Nabco Opus Control User manual

1 of 35
Opus Control Wiring and Programming
Installaon Manual
P/N C-00139 Rev 3-9-18
Nabco Entrances Inc. S82 W18717 Gemini Drive Muskego, Wisconsin 53150
Phone: [phone] Fax: [phone] www.nabcoentrances.com
NABCO hours of Operaon: Monday to Friday 8:00 a.m.- 4:30 p.m. (Central Time)
• Turn OFF all power to the Automatic Door if a Safety System is not working.
• Instruct the Owner to keep all power turned OFF until corrective action can be achieved
by a NABCO trained technician. Failure to follow these practices may result in serious
consequences.
• NEVER leave a Door operating without all Safety detection systems operational.
WARNING
Table of Contents
CHAPTER 1: SAFETY ............................................................. 3
CHAPTER 2: SCOPE .............................................................. 4
SECTION 2.1: To the Installer ......................................................................4
SECTION 2.2: Objecve ...........................................................................4
CHAPTER 3: FEATURES ........................................................... 4
CHAPTER 4: SPECIFICATIONS ..................................................... 4
SECTION 4.1 General Specicaons .................................................................4
SECTION 4.2 Electrical Specicaons ................................................................5
SECTION 4.3 Output Power Guidelines ..............................................................5
CHAPTER 5: 120 VAC GENERAL WIRING ............................................ 6
CHAPTER 6: THE OPUS CONTROL .................................................. 7
CHAPTER 7: THE ROTARY DIAL .................................................... 7
CHAPTER 8: LCD CATAGORY SCREENS .............................................. 8
SECTION 8.1: Level One: Specicaon Screens ........................................................8
SECTION 8.2: Level Two: Access Screen ..............................................................9
SECTION 8.3: Level Three and Four: Seng Category and Menu Items ...................................10
CHAPTER 9: PROGRAMMING MENUS ............................................. 11
SECTION 9.1: Base Sengs .......................................................................11
SECTION 9.2: Movement Sengs ..................................................................11
SECTION 9.3: Oponal Sengs ....................................................................12
SECTION 9.4: Output Sengs .....................................................................14
SECTION 9.5: Input Sengs .......................................................................15
SECTION 9.6: History Seng ......................................................................16
SECTION 9.7: Test Open ..........................................................................16

2 of 35
Opus Control Wiring and Programming Installaon Manual www.NabcoEntrances.com
P/N C-00139 Rev 3-9-18
CHAPTER 10: COMMON PROGRAM ADJUSTMENTS ................................. 17
SECTION 10.1: Stroke Learning ....................................................................17
SECTION 10.2: Movement Sengs .................................................................17
SECTION 10.3: Recycle Count “Reset” ..............................................................17
CHAPTER 11: FOLD DOOR WIRING DIAGRAMS ..................................... 18
SECTION 11.1: Switches and Sensors ...............................................................18
SECTION 11.2: Switches and Sensors with Monitoring .................................................19
CHAPTER 12: SWING DOOR WIRING DIAGRAMS.................................... 20
SECTION 12.1: Acvaon .........................................................................20
SECTION 12.2: Acvaon using ON/OFF/Hold-Open Switch .............................................21
SECTION 12.3: Safety ............................................................................22
SECTION 12.4: Safety with Monitoring ..............................................................23
SECTION 12.5: Lock ..............................................................................24
SECTION 12.6: Standard Wiring for Single Full Automac ..............................................25
SECTION 12.7: Single Full Automac with Monitoring .................................................26
SECTION 12.8: Standard Wiring for Simultaneous Pair Full Automac ....................................27
SECTION 12.9: Simultaneous Pair Full Automac with Monitoring .......................................28
SECTION 12.10: Connecng a Break-Out Switch ......................................................29
SECTION 12.11: No Security System: One Way / Two Way Operaon .....................................30
SECTION 12.12: Other ...........................................................................31
SECTION 12.13: Motor Wiring .....................................................................31
CHAPTER 13: TROUBLESHOOTING ................................................ 32
SERVICE PARTS: OPUS SIDE LOAD UNITS ........................................... 34
SERVICE PARTS: OPUS BOTTOM LOAD UNITS ....................................... 35

