Mytee ECO-15-24VDC User manual

ORBITAL Model: ECO-15-24VDC
Battery Powered Orbital Floor Machine
User Manual
13655 Stowe Dr. Poway, CA 92064 • P: [phone] • F: [phone]
REV. 2/12/18

2
INTRODUCTION
Dear Customer:
Congratulations on the purchase of your new Battery Orbital All-Surface Floor
Machine.
As technology continues to develop you can work condently knowing that
both Mytee Products and its employees are equally dedicated to developing
with the industry and its advances.
Like any other piece of machinery or technology, the ECO-15-24VDC also re-
quires proper maintenance and care to keep the product working over extend-
ed use. Neglecting your machine, abusing it or not operating it properly can
void its warranty and prevent the machine from performing to the quality and
standard you’d expect out of the Mytee Products line.
If you have any warranty concerns or questions, please review this manual
thoroughly or do not hesitate to contact your distributor. If there are questions
regarding maintenance, replacement, or ordering parts please contact an
authorized Mytee Products Service Center. To see an updated list please visit
our website at http://www.mytee.com/support/service-centers.
Before using your Mytee product, please read this manual thoroughly.
Sincerely,
Mytee Customer Care Dept.

3
TABLE OF CONTENTS
1
2
3
5
4
IMPORTANT SAFETY INFORMATION 4
AT A GLANCE 6
1.1 - Technical Specications 6
1.2 - Included with the ECO-15-24VDC 6
1.3 - ECO-15-24VDC Front View 7
1.4 - ECO-15-24VDC Rear View 8
1.5 - Gravity Feed/Spray Jets Selector Valve 9
MACHINE OPERATION 10
2.1 - Connecting the Battery Pack 10
2.2 - Pad Driver and Pads 10
2.3 - Filling the Shampoo Tank 10
2.4 - Operating the ECO-15-24VDC 11
2.5 - Emptying the Shampoo Tank 11
BATTERY INFORMATION 12
3.1 - About the Battery 12
3.2 - The Battery Panel 12
3.3 - About the Battery Charger 12
3.4 - Tips for Battery Longevity 13
3.5 - Battery Troubleshooting 13
MACHINE MAINTENANCE 14
4.1 - Flywheel Bearing Replacement 14
4.2 - Flywheel Replacement 15
TROUBLESHOOTING 16

4
IMPORTANT SAFETY INFORMATION
Grounding Instructions
This machine must be grounded. If it should malfunction
or breakdown, grounding provides a path of least resis-
tance for electrical shock. This machine is equipped with
a cord having an equipment-grounding conductor and
grounding plug. The plug must be plugged into an appro-
priate outlet that is properly installed in accordance with
all local code and ordinances. Do not remove ground pin;
if missing, replace plug before use.
Improper installation of the equipment-grounding conduc-
tor can result in a risk of electric shock. Be sure to check
with a qualied electrician or service person if you are in
doubt as to whether the outlet is properly grounded. If
the plug will not t in the outlet do not modify either the
plug nor the machine’s cord, instead have a proper outlet
installed by a qualied technician.
This machine is for use on a nominal 120-volt circuit and
with a grounding plug similar to the one in Figure 1 below.
If a proper outlet is not available, follow the illustrations of
Figure 2 & 3 to install a temporary-grounding plug. This
temporary work-around should be used only until a proper
outlet (Figure 1) can be installed by a qualied electrician.
When and if this type of adapter is employed, screw the
adapter’s extended tab into place with a metal screw.
However, grounding adapters are not approved for use in
Canada.
Again, be sure to check the grounding pin for damages
and replace if necessary.
The Green, or Green-Yellow, wire in the cord is the
grounding wire. When replacing a plug, this wire must be
attached to only the grounding pin.
DO NOT use extension cords.
Please Note for America use only.
Parts and Service
Please contact a Mytee service personnel or Mytee
authorized Service Center using Mytee original replace-
ment parts and accessories for repairs are needing to be
performed. When and if calling Mytee for support, please
have your Model and Serial Number available for faster
assistance.
Name Plate
The Model and Serial Number are located on the lower
half of the back of the machine near the power plugs and
will be required for ordering replacement parts. You can
use the space provided on the front of this manual to note
down both for future referencing.
Unpacking the Machine
When your new machine is delivered, please carefully in-
spect both the shipping carton and the machine for dam-
ages. If damage is evident, save both the shipping carton
and machine so that the delivering carrier can inspect it.
Contact the carrier immediately to le a freight claim if
there has been any damage.
Caution and Warnings
Symbols
Mytee uses the symbols below to signal potentially dan-
gerous conditions. Always read this information carefully
and take the necessary steps to protect personnel and
property.
Is used to warn of immediate hazards that will cause se-
vere personal injury or death.
Is used to call attention to a situation that could cause
severe personal injury.
Is used to call attention to a situation that could cause
minor personal injury or damage to the machine or other
property. When using an electrical appliance, basic pre-
cautions should always be followed, including the follow-
ing: Read all instructions before using this machine. This
Figure 1
Grounding Pin
Grounded Outlet
Grounded Outlet Box
Adapter
Tab for Grounding
Screw
Metal
Screw
Figure 2 Figure 3

