Mytee Hot Turbo 240-120 User manual

Mytee Hot Turbo Models:
240-120, 480-120
User Manual
13655 Stowe Dr. Poway, CA 92064
P: [phone]
F: [phone]
www.mytee.com
REV. 1/26/22

2
Introduction
Dear Customer:
Congratulations on the purchase of your new Mytee Hot Turbo External Heater. As tech-
nology continues to develop you can work condently knowing that both Mytee and its
employees are equally dedicated to developing with the industry and its advances.
Like any other piece of machinery or technology, the Mytee Hot Turbo also requires
proper maintenance and care to keep the product working over extended use.
Neglecting your machine, abusing it or not operating it properly can void its warranty
and prevent the machine from performing to the quality and standard you’d expect out
of the Mytee line.
If you have any warranty concerns or questions, please review this manual thoroughly
or do not hesitate to contact your distributor. If there are questions regarding main-
tenance, replacement, or ordering parts please contact an authorized Mytee Service
Center. To see an updated list please visit our website at http://www.mytee.com/
support/service-centers.
Before using your Mytee product, please read this manual thoroughly.
Sincerely,
Mytee Customer Care Dept.

3
Table of Contents
1
2
3
Important Safety Information 4
At a Glance 6
1.1 - Technical Specications 6
1.2 - Product Features 6
Machine Operation 7
2.1 - Powering the Mytee Hot Turbo 7
2.2 - Connecting to Extractor/Truckmount 7
2.3 - Operation 7
Machine Maintenance 8
3.1 - Opening the Machine for Maintenance 8
3.2 - System Maintainer 8

4
Important Safety Information
Please read and understand this manual completely before
operating this machine.
Grounding Instructions
This machine must be grounded. If it should malfunction or break
down, grounding provides a path of least resistance for electrical
shock. This machine is equipped with a cord having an equip-
ment-grounding conductor and grounding plug. The plug must
be plugged into an appropriate outlet that is properly installed in
accordance with all local code and ordinances. Do not remove
ground pin; if missing, replace plug before use.
Improper installation of the equipment-grounding conductor can
result in a risk of electric shock. Be sure to check with a qualied
electrician or service person if you are in doubt as to whether the
outlet is properly grounded. If the plug will not t in the outlet do
not modify the plug or the machine’s cord, instead have a proper
outlet installed by a qualied technician.
This machine is for use on a nominal 120-volt circuit and with a
grounding plug similar to the one in Figure 1 below. If a proper
outlet is not available, follow the illustrations of Figure 2 & 3
to install a temporary-grounding plug. This temporary work-
around should be used only until a proper outlet (Figure 1) can
be installed by a qualied electrician. When and if this type of
adapter is employed, screw the adapter’s extended tab into
place with a metal screw. However, grounding adapters are not
approved for use in Canada.
Again, be sure to check the grounding pin for damages and
replace if necessary.
The Green, or Green-Yellow, wire in the cord is the grounding
wire. When replacing a plug, this wire must be attached to only
the grounding pin.
DO NOT use extension cords.
Please Note for America use only.
Parts and Service
Please contact Mytee service personnel or a Mytee authorized
Service Center using Mytee original replacement parts and
accessories if repairs need to be performed. When and if calling
Mytee for support, please have your Model and Serial Number
available for faster assistance.
Name Plate
The Model and Serial Number are located on the lower half of the
back of the machine near the power plug and will be required for
ordering replacement parts. You can use the space provided in
this manual to note down both for future referencing.
Unpacking the Machine
When your new machine is delivered, please carefully inspect
both the shipping carton and the machine for damages. If
damage is evident, save both the shipping carton and machine
so that the delivering carrier can inspect it. Contact the carrier
immediately to le a freight claim if there has been any damage.
Caution and Warnings
Symbols
Mytee uses the symbols below to signal potentially dangerous
conditions. Always read this information carefully and take the
necessary steps to protect personnel and property.
Is used to warn of immediate hazards that will cause severe
personal injury or death.
Is used to call attention to a situation that could cause severe
personal injury.
Is used to call attention to a situation that could cause minor
personal injury or damage to the machine or other property.
When using an electrical appliance, basic precautions should
always be followed, including the following: Read all instructions
before using this machine. This product is intended for commer-
cial use only.
Figure 1
Grounding Pin
Grounded Outlet
Grounded Outlet Box
Adapter
Tab for Grounding
Screw
Metal
Screw
Figure 2 Figure 3

