MyStar Extra Operator's manual

Quick operating guide* –
Blood glucose measurement with
TIP: Before measuring, wash your hands
thoroughly, keep them warm
or gently massage the (lancet)
insertion point before measuring to
stimulate the circulation.
PREPARING THE LANCING DEVICE
Pull off the cap from the
lancing device.
OVERVIEW OF MYSTAR EXTRA®
Mini USB connection
- Easy transfer of your data onto a PC or laptop
with Sanofi-authorised software.
DISPLAY
- Displays readings, symbols, calculations
and error messages
CONFIRM button
- Switching on and off
- Menu navigation
MEALS button
- Allocation of mealtime tags
UP arrow key
- Searching through next options
6DOWN arrow key
- Searching through previous options
Test strip slot
- MyStar Extra®works with the tried and tested
BGStar®test strips
OVERVIEW OF THE BGSTAR®TEST STRIPS
CONTACTS
- Insert the test strips with the contacts
pointing upwards
SAMPLE AREA
- Please dab blood on here!
MONITORING WINDOW
- Please do NOT put any blood on here!
1
2
3
4
5
6
7
8
9
10
1.
Fit a new lancet into the lancet
holder.
- Twist off the lancet cap.
2.
Replace the cap on the
lancing device.
3.
Adjust the penetration depth.
4.
Pull the tensioning device
until you hear a click.
5.
*These instructions are only a guideline. Please
read through the operating instructions carefully
before using MyStar Extra®for the first time.
4
2
3
5
6
7
8
10
9
1

Quick operating guide* –
Blood glucose measurement with the
Reading display
- Your reading is shown on the
display together with the time
and date.
- Press the ‘Confirm’ button
and confirm the suggested
mealtime tag.
- The measurement result is
saved automatically.
1. CARRYING OUT A MEASUREMENT
A
A
E
B
B
C
D
Inserting a test strip
- Insert the test strip into the
test strip slot with the contacts
pointing upwards.
IMPORTANT: Please only use BGStar®
test strips with the MyStar Extra®system.
Calculation of reading
- Remove the test strip from the
blood sample when you hear
a beep.
- The scroll bar and the
animation of the number
sequence 1-2-3 show that your
result is being calculated.
TIP: If the suggested mealtime tag is
incorrect, you can change it within
the next 48 hours.
Taking a blood sample
- Position the lancing device on
your finger pad and press the
release button.
- For taking blood samples
from alternative parts if
the body, please read the
operating instructions.
Application of the blood sample
- Dip the test strip into the blood
sample
- The measuring device now
displays the ‘drop’ symbol
- The test strip absorbs blood
from the tip so that it is full
2. CONCLUDING THE MEASUREMENT
Remove the used test strip
- Dispose of the test strip in the proper manner.
- The blood glucose measurement device will
switch off automatically.
Pull off the cap from the lancing device and
place the lancet cap on the lancet.
Remove the used lancet and dispose of it in
the proper manner.
The ServiceCenter Diabetes is happy to help you with any
questions you may have.You can also find further information
on the Internet at www.mystar.sanofi.de
DATA MANAGEMENT IN JUST 3 CLICKS
1 x CLICK
Diary with fasting blood
glucose trend arrow
2 x CLICK
Averaging function with
mealtime tags
3 x CLICK
HbA1c function with
HbA1c value and trend
034060
C
(Calls from German landlines 6ct/call,
mobile prices max. 42ct/minute)