3 of 35
www.NabcoEntrances.com OpusControlWiringandProgrammingInstallaonManual
Rev. 3-9-18 P/N C-00139
CHAPTER 1: SAFETY
SECTION 1.1: Warning Labels
Warning labels are universal and used to alert an individual of potenal harm to one’s self or to others. The following warning labels
are listed in a hierarchy order that denes the most potenal danger rst, and the least potenal danger last.
Indicates potentially dangerous situations. Danger is used when there is a hazardous situation
where there is a high probability of severe injury or death. It should not be considered for
property damage unless personal injury risk is present.
Indicates a hazardous situation which has some probability of severe injury. It should not be
considered for property damage unless personal injury risk is present.
Indicates a hazardous situation which may result in a minor injury. Caution should not be
used when there is a possibility of serious injury. Caution should not be considered for
property damage accidents unless a personal injury risk is present.
Aenon: A situaon where material could be damaged or the funcon impaired.
Notice: Indicates a statement of company policy as the message relates to the personal safety or protecon of
property. Noce should not be used when there is a hazardous situaon or personal risk.
Note: Indicates important informaon that provides further instrucon.
SECTION 1.2: General Safety Recommendaons
Disconnect all power to the junction box prior to making any electrical connections. Failure to
do so may result in seriouc personal or fatal injury. When uncertain whether power supply is
disconnected, always verify using a voltmeter.
Do not place nger or uninsulated tools inside the electrical controller. Touching wires or
other parts inside the enclosure may cause electrical shock, serious injury or death.
Read, study and understand general safety recommendations, warning labels, installation and
operating instructions contained in, or referenced in this manual before operating. If you do
not understand the instruction, ask a qualied
technician. Failure to do so may result in bodily injury, or property damage and will nullify all
warranties.
The Ground wire from the Opus Control 120 VAC Harness, and the Incoming 120 VAC Ground
wire must be connected to the Ground screw located within the Swing door Header.
All electrical troublshooting or service must be performed by trained, qualied electrical
technicians and comply with all applicable governing agency codes.
Do Not touch other parts of the Opus Control board with a screwdriver or anything else metal.
Damage to electrical circuitry may occur.
If the door appears broken or does not seem to work correctly, it should be immediately
removed from service until repairs can be carried out or a qualied service technician is
contacted for corrective action.
Notice: Wiring must meet all local, state, federal or other governing agency codes.
Note: All Adjustments must be made with a small screwdriver. Do Not use a pencil.
Note: Final installaon must conform to current versions of ANSI 156.19 for Low Energy Swingers or ANSI 156.10 for Full
Automac Swingers.
Note: Study and understand both ANSI Standard Codes A156.10 and A156.19.
DANGER
WARNING
CAUTION
DANGER
DANGER
WARNING
CAUTION
CAUTION
CAUTION
CAUTION

