Mytee S-300 TEMPO User manual

1
Instructions for
S-300 Tempo™
Set up p. 2
How to p. 4
General information p.14
13655 Stowe Dr., Poway, Ca. 92064
Model #
Serial #
Form # ADM-Tempo
1-14
Please read before use.
Register your product
at http://www.mytee.
com/support/register

2

3
FRONT BACK
VACUUM AND SOLUTION
HOSE CONNECTION
Located at the back of the Tempo™, attach the male end
of the solution hose to the Tempo’s™ QD. Then connect
the vacuum hose to the Tempo’s™ hose port.
ACCESSORY
8’ vacuum and solution hose combo.
1. Handle
2. Solution Tank Lid
3. 3” Wheels
4. Solution Tank
2
4
7
3
5
5. Recovery Tank
6. Recovery Tank Lid
1
7. Vacuum Hose Hook Up
8. Recovery Tank Drain Cap
9. Quick Disconnect
10. Power Switch
6
11. 25’ Power Cord
8
9
10 11
S-300 TEMPO™

4
FILL SOLUTION TANK POWER SWITCH
EMPTY RECOVERY TANK
Plug machine’s cord into a grounded wall outlet then
switch power on. FOR SAFETY: Do not operate machine
unless cord is properly grounded.
To empty the recovery tank, remove cap located above the quick disconnect to releases uid.
Twist off solution tank lid and ll with water. For best
results, ll with warm water (140o F).
S-300 TEMPO™

5
FILTER DEFOAMER
SYSTEM MAINTAINER
Add defoamer in the recovery tank to reduce foam and
prolonging the life of the Tempo’s™ vacuum motor .
Weekly ushing of the solution system with Mytee System Maintainer helps keep lines clean and prevents chemical build-
up, improving pump life, performance and pressure.
To get the best performance out of the Tempo™, after
each job, twist off the recovery tank lid and clean off the
lter located on the vacuum stack.
S-300 TEMPO™

