Music Man BT–X8 User manual

MusicMan
®
MICRO Bluetooth Soundstation BT–X8
User Manual
Declaration of Conformity is under: www.technaxx.de (in bottom bar “Konformitätserklärung”)
Have fun with this speaker in MICRO format and built-in microphone!
Portable Bluetooth speaker system with wireless audio transfer for CD/DVD, iPhone, iPad,
iPod, Mobile phones, Tablet PC, PC/Notebook.
Features
Easy conection with Bluetooth compatible devices (= Pairing)
MicroSD card slot bis 32GB and built-in FM radio
Line–IN 3.5mm for connection to other audio devices
Built-in hands-free function with built-in microphone
Built-in rechargable 3.7V lithium 600mAh battery, charging by USB power cable
Playing time approx. 5 – 6 hours by medium volume
Changeable silicone sleeves in different colours
Bluetooth Version 3.0 with 3W output power
Ideal for traveling, easy installation, excellent sound quality
Product overview
1 Power On / Power Off / Hands-free
2 3.5mm Line–IN / AUX slot
3 Indicator Light (LED)
4 Micro USB slot to charge the unit

Key Functions
(1) Power key / Hands-free key: Press the POWER key for 2 seconds to turn ON
the speaker. The user hears a “BEEP” tone when the speaker is turned ON.
The BLUE LED is blinking. To turn the speaker OFF, press the POWER key for
2 seconds. When the BLUE LED turns off, the speaker is also off.
Users are able to answer an incoming call or hang up a call with pressing the button
/shortly once when Bluetooth of speaker and mobile phone are connected.
(6)
/
Play key / Pause key: Short press to play or pause music from Bluetooth
devices and MicroSD card. the BLUE LED shines constantly.
While the speaker plays music through Line–IN/AUX, users play or pause
music on their phones, PC, Tablet PC, MP3, MP4 etc.
(7)
/ –
Back key / Volume – key: Short press to go back to the last song, long press
to decrease the volume (VOL–) while playing music through Bluetooth or from
MicroSD card. While playing music through Line–IN/AUX, please control on
the phone, PC, Tablet PC, MP3, MP4 etc.
(8)
＋/ 
Forth key / Volume + key: Short press to go forth to the next song, long press
to increase the volume (VOL+) while playing music through Bluetooth or from
MicroSD card. While playing music through Line–IN/AUX, please control on
the phone, PC, Tablet PC, MP3, MP4 etc.
5 Microphone
6 Play / Pause
7 Back / Volume –
8 Forth / Volume +
9 MicroSD card slot

Charging of the battery
Plug in the Micro USB cable* (* included) into the MicroUSB slot (4) of the speaker. Then
connect the USB port to the USB slot of PC or other USB slot of chargers. When the
speaker is being connected, the LED first shines BLUE and then turns to RED. The LED
will shine RED until the speaker is fully charged, and it will turn off when the speaker is full
charged. (Recommendation: turn OFF the speaker while charging. When it is working, it will
take a longer time to get it fully charged.) Please always fully upload the battery.
Handling the MicroSD card
Turn ON the speaker and insert a MicroSD memory card (up to 32GB, formatted with
windows FAT32 and MP3 tracks are copied on it) into the MicroSD card slot of the speaker
(9). The speaker starts playing automatically.
Handling Bluetooth
Turn ON speaker. Bluetooth works spontaneously, searching previous pairing Bluetooth set.
If the speaker fails to connect, it starts pairing other Bluetooth devices. In this case, turn ON
your Bluetooth device to search the speaker. The PIN code is “0000”, if necessary! The
user hears one signal tone (different from “Beep”) when the speaker is connected to
Bluetooth. Music streams after pairing successfully.
When the key /at the speaker is pressed once, both – the speaker and the
connected Bluetooth compatible device – are paused, the BLUE LED lights constantly.
Press the /the speaker starts playing. Press the ＋/key shortly to move on to
the next song, press it long to increase the volume.
Press the /– key shortly to go back to the last song, press it long to decrease volume.
When the speaker is playing from a Bluetooth compatible device (eg. Smartphone)
connected via Bluetooth, the BLUE LED is blinking.
Handling Hands-free
Before using the hands-free function make sure that Bluetooth is connected. When there
are incoming calls, press the /key of the speaker or on your phone (the answer
button) to answer. When the call finishes, press the /key of the speaker or on your
phone (the hung up button) to hang up.