5
IMPORTANT SAFETY INFORMATION
product is intended for commercial use only.
To reduce the risk of re, electrical shock, or injury:
1. Read all instructions before using equipment.
2. Use only as described in this manual. Use only manu-
facturer’s recommended attachments.
3. Always disconnect machine from power source before
attempting any adjustments or repairs.
4. Do not unplug charger by pulling on cord. To unplug,
grasp the plug, not the cord.
5. Do not pull or carry by cord. Do not close a door on
cord or pull cord around sharp edges or corners.
6. Keep charger power cord away from heated surfaces.
7. Do not use charger with damaged cord or plug. If cord
is damaged, repair immediately.
8. Do not use outdoors or on wet surfaces and or stand-
ing water.
9. Always unplug or disconnect the appliance from battery
when not in use.
10. Do not allow to be used as a toy. Close attention is
necessary when used by or near children.
11. Do not use in areas where ammable or combustible
material may be present.
12. Do not leave the unit exposed to harsh weather ele-
ments. Temperatures below freezing may damage compo-
nents and void warranty.
13. Use only the appropriate handles to move and lift unit.
Do not use any other parts of this machine for this pur-
pose.
14. Keep hair, loose clothing, ngers, and all parts of the
body away from all openings and moving parts.
15. Use extra care when using on stairs.
16. To reduce the risk of re or electric shock, do not use
this machine with a solid-state speed control device.
17. When cleaning and servicing the machine, local or na-
tional regulations may apply to the safe disposal of liquids
which may contain: chemicals, grease, oil, acid, alkalines,
or other dangerous liquids.
18. Be sure that the air is free of ammable vapors before
charging or running the machine.
19. Do not open the battery box, there are no user ser-
viceable parts inside.
20. Do not burn the battery, dispose of it properly.
21. Do not leave operating unattended.

6
1 - AT A GLANCE
1.1 - Technical Specications
1.2 - Included with the ECO-15-24VDC
Cleaning Path 15”
Solution Tank 4 gallons
Motor 3/4 horsepower
Motor RPM 1,800
Orbit 9/16”
Pump PSI 100
Pump GPM 1.3
Battery Life 1 hour per charge
Machine Weight 130 lbs.
Machine Dimensions 36” x 15.5” x 48.5”
Pad Driver
Two Battery Packs
Two Cleaning Pads
Battery Charger

7
1 - AT A GLANCE
1. Handle Height Adjustment
Lever
2. Solution Tank Lid
3. 4 Gallon Solution Tank
4. 100 PSI Diaphragm Pump
5. ECO-BP Battery Pack
6. Forward-Facing Spray Jets
7. Lifting Handle
8. 3/4 Horsepower Motor
9. Spray Jets/Gravity Feed
Selector Valve
10. Power Switch
1.3 - ECO-15-24VDC Front View
1
2
3
4
5
67
8
10
9

8
1 - AT A GLANCE
1. Solution Spray Levers
2. Solution Tank Drain Cap
3. 10” Foam-Filled Wheels
4. Faucet Fill Hose
1.4 - ECO-15-24VDC Rear View
1
2
3
4

9
1 - AT A GLANCE
Gravity Feed
Water or shampoo solution is pumped down
to the cleaning head, wetting the oor directly
under the pad or brush.
Spray Jets
Water or shampoo solution is pumped out of the
spray jets on the front on the machine, wetting
the oor directly in front of the unit.
1.5 - Gravity Feed/Spray Jets Selector Valve
Arrow points in the direction
of the selected feature.

10
2 - MACHINE OPERATION
2.1 - Connecting the Battery Pack
To connect the battery pack to the machine, position the
hooks above the wheel axle and angle it slightly while low-
ering until the hooks engage on the axle. Then plug in the
battery to the cable from the machine. ♦
2.2 - Pad Driver and Pads
Pad Driver
The pad driver comes pre-installed on the ECO-15-24VDC.
To remove the pad driver, undo the four screws on the
bottom of the pad driver.
Applying Cleaning Pad
To apply a cleaning pad, just lower the machine with pad
driver onto a 17” cleaning pad. Make sure the pad is as
centered as possible on the pad driver with no driver bris-
tles exposed to carpet. ♦
2.3 - Filling the Shampoo Tank
Faucet Fill
The shampoo tank can be lled from a standard faucet.
Simply lift the Faucet Fill hose out of the tank and press it
against the faucet. Turn on the faucet to allow water to ow
down into the tank.
Bucket Fill
To ll using a bucket, twist o the shampoo tank cap
counter-clockwise and pour in water. Add shampoo or
chemical if desired. ♦