6
Part prices are subject to change.Order parts at: www.mytee.com/products/product.php?id=8901
S-300 TEMPO™ PARTS & PRICING
ACCESSORIES
ITEM
NO.
PART NO.
DESCRIPTION
QTY.
MSRP
1
H304
screw, #8 x 5/8 phil oval, s/s
12
$0.99 ea
2
G030 lid, vac tank, 3.5", clear
2
$13.99 ea
3
G039
gasket, vac lid, 3.5", clear
1
$4.99 ea
4
P728A
sol tank, spotter
1
$49.99 ea
5
H358
wheel, 3"
2
$1.49 ea
6
H650
bolt, 5/16" shoulder x 1-1/2" lg, alloy
2
$1.49 ea
7
H221
nut, lock, 1/2" steel
1
$1.99 ea
8
H273
nut, kep, #10-32 zinc
4
$0.99 ea
9
H410
plate, switch, spotter
1
$5.99 ea
10
E515
switch, rocker, 2 position
1
$13.99 ea
11
H612
washer, #8 at, s/s
2
$0.99 ea
12
H389
screw, #10-32 x 1/2" SHCS, alloy
2
$0.99 ea
13
H220
tting, strain relief, cord
1
$3.19 ea
14
H246
screw, #8-32 x 3/8" SHCS, alloy
2
$0.99 ea
15
E533
power cord, end, 25', 16/3
1
$35.49 ea
16
G004
gasket, vacuum motor
1
$1.49 ea
17
C316
vac motor, 2 stage, 115V, peripheral
1
$99.99 ea
18
H646
plate, vac. mounting, spotter
1
$20.99 ea
19
H210
washer, 1/4" at, s/s
5
$0.99 ea
20
H213
washer, 1/4" lock, s/s
3
$0.99 ea
21
H342
bolt, 1/4-20 x 1" hex head, s/s 3
$0.99 ea
22
B119
lter, strainer, 1/4"
1
$3.99 ea
24
B109
adapter, brass, 1/4" barb x 1/4" mpt
1
$1.75 ea
24
PH634-8
sol hose, 1/4" kuri 150psi
1
$6.49 ea
25
B131
tting, 1/4" barb x 1/8" FPT
1
$2.99 ea
26
H384
washer, 3/8 at, s/s
2
$ 0.99 ea
27
B129
nipple, hex, 1/8" mpt x 1/8" mpt
1
$1.99 ea
28
C378
pump, 55psi, 115V ojet
1
$41.99 ea
29
H230
screw, 10-32 x 1/2 phil pan
5
$0.99 ea
30
H250
bracket, set 55 psi pump
1
$4.99 ea
31
B140
connector, 1/4" tube push-in x 1/8" mpt
1
$7.49 ea
32
PH657-8
tubing, 1/4", nylon black
1
$1.99 ea
33
B166
tting, brass, 1/4"mpt x 1/4" push-in
1
$9.99 ea
34
H212 washer, 9/16"id x 1"od, at, s/s
5
$0.99 ea
35
B102
qd, brass, 1/4" f
1
$17.99 ea
36
H898
plate, base & qd, spotter
1