Handling Line–IN (AUX)
Turn ON the speaker. Plug one end of 3.5mm cable into LINE IN slot of the speaker and the
other end into the audio slot of Mobile Phone, Notebook, Tablet PC, MP3/MP4 Player etc.
After that you will be able to enjoy the music.
When the /key of the speaker is pressed once, the speaker is on “Mute Mode” and
the connected device continues playing. The keys and are without function.
Handling FM Radio
Plug the audio cable in the slot for better reception. Press the /key to switch to the
FM radio function. When transferred into FM, keep pressing the /key for 2 seconds
to search tracks. The speaker searches for available tracks automatically and stores them
after pre-playing; meanwhile the LED flashes in BLUE until the search ends.
Then press the /key to Play/Pause. Press the /– to go to the last track or to
decrease the volume. Press the ＋/key to go to the next track or to increase the
volume. Press the /key to transfer to MicroSD card, AUX or Bluetooth.
Technical Specifications
Bluetooth Bluetooth Version 3.0
BT transmission distance ≧10 meters
Sound track Mono
Function Line–IN, Bluetooth, Hands-Free, AUX, FM Radio
Memory MircoSD* memory card up to 32GB (* not included)
Audio playing Built-in 3.5mm Line–IN socket and USB audio slot
Impedance / Output power
4Ω/ 3W
Sensitivity 420mV
Frequency 150 Hz – 18 KHz
Signal Noise Ratio S / N ≧80 dB
Total Harmonic Distortion THD ≦1% 1W 1KHz
Battery Built-in rechargable 3.7V Lithium 600mAh battery
(rechargeable by Micro USB slot)
Charging Time ~ 1.5 – 2 hours
Playing Time ~ 5 – 6 hours (medium volume)
Power Supply DC 5V and built-in Li-battery
Ø Speaker cone Ø 45mm
Weight / Dimensions 110g (with hand loop) / 6.0 x 6.0 x 5.3 cm
Package Contents MusicMan
®
MICRO Bluetooth Soundstation BT–X8,
MicroUSB cable (for charging), Audio cable, Hand loop,
3 silicone sleeves in different colours, User Manual

Warnings
1. If the speaker cannot be turned on after pressing the POWER key, or it turns off on
turning on, the user shall check whether it is powerful. If it is out of power, get it charged
and try again later.
2. ONLY charge the speaker with the original Micro USB charging cabel* (* included),
otherwise the speaker may fail to work or even may get damaged!
3. Do not attempt to disassamble, drop, shake the speaker. It may result in short-circuit or
even damage the speaker’s mechanics or the speaker itself.
4. Do not increase the volume of your Mobile Phone, PC, MP3/MP4 Player, CD, DVD etc
to the maximum, while sonic boom or sound distortion may occur. In case of sonic boom
or sound distortion, please decrease volume either of Mobile Phone, PC, MP3/MP4
Player, CD, DVD or the speaker. The sound gets normal soon.
5. If Bluetooth device of Mobile Phone, PC etc fails to link to the speaker or if fails to
playing music after being connected, the user shall check if he/she enters the correct
PIN code or if Bluetooth device of his/her Mobile Phone, PC etc supports A2DP.
6. Keep the speaker in dry and ventilated environment, avoid high humidity/temperature.
Also batteries should not be exposed to excessive heat or direct sunlight.
7. Keep the surface of the speaker clean, but do not use organic solvents.
8. Keep the speaker away from little children.
Security and Disposal Hints for Batteries: Hold children off batteries. When a child swallowed a battery go to a doctor’s place or bring
the child into a hospital promptly! Look for the right polarity (+) and (--) of batteries! Always change all batteries. Never use old and new
batteries or batteries of different types together. Never short, open, deform or load up batteries! Risk of injury! Never throw batteries into
fire! Risk of explosion!
Hints for Environment Protection: Packages materials are raw materials and can be recycled. Do not disposal old devices
or batteries into the domestic waste. Cleaning: Protect the device from contamination and pollution (use a clean drapery).
Avoid using rough, coarse-grained materials or solvents/aggressive cleaner. Wipe the cleaned device accurately. Important
Notice: Should battery fluid leak from a battery, wipe the battery case with a soft cloth dry.
Distributor: Technaxx Deutschland GmbH & Co.KG, Kruppstr. 105, 60388 Frankfurt a.M., Germany
