Mytee M-3 User manual

Instructions for
M-3, M-5, M-12 & M-16 M-Series™
13655 Stowe Dr., Poway, Ca. 92064
Model #
Serial #
Form # ADM-MSeries
1-12
M-3 p. 2
M-5 p. 8
M-12 p. 14
M-16 p. 21
General information p. 27
Please read before use.
Register your product
at www.mytee.com/help

1

2
M-3 BACKM-3 FRONT
1. Switch plate
2. 2” Male Cuff-Lynx™
3. Female quick disconnect (QD)
4. Front handles
5. Prime valve
1
6. Pressure regulator
7. Front cooling fan
8. 4” locking casters
9. Solution tank
10. Solution tank cover
5
6
8
11. Recovery tank lid
12. Push handle
13. Drain valve
14. Auto-ll
15. Auto pump-out
12
14
16. Rear cooling fan
17. Dual power cords
18. 12” rear wheels
19. Latches (x2)
20. Recovery tank
16
11
10
9
2
3
4
7
13
15
17 18
19
20
M-3 ITEMS INCLUDED
H375 Hose Hanger H226 Drain Elbow
(4) screws
H110 Cuff-Lynx™ H141 Cuff-Lynx™
2” Hose Adapter 2” Hose Reducer to 1.5”
M-3 DUAL CORDS
Plug each of the two power cords into two separate, 20A grounded
wall outlets. The amber light indicator on the switch plate will illumi-
nate when cords are plugged into two separate circuits.
Top cord: Plug into power Vac 1, Pump & Heater 1.
Bottom cord: Plug into power Vac 2, Pump-out & Heater 2.
Top cord
Bottom cord
M-3 M-SERIES™

3
M-3 SWITCHES & PRESSURE GAUGE
Switches and Pressure Gauge are located on the plate in front
of the machine. The Amber light left of the Pressure Gauge will
illuminate when cords are plugged into two separate circuits. To use
vacuums, turn on Vac 1 and Vac 2 switches. To use Pump, turn on
Pump switch. Heater switch has three positions: Off (middle); 1,000
watts using one heater (left); and 2,000 using two heaters (right).
Red lights on panel display indicate watts selected: one light =
1,000 watts; two lights = 2,000 watts; no lights = heater is off.
VAC 1 VAC 2
PUMP HEATER
M-3 VAC/SOL HOSE CONNECTIONS
Before turning on switches, connect hoses to the extractor and a
wand or tool. Attach a solution hose to the front QD, the other end
to the tool. Attach a vacuum hose to the tool, the other to the front
Cuff-Lynx™ vacuum hose port. Just twist into place.
M-3 AUTO-FILL & PUMP-OUT
If using Auto-ll and Pump-out, connect one end of a 1/2 inch
garden hose to the top hose inlet in back of the machine, the other
end to a faucet. Add water pressure by turning on faucet. Attach a
second 1/2 inch garden hose to the bottom hose inlet, and place the
other end in a location where dirty water can drain. Turn on Pump-
out switch. When job is complete, turn off Pump-out switch.
AUTO-FILL
PUMP-OUT
M-3 FILL SOLUTION TANK
If not using the Auto-ll feature, lift the solution tank lid and manually ll
the tank.
PUMP-OUT
M-3 M-SERIES™

4
M-3 DRAIN VALVE & LATCHES
You can drain the recovery tank by using the Drain Valve. When
not using the Auto Pump-out, you can drain the recovery tank by
using the Drain Valve. When the tank is full, an internal ball oat
will automatically shut off the vacuum. Attach the 45˚ drain elbow
to the drain spout, and lift up the Drain Valve to empty the tank.
Latches are located in the back to open tank for internal repairs.
M-3 FILTER MAINTENANCE
CLEAN WATER
INTAKE FILTER
PUMP-OUT
FILTER
PRIME VALVE
FILTER
To clean the internal lters, lift solution lid and/or remove recovery tank
lid, reach in and twist off. Rinse with clean water and replace.
M-3 PRIME VALVE & PRESSURE REGULATOR
M-3 AUTO-FILL & FLOAT
After attaching a garden hose to the Auto-ll inlet, water will ll the
tank to a predetermined level until stopped by the oat. As water is
used and the level drops, water will once again enter the tank, and
be stopped again by the oat when maximum level is reached.
With each new job, check to make sure oat stops water after the
rst ll.
PRESSURE
REGULATOR
PRIME VALVE
1003/1005
Prime the pump by turning the valve to the Prime position for 30
seconds, then turn horizontally to the Run position. Turn the
Pressure Regulator to the left to decrease the water pressure.
Turn the pressure regulator to the right to increase the water
pressure. Monitor pressure while adjusting, using Pressure Gauge
on Switch Panel.
HIGHER PSI
LOWER PSI
M-3 M-SERIES™