$29.99 ea
37
G058
vac tank deector
1
$8.99 ea
38
P728B
vac tank, spotter
1
$59.99 ea
39
H664
lter strainer, spotter
1
$4.49 ea
40
H645 pvc, 90, 3/4"
1
$0.99 ea
41
PH610-2.5
pipe, pvc, 3/4"
1
$0.99/ft
42
H644
adapter, pvc, 3/4"
1
$0.99 ea
43
B653
nut, brass, 3/4", lock 1
$3.99 ea
44
G036
cap, 2.5" threaded, tethered
1
$3.49 ea
PART NO.
DESCRIPTION
QTY.
MSRP
AD127
stop sign register your product
1
H141
cu-lynx, 2" to 1.5" reducer
1
$3.99 ea
G147
strap, velcro, w/buckle
3
$3.49 ea
B101
quick disconnect, male, 1/4" male x 1/4" fpt
1
$8.49 ea
AH135
sol hose, 1/8" x 97", (OAL), m
1
$36.99 ea
H360
vac hose, 1-1/4" x 8' 1
$19.99 ea
B102
quick disconnect, 1/4" female x 1/4" fpt
1
$17.99 ea
H282
tool, uph, s/s w/ valve
1
$98.99 ea
D
C
B
A
B
C
D
1
2
3
4
5
6
7
8
8
7
6
5
4
3
2
1
E
F
E
F
S-300
SHEET 1 OF 2
Spotter
4/5/11
OD
SCALE: 1:2
REV
DWG. NO.
C
SIZE
TITLE:
NAME
DATE
CHECKED
DRAWN
PROPRIETARY AND CONFIDENTIAL
A
DO NOT
SCALE DRAWING
858-679-1191
mytee
PRODUCTS, INC.
J. Cash
THE INFORMATION CONTAINED IN THIS DRAWING IS THE SOLE PROPERTY OF MYTEE PRODUCTS, INC. ANY REPRODUCTION IN PART OR AS A WHOLE WITHOUT THE WRITTEN PERMISSION OF MYTEE PRODUCTS, INC. IS PROHIBITED.

7
S-300 TEMPO™ PARTS & PRICING
1
2
3
32
33
35
1
2
37
39 40
42
43
36
8
11
12
29
4
8
8
9
10
12
11
14
13
15
16 17
18
19 20 2119
20 21
31
30 29 28
27
26
26 25
24
24
22
34 34
34
34
34
38
7
5
6
19
29
44
8
Inside sol tank
41
D
C
B
A
B
C
D
1
2
3
4
5
6
7
8
8
7
6
5
4
3
2
1
E
F
E
F
S-300
SHEET 2 OF 2
Spotter
4/5/11
OD
SCALE: 1:4
REV
DWG. NO.
C
SIZE
TITLE:
NAME
DATE
CHECKED
DRAWN
PROPRIETARY AND CONFIDENTIAL
A
DO NOT
SCALE DRAWING
858-679-1191
mytee
PRODUCTS, INC.
J. Cash
THE INFORMATION CONTAINED IN THIS DRAWING IS THE SOLE PROPERTY OF MYTEE PRODUCTS, INC. ANY REPRODUCTION IN PART OR AS A WHOLE WITHOUT THE WRITTEN PERMISSION OF MYTEE PRODUCTS, INC. IS PROHIBITED.

