Mutable Instruments Ripples User manual

Ripples
Liquid filter
Installation
Ripples requires a -12V /
+12V power supply (2x5 pin
connector). The ribbon cable
connector must be aligned
so that the red stripe of the
ribbon cable (-12V) is on the
same side of the module’s
power header as the “Red
stripe” marking on the
board.
The power consumption is:
+12V: 35 mA; -12V: 35 mA
Calibration
Adjust the trimmer on the
back of the module so that
the tone emitted by the filter
(when it self-oscillates)
tracks a 1V/oct CV sent to
the FREQ input.
Online manual
and help
The full manual can be
found online at
mutable-instruments.net/
modules/ripples/manual
For help and discussions,
head to
mutable-instruments.net/
forum/

Front panel
Controls
A. Resonance. Ripples can
be set to self-oscillate with
a high resonance setting.
B. Frequency. The Cutoff
frequency of the filter.
C. FM Attenuverter. Adjusts
the amount and polarity of
frequency modulation from
the FM input.
Inputs and Outputs
1. CV inputs for Resonance,
Frequency (with 1V/Oct
scale) and FM.
2. Audio input.
3. Voltage-controlled out-
put gain for the LP4>VCA
output.
4. Filter outputs. 2-pole
band-pass, 2-pole low-pass,
4-pole low-pass, and 4-pole
low-pass with amplitude
controlled by input 3.
A
B
C
1
2
3
4