5
M-3 M-SERIES™ PARTS & PRICING
Part prices are subject to change.Order parts at: http://www.mytee.com/products/product.php?id=M-3
ITEMS NOT SHOWN
ITEM
NO.
PART
NO.
DESCRIPTION
QTY.
MSRP
1
H304
screw, #8 x 5/8 phil oval, s/s
6 $0.99 ea
2
G090
lid, vac tank, black, 7"
1 $36.99 ea
3
G091
gasket, 7", vac lid
1 $11.99 ea
4
P726
elbow, 2" float
1 $11.49 ea
5
H297
screw, 8 x 1/2", hex head, zinc
3
6
H490
float, 2", ball style
1 $18.49 ea
7
P682
pipe, pvc, 2" 1
$7.99/ft
8
P684
adaptor, pvc 2, fmsl x fmt
1 $6.99 ea
9
P685
inlet, 2"
1 $10.99 ea
10
H135
Cuff-Lynx, 2" m cuff x 2" mpt
1 $3.99 ea
11
A926
elbow, inlet assembly 2"
1 $15.99 ea
12
P709 vac tank, m series
1 $243.99 ea
13
H225
valve, drain, 1-1/2"
1 $20.99 ea
14
H390A
bracket, "L" (all extracters)
2 $6.99 ea
15
H770
bolt, 1/4-20 x 1/2" serrated hex flange, zinc
4 $0.99 ea
16
B119
filter, strainer, 1/4"
1 $3.99 ea
17
B130
45 deg, street elbow, brass, 1/4" male NPTF
3 $5.49 ea
18
H212
washer, 9/16"id x 1"od, flat, s/s
6 $0.99 ea
19
B106
nipple, brass, 1/4" x close
1 $3.49 ea
20
B111
adapter, brass, extender, 1/4" mpt x 1/4" fpt, hex
3 $3.49 ea
21
H333
mesh filter, auto dump, 1/2" npt
1 $9.99 ea
22
B210
bushing, brass, 1/2"mpt x 3/8" fpt, hex
3 $2.49 ea
23
H299
washer, 11/16"id x 1-1/2"od x .075, s/s
9 $0.99 ea
24
B216
nipple, brass, 3/8" x close
2 $1.99 ea
25
B103
elbow, brass, 90 deg, 1/4"mpt x 1/4" fpt 8 $4.49 ea
26
AH203
hose, pulse, 3/8" x 34", (OAL)
1 $47.99 ea
27
H337
plate, switch, sp, 4 hole w/gauge
1 $8.99 ea
28
E512B
light, indicator, 125v (amber)
1 $9.99 ea
29
E511
light, red, 250v
2 $5.99 ea
30
E515
switch, rocker, 2 position
4 $13.99 ea
31
E516
switch, rocker, 3 position
1 $14.99 ea
32
H389
screw, #10-32 x 1/2" SHCS, alloy
3 $0.99 ea
33
H616
Washer, #8, flat regular
3 $0.99 ea
34
H308D
gauge, pressure, 2000 PSI
1 $38.99 ea
35
B643
adapter, brass, 3/8" female npt x 1/4" male npt
1 $4.99 ea
36
AH195
sol hose, 57 x 1/4", (OAL), m x msw 3000psi
1 $37.99 ea
37
H484
plate, mounting, QD
1 $4.99 ea
38
H230
screw, 10-32 x 1/2" phil pan head, s/s 19 $0.99 ea
39
B102
qd, brass, 1/4" f
1 $17.99 ea
40
H203
bolt, 1/4-20 x 1 1/4"
2 $0.99
41
H211
washer, 1/4"id x 1"od, flat, s/s
8 $0.99 ea
42
G052
washer, buna 1-1/8" od x 3/16" id
6 $1.99 ea
43
H213
washer, 1/4" lock, s/s
4 $0.99
44
H215
nut, hex, 1/4-20 s/s
2 $0.99 ea
45
G212
cover, sol tank (m-series)
1 $12.99 ea
46
H541
valve, float, autofill
1 $124.99 ea
47
B115
nipple, 12" x 1/4" npt, m x m
1 $23.99 ea
48
B105
bushing, brass, 3/8"mpt x 1/4" 4 $3.19 ea
49
P708
sol tank, m series
1 $210.99 ea
50
H485
handle, breeze and dx
2 $6.99 ea
51
H768
bolt, 1/4-20 x 3/4" serrated hex flange, zinc
13 $0.99 ea
52
B119A
filter, strainer, 1/2"
1 $6.49 ea
53
B186
elbow, brass, 90 deg, 3/8"mpt x 3/8" fmpt
5 $8.99 ea
54
H343
screw, #10 x 5/8" hex head zinc
10 $0.99 ea
55
H544
cuff hose, 2 X 2, wire reinforced
1 $12.49 ea
56
PH628-25
vac hose, 2", black wire reinforced
1
$8.99/ft
57
G059
exhaust boot, plastisol
2 $4.99 ea
58
C302 vac motor, 3 stage, 120V, tangential
2 $139.99 ea
59
H501
vac support, 3 stage, 4-1/16"
6 $4.99 ea
60
H217
clamp, hose, 2-1/4 dia
3 $1.49 ea
61
G004
gasket, vacuum motor
2 $8.99 ea
62
P750
manifold, dual vac, parallel
1 $15.99 ea
63
H601
plate, manifold, parallel
1 $13.49 ea
64
H216
nut, lock, 1/4-20, nylon insert, s/s
17 $0.99
65
H210
washer, 1/4" flat, s/s
35 $0.99 ea
66
H202
bolt, 1/4x20x3/4" hex head
10 $0.99
67
H191
washer, zinc, 1.625 x .847 x .078
2 $0.99 ea
68
AH202
hose, pulse, 3/8" x 34", (OAL)
1 $39.99 ea
69
H903A
heater, aluminum cast, single
2 $78.99 ea
70
E519
heating rod, 1000W, 115V
2 $51.99 ea
ITEM
NO.
PART
NO.
DESCRIPTION
QTY.
MSRP
71
E573
Thermostat, 200°, Auto, 1/4"
2 $16.49 ea
72
H274
screw, #6x3/16,phil pan head, self-tapping
2 $0.99 ea
73
E574
Thermostat, 310°F ± 10°F, Manual, 1/4"
2 $17.99 ea
74
AH184
hose, 3/8" x 14-1/2" (OAL), f
1 $27.99 ea
75
AH156
hose, 3/8" x 6.5", (OAL), f x fsw, 5400 Gray
1 $23.99 ea
76
B207
elbow, brass, 90 deg, 1/4" fpt x 1/4" fpt 1 $5.99 ea
77
H528
bracket, heater mounting, dual
1 $29.99 ea
78
B235
adapter, brass, 3/8" barb x 1/4" fsw
2 $7.99 ea
80
H347
clamp, hose, 5/16-29/32
24 $1.99 ea
80
PH715-28
sol hose, kuriyama, 3/8"
1
$7.99/ft
81
AH103
hose, 3/8" x 10", (OAL), f x f
1 $30.49 ea
82
B136
elbow, brass, 90 deg, 1/4" mpt x 1/4" mpt
1 $4.99 ea
83
B107 nipple, brass, 1/4"m, hex
3 $3.19 ea
84
B656
ball valve, 1/4''
1 $13.49 ea
85
B246
plug, brass, 3/8" mpt, hex
3 $1.99 ea
86
AH108S
sol hose, 1/4" x 24 1/2", (OAL)
1 $39.99 ea
87
C313
pump, 500 psi, 115V 1 $588.99 ea
88
B160
adapter, brass, 1/2" barb x 3/8" fsw, ball end
2 $3.49 ea
89
PH615-21
sol hose, 1/2", kuri 100 psi
1
$8.99/ft
90
B644
adapter, brass, 1/2" barb x 1/4" mpt
2 $2.49 ea
91
C313C
regulator, 450 psi, silver spring
1 $86.99 ea
92
B652
elbow, brass, 90 deg, 3/8"mpt x 1/4"mpt
1 $8.49 ea
93
PH615-24
sol hose, 1/2", kuri 100 psi
1
$8.99/ft
94
B172
elbow, brass, 90 deg, 1/2" barb x 3/8"mpt
2 $9.49 ea
95
B242
tee, brass, 3/8" fpt x 3/8" mpt x 3/8" fpt
1 $13.99 ea
96
PH615A-10
solution hose, black, low pressure, 1/2"
1
$5.99/ft
97
E550
power cord, pigtail, 30", 12/3, black
2 $11.49 ea
98
H220
fitting, strain relief, cord
2 $3.19 ea
99
H221
nut, lock, 1/2" steel
2 $1.99 ea
100
H486
latch, front breeze
2 $13.99 ea
101
H273
nut, kep, #10-32 zinc
13 $0.99 ea
102
H256
screw, #10-32 x 3/4" phil pan head, zinc
1 $0.99 ea
103
H410
plate, switch, spotter
1 $5.99 ea
104
B221
plug, brass, 3/4", garden hose 1 13.99 ea
105
B640
filter, 60 mesh, garden hose
1 $1.99 ea
106
B642
swivel, brass, 3/4" fgh x 1/2" fpt 1 $5.49 ea
107
B120
cap, brass, 3/4", garden hose 1 $1.49 ea
108
B196
fitting, brass, 3/4" mgh x 1/2" fpt
1 $5.99 ea
109
H296
guard, cooling fan, wire
2 $2.99 ea
110
H219 cap, axle, 1/2"
2 $0.99 ea
111
H251
wheel, 12"
2 $41.99 ea
112
H254
washer, axle, cut 1/2" id
3 $0.99 ea
113
H232 axle, 19.75" x .50"
1 $9.99 ea
114
P707
base, m series 1 $196.99 ea
115
H378
bracket, front hinge, sp/fb
1 $8.99 ea
116
H378
bolt, 1/4-20 x 1 3/4" hex head, s/s
2 $0.99
117
H201
bolt, 1/4-20 x 1/2", hex head, zinc
2 $0.99 ea
118
H668
caster, 4", black hub & gray tread
2 $19.49 ea
119
H342
bolt, 1/4-20 x 1" hex head, s/s 8 $0.99
120
B236
elbow, brass, 90 deg, 1/2" barb x 3/8" fpt
1 $14.49 ea
121
PH615-37
sol hose, 1/2" kuri 100psi
1 $0.99 ea
122
C381
pump out, 115v
1 $187.49 ea
123
PH615-17 sol hose, 1/2", black, 200 psi 200 degree max
1
$8.99/ft
124
H186
screw, 10-32 x 3/4", phil flat full thread, black oxide
4 $0.99 ea
125
B132
adapter, brass, 1/2" barb x 1/2" mpt
1 $9.49 ea
PART
NO.
DESCRIPTION
QTY.
MSRP
G010
filter, bag, vac tank, draw string
1 $9.99 ea
E564
controller, circuit light
1 $62.49 ea
G085
gasket, strip, 3/4" x 36" x 1/8"
2 $4.99 ea
H375
hanger, wire formed, hose
1 $10.99 ea
H226
spout, drain, 45 degree
1 $3.19 ea
D
C
B
A
A
B
C
D
1
2
3
4
5
6
7
8
8
7
6
5
4
3
2
1
E
F
E
F
M3
SHEET 1 OF 2
M Series
SCALE: 1:2
REV
DWG. NO.
D
SIZE
TITLE:
NAME
DATE
CHECKED
DRAWN
PROPRIETARY AND CONFIDENTIAL
THE INFORMATION CONTAINED IN THIS DRAWING IS THE SOLE PROPERTY OF MYTEE PRODUCTS, INC. ANY REPRODUCTION IN PART OR AS A WHOLE WITHOUT THE WRITTEN PERMISSION OF MYTEE PRODUCTS, INC. IS PROHIBITED.
mytee
PRODUCTS, INC.
858-679-1191
M. LaBarbera
5/25/11
OD
DO NOT SCALE DRAWING

