MyStar Extra Installation guide

Meter & Test Strip Overview
Display
Mini-USB-Port
Test Strip Port
Front of the Test Strip
(black-coloured side)
Sample Area
Blood should be applied here.
Visual Fill
Window
Turns red when enough
blood has been applied.
Contact Bars
– insert strip with
bars facing up
Mealtime Button
– use to select or
change a meal tag or to
logbook
UP Arrow Button
– use to scroll to a more
recent result in logbook
or to increase a value
(e.g. in settings)
DOWN Arrow
Button – use to scroll
to a past result in
logbook or to decrease a
value (e.g. in settings)
CHECK Button
– use to accept and/or
move to next step
Refer to the MyStar Extra® Owner’s Guide for complete instructions for use.
Blood Glucose Test
IMPORTANT: See your MyStar Extra® Owner’s Guide for a more detailed
step-by-step guide on how to perform the test.
[1] Insert the test strip into the
meter
[2] Lance test site
[3] Bring test strip
to blood sample
Refer to the MyStar Extra® Owner’s Guide for complete instructions for use.
Symbols & Messages
Refer to the MyStar Extra® Owner’s Guide for complete instructions for use.
No Tag
Fasting
Pre Meal
Post Meal
Mealtime Tags
Logbook
Averages
Estimated A1c
Settings
Meter Modes
Time Setting
Date Setting
Time & Date Setting
(in Settings Mode )
Trending Up
Trending Down
Steady
Trending Arrows
(in Logbook Mode )
(and in ~A1c Mode )
Number of days remaining until
~A1c Percentage
Viewing Estimated A1c (~A1c)
(in ~A1c Mode )
Number of readings
used in calculation
Number of days
used in calculation
Viewing Averages
(in Averages Mode )
Symbole und Meldungen
Für eine vollständige Information lesen Sie bitte die Bedienungsanleitung
des MyStar Extra™.
Outside operating
temperature range
Low Battery
Dead Battery
An Error occurred
Glucose test result is
lower than 1.11 mmol/L
Glucose test result is
above 33.3 mmol/L
Control Solution result
Apply Sample to
Test Strip
Time
Date
Test Result
Unit of
Measurement
Mealtime Tag
(appears here)
Viewing a
Blood Glucose
Test Result
Symbols& Messages
Refer to the MyStar Extra® Owner’s Guide for complete instructions for use.
<MAT>521878
Setting Time & Date
[1] When your meter is deactivated,
press and hold the CHECK button to
enter settings mode.
Select the time format (12 hr vs. 24 hr)
and press the CHECK button to select.
The setting icon ( ) will appear
time icon ( ).
[2] Press the DOWN or UP arrow
Repeat step [2] until time and date
are set correctly
[3] Press and hold the CHECK button
to exit the settings mode.
Toll-Free, 24-Hour Customer
Service: 08000 35 25 25
Manufacturer:
AgaMatrix, Inc.,
7C Raymond Avenue,
Salem, NH 03079 USA
UP Arrow DOWN Arrow CHECK
Meter Buttons:
Refer to the MyStar Extra® Owner’s Guide for complete instructions for use.
Example of
setting hour (ashing):
<MAT>521900
