u f f e r , w h i c h i s b a c k e d - u p b y a b a t t e r y i s u s e d t o s t o r e m e m o r i z e d
documents.
NOTE: The SDRAM back-up battery is connected to the PCB MAIN. When the PCB MAIN is replaced,
the connection will be lost. Therefore, please reenter the date and time, after you have replaced
the PCB MAIN. (Press MENU, 2, 1, 0, 9, and enter month, then day, year, hour and minute in 24-
hour format.)
NOTE: Turning parameters for Color(R,G,B) and Gray mode are stored in the EEPROM(IC42). When the
PCB MAIN is replaced, the EEPROM on malfunction PCB should be replaced to the new PCB.
FBS
MOTOR
ADF
MOTOR
NCU PCB
TONE RXA TXA
DISPLAY
KEY
PANE L
G/A
PNAEL PCB
MODEM MONITOR
CONTROL
CPU USB
SRAM
SDRAM SDRAM
Ni-MH
H.V.POWER
SUPPLY UNIT
AC
PRINTER
CONTROL
MOTOR
CONTROL
PROCESS
CCD
SDRAM
INVERTERCCFL
CCD PCB
+24V,
+24V,
+5V,+3.3V
MAIN CONTROL PCB
CENECTOR-B PCB
Extention Memory
Lithium
+24V
+24V,+12V,AREF
FLASH
MEMORY
POWER SUPPLY
UNIT
PRINTER
UNIT
MFP
ENGINE
Main control PCB block diagram
2-3

2.3 Network Control Unit (NCU) PCB
The NCU PCB provides the connection to the telephone line. It consists of the interface circuit, ring signal
detector and telephone control circuit.
NCU PCB block diagram
Major components of the NCU
DP relay
Connects the telephone line to the fax.
S relay
Used to connect the telephone line at seizure state.
OH & Tone detector
Detects the On-hook condition of the second telephone unit.
H relay
Disconnects the Tel1 and Tel2 line from PSTN.
24V generator
Supplies 24 volts to the relays for OH detection of optional handset or external telephone line.
Ring signal detector
A photo coupler that detects an incoming ring.
2-4

2.4 Power Supply Unit (PSU)
The power supply unit receives the input line voltage and currents it to output voltages of +5 VDC, +24
VDC, +12 VDC, and -12 VDC.
The heater circuit controls output voltage to the fuser heater according to instructions received from the
heater control circuit.
If an over-current is sensed in the secondary circuit, power is interrupted.
Power supply unit block diagram
The power supply unit has two output connectors.
The following table shows the connector outputs:
CN101 -- to the Fuser Heater
Pin No. 1 2
Output L N
CN2 -- to the Main Control PCB.
Pin No. 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15
Output
voltage PC HC2 HC1 +5V SG +3.3V SG -24V PG
2-5

2.5 Sensors
2.5.1 Sensor Locations
The following illustration shows the relative positions of the machine’s sensors.
HS
TS2
PES1
PES2
OPEN2
OPEN1
TRAYS
JAMC2
TS1
TXIL
DS2
DS1
APS
Thermistor
DPS
JAMC1
PSS
PDS
COVER-SW
2-6

2.5.2 Sensor Descriptions
The following table gives a brief description of each sensor and its function.
Code Name Detects Sensor Type Remarks
DS1 Document sensor 1 Presence of document in
feeder
interrupter
DS2 Document sensor 2 Leading and trailing edge of
document
interrupter
APS ADF permit sensor Platen cover quite close or
not
interrupter
HS Mirror carriage home
position sensor
Mirror carriage position Photo
interrupter
TXIL(ADF) Interlock switch
(ADF)
Scanner cover open or close Mechanical
Switch
Interlock --- Detects front cover and the
1st cassette jam access cover
are open or close
Mechanical
Switch
PDS Paper discharge
sensor
Detects paper pass at paper
exit.
interrupter
DPS Duplex paper sensor Detects paper pass of the
duplex printing paper
interrupter
MFX-1330 only
Thermistor ---- Detects and controls the
Heater Roller temperature
Thermistor
OPEN1 Paper cassette open
sensor
Detects the 1st paper
cassette open or close
interrupter
PES Paper empty sensor Detects presence of recording
paper in the 1st paper
cassette
interrupter
TS1 Toner sensor 1 Detects the toner empty for
small capacity toner cartridge
interrupter
TS2 Toner sensor Detects the toner empty for
large capacity toner cartridge
interrupter
PSS Paper supply sensor Detects paper feeding out of
cassette/tray
interrupter
TRAYS Tray sensor Detects presence of recording
paper in the bypass tray
interrupter
JAMC1 Jam access cover
sensor
Detects the side cover open
or close
interrupter
PES2 Paper empty sensor Detects presence of recording
paper in the 2nd paper cassette
Photo interrupter
OPEN2 Paper cassette open
sensor
Detects the 2nd paper cassette
open or close
Photo interrupter
JAMC2 Jam access cover
sensor
Detects the 2nd paper cassette
side cover open or close
Photo interrupter
2-7

2.6 Document Scanning Sequence
2.6.1 ADF Detection
When a document is placed into the document feeder, Document Sensor 1 (DS1) is activated and you
will hear the short beep.
The document will be transferred when the start key is pressed.
Document separation is the process that allows a multi-page document to go through the scanner one
page at a time. The bottom document is separated from the remaining documents by the friction of the
separator pad.
Following the document separation, the feed roller causes the document to advance. As it advances, the
leading edge of the document activates the Document Sensor 2 (DS2) sensor. Once DS2 is activated,
the feed roller continues to rotate until the document reaches the scan position. The machine uses the
distance from DS2 to the scan position and the diameter of the feed roller to determine the number of
rotations necessary to feed the document to the scan position.
When the document reaches the scan position, the light from the scanner lamp strikes the face of the
document and is reflected into the lens through mirrors A, B, and C. In case the light intensity along the
length of the scanner lamp is not uniform, shading compensation is provided to ensure even illumination.
As the reflected image passes through the lens, it is focused onto the charged coupled device (CCD).
The CCD then converts the dark and light areas of the image into electrical impulses, or image data.
When DS2 detects the trailing edge of the document, the image signal output is turned off. The scanner
continues to remain active for a few more seconds in case there is another document to follow.
The scanned document is discharged through the document exit by the exit roller.
MFX-1330
Pickup roller
DS1 (Feeler)
Separator roller
Separator pad
Feed roller
DS2 (Feeler)
Press roller
CCD
Mirror B
Mirror A
Mirror A
Mirror C
Scanner unit
Lens
Home sensor
Exit roller
F-300
Pickup roller
DS1 (Feeler)
Separator roller
Separator pad
Feed roller
DS2 (Feeler)
Press roller
CCD
Mirror B
Mirror A
Mirror A
Mirror C
Scanner unit
Lens
Home sensor
Exit roller
2-8