5
Important Safety Information
To reduce the risk of re, electrical shock, or injury:
1. Read all instructions before using equipment.
2. Use only as described in this manual. Use only manufacturer’s
recommended attachments.
3. Always unplug power cord from electrical outlet before at-
tempting any adjustments or repairs.
4. Do not unplug by pulling on cord. To unplug, grasp the plug,
not the cord.
5. Do not pull or carry by cord. Do not close a door on cord or
pull cord around sharp edges or corners.
6. Do not run appliance over cord. Keep cord away from heated
surfaces.
7. Do not use with damaged cord or plug. If cord is damaged,
repair immediately.
8. Do not use outdoors or on wet surfaces and/or standing
water.
9. Always unplug or disconnect the appliance from power
supply when not in use.
10. Do not allow to be used as a toy. Close attention is
necessary when used by or near children.
11. Do not use in areas where ammable or combustible
material may be present.
12. Do not leave the unit exposed to harsh weather elements.
Temperatures below freezing may damage components and void
warranty.
13. Use only the appropriate handles to move and lift unit. Do
not use any other parts of this machine for this purpose.
14. Keep hair, loose clothing, ngers, and all parts of the body
away from all openings and moving parts.
15. Use extra care when using on stairs.
16. To reduce the risk of re or electric shock, do not use this
machine with a solid-state speed control device.
17. The voltage and frequency indicated on the name plate must
correspond to the wall receptacle supply voltage.
18. When cleaning and servicing the machine, local or national
regulations may apply to the safe disposal of liquids which
may contain: chemicals, grease, oil, acid, alkalines, or other
dangerous liquids.
19. Do not leave operating unattended.

6
1 - At a Glance
1. Carrying Handle
2. Switch Plate
3. Input Hose with Male Quick Connect
4. Output Female Quick Connect Fitting
5. Power Cord(s)
1.1 - Technical Specications
1.2 - Product Features
240-120 Mytee Hot Turbo
Max. Pressure 1,500 PSI
Max.
Temperature 210º F
Max. Wattage 2,400 W (4x 600 W)
Power Cord Single 25’ 12/3
Amp Draw 5 amps per switch @ 115V
2.5 amps per switch @ 230V
Product Weight 26 lbs.
Product
Dimensions 11.5” x 12.5” x 11”
480-120 Mytee Hot Twin Turbo
Max. Pressure 1,500 PSI
Max.
Temperature 210º F
Max. Wattage 4,800 W (4x 1,200 W)
Power Cord Dual 25’ 12/3
Amp Draw 10 amps per switch @ 115V
5 amps per switch @ 230V
Product Weight 30 lbs.
Product
Dimensions 11.5” x 12.5” x 11”
1
2
3
4
5

7
2 - Machine Operation
2.1 - Powering the Mytee Hot Turbo
Plug the power cord(s) into the appropriate outlet(s).
For dual cord units, plug the two cords into two separate circuits. The indicator light will turn on when
this is done. ♦
2.2 - Connecting to Extractor/Truckmount
Connect the input hose to your extractor or truckmount. A longer
solution hose can be used between the Mytee Hot Turbo and the
extractor if necessary.
Connect a solution line from the output connection to your
cleaning tool. ♦
2.3 - Operation
In order to avoid vapor lock, the extractor/truckmount and Mytee Hot Turbo should be switched on by following the procedure below
after a cleaning tool is connected:
1. Activate the pump on your extractor or truckmount. Pull the lever on the cleaning tool to release air in the line. Hold lever until a
steady ow of water comes out of the tool.
2. Once pump is primed and there is pressure in the solution line, turn on however many heaters on the Mytee Hot Turbo you are
using and wait a few minutes for water to heat up.
3. Once water is heated, turn on vacuum and begin cleaning. ♦
Dual cord units must
be plugged into two
separate circuits.

8
3 - Machine Maintenance
In order to keep the Mytee Hot Turbo operating smoothly and reduce the risk of damage to the machine and subsequent downtime,
Mytee recommends following the maintenance schedule below:
Maintenance Item Daily Weekly
Clean and inspect hoses and ttings. X
Check power cable. X
Clean machine with all-purpose cleaner
and cloth. X
Flush solution system with Mytee
System Maintainer X
3.1 - Opening the Machine for Maintenance
Unscrew the four Phillips head screws around the outside of the heater lid. The lid can then be lifted o to gain access to the compo-
nents. ♦
3.2 - System Maintainer
Regular ushing of the solution system with Mytee System Maintainer keeps your extractor running eciently by removing hard
water scaling that builds up in the system.
How to use System Maintainer:
1. Thoroughly mix System Maintainer with warm water at a 1:1 ratio in a separate container. Pour into your extractor’s solution tank.
2. Connect the Mytee Hot Turbo to the extractor and connect a cleaning tool to the Mytee Hot Turbo.
3. Turn on the extractor’s pump and run the System Maintainer solution through the Mytee Hot Turbo and into a bucket or receptacle
until you have a solid stream.
4. Let sit for about 5 minutes while the System Maintainer solution works.
5. Finish running the rest of the solution through the system.
6. Run clean water through the system to ush out any remaining System Maintainer. ♦