8
Dear Customer:
Congratulations on the purchase of your new Tempo™ spotter. As you are
already aware, the scene of the equipment world is becoming more high tech, and
we at Mytee Products Inc. strive to keep you on the cutting edge with superior
quality and technology.
Keep in mind that the S-300 Tempo™ is a machine, so neglect or abuse
will cause unnecessary damage and void the warranty. However with simple
maintenance the S-300 will give quality performance for many years to come.
If warranty questions arise, please consult your user manual or get in touch with
your distributor. If you have questions about maintenance, replacing parts or
ordering parts, please call an authorized Mytee Products Inc. Service Center.
To see an updated list, visit our website at www.mytee.com
Before you begin cleaning, please read your manual thoroughly.
Sincerely,
Mytee Customer Care Dept.
Grounding Instructions
This machine must be grounded. If it should malfunction or breakdown, grounding
provides a path of least resistance for electrical shock. This machine is equipped with
a cord having an equipment-grounding conductor and grounding plug. The plug must
be plugged into an appropriate outlet that is properly installed in accordance with all
local code and ordinances. Do not remove ground pin; if missing, replace plug before
use.
Improper connection of the equipment-grounding conductor can result in a risk of
electric shock. Check with a qualied electrician or service person if you are in doubt
as to whether the outlet is properly grounded. Do not modify the plug provided with
the machine. If it will not t the outlet, have a proper outlet installed by a qualied
electrician.
This appliance is for use on a nominal 120-volt circuit, and has a grounding plug
that looks like the plug illustrated in Figure 1 below. A temporary adapter illustrated
in Figures 2 and 3 may be used~to connect this plug to a 2-pole receptacle as
shown in Figure 2 if a properly grounded outlet is not available. The temporary
adapter should be used only until a properly grounded outlet (Figure 1) can be
installed by a qualied electrician. The green colored rigid ear, tab or the like
extending from the adapter must be connected to a permanent ground such as a
properly grounded outlet box cover. Whenever the adapter is used, it must be held
in place by a metal screw. Grounding adapters are not approved for use in Canada.
Replace the plug if the grounding pin is damaged or broken.
The Green (or GreenYellow) wire in the cord is the grounding wire. When replacing
a plug, this wire must be attached to the grounding pin only.
DO NOT use extension cords.
Please Note for America use only
Parts and Service
Repairs, when required, should be performed by Mytee service personnel or Mytee
authorized Service Center using Mytee original replacement parts and accessories.
Call Mytee for repair parts or service. Please specify the Model and Serial Number
when discussing your machine.
Name Plate
The Model and Serial Number of your machine are shown on the Nameplate on the
back panel of the machine. This information is needed when ordering repair parts
for the machine. Use the space provided on the front cover to note the Model and
Serial Number of your machine for future reference.
Unpacking the Machine
When the machine is delivered, carefully inspect the shipping carton and the
machine for damage. If damage is evident, save the shipping carton so that it can
be inspected by the carrier that delivered it. Contact the carrier immediately to le a
freight damage claim.
Caution and Warnings
Symbols
Mytee uses the symbols below to signal potentially dangerous conditions. Always
read this information carefully and take the necessary steps to protect personnel
and property.
Is used to warn of immediate hazards that will cause severe personal injury or death.
Is used to call attention to a situation that could cause severe personal injury.
Is used to call attention to a situation that could cause minor personal injury or
damage to the machine or other property. When using an electrical appliance, basic
precautions should always be followed, including the following: Read all instructions
before using this machine. This product is intended for commercial use only.
To reduce the risk of re, electrical shock, or injury:
1. Read all instructions before using equipment.
2. Use only as described in this manual. Use only manufacturer’s recommended
attachments.
3. Always unplug power cord from electrical outlet before attempting any adjustments
or repairs.
4. Do not unplug by pulling on cord. To unplug, grasp the plug, not the cord.
5. Do not pull or carry by cord. Do not close a door on cord or pull cord around sharp
edges or corners.
6. Do not run appliance over cord. Keep cord away from heated surfaces.
7. Do not use with damaged cord or plug. If cord is damaged, repair immediately.
8. Do not use outdoors or on wet surfaces and or standing water.
9. Always unplug or disconnect the appliance from power supply when not in use.
10. Do not allow to be used as a toy. Close attention is necessary when used by or
near children.
11. Do not use in areas where ammable or combustible material may be present.
12. Do not leave the unit exposed to harsh weather elements. Temperatures below
freezing may damage components and void warranty.
13. Use only the appropriate handles to move and lift unit. Do not use any other parts
of this machine for this purpose.
14. Keep hair, loose clothing, ngers, and all parts of the body away from all
openings and moving parts.
15. Use extra care when cleaning on stairs.
16. To reduce the risk of re or electric shock, do not use this machine with a solid-
state speed control device.
17. The voltage and frequency indicated on the name plate must correspond to the
wall receptacle supply voltage.
18. When cleaning and servicing the machine, local or national regulations may apply
to the safe disposal of liquids which may contain: chemicals, grease, oil, acid, alka-
lines, or other dangerous liquids.
19. Do not leave operating unattended.
Filling the Solution Tank
1. Fill the solution tank with the approved cleaning solution.
2. Do not ll up the solution tank completely: 1” should be left free at the top.
3. Typically, the solution should be a mixture of water and a cleaning chemical
appropriate for the type of job.
4. Always follow the dilution instructions on the chemical container label.
5. The temperature of the cleaning solution must not exceed 70oC/160oF.
Use only non-ammable liquid in this machine.
GENERAL INFORMATION
Figure 1
Grounding Pin
Grounded Outlet
Grounded Outlet Box
Adapter
Tab for Grounding
Screw
Metal
Screw
Figure 2 Figure 3