6
M-3 M-SERIES™ PARTS & PRICING
58
59
60
58
57
55
6722
68
53
69
70
25
25
75
76
86
83 48
66
65
65
90
96
94
80
80 78
18
25
18 83
17
83
81
89
90
91
80
92
53
53
114
5141
50
65
118
65
119 23
98
97
54
100
46
25
20
47
48
23
49
17
18
18
25
52
23
23
23
24
23
53
39
20 38
36
37
44
43
41
42
42
41
40
29
30
31
32
33
28
27
25
35
14
15
16
17
18 18
19
20
24
23
23
21
12
11
10
9 8
7
4
2
95
38
104
107
106
108
101
113
112 112
111 110
103
51
41
42
50
64
63
65
51
66
78
1
to pump "OUT"
thru AH108s
#
86
to pressure
guage
through B643
#
35
74
to heaters "OUT"
thru B207
#
76
to AH202
thru B186
#
53
23
94
48
80
88
93
120
121
122
124
65
101
123
80
125
67
50
25
84
to sol tank
through B186
#
53
to pump "in"
#
87
38
30
102
109
99
to pump out
thru B132
#
125
to B196
#
108
to vac tank
thru B142
#
24
to pump in
thru B160
#
88
to regulator
thru B105
(#
48
)
to prive valve
thru B235
#
78
to pump out
thru B236
#
120
to sol tank
thru B103
#
25
to vac tank
thru B111
#
20
to sol tank
thru B105
#
48
to B642
#
106
34
115
116
65 65 43
117
88
48
80
25
6
105
45
56
54
51
61
71
72
73
?
to AH202
thru B210
#
22
To qd
thru AH195
#
36
87
85
22
13
5
101
3
26
82
77
D
C
B
A
A
B
C
D
1
2
3
4
5
6
7
8
8
7
6
5
4
3
2
1
E
F
E
F
M3
SHEET 2 OF 2
M Series
SCALE: 1:2
REV
DWG. NO.
D
SIZE
TITLE:
NAME
DATE
CHECKED
DRAWN
PROPRIETARY AND CONFIDENTIAL
THE INFORMATION CONTAINED IN THIS DRAWING IS THE SOLE PROPERTY OF MYTEE PRODUCTS, INC. ANY REPRODUCTION IN PART OR AS A WHOLE WITHOUT THE WRITTEN PERMISSION OF MYTEE PRODUCTS, INC. IS PROHIBITED.
mytee
PRODUCTS, INC.
858-679-1191
M. LaBarbera
5/25/11
OD
DO NOT SCALE DRAWING

7
M3
Amber
M3Wiring
PUMP OUT
TopCord
BottomCord
M-3 M-SERIES™ WIRING DIAGRAM

8
M-5 DUAL CORDS
Plug each of the two power cords into two separate, 20A grounded
wall outlets. The amber light indicator on the switch plate will illumi-
nate when cords are plugged into two separate circuits.
M-5 BACKM-5 FRONT
1. Switch plate
2. 2” Male Cuff-Lynx™
3. Female quick disconnect (QD)
4. Front handles
5. Prime valve
1
6. Pressure regulator
7. Front cooling fan
8. 4” locking casters
9. Solution tank
10. Solution tank cover
5
6
8
11. Recovery tank lid
12. Push handle
13. Drain valve
14. Auto-ll
15. Auto pump-out
12
14
16. Rear cooling fan
17. Dual power cords
18. 12” rear wheels
19. Latches (x2)
20. Recovery tank
16
11
10
9
2
3
4
7
13
15
17 18
19
20
M-5 ITEMS INCLUDED
H375 Hose Hanger H226 Drain Elbow
(4) screws
H110 Cuff-Lynx™ H141 Cuff-Lynx™
2” Hose Adapter 2” Hose Reducer to 1.5”
Top cord: Plug into power Vac 1 & Pump.
Bottom cord: Plug into power Vac 2 & Pump-out.
Top cord
Bottom cord
M-5 M-SERIES™

9
M-5 SWITCHES & PRESSURE GAUGE
Switches and Pressure Gauge are located on the plate in front of
the machine. The Amber light left of the Pressure Gauge will il-
luminate when cords are plugged into two separate circuits. To use
vacuums, turn on Vac 1 and Vac 2 switches. To use Pump, turn on
Pump switch. The Pressure Gauge displays the water pressure as
PSI. To use Pump-out feature, turn on Pump-out switch.
VAC 1 VAC 2
PUMP OUT PUMP
M-5 VAC/SOL HOSE CONNECTIONS
M-5 AUTO-FILL & PUMP-OUT
AUTO-FILL
PUMP-OUT
M-5 FILL SOLUTION TANK
If not using the Auto-ll feature, lift the solution tank lid and manually ll
the tank.
If using Auto-ll and Pump-out, connect one end of a 1/2 inch
garden hose to the top hose inlet in back of the machine, the other
end to a faucet. Add water pressure by turning on faucet. Attach a
second 1/2 inch garden hose to the bottom hose inlet, and place
the other end in a location where dirty water can drain.
Before turning on switches, connect hoses to the extractor and a
wand or tool. Attach a solution hose to the front QD, the other end
to the tool. Attach a vacuum hose to the tool, the other to the front
Cuff-Lynx™ vacuum hose port. Just twist into place.
M-5 M-SERIES™