11
2 - MACHINE OPERATION
Running the ECO-15-24VDC
To eectively clean oors, move the machine forwards and
backwards, similar to using a household vacuum clean-
er. Wet the oor by spraying solution as you roll the unit
forwards. ♦
2.5 - Emptying the Shampoo Tank
The shampoo tank can be easily emptied into a bucket by
unscrewing the drain cap on the bottom of the tank. ♦
2.4 - Operating the ECO-15-24VDC
Switching On the ECO-15-24VDC
After connecting the battery pack, lower the handle to a
comfortable height and press the power switch on the
handle to turn on the machine.

12
3 - BATTERY INFORMATION
3.1 - About the Battery
There are two batteries supplied with your machine and
a charger. Under normal use, the batteries will run the
machine for about an hour. The battery charger will also
charge the batteries in less than 1 hour. You can have
one battery on your machine to run it while the other is
charging. In this way, you can keep your machine running
continuously. ♦
3.2 - The Battery Panel
On the Battery Panel:
1. Circuit Breaker - The circuit breaker will pop out when
the current drawn from the battery exceeds 30A. Currents
exceeding 30A can occur when the brush (or pad) gets
stuck, too much pressure is applied, or the surface has
too much resistance. If this should happen, simply wait 3
minutes and push the button labeled “30” back in. Your
machine will be ready for use.
2. Factory Service Connector - The factory service
connector is for performing initial calibration of the battery
management computer inside the battery pack. It is for
use only at the factory.
3. Charge Display - The charge display will tell you how
much charge is still in the battery, just like the gas gauge in
your car tells you how much gas is left. ♦
3.3 - About the Battery Charger
To charge the battery, rst plug the battery into the char-
ger and then plug the charger into a wall outlet. The fan in
the charger will start and the LEDs will go on both on the
charger and on the battery’s charge display.
Battery Charger Display:
When the charger is plugged in and charging the batter-
ies, the column of green LEDs will light one on top of the
other. When the battery is low the rst green LED will ash,
indicating that the battery is less than 20% charged. When
the battery reaches 20%, the 20% light will stay on and
the 40% light will ash. This will continue until the battery
reaches 100% and all the LEDs will be lit. The fan will usu-
ally turn o when the battery is charged, however it is not
sign of a problem if the fan stays on. ♦
Flashing - 0-15%
ON Steady - 16-25%
Flashing - 100%
ON Steady - 76-99%
26-50% 51-75%
1 2
3
≥20%
40%
60%
80%
100%
Fault
Indication
Power output to
battery
Fan
Override switch
Charge status
indicator lights

13
3 - BATTERY INFORMATION
3.4 - Tips For Battery Longevity
• Charge the battery every 3 months when it is stored for
an extended period.
• Do not submerge the battery in water or other liquids.
• Do not spray the battery with high pressure spray.
• Do not use or charge the battery in temperatures below
-20F or above 150F.
• Use the charger supplied with the machine. Other char-
gers may damage the battery and void the warranty. ♦
3.5 - Battery Troubleshooting
Problem Solutions
Machine won’t run. Check battery is securely
plugged into charger.
Make sure battery is
charged.
Check circuit breaker has
not popped out.
Battery charger not turning
on.
Check battery charger is
securely plugged into AC
power.
Ensure the outlet that the
charger is plugged into is
working.
Lights on battery do not
turn on when plugged into
charger.
Plug battery into charger
while the charger is un-
plugged from AC power.
Only plug charger into
AC power after battery is
plugged into charger.
Check battery is securely
plugged into charger.
Check battery charger is
securely plugged in to AC
power.
Check outlet charger is
plugged into is functional.
Red light on charger blinks. Check battery is securely
plugged into charger.
Check circuit breaker has
not popped out.
Check Override switch is in
the “on” position.
Put charger and battery in
cooler location.
With the battery still
plugged into the charger,
unplug the charger from
the wall outlet for 20 sec-
onds. Then plug back into
the wall.
Battery does not run long
enough.
Charge battery again.
Apply less pressure to
brush or pad.