9
Setup
1. Fill solution tank with water or approved cleaning agent. For best results, ll with
warm water (140o). Replace vacuum tank.
Flammable materials can cause an explosion or re. Do not use ammable solutions
or materials in tank(s).
FOR SAFETY: When using machine, follow mixing and handling instructions on
chemical containers.
ATTENTION: If using powdered cleaning chemicals, mix prior to adding.
2. Attach solution hose (located front of machine). NOTE: Make sure the quick
disconnect snap together rmly. As you do this, always inspect hoses for cracks or
fraying. Do not use if hoses are damaged.
3. Attach vacuum hose to recovery tank.
4. Plug machine’s cord into a grounded wall outlet. FOR SAFETY: Do not operate
machine unless cord is properly grounded. FOR SAFETY: Do not operate machine
with the use of an extension cord.
5. Turn on power. Key tool until you have a steady ow.
6. Re-key upholstery tool until hot water begins owing.
7. Begin cleaning. Make two dry passes to every wet pass.
8. Work away from cords to avoid damage.
9. Use a defoamer in your recovery tank.
10. To clean heavily soiled areas, repeat cleaning from different directions.
11. When vacuum tank is full, empty tank.
12. When work is complete, unplug cords and hoses.
13. Wrap and clean hoses. Clean all tanks.
Pre-Operation
1. Vacuum carpet and upholstery and remove other debris.
2. Perform machine setup procedures.
3. Inspect power cord for damage.
Operation
1. Turn power switch on.
2. Pull up on tool lever to release air in the line. Hold lever until a steady ow of water
comes out of the upholstery tool.
Note: When cleaning upholstery, always check manufacturer’s cleaning instructions.
1. Work away from outlet and power cord to prevent cord damage.
2. Use a recommended foam control solution in the recovery tank to prevent vacuum
motor damage. Periodically check for excessive foam buildup in solution tank, and
recovery tank.
3. To clean heavily soiled areas, repeat cleaning path from different direction.
4. When vacuum tank is full, it is time to empty the dirty water from the recovery tank,
and rell solution tank.
5. After cleaning, relieve water pressure from tool before disconnecting hose.
Squeeze trigger for ve seconds after turning main power switch off.
After Use
1. Unplug.
2. Empty solution tank and rinse it with clean water.
3. Inspect hoses and replace if damaged.
4. Attach 45o drain elbow to dump valve and lift up drain valve lever to empty
recovery tank.
5 Inspect solution lter. Clean or replace if damaged.
6. Store the machine in a clean, dry place.
7. Open recovery tank cover to promote air circulation.
8. Do not expose to rain. Store indoors.
Maintenance Schedule
Maintenance item Daily Once a week
Clean and inspect Tanks
Clean and inspect Hoses
Check power supply cable
Clean machine with all purpose cleaner and cloth
Check spray nozzles
Flush solution system with Mytee system maintainer
Remove and clean oat shut-off screen from tank
Inspect vacuum hoses for holes and loose cuffs
Inspect machine for water leaks and loose hardware
x
x
x
x
x
x
x
x
x
Trouble Shooting
There is no power.
1. Plug machine in proper outlet.
2. Check circuit breaker; reset circuit breaker, other items should not run on the
same circuit as machine. Outlet must be a 20-amp circuit.
Pump does not work properly.
1. Snap quick disconnects rmly together.
2. Check solution tank; may be empty.
3. Jets clogged, remove jet and ush clean.
4. Filters clogged, remove lters and rinse clean with water.
5. If brass check valve is stuck replace valve.
6. Check pump wire. May need to reconnect wire.
7. Switch plate switch may need to be replaced.
8. If pump motor brushes are worn, replace pump.
Vacuum motor does not work properly.
1. Check that hose is tightly connected.
2. Close drain hose valve completely.
3. Check and clean foam lter located in recovery tank.
4. If water is coming out of vacuum motor, use a low foaming detergent.
5. Clean upholstery tool.
FAQs
Q: How much does the S-300 weigh and what are the dimensions?
A: 20 Pounds - Dimensions are: 20” x 10” x 16 1/2”. Shipping weight is 23 lbs. and
shipping dimensions are 19” x 10 3/4” x 20”
Q: What comes standard with the S-300?
A: The S-300 comes with 8’ Vacuum/Solution Hose with a 4” Stainless Steel
Upholstery Tool attached.
Q: Where do I plug the machine in?
A: The S-300 requires a 20A grounded circuit. Please note: GFI outlets may trip
before the breaker setting.
Q: Is there anything I can do to increase the expected life of my machine?
A: Running the vacuum motors with the tank empty and lid off will allow excess
moisture in the vacs to dry off. You should also run a System Maintainer through
the system to keep the hoses, pump, and heater clean and free of debris.
Warranty
MYTEE LIFETIME LIMITED WARRANTY POLICY
Mytee Products, Inc. endeavors to provide high quality products and product support
to its customers and therefore backs up all of its new products purchased from Mytee
Products Inc. (“Mytee”) or any authorized Mytee distributor/service center with this
lifetime limited warranty. This limited warranty begins on the date of the customer’s
purchase and is valid and available to the original purchaser with proof of purchase,
and is not transferable. Mytee’s products are for commercial use only and are not
intended for personal, family or household uses.
HOUSING LIMITED LIFETIME WARRANTY: Mytee warrants for life that its rotation-
ally-molded housings will be free from manufacturing defects. This warranty covers
the cost of replacement or repair only and does not cover shipping or labor costs.
WEAR PARTS 90-DAY LIMITED WARRANTY: Mytee will replace all wear parts for
90 days from the date of original purchase. “Wear parts” are items which wear out
as a result of usage or the passage of time and are consumed despite attempts to
maintain them, such as gaskets, wheels, brass, cords, wires, electrical terminals,
hoses, switches, thermostats, plastisol parts, lters, bearings, brushes, solenoids, o-
rings, bulbs, heating elements, castors, or other parts deemed wear items in Mytee’s
sole discretion. This warranty covers the cost of replacement only and does not cover
GENERAL INFORMATION