10
M-5 FILTER MAINTENANCE
CLEAN WATER
INTAKE FILTER
PUMP-OUT
FILTER
PRIME VALVE
FILTER
To clean the internal lters, lift solution lid and/or remove recovery tank
lid, reach in and twist off. Rinse with clean water and replace.
M-5 DRAIN VALVE & LATCHES
You can drain the recovery tank by using the Drain Valve. When
not using the Auto Pump-out, you can drain the recovery tank by
using the Drain Valve. When the tank is full, an internal ball oat
will automatically shut off the vacuum. Attach the 45˚ drain elbow
to the drain spout, and lift up the Drain Valve to empty the tank.
Latches are located in the back to open tank for internal repairs.
M-5 PRIME VALVE & PRESSURE REGULATOR
M-5 AUTO-FILL & FLOAT
PRESSURE
REGULATOR
PRIME VALVE
Prime the pump by turning the valve to the Prime position for 30
seconds, then turn horizontally to the Run position. Turn the
Pressure Regulator to the left to decrease the water pressure.
Turn the pressure regulator to the right to increase the water
pressure. Monitor pressure while adjusting, using Pressure Gauge
on Switch Panel.
After attaching a garden hose to the Auto-ll inlet, water will ll the
tank to a predetermined level until stopped by the oat. As water is
used and the level drops, water will once again enter the tank, and
be stopped again by the oat when maximum level is reached.
With each new job, check to make sure oat stops water after the
rst ll.
HIGHER PSI
LOWER PSI
M-5 M-SERIES™
1003/1005

11
M-5 M-SERIES™ PARTS & PRICING
Part prices are subject to change.Order parts at: http://www.mytee.com/products/product.php?id=M-5
ITEMS NOT SHOWN
ACCESSORIES
ITEM
NO.
PART NO.
DESCRIPTION
QTY.
MSRP
1
H186
screw, 10-32 x 3/4", phil flat full thread, black oxide
4 $0.99 ea
2
H210
washer, 1/4" flat, s/s
27 $0.99 ea
3
H273
nut, kep, #10-32 zinc
14 $0.99 ea
4
C381
pump out, 115v
1 $187.49 ea
5
PH615-37
sol hose, 1/2", kuri 100 psi
1
$8.99/ft
6
H347
clamp, hose, 5/16-29/32
24 $1.99 ea
7
B236
elbow, brass, 90 deg, 1/2" barb x 3/8" fpt
1 $14.49 ea
8
H299
washer, 11/16"id x 1-1/2"od x .075, s/s
9 $0.99 ea
9
PH615-17
sol hose, 1/2", kuri 100 psi
1
$8.99/ft
10
B132
adapter, brass, 1/2" barb x 1/2" mpt
1 $9.49 ea
11
B644
adapter, brass, 1/2" barb x 1/4" mpt
2 $2.49 ea
12
H191
washer, zinc, 1.625 x .847 x .078
2 $0.99 ea
13
H219 cap, axle, 1/2"
2 $0.99 ea
14
H251
wheel, 12"
2 $41.99 ea
15
H254
washer, axle, cut 1/2" id
3 $0.99 ea
16
H232 axle, 19.75" x .50"
1 $9.99 ea
17
P707
base, m series 1 $196.99 ea
18
H668
caster, 4", black hub & gray tread
2 $19.49 ea
19
H342
bolt, 1/4-20 x 1" hex head, s/s 8 $0.99 ea
20
H216
nut, lock, 1/4-20 nylon insert
17 $0.99 ea
21
H768
bolt, 1/4-20 x 3/4" serrated hex flange, zinc
13 $0.99 ea
22
H211
washer, 1/4"id x 1"od, flat, s/s
8 $0.99 ea
23
H485
handle, breeze and dx
2 $6.99 ea
24
B105
bushing, brass, 3/8"mpt x 1/4" 5 $3.19 ea
25
B160
adapter, brass, 1/2" barb x 3/8" fsw, ball end
2 $3.49 ea
26
PH615-21
sol hose, 1/2", kuri 100 psi
1
$8.99/ft
27
B136
elbow, brass, 90 deg, 1/4" mpt x 1/4" mpt
1 $4.99 ea
28
C313C
regulator, 450 psi
1 $86.99 ea
29
B103
elbow, brass, 90 deg, 1/4"mpt x 1/4" fpt 5 $4.49 ea
30
B656
ball valve, 1/4''
1 $13.49 ea
31
H212
washer, 9/16"id x 1"od, flat, s/s
6 $0.99 ea
32
B107 nipple, brass, 1/4"m, hex
3 $3.19 ea
33
B130
45 deg, street elbow, brass, 1/4" male NPTF
3 $5.49 ea
34
B235
adapter, brass, 3/8" barb x 1/4" fsw
2 $7.99 ea
35
AH103
hose, 3/8" x 10", (OAL), f x f
1 $30.49 ea
36
PH715-28
sol hose, kuriyama, 3/8"
1
$7.99/ft
37
B111
adapter, brass, extender, 1/4" mpt x 1/4" fpt, hex
3 $3.49 ea
38
B106
nipple, brass, 1/4" x close
1 $3.49 ea
39
H343
screw, 10 x 5/8" hex head, zinc
14 $0.99 ea
40
H296
guard, cooling fan, wire
3 $2.99 ea
41
B186
elbow, brass, 90 deg, 3/8"mpt x 3/8" fmpt
4 $8.99 ea
42
AH202
hose, pulse, 3/8" x 34", (OAL)
1 $39.99
43
B210
bushing, brass, 1/2"mpt x 3/8" fpt, hex
3 $2.49 ea
44
H230
screw, 10-32 x 1/2 phil pan
18 $0.99 ea
45
H486
latch, front breeze
2 $13.99 ea
46
H221
nut, lock, 1/2" steel
2 $1.99 ea
47
H220
fitting, strain relief, cord
2 $3.19 ea
48
E550
power cord, pigtail, 30", 12/3, black
2 $11.49 ea
49
G131
connector, cord lock
2 $4.99 ea
50
B221
plug, brass, 3/4", garden hose 1 13.99 ea
51
B120
cap, brass, 3/4", garden hose 1 $1.49 ea
52
B640
filter, 60 mesh, garden hose
1 $1.99 ea
53
B642
swivel, brass, 3/4" fgh x 1/2" fpt 1 $5.49 ea
54
B196
fitting, brass, 3/4" mgh x 1/2" fpt
1 $5.99 ea
55
B172
elbow, brass, 90 deg, 1/2" barb x 3/8"mpt
2 $9.49 ea
56
PH615-10
sol hose, 1/2", kuri 100 psi
1
$8.99/ft
57
B652
elbow, brass, 90 deg, 3/8"mpt x 1/4"mpt
1 $8.49 ea
58
B246
plug, brass, 3/8" mpt, hex
3 $1.99 ea
59
B242
tee, brass, 3/8" fpt x 3/8" mpt x 3/8" fpt
1 $13.99 ea
60
PH615-15
sol hose, 1/2", kuri 100 psi
1
$8.99/Ft
61
AH195
sol hose, 57 x 1/4", (OAL), m
1 $37.99 ea
62
C313
pump, 500 psi, 115V 1 $588.99 ea
63
AH108S
sol hose, 1/4" x 24 1/2", (OAL)
1 $26.49 ea
64
H202
bolt, 1/4-20 x 3/4" hex head, s/s
10 $0.99 ea
65
P735
manifold, single vac, no gasket
2 $14.99 ea
66
H217
clamp, hose, 2-1/4 dia
4 $1.49 ea
67
PH628-25
vac hose, 2", black wire reinforced
1
$ 8.99/ft
68
H544
cuff hose, 2 X 2, wire reinforced
2 $12.49 ea
69
G059
exhaust boot, plastisol
2 $4.99 ea
70
C302A
motor, 3-stage, 115 cfm,14.5 amps
2 $148.99 ea
ITEM
NO.
PART NO.
DESCRIPTION
QTY.
MSRP
71
G004
gasket, vacuum motor
2 $8.99 ea
72
H501
vac support, 3 stage, 4-1/16"
6 $4.99 ea
73
H253
plate, dual manifold, 9" x 13"
1 $14.99 ea
74
G212
cover, sol tank (m-series)
1 $12.99 ea
75
B115
nipple, 12" x 1/4" npt, m x m
1 $23.99 ea
76
H541
valve, float, autofill
1 $124.99 ea
77
H215
nut, hex, 1/4-20 s/s
2 $0.99 ea
78
H213
washer, 1/4" lock, s/s
4 $0.99 ea
79
G052
washer, buna 1-1/8" od x 3/16" id
6 $1.99 ea
80
H203
bolt, 1/4-20 x 1-1/4" hex head, s/s
2 $0.99 ea
81
P708
sol tank, m series
1 $210.99 ea
82
H484
plate, mounting, QD
1 $4.99 ea
83
B102
qd, brass, 1/4" f
1 $17.99 ea
84
B119
filter, strainer, 1/4"
1 $3.99 ea
85
B119A
filter, strainer, 1/2"
1 $6.49 ea
86
H378
bracket, front hinge, sp/fb
1 $8.99 ea
87
H201
bolt, 1/4-20 x 1/2", hex head, zinc
2 $0.99 ea
88
H204
bolt, 1/4-20 x 1-3/4" hex head, s/s
2 $0.99 ea
89
H135
Cuff-Lynx, 2" m cuff x 2" mpt
1 $3.99 ea
90
P684
adaptor, pvc 2, fmsl x fmt
2 $6.99 ea
91
P682
pipe, pvc, 2" 2
$7.99/ft
92
H490
float, 2", ball style
2 $18.49 ea
93
P726
elbow, 2" float
2 $11.49 ea
94
H297
screw, #8 x 1/2", hex head, zinc
6 $0.99 ea
95
H304
screw, #8 x 5/8 phil oval, s/s
6 $0.99 ea
96
G090
lid, vac tank, black, 7"
1 $36.99 ea
97
G091
gasket, 7", vac lid
1 $11.99 ea
98
A926
elbow, inlet assembly 2"
1 $15.99 ea
99
P709 vac tank, m series
1 $243.99 ea
100
H225
valve, drain, 1-1/2"
1 $20.99 ea
101
E564
controller, circuit light
1 $62.49 ea
102
H246
screw, #8-32 x 3/8" SHCS, alloy
1 $0.99 ea
103
P685
inlet, 2"
2 $10.99 ea
104
H390A
bracket, "L" (all extracters)
2 $6.99 ea
105
H770
bolt, 1/4-20 x 1/2" serrated hex flange, zinc
4 $0.99 ea
106
H333
mesh filter, auto dump, 1/2" npt
1 $9.99 ea
107
B643
adapter, brass, 3/8" female npt x 1/4" male npt
1 $4.99 ea
108
AH203
hose, pulse, 3/8" x 34", (OAL)
1 $47.99 ea
109
H308D
gauge, pressure, 2000 PSI
1 $38.99 ea
110
E515
switch, rocker, 2 position
4 $13.99 ea
111
H389
screw, #10-32 x 1/2" SHCS, alloy
3 $0.99 ea
112
H612
washer, #8 flat, s/s
3 $0.99 ea
113
E512B
light, indicator, 125v (amber)
1 $9.99 ea
114
H337
plate, switch, sp, 4 hole w/gauge
1 $8.99 ea
115
B216
nipple, brass, 3/8" x close
2 $1.99 ea
116
H422
plug, dome 3/8", black
2 $0.99 ea
PART NO.
DESCRIPTION
QTY.
MSRP
G085
gasket, strip, 3/4" x 36" x 1/8"
1 $4.99 ea
G010
filrer, bag, vac tank, drawstring
1 $9.99 ea
PART NO.
DESCRIPTION
QTY.
MSRP
ADM-M-SERIES
manual, m-series
1
AD127
stop sign, register your product
1
H226
spout, drain, 45 degree
1 $3.19 ea
H110
cuff-lynx, 2" hose x 2" fem swivel cuff-lynx
1 $3.99 ea
H375
hanger, wire formed, hose
1 $10.99 ea
H230
screw. 10-32 x 1/2" phil pan head, s/s 2 $0.99 ea
H141
cuff-lynx, 2" to 1.5" reducer
1 $3.99 ea
G029
banana bag, mesh bag, yellow
1 $3.99 ea
D
C
B
A
A
B
C
D
1
2
3
4
5
6
7
8
8
7
6
5
4
3
2
1
E
F
E
F
M5
SHEET 1 OF 2
M Series
SCALE: 1:4
REV
DWG. NO.
D
SIZE
TITLE:
NAME
DATE
CHECKED
DRAWN
PROPRIETARY AND CONFIDENTIAL
THE INFORMATION CONTAINED IN THIS DRAWING IS THE SOLE PROPERTY OF MYTEE PRODUCTS, INC. ANY REPRODUCTION IN PART OR AS A WHOLE WITHOUT THE WRITTEN PERMISSION OF MYTEE PRODUCTS, INC. IS PROHIBITED.
mytee
PRODUCTS, INC.
858-679-1191
M. LaBarbera
5/24/11
OD
DO NOT SCALE DRAWING