14
4 - MACHINE MAINTENANCE
In order to keep the Orbital Floor Machine running
smoothly and reduce the risk of damage to the machine
and subsequent downtime, Mytee recommends following
the maintenance schedule to the right:
Maintenance Item Daily Weekly
Clean and inspect motor. X
Check power supply cable. X
Clean machine with all purpose
cleaner and cloth. X
Inspect machine for water leaks and
loose hardware. X
1. Remove the pad driver assembly
by removing the four bolts with a 7/16”
wrench or socket.
2. Using a 3/16” Allen wrench, undo
the two Allen bolts holding the bearing
onto the ywheel.
3. Remove the Allen bolts from the
bearing and apply Blue Loctite®.
4. Insert the Allen bolts into the new
bearing and line up the bolts with the
holes on the ywheel.
5. Using the 3/16” Allen wrench, bolt
the new bearing onto the ywheel.
6. Apply Blue Loctite®to the pad
driver bolts and bolt it back onto the
machine. ♦
4.1 - Flywheel Bearing Replacement
The ywheel bearing is a wear part, similar to rotors on a
car. Over time, the bearing will require replacing.
Tools Needed:
• 7/16” open-ended wrench or socket
• 3/16” Allen wrench
• Blue Loctite®

15
4 - MACHINE MAINTENANCE
1. Remove the pad driver assembly
by removing the four bolts with a 7/16”
wrench or socket.
2. Hold the jam nut, located between
the ywheel and motor, in place with a
15/16” open-end wrench. Using a mal-
let, tap the ywheel counter-clockwise
to loosen.
3. Remove the plastic plug from the
top of the motor and hold the motor
shaft in place by inserting a athead
screw- driver into the top of the shaft
on top of the motor. Loosen the y-
wheel the rest of the way o with the
other hand.
4. Apply Anti-Sieze to the motor shaft.
To install the new ywheel, hold the
motor shaft in place with the athead
screwdriver just like before and thread
the new ywheel on with the other
hand until it stops at the jam nut.
5. Use the 15/16” wrench to hold the
jam nut in place and use a mallet to
strike the ywheel counterweight to
tighten the ywheel against the jam
nut.
6. Apply Blue Loctite®to the pad
driver bolts and bolt it back onto the
machine. ♦
4.2 - Flywheel Replacement
These instructions cover how to remove and replace the
ywheel assembly on ECO-17 and ECO-13 models.
Tools Needed:
• 7/16” open-end wrench or
socket
• 15/16”open-end wrench
• Soft-face dead blow
mallet
• Anti-Sieze
• Flathead screwdriver
• Blue Loctite®

16
5 - TROUBLESHOOTING
6.1 - Machine Troubleshooting
Plug on the power cord doesn’t light up when
plugged in.
Possible Causes Solutions
Problem with the power
cord.
Replace power cord.
38” Pigtail: Part # E575
Burnt out light. No action needed or
replace power cord.
38” Pigtail: Part # E575
Plug lights up when plugged in but machine does not
turn on.
Possible Causes Solutions
Wires connecting to the
switch may be loose or
disconnected.
Open up the faceplate on
the handle and check the
switch for loose or discon-
nected wires. Re-connect
any loose wires.
Bad power switch. Replace switch. Part #
E515
(120 volt units only) Motor
circuit breaker may have
tripped.
Make sure motor is rst
cooled down, then reset
breaker by pressing button
located on bottom of motor
conduit box (see Figure
A). Make sure that only the
proper Mytee power cord
extension is being used,
and that it is good condi-
tion. If the problem persists
or reoccurs, contact a
Mytee Service Center.
Motor is drawing too many amps and blowing
breakers.
Possible Causes Solutions
Power cord is defective or
damaged.
Replace power cord. 38”
Pigtail: Part # E575
Power switch has shorts or
loose connections.
Replace power switch. Part
# E515
Power cord from the switch
is defective or damaged.
Replace power cord. 38”
Pigtail: Part # E575
Machine is making a loud grinding noise.
Possible Causes Solutions
Bearing failure. Replace bearing (click for
instructions). Install Part
# A140 Kit if using gravity
feed (click for instructions).
6.2 - Pump Troubleshooting
No water ow.
Possible Causes Solutions
Tank is empty. Fill tank.
Filter is clogged. Clean the lter.
Pump valves are clogged
or damaged.
Examine the valves and
clean or replace.
Low pressure.
Possible Causes Solutions
Work nozzle. Replace nozzle with a new
one of the same size.
Leak in high pressure hose
or connections.
Check the hose and con-
nections.
Filter is clogged. Clean the lter.
Pump valves are clogged
or damaged.
Examine the valves and
clean or replace.
Pump pulsates when spraying.
Possible Causes Solutions
Filter is clogged. Clean the lter.
Pump valves are clogged
or damaged.
Examine the valves and
clean or replace.
Leaks seen under pump.
Possible Causes Solutions

17
5 - TROUBLESHOOTING
Worn pump seals. Replace with new plunger
and seals.
Abrasives in solution have
damaged pump seals.
Mix chemical thoroughly
and make sure lter is not
damaged.

Mytee Products, Inc.
13655 Stowe Dr.
Poway, CA 92064
www.mytee.com
© 2018 Mytee Products, Inc.
Printed in the USA
NOTES