4 of 35
Opus Control Wiring and Programming Installaon Manual www.NabcoEntrances.com
P/N C-00139 Rev 3-9-18
CHAPTER 2: SCOPE
SECTION 2.1: To the Installer
The purpose of this manual is to familiarize the installer with the proper installaon and operaon of this system. It is essenal
that this equipment be properly installed and operaonal before the door is used by the public. It is the installer’s responsibility
to inspect the operaon of the entrance system to be sure it complies with any applicable standards. In the United States, ANSI
Standard 156.10 (Used to cover Full Energy doors) and ANSI Standard 156.19 (Used to cover Low Energy doors) apply. Other local
standards or codes may apply. Use them in addion to the ANSI standards.
The owner should determine the door is operang properly and should immediately call for service if there is any malfuncon. All
installaon changes and adjustments must be made by qualied, NABCO trained technicians.
If aer troubleshoong a problem, a sasfactory soluon cannot be achieved, please call Nabco Entrances at 1-877-622-2694
between 8 am – 4:30 pm Central me for addional assistance.
SECTION 2.2: Objecve
The Opus Control is designed to be installed within the Header of:
XNew Swing and Folding Doors.
XExisting swing and folding doors using Analog, Magnum, or U01-U19 controls (works with encoders or
microswitches).
X
1-888-679-3319.
This manual oers step by step instrucons. Do Not take shortcuts.
CHAPTER 3: FEATURES
Specification Description
Power Close Built-in
Back Check Angle Adjustment ► ►
Latch Check Angle Adjustment ► ►
Built In Sequencer Can acvate:
►Electric Locks
►Electric Strikes
►
CHAPTER 4: SPECIFICATIONS
SECTION 4.1 General Specicaons
Specification Description
Temperature Range -13 degrees to 140 degrees Fahrenheit
Motor Type DC Brush Motor with Encoder, 115V
Number of Signal Inputs ► ►2 x Door Mode
► ►1 x Sequential
► ►
Number of Outputs ►
►

5 of 35
www.NabcoEntrances.com OpusControlWiringandProgrammingInstallaonManual
Rev. 3-9-18 P/N C-00139
SECTION 4.2 Electrical Specicaons
Note: All Wiring Diagrams included within this manual, reect typical primary and secondary circuits that might be commonly
used. On site wiring may be dierent from that shown.
Note: NABCO factory ulizes Underwriters Laboratories (UL) recognized component wire, terminals and connector housings to
manufacture all Automac Door systems.
Table 1 Wiring
Item Description
Power Input 100VAC - 130 VAC, AC 50-60 Hz; 3A (NABCO recommends min. 5A service)
Power for accessories 12VDC; 750mA
Output Rang Transistor Output; 100mA @ 12VDC
 
F1 Fuse 120VAC Power Circuit of Control
Table 2 
Sensor Part Number Current Consumption
Acuvision V-00202 80mA
(ea.unit) at 12VDC
Optex Reacon V-00173 125mA
Acusensor M A-01306 150mA
Optex i-one V-00055 130mA
Radio Control Receiver 24-11467 50mA
CX33 Logic Relay V-00734 320mA
SECTION 4.3 Output Power Guidelines
TOTAL current draw from the Opus Control must not exceed 0.7A when providing power to:
XSensors XModules XAccessories X
If TOTAL current draw exceeds 0.7A the installer must ulize an auxiliary power supply such as the NABCO Transformer 24 VAC,
P/N A-01185.
The Opus Control must Not be used to output power to:
►Magnetic Locks ►Electric Strikes
To determine if an auxiliary power supply must be used, add the total current draw of all devices. Please refer to the formula below:

2 x Acusensor M @ 150 mA = 300 mA
 50 mA
 350 mA
350mA does not exceed total current draw.