12
M-5 PARTS & PRICING
1
2
3
4
5
7
8
9
10 12
13
14
15
16
17
18
19
2
21
22
23
24
25
26
6
27
11
28
29
30
29
31
32
32 33
34 35
36
34
37
31
38
39
40
41
115
8
42 43 12
45 46
48 49
47
344
50
51
53
54
55
56
11
57
41 41
58
24
59
55
6
60 25
24
61
62
63
32
24
64
2
20
21
2
65
20
69
70
21
71
72
73
64
8
75
37
29
76
77 78 22
79
79 22
80
81
82
44
37
83
85
43
8
8
41
29
31 31
33
86
87
782
20
2
88
23
79
22
21
107
108
109
111
112
114
113
29
89
90
91
92
93
95
96
98
99
100
103 104
105
31
33
84
8
43
106
to female
garden hose
thru B196
#
54
to vac tank
thru B216
#
115
to sol tank
thru B103
#
29
to vac tank
thru B130
#
33
to male
garden hose,
B642
#
53
to pump out "OUT"
thru B132
#
10
to sol tank
thru B210
#
43
to B105
#
24
to B644 #
11
to sol tank
thru B186
#
41
to female QD
thru B111
#
37
to pressure gauge
thru B643
#
107
to auto fill
thru B105
#
24
to regulator
thru B105
#
24
to 500psi
pump "IN"
thru B160
#
25
to 500 PSI pump
thru Ah108S
#
63
to pump out "IN"
thru B236
#
7
to prime valve
thru B106
#
38
110
52
20
3 3
115
8
8
74
40 39
39
to auto fill thru
B115
#
75
24
8
31
to pump "OUT"
thru B186
41
to regulator
thru B652
#
57
65
69
66
66
67
68
70
to 500 PSI
pump "OUT"
thru Ah195
#
61
94
97
6
66
6
66
101
102
D
C
B
A
A
B
C
D
1
2
3
4
5
6
7
8
8
7
6
5
4
3
2
1
E
F
E
F
M5
SHEET 2 OF 2
M Series
SCALE: 1:5
REV
DWG. NO.
D
SIZE
TITLE:
NAME
DATE
CHECKED
DRAWN
PROPRIETARY AND CONFIDENTIAL
THE INFORMATION CONTAINED IN THIS DRAWING IS THE SOLE PROPERTY OF MYTEE PRODUCTS, INC. ANY REPRODUCTION IN PART OR AS A WHOLE WITHOUT THE WRITTEN PERMISSION OF MYTEE PRODUCTS, INC. IS PROHIBITED.
mytee
PRODUCTS, INC.
858-679-1191
M. LaBarbera
5/24/11
OD
DO NOT SCALE DRAWING

