MWBS studio User manual

Let’s build a Wallbed together!
Universal Desk/Table for All
Sizes of Alpha Panel Wall
Beds
Assembly Instructions
www.murphywallbedsystems.com
** LIFETIME WARRANTY **
Designed to Exceed International ISO 9002
Standards for Residential Specifications
- Patent Pending -
Issue:041414

Exploded Assembly
2.
(3pc) 2”x3”Black Hinge
(3pc) Hinge Clips
Hinges and Hinge Clips to Back and Bed Face Panel
(30pcs) 19mm Self tapping Screw
Pivot Brackets to Cabinet Panels. The Desk/Table to the Upper Brackets
(27pcs) Flat Head Self tapping Screw#5x16mm
(10pc) #8x40mm Wood Screws
INSERT 16mm DESK
LEG PACKER TO BE
FIXED BETWEEN LEG
PIVIOT BRACKET &
WALLBED END PANEL
USING 28MM WOOD
SCREWS

Pre Assembled KIT
3.
(4pcs) Black Steel Washer Ø7.0xØ16.0mm
(2pc) M6x40mm Bolt
(2pcs) M6 Nylock Nut
(4pc) Black Nylon Washer Ø13xØ30mm
Washers stop friction between
Legs, Upper and Lower Brackets
Legs to Upper Brackets
Legs to Pivot Brackets
Upper Bracket
(Left and Right)
Leg (2)
Pivot Bracket
(Left and Right)
(2pc) Black Steel Washer Ø8.5xØ20mm
(2pc) M8x16mm Bolt

1.
2.
STEP 1: Assemble Desk Top and Back to the Brackets.
Assemble the Desk/Table with the Upper Brackets as shown in Drawing #1.
Screw the Desk Top first to the Left and Right Brackets. This provides a seat for the Back.
Attach the Desk Back to the back bracket. Be sure of alignment and then screw the Desk and Back
together from the bottom side with the #8x40mm Screws provided.
Mount the Hinges to the Back as shown in Drawing #2.
1.
2.
3.
4.
Project Start-Up
Familiarise yourself with all of the components in the Studio Desk/Table mechanism cartons, as
well as thoroughly study this manual so you may plan the steps required to complete this project.
Study all illustrations and plan drawings. Make sure that the space available in the room is adequate
for the specified dimensions in both the open and closed positions.
Steps to Complete the Project
4.
NOTE: If the Panel Bed is slightly too heavy too open and close without the Studio Desk/Table mounted,
you should add one Spring to the right and to the left to assist in balance. An odd number of
Springs right and left may be used to get balance.
Alpha Studio Desk Cut List - Maximum material thickness is 18mm
Desk Back
Single 1/1020x560 2L 1/1020x216 2L
Double 1/1399x560 2L 1/1399x216 2L
Queen 1/1552x560 2L 1/1552x216 2L
King 1/1960x560 2L 1/1960x216 2L
2 x 100(h) x 25(w) x 16mm Desk Leg Packers

Drawing #1: Upper Bracket
Drawing #2: Hinges to Back
Desk/Table Top
Back
The short Hinge leaf attaches to the Back,
the long Hinge leaf attaches to the Bed Face
Back
Back
5.

STEP 2: Install Pivot Brackets and Desk Leg Packers
Install the left and right Pivot Brackets as shown in Drawing #3. Insert Desk Packers between
pivot bracket and end panel of the cabintery. This will square up the legs with the cabintery.
Mount the Brackets exactly 25mm inside of the Cabinet vertical. The pivot point (standoff)
must face outward to allow the Leg to line up with the vertical edge of the Panel.
1.
2.
STEP 3: Assemble Desk/Table to Bed Face
Assemble the Desk/Table on the floor where it will be located when it is in use (Drawing #4).
Hand tighten the Bolts as the Legsneeds to be detached later to mount the Desk to the Bed Face.
1.
2.
Drawing #3: Pivot Brackets and Desk Leg Packers
Drawing #4: Desk/Table on floor (Side View)
25mm
Insert Desk Legs Packer
Between Pivot Brackets and
Bed Cabinet.
*ATTACH 16mm DESK
PACKERS TO WALLBED
END PANEL USING 28MM
WOOD SCREWS.
Cabinet
6.
Desk Top
Leg
Pivot
Bracket
Cabinet

STEP 4: Install Desk/Table to Bed Face Panel
Raise the Desk and hold it in the UP position (where it will be when mounted to the Bed Face).
Hold the Desk against the Bed Face, making sure that the Desk is level both front to back and end to
end.
Using a pencil, lightly mark the 3 Hinge locations and the height of the top of the desk back on the
Bed Face Panel.
Lower the Desk to the floor and detach the Legs from the Pivot Brackets.
Mount the Hinge Mate Clips to the Bed Face to assist in mounting and leveling the desk. Attach the
Clips so the clip shelves are 38mm below the pencil mark of the top edge of the Desk Back. Check
the level line between all three Clips to ensure that the desk will be level. Secure all three Hinge
Clips. See Drawing #5.
Bring the Studio Desk/Table back up to the Bed Face and place the long Hinge leaves in the Hinge
Clips (you will need to flip the desk up to access the screw holes for the 3 hinges) . Screw the long leaves
of the Hinges to the Bed Face. Recheck levelness in all directions.
Re-attach the Legs and snug up both upper and lower pivots. It is not necessary to remove Hinge
Clips as they are out of sight after the installation.
1.
2.
3.
4.
5.
6.
7.
STEP 5: Test
Operate the Desk/Table slowly.
Double check the levels.
Make sure that all End Caps are installed.
1.
2.
3.
Drawing #5: Hinge Clips
7.
Hinge
Hinge Clip
Desk
Back
38mm
Bed
Face
Long Hinge
Leaf
Hinge Clip
Clip Shelf
Clip
Shelf
Pencil Mark
top of Desk
Back