CAUTION

6 of 35
Opus Control Wiring and Programming Installaon Manual www.NabcoEntrances.com
P/N C-00139 Rev 3-9-18
CHAPTER 5: 120 VAC GENERAL WIRING
Shut the installation site branch Circuit Breaker OFF. Failure to do so may result in serious
personal or fatal injury. When uncertain whether power supply is disconnected, always verify
using a voltmeter.
All high voltage electrical connections must be made by licensed electricians according to
National and Local electrical codes/regulations.
Permanent wiring shall be employed as required by local codes.
Electrical circuit to Nabco operator must not be not shared with other equipment such as
lighting, cash registers, or any device that might cause electrical interference on the circuit.
Keep sufcient spacing between high-voltage and low-voltage wiring. 120 VAC Power wires
must be routed (separate from other wiring) located near the top of inside Header.
Ensure that incomming electrical ground is properly secured to the grounding screw or
grounding wire, whichever is provided.
Aenon: Insert all Incoming 120 VAC Power wires into the pre drilled Electric Service Access Hole located at the
le or right side of Header End Cap.
Aenon: Electrical circuit to Nabco operator must not be not shared with other equipment such as lighng,
cash registers, or any device that might cause electrical interference on the circuit.
Aenon: Any non-factory low voltage wiring added inside the Header must be Type CL2 wire or the equivalent
in accordance with Arcle 725 of the NEC.
Note: It is recommended for the Installer to house all Incoming 120 VAC wires within an Electrical Conduit.
DN 1335
SINGLE
120 VAC
SIMULTANEOUS PAIR
120 VAC
WHITE
BLACK
NEUTRAL
HOT
GROUND
OPUS CONTROL
BLACK
BLACK
1413121110
98
7
6
54
321
Ground Screw
ON/OFF
Rocker
Switch
WHITE
BLACK
NEUTRAL
HOT
GROUND
OPUS CONTROL
BLACK
BLACK
OPUS CONTROL
BLACK
WHITE
GREEN
GREEN
1413121110
98
7654321
1413121110
98
7654321
Ground Screw
ON/OFF
Rocker
Switch
Motor
21
Motor
BLACK
21
Motor
21
WARNING
WARNING
CAUTION
CAUTION
CAUTION
CAUTION

7 of 35
www.NabcoEntrances.com OpusControlWiringandProgrammingInstallaonManual
Rev. 3-9-18 P/N C-00139
CHAPTER 6: THE OPUS CONTROL
The Opus Control is used to power and control operang characteriscs of the door with the use of harnesses and wiring.
Note: When the LCD Screen is LIT, the Hold Close feature is disabled. When the LCD screen is OFF, the Hold Close feature is
enabled.
Figure 1 
DN 1328
1413121110
98
7
6
54
321
①
②
③
④⑤⑥
⑦
⑧
1 CN3 I/O Terminal Strip 5- LCD Screen
2CN5 Relay Output Terminal Strip 6 CN2 Motor Connector
3 CN4 CAN Bus Communicaon 7 CN1 Power Connector
4- Rotary Dial 8 - Fuse
CHAPTER 7: THE ROTARY DIAL
X



X


DN 1242
Type: GT710 Swing
Status: Slow Closing
Error: -----
Ac va on: IN EXT
Switch: LCHK BCHK
Other: BA 6B SWL
Push and Hold Dial
Go to Se ng Mode
Rotary Dial
UNIT SPECIFICATIONS
11
20
10
12
LCD Screen
Figure 2 