13
D
C
B
A
A
B
C
D
1
2
3
4
5
6
7
8
8
7
6
5
4
3
2
1
E
F
E
F
M5
SHEET 1 OF 1
M Series
SCALE: 1:2
REV
DWG. NO.
D
SIZE
TITLE:
NAME
DATE
CHECKED
DRAWN
PROPRIETARY AND CONFIDENTIAL
THE INFORMATION CONTAINED IN THIS DRAWING IS THE SOLE PROPERTY OF MYTEE PRODUCTS, INC. ANY REPRODUCTION IN PART OR AS A WHOLE WITHOUT THE WRITTEN PERMISSION OF MYTEE PRODUCTS, INC. IS PROHIBITED.
mytee
PRODUCTS, INC.
858-679-1191
J.Cash
9/10/2010
DO NOT SCALE DRAWING
Green Green
Green
Green
White
White
Amber Light
Blue
Blue
Yellow
Brown
Brown
Yellow
White White
White White
Black
Black
Black
Black
Red
Red
Red Red
Black
Black
Vacuum
Vacuum
Pump
500psi
Pump
Out
115V 115V
Bottom Cord Top Cord
M-5 WIRING DIAGRAM

14
M-12 BACKM-12 FRONT
1. Switch plate
2. 2” Male Cuff-Lynx™
3. Female quick disconnect (QD)
4. Front handles
5. Prime valve
1
6. Pressure regulator
7. Front cooling fan
8. 4” locking casters
9. Solution tank
10. Solution tank cover
5
6
8
11. Recovery tank lid
12. Push handle
13. Drain valve
14. Auto-ll
15. Auto pump-out
12
14
16. Rear cooling fan
17. Dual power cords
18. 12” rear wheels
19. Latches (x2)
20. Recovery tank
16
11
10
9
2
3
4
7
13
15
17 18
19
20
M-12 ITEMS INCLUDED
H375 Hose Hanger H226 Drain Elbow
(4) screws
M-12 DUAL CORDS
Plug each of the two power cords into two separate, 20A grounded
wall outlets. The amber light indicator on the switch plate will illumi-
nate when cords are plugged into two separate circuits.
H110 Cuff-Lynx™ H141 Cuff-Lynx™
2” Hose Adapter 2” Hose Reducer to 1.5”
Top cord: Plug into power Vacuum 1, 2 & Pump-out.
Bottom cord: Plug into power Pump-Mode: Carpet & Tile.
Top cord
Bottom cord
M-12

15
Switches and Pressure Gauge are located on the plate in front
of the machine. The Amber light left of the Pressure Gauge will
illuminate when cords are plugged into two separate circuits. To
use vacuums, turn on Vac 1 and Vac 2 switches. To use Pump-out,
turn on Pump-out switch. To use on carpet, turn the Pump Mode switch
to Carpet. To use for Tile, turn the Pump Mode switch to Tile. The Pres-
sure Gauge displays the water pressure as PSI.
M-12 SWITCHES & PRESSURE GAUGE
VAC 1 VAC 2
PUMP OUT PUMP MODE
CARPET TILE
M-12 VAC/SOL HOSE CONNECTIONS
M-12 CARPET MODE
Press left side of Pump mode button for Carpet. The Amber light left of the Pressure Gauge will illuminate when cords are plugged into two
separate circuits. Two red lights left of switches will appear when Carpet mode is activated. In carpet cleaning mode, a 220 PSI pump and
solution heater are used. The 220 PSI is not adjustable. Adjusting the regulator in this mode will not affect the pump pressure.
Before turning on switches, connect hoses to the extractor and a
wand or tool. Attach a solution hose to the front QD, the other end
to the tool. Attach a vacuum hose to the tool, the other to the front
Cuff-Lynx™ vacuum hose port. Just twist into place.
M-12
PUMP MODE
CARPET
ON

16
Press right side of Pump mode button for Tile. The Amber light left of the Pressure Gauge will illuminate when cords are plugged into two
separate circuits. In Tile cleaning mode, a 1200 PSI pump will be used. Pump pressure is set using the regulator on the front of the unit.
There is no heat in tile mode. It is not possible to run the heater and 1200 PSI pump simultaneously.
M-12 TILE MODE
M-12 AUTO-FILL & PUMP-OUT
AUTO-FILL
PUMP-OUT
If using Auto-ll and Pump-out, connect one end of a 1/2 inch
garden hose to the top hose inlet in back of the machine, the other
end to a faucet. Add water pressure by turning on faucet. Attach a
second 1/2 inch garden hose to the bottom hose inlet, and place
the other end in a location where dirty water can drain.
M-12 FILL SOLUTION TANK
If not using the Auto-ll feature, lift the solution tank lid and manually ll
the tank.
M-12
PUMP MODE
TILE
ON

17
M-12 FILTER MAINTENANCE
To clean the internal lters, lift solution lid and/or remove recovery tank
lid, reach in and twist off. Rinse with clean water and replace.
CLEAN WATER
INTAKE FILTER
PUMP-OUT
FILTER
PRIME VALVE
FILTER
M-12 DRAIN VALVE & LATCHES
You can drain the recovery tank by using the Drain Valve. When
not using the Auto Pump-out, you can drain the recovery tank by
using the Drain Valve. When the tank is full, an internal ball oat
will automatically shut off the vacuum. Attach the 45˚ drain elbow
to the drain spout, and lift up the Drain Valve to empty the tank.
Latches are located in the back to open tank for internal repairs.
M-12 PRIME VALVE & PRESSURE REGULATOR
PRESSURE
REGULATOR
PRIME VALVE
Prime the pump by turning the valve to the Prime position for 30
seconds, then turn horizontally to the Run position. Turn the
Pressure Regulator to the left to decrease the water pressure.
Turn the pressure regulator to the right to increase the water
pressure. Monitor pressure while adjusting, using Pressure Gauge
on Switch Panel.
HIGHER PSI
LOWER PSI
M-12 AUTO-FILL & FLOAT
After attaching a garden hose to the Auto-ll inlet, water will ll the
tank to a predetermined level until stopped by the oat. As water is
used and the level drops, water will once again enter the tank, and
be stopped again by the oat when maximum level is reached.
With each new job, check to make sure oat stops water after the
rst ll.
M-12
1003/1005