10
GENERAL INFORMATION
shipping or labor costs.
PUMP, VACUUM MOTOR AND HEATER ONE-YEAR LIMITED WARRANTY: Mytee
warrants that pumps, vacuum and oor machine motors, and heaters will be free
from manufacturing defects, defects in workmanship, and defects in material for one
(1) year from the date of original purchase. This warranty does not apply and is void
if the pump, vacuum motor, or heater has worn brush motors, water damage, chemi-
cal build-up, chemical damage, or evidence of abuse, neglect or tampering. This
warranty covers the cost of replacement or repair only and does not cover shipping
or labor costs.
HOWEVER, OTHER THAN SET FORTH HEREIN, MYTEE GIVES NO WARRANTY,
EXPRESS OR IMPLIED, AS TO DESCRIPTION, QUALITY, MERCHANTABILITY,
FITNESS FOR ANY PARTICULAR PURPOSE, PRODUCTIVENESS, INFRINGE-
MENT, OR OTHER MATTER, OF ANY GOODS WHICH MYTEE SHALL SUPPLY.
THERE ARE NO WARRANTIES WHICH EXTEND BEYOND THE DESCRIPTION
ON THE FACE HEREOF. MYTEE SHALL IN NO WAY BE RESPONSIBLE FOR THE
PROPER USE AND APPLICATION OF THE GOODS. MYTEE NEITHER ASSUMES
NOR AUTHORIZES ANY OTHER PERSON TO ASSUME FOR MYTEE ANY OTHER
LIABILITY IN CONNECTION WITH THE SALE OF MYTEE’S GOODS. THIS LIM-
ITED WARRANTY POLICY MAY BE CHANGED OR WITHDRAWN BY MYTEE AT
ANY TIME WITHOUT NOTICE.
LIMITATION OF DAMAGES: THE REMEDY OF REPLACEMENT OR REPAIR
OF ANY DEFECTIVE GOODS SHALL BE THE EXCLUSIVE REMEDY UNDER
ANY WARRANTY MADE BY MYTEE, WHETHER EXPRESS OR IMPLIED. IN NO
EVENT SHALL MYTEE BE LIABLE FOR ANY INCIDENTAL OR CONSEQUENTIAL
DAMAGES, PROPERTY DAMAGES, OR PERSONAL INJURIES.
All limited warranties are void for, and Mytee does not warrant in any way, any prod-
uct that evidences misapplication, improper installation, abuse, lack of maintenance,
negligence in use or care, abnormal use, alteration of design, modication, use of
incompatible or corrosive chemicals, use in a rental service, and/or servicing, installa-
tion of parts, or repairs by anyone other than Mytee or a Mytee authorized distributor
or service center. Mytee may make changes in products it manufactures and markets
at any time; these changes are made without obligation to change, retrot, or up-
grade any product previously sold or manufactured.
Mytee has no obligation to honor the limited warranties set forth herein unless the
original purchaser, promptly upon discovering the warranty claim and prior to continu-
ing to use the product, contacts Mytee or a Mytee authorized distributor or service
center to describe the claim and to receive and follow instructions for documenting
and resolving the claim. In addition, the purchaser must provide the product to which
the claim applies to Mytee or a Mytee authorized distributor or service center for a
thorough inspection. In addition, the purchaser must provide/return the product intact,
unmodied, with all of its original parts.
If any provision or portion of this limited warranty policy is found to be unenforceable,
then the remaining provisions and portions shall remain valid and enforceable.
If any provision or portion of this limited warranty policy is found to be limited by law,
then that provision or portion shall be construed to make it effective within the
bounds of law. For example, if there are legal limitations on the duration of warran-
ties, the warranties made herein shall be construed to have the minimum duration
required by law, or, if there are legal limitations of exclusion of remedies, the exclu-
sions made herein shall be construed to apply to the fullest extent possible without
violating the law.
The validity, construction and performance of this warranty policy shall be governed
by the laws of the State of California, without respect to conicts of laws principles.
The exclusive jurisdiction of any legal action arising from or related to this warranty
policy shall be in the State of California and no legal action shall be commenced
elsewhere.
Return Material Authorization Procedure
It is the responsibility of any Authorized Service Center (ASC) or Distributor with
written authorization to ensure the Customers equipment is repaired as soon as
possible. Only Mytee Products Inc. or it’s authorized dealers with written authoriza-
tion, service centers, and agents may make warranty repairs on these products. All
others do so at their own risk and expense.
The Distributor must follow Mytee Products, Inc. standard RMA procedure:
1. When a repair falls within the Warranty time period for a piece of equipment, the
Distributor will ll out a RMA/Warranty claim form. This form will act as a repair order
to replace any defective parts.
2. All defective parts must be returned to Mytee Products, Inc. with the RMA/claim
form for evaluation at the customer’s expense. This shipping is non-refundable. All
warranty claims are subject to an evaluation by Mytee Products, Inc. to determine if
warranty will be approved. Any credit for repair and/or parts will only be issued upon
evaluation and approval from Mytee Products, Inc.
3. When Warranty is approved, the Distributor’s account will be credited for the
replacement part(s). Mytee Products, Inc. will ship the warranted replacement part(s)
to the Distributor prepaid. If Warranty is denied the Distributor’s account will not be
credited for any parts sent for this claim.

11
NOTES

12
Mytee Products Inc.
13655 Stowe Dr.
Poway, CA 92064
www.mytee.com
© 2014 Mytee Products Inc.
Printed in the U.S.A.
NOTES