18
M-12 PARTS & PRICING
Part prices are subject to change.Order parts at: http://www.mytee.com/products/product.php?id=M-12
ITEMS NOT SHOWN
ACCESSORIES
PART NO.
DESCRIPTION
QTY.
MSRP
E530
power cord, ext, 50', 12/3, black
2
$74.99 ea
E564
controller, circuit light
1
$62.49 ea
G010
filter, bag, vac tank, drawstring
1
$9.99 ea
G147
strap, velcro, w/buckle
1
$3.49 ea
PH634-36
sol hose, 1/4", kuri
1
$6.49 ft
PART NO.
DESCRIPTION
QTY
MSRP
ADM-M-SERIES
manual, m-series
1
ADM-Cuff-Lynx
Cuff-Lynx instruction guide
1
AD127
stop sign, register your product
1
H110
Cuff-Lynx, 2" hose x 2" fem swivel Cuff-Lynx
1
$3.99 ea
H141
Cuff-Lynx, 2" ro 1.5" reducer
1
$3.99 ea
H226
spout, drain, 45 degree
1
$3.19 ea
H230
screw, 10-32 x 1/2" phil pan head s/s 2
$0.99 ea
H375
hanger, wire formed, hose
1
$10.99 ea
G029 banana bag, mash bag, yellow
1
$3.99 ea
ITEM
NO.
PART NO.
DESCRIPTION
new/QTY.
MSRP
1
B108
valve, brass, 1/4" check
1
$13.99 ea
2
AH184 hose, 3/8" x 14-1/2" (OAL), f
1
$27.99 ea
3
B136
elbow, brass, 90 deg, 1/4" mpt x 1/4" mpt
2
$4.99 ea
4
B105
bushing, brass, 3/8"mpt x 1/4" 5
$3.19 ea
5
H185
screw, 10-32 x 1-1/4", phil flat full thread, black oxide
4
$0.99 ea
6
C322D
pump, 200psi, bypass, 115V
1 $208.99 ea
7
H210
washer, 1/4" flat, s/s
24
$0.99 ea
8
H273
nut, kep, #10-32 zinc
20
$0.99 ea
9
B103
elbow, brass, 90 deg, 1/4"mpt x 1/4" fpt
7
$4.49 ea
10
H219 cap, axle, 1/2"
2
$0.99 ea
11
H251
wheel, 12"
2
$41.99 ea
12
H254
washer, axle, cut 1/2" id
4
$0.99 ea
13
H232 axle, 19.75" x .50"
1
$9.99 ea
14
P707
base, m series 1 $196.99 ea
15
H215
nut, hex, 1/4-20 s/s
16
$0.99 ea
16
H668
caster, 4", black hub & gray tread
2
$19.49 ea
17
H342
bolt, 1/4-20 x 1" hex head, s/s 8
$0.99 ea
18
H213
washer, 1/4" lock, s/s
12
$0.99 ea
19
B107 nipple, brass, 1/4"m, hex
3
$3.19 ea
20
H212 washer, 9/16"id x 1"od, flat, s/s
2
$0.99 ea
21
B102
qd, brass, 1/4" f
2
$17.99 ea
22
H768
bolt, 1/4-20 x 3/4" serrated hex flange, zinc
10 $0.99
23
H211 washer, 1/4"id x 1"od, flat, s/s
8
$0.99 ea
24
H485
handle, breeze and dx
2
$6.99 ea
25
H206
screw, 10-32 x 5/8" hex head, zinc
4
$0.99 ea
26
H296
guard, cooling fan, wire
3
$2.99 ea
27
C317
fan, cooling, 115V
1
$21.49 ea
28
H343
screw, 10 x 5/8" hex head, zinc
8
$0.99 ea
29
B132
adapter, brass, 1/2" barb x 1/2" mpt
2
$9.49 ea
30
H191
washer, zinc, 1.625 x .847 x .078
2
$1.99 ea
31
PH615-36
sol hose, 1/2" black, 200 psi 200 degree max
1
$8.99 ft
32
B236
elbow, brass, 90 deg, 1/2" barb x 3/8" fpt
2
$14.49 ea
33
H299
washer, 11/16"id x 1-1/2"od x .075, s/s
9
$0.99 ea
34
H347
clamp, hose, 5/16-29/32
16
$1.99 ea
35
H256
screw, #10-32 x 3/4" phil pan head, zinc
6
$0.99 ea
36
H528
bracket, heater mounting, dual
1
$29.99 ea
37
H903A
heater, aluminum cast, single
2
$78.99 ea
38
E573
Thermostat, 200°, Auto, 1/4"
2
$16.49 ea
39
H274
phil pan head screw zinc, 6-32 x 3/16"
10
$0.99 ea
40
H275
6-32 x 3/16 p-pan internal sem zinc
8
$0.99 ea
41
E574
Thermostat, 310°F ± 10°F, Manual, 1/4"
2
$17.99 ea
42
E519
heating rod, 1000W, 115V
2
$51.99 ea
43
B207
elbow, brass, 90 deg, 1/4" fpt x 1/4" fpt 1
$5.99 ea
44
AH156
hose, 3/8" x 6.5" (OAL), f x fs, 5400 gray
1
$23.99 ea
45
G059
exhaust boot, plastisol
2
$4.99 ea
46
H500
vac support, 2 stage, 3-1/8"
6
$3.99 ea
47
G004
gasket, vacuum motor
2
$8.99 ea
48
P750
manifold, dual vac, parallel
1
$15.99 ea
49
H216
nut, lock, 1/4-20 nylon insert
9
$0.99 ea
50
H202
bolt, 1/4-20 x 3/4" hex head, s/s
10
$0.99 ea
51
H188
screw, 1/4-20 x 1", phil flat
3
$0.99 ea
52
H601
plate, manifold, parallel
1
$13.49 ea
53
H217
clamp, hose, 2-1/4 dia
3
$1.49 ea
54
H544
cuff hose, 2 X 2, wire reinforced
1
$12.49 ea
55
PH628-21
vac hose, 2", black, wire reinforced
1
$8.99/ft
56
C310
vac motor, 2 stage high performance
2 $103.99 ea
57
B221
plug, brass, 3/4", garden hose 1
13.99 ea
58
B640
filter, 60 mesh, garden hose
1
$1.99 ea
59
B642
swivel, brass, 3/4" fgh x 1/2" fpt 1
$5.49 ea
60
B120
cap, brass, 3/4", garden hose 1
$1.49 ea
61
B196
fitting, brass, 3/4" mgh x 1/2" fpt
1
$5.99 ea
62
H230
screw, 10-32 x 1/2 phil pan
18
$0.99 ea
63
H486
latch, front breeze
2
$13.99 ea
64
H221
nut, lock, 1/2" steel
2
$1.99 ea
65
H220
fitting, strain relief, cord
2
$3.19 ea
66
E550
power cord, pigtail, 30", 12/3, black
2
$11.49 ea
67
G131
connector, cord lock
2
$4.99 ea
68
C381
pump out, 115v
1 $187.49 ea
69
B113
tee, brass, 1/4" fpt
1
$6.99 ea
70
B643
adapter, brass, 3/8" female npt x 1/4" male npt
1
$4.99 ea
71
AH202
hose, pulse, 3/8" x 34", (OAL)
1
$39.99 ea
72
B135
tee, brass, 1/4" mpt
2
$5.49 ea
73
C359A
pump, 1200 psi 1 $708.99 ea
74
B186
elbow, brass, 90 deg, 3/8"mpt x 3/8" fmpt
4
$8.99 ea
75
B652
elbow, brass, 90 deg, 3/8"mpt x 1/4"mpt
1
$8.49 ea
76
PH615-9
sol hose, 1/2", black, 200 psi 200 degree max
1
$8.99 ft
77
B644
adapter, brass, 1/2" barb x 1/4" mpt
1
$2.49 ea
78
AH117
hose, pulse, black, 49" (OAL), 1/4" fswl x 1/4" fswl
1
79
B111
adapter, brass, extender, 1/4" mpt x 1/4" fpt, hex
2
$3.49 ea
80
B106
nipple, brass, 1/4" x close
1
$3.49 ea
ITEM
NO.
PART NO.
DESCRIPTION
new/QTY.
MSRP
81
B142A
coupling, brass, 1/4" fpt x 1/4" fpt
1
$4.49 ea
82
H484
plate, mounting, QD
1
$4.99 ea
83
C359C
regulator, 1000 psi, white spring
1
$86.99 ea
84
PH634-36
sol hose, 1/4", 300 PSI
1
$6.49 ft
85
B109
adapter, brass, 1/4" barb x 1/4" mpt
2
$1.99 ea
86
PH634-20
sol hose, 1/4", 300 PSI
1
$6.49 ft
87
G034 grommet, rubber, 3/4" ID x 1-5/8" OD
1
$0.99 ea
88
B656
ball valve, 1/4''
1
$13.49 ea
89
B119A
filter, strainer, 1/2"
1
$6.49 ea
90
B210
bushing, brass, 1/2"mpt x 3/8" fpt, hex
2
$2.49 ea
91
B216
nipple, brass, 3/8" x close
2
$1.99 ea
92
H378
bracket, front hinge, sp/fb
1
$8.99 ea
93
H201
bolt, 1/4-20 x 1/2", hex head, zinc
2
$0.99 ea
94
H316
bolt, 1/4-20 x 1-1/2" hex head, s/s
2
$0.99 ea
95
G052
washer, buna 1-1/8" od x 3/16" id
6
$1.99 ea
96
G212
cover, sol tank (m-series)
1
$12.99 ea
97
B115
nipple, 12" x 1/4" npt, m x m
1
$23.99 ea
98
H541-A
valve, float, autofill
1 $124.99 ea
99
H203
bolt, 1/4-20 x 1-1/4" hex head
2
$0.99 ea
100
P708
sol tank, m series
1 $210.99 ea
101
AH101
hose, pulse, black, 76" (OAL), 1/4" fsw x 3/8" msw
1
$22.99 ea
102
H308D
gauge, pressure, 2000 PSI
1
$38.99 ea
103
E516
switch, rocker, 3 position
1
$14.99 ea
104
E515
switch, rocker, 2 position
3
$13.99 ea
105
E511
light, red, 250v
2
$5.99 ea
106
H389
screw, #10-32 x 1/2" SHCS, alloy
3
$0.99 ea
107
H612
washer, #8 flat, s/s
3
$0.99 ea
108
E512B
light, indicator, 125v (amber)
1
$9.99 ea
109
H337
plate, switch, sp, 4 hole w/gauge
1
$8.99 ea
110
H135
Cuff-Lynx, 2" m cuff x 2" mpt
1
$3.99 ea
111
G002
gasket, cam fitting polyethylene, 2.35" OD 1.90" ID
2
$6.49 ea
112
P684
adaptor, pvc 2, fmsl x fmt
1
$6.99 ea
113
P682
pipe, pvc, 2" 1
$7.99/ft
114
H297
screw, #8 x 1/2", hex head, zinc
3
$0.99 ea
115
P726
elbow, 2" float
1
$11.49 ea
116
H490
float, 2", ball style
1
$18.49 ea
117
G090
lid, vac tank, black, 7"
1
$36.99 ea
118
H304
screw, #8 x 5/8 phil oval, s/s
6
$0.99 ea
119
G091
gasket, 7", vac lid
1
$11.99 ea
120
A926
elbow, inlet assembly 2"
1
$15.99 ea
121
P709 vac tank, m series
1 $243.99 ea
122
H225
valve, drain, 1-1/2"
1
$20.99 ea
123
H390A
bracket, "L" (all extracters)
2
$6.99 ea
124
H770
bolt, 1/4-20 x 1/2" serrated hex flange, zinc
4
$0.99 ea
125
H333
mesh filter, auto dump, 1/2" npt
1
$9.99 ea
126
P685
inlet, 2"
1
$10.99 ea
D
C
B
A
A
B
C
D
1
2
3
4
5
6
7
8
8
7
6
5
4
3
2
1
E
F
E
F
REV
M12 updating
D
M12
SHEET 1 OF 2
M Series
UNLESS OTHERWISE SPECIFIED:
SCALE: 1:8
REV
DWG. NO.
D
SIZE
TITLE:
NAME
DATE
COMMENTS:
CHECKED
DRAWN
FINISH
MATERIAL
DIMENSIONS ARE IN INCHES TOLERANCES: ANGULAR:
.5
ONE PLACE DECIMAL
.005
TWO PLACE DECIMAL
.003
THREE PLACE DECIMAL
.001
PROPRIETARY AND CONFIDENTIAL
THE INFORMATION CONTAINED IN THIS DRAWING IS THE SOLE PROPERTY OF MYTEE PRODUCTS, INC. ANY REPRODUCTION IN PART OR AS A WHOLE WITHOUT THE WRITTEN PERMISSION OF MYTEE PRODUCTS, INC. IS PROHIBITED.
mytee
PRODUCTS, INC.
858-679-1191
M. LaBarbera
7/10/11
OD
DO NOT SCALE DRAWING

19
M-12 PARTS & PRICING
1
2
3
4
5
6
7
8
2
16
17
7
18
15
10
11
12
13
14
19
21
22
23
24
25
26 27
29
30
31
32
33
4
34
39
39
40
38
41
42
8
35
36
37
9
2
43
44
56
22
45
46
47
15
48
49
50
51 52
53 54
55
32
33
32
68
29
30
32
35
8
64 65
66
67
63
8
62 61
60
59
58
57
69
70
71
72 449
7
50
19 4
73 74
74
74
75
76
77
78
9
79
80
81
19
82
62
83
7221
85
87
89
33
91
33
74
90
93
18
7
92
49
7
94
24
95
23
22
96
33
97 79
9
98
15
18
23
95 95 23
99
100
101
102
9
103
104 105
106
107
108 109
110
111
111 112 113 114
115 116
117
118
119
120
121
122
123
124
91
33
90
125
126
9
28 8
107106
to 12oo psi
pump "OUT"
thru B186
#
74
to 1200 psi
pump "OUT"
thru B107
#
19
to 220/1200 psi
pumps "IN"
thru AH202
#
71
to auto fill
thru B105
#
4
to pressure
guage
thru AH101
#
101
to 220 psi
pump "IN"
thru B130
#
9
to vac tank
thru B216
#
91
to female
garden
hose thru B196
#
61
to auto fill
thru B132
#
31
to pump-out
"OUT" thru
H191 #
29
to 220 psi
pump "OUT"
thru B108
#
1
to QD
(lower)
thru B107
#
21
to male
garden
hose
thru B642
#
59
to auto fill
thru B115
#
97
to heater
"IN" thru
B207
#
43
to heater
"OUT" thru
AH184
#
2
to QD
(upper)
thru AH117
#
78
to pump-out
"IN' thru B236
#
32
88 85
20
to sol tank
thru B135
#
72
86
84
D
C
B
A
A
B
C
D
1
2
3
4
5
6
7
8
8
7
6
5
4
3
2
1
E
F
E
F
REV
M12 updating
D
M12
SHEET 2 OF 2
M Series
UNLESS OTHERWISE SPECIFIED:
SCALE: 1:7
REV
DWG. NO.
D
SIZE
TITLE:
NAME
DATE
COMMENTS:
CHECKED
DRAWN
FINISH
MATERIAL
DIMENSIONS ARE IN INCHES TOLERANCES: ANGULAR:
.5
ONE PLACE DECIMAL
.005
TWO PLACE DECIMAL
.003
THREE PLACE DECIMAL
.001
PROPRIETARY AND CONFIDENTIAL
THE INFORMATION CONTAINED IN THIS DRAWING IS THE SOLE PROPERTY OF MYTEE PRODUCTS, INC. ANY REPRODUCTION IN PART OR AS A WHOLE WITHOUT THE WRITTEN PERMISSION OF MYTEE PRODUCTS, INC. IS PROHIBITED.
mytee
PRODUCTS, INC.
858-679-1191
M. LaBarbera
7/10/11
OD
DO NOT SCALE DRAWING