8 of 35
Opus Control Wiring and Programming Installaon Manual www.NabcoEntrances.com
P/N C-00139 Rev 3-9-18
CHAPTER 8: LCD CATAGORY SCREENS
Passcode
Go to Se ng Menu
Stroke Learning
Yes No
UNIT SPECS ERROR ANSI TERMINAL Long
Push
LEVEL 1 LEVEL 2
Rotate Dial to navigate screen. Short Push Dial to select
Se ng Category
LEVEL 3
ParameterOp ons
Base Se ng Operator Type/Low or Full Energy/Handing/Encoder
Movement Se ng
(Rotate Rotary Dial)
Open Speed/Back Check Speed/Back Check Range/Close Speed/Latch Check Speed/
Latch Check Range/Open Timer/Reac on Power/Open Recycle Sens/Close Recycle Sens/
A er Open Recycle
Op onal Se ng Hold Close Force/Power Close Range/Manual Open Func on/Manual Open Sens/Manual
Open Timer/BCHK Lockout Angle/LCHK Lockout Angle/Stop Force adjustment/SimPair Se ng
Output Se ng Output1 Se ng/Output2 Se ng/RelayOutput3 Se ng/Open Delay Timer/
Sequence Delay Timer/Lock Condi on
Input Se ng Input 62 Se ng/Input 62 Open Timer/Input H Se ng/Input H Open Timer/Input 61 Circuit/
Input 62 Circuit/Input 6B Circuit/Input SWL Circuit/Input BA Circuit/6B Stop Closing/A er 6B
Open?/61 Monitoring/62 Monitoring/6B Monitoring/SWL Monitoring
History Se ng Opera on Cnt/Open Recycle Cnt/Close Recycle Cnt/Latest Recycle Posi on
DN 1334
LEVEL 4
Push and Hold Rotary Dial (2 Sec.)
Rotate
Dial
Rotate
Dial
Rotate
Dial
Short
Push
Figure 3 
SECTION 8.1: Level One: Specicaon Screens
Type: GT710 Swing
Status: Slow Closing
Error: -----
Ac va on: IN EXT
Switch: LCHK BCHK
Other: BA 6B SLS
Keep Pushing Switch
=> Se ng Mode
DN 1241
UNIT SPECS
ANSI specs (reference)
Opening Time to 80 deg
Closing Time to LCHK
LCHK to FullClosed
8BA112VDC
9SQ2GND
10 Mul 361
11 M0 462
12 M1 56B
13 Out3 6SWL
14 GND 7 Out2
Terminal
Error Screen
Mfg: 11/2016 Rev.B:21
Rotate
Dial
Rotate
Dial Rotate
Dial
ANSI SPECS
ERROR SPECSTERMINAL SPECS
Figure 4 
Level One screens are used to inform the User all specicaons that have already been programmed into the Opus Control. If a
specicaon needs to be changed, the User must reprogram the Opus Control within the Level Three screen, or Level Four screen.
When Power is turned ON for the rst me, the Door does not move. Instead, an LCD screen will illuminate to display a Level One:
Unit Specicaon screen (Default screen). There are (4) Level One screens:
X




9 of 35
www.NabcoEntrances.com OpusControlWiringandProgrammingInstallaonManual
Rev. 3-9-18 P/N C-00139
X

DN 1249
Type: GT710 Swing
Status: Slow Closing
Error: -----
Ac va on: IN EXT
Switch: LCHK BCHK
Other: BA 6B SLS
Keep Pushing Switch
=> Se ng Mode
UNIT SPECS
Recycle Warning!
Rotate
Dial
ERROR SPECS
Short
Push
FLASHING
SCREEN
Long
Push
Recycle Warning!
Clear Yes No
ERROR SPECS
Rotate
Dial
Recycle Warning!
Clear No
ERROR SPECS
Yes
Short
Push
Figure 5 
X


X

SECTION 8.2: Level Two: Access Screen
Note: The “Acvate Passcode” opon is only displayed in the event “0045” had not already been entered.
DN 1713
Passcode
Stroke Learning
Yes No
LEVEL 2
Rotate
Dial
Passcode
Stroke Learning
Yes No
Passcode
Go to Seng Menu
Stroke Learning
Passcode
Go to Seng Menu
Stroke Learning
Go to Seng menu Reset to Default Set
YesNo
Passcode
Stroke Learning
Yes No
Acvate Passcode
Rotate
Dial
Rotate
Dial
Rotate
Dial
Figure 6 
Aenon: To prevent tampering, a Universal Passcode (0045) has been programmed into all Opus Controls. This
Passcode cannot be changed, but can be turned OFF and ON.
Aenon: Do Not acvate Passcode (0045) unl programming of the Opus Control is complete. Failure to do so,
will force the User to enter (0045) each me a change is made.
8.2.1 Enter Passcode
Short
Push
LEVEL 2Reset to Default Set
If you don’t know
the passcode,
Keep Pushing Switch,
Return to Normal mode
0
Short
Push
Reset to Default Set
If you don’t know
the passcode,
Keep Pushing Switch,
Return to Normal mode
00
Short
Push
Reset to Default Set
If you don’t know
the passcode,
Keep Pushing Switch,
Return to Normal mode
000
Rotate
Dial
Reset to Default Set
If you don’t know
the passcode,
Keep Pushing Switch,
Return to Normal mode
004
Short
Push
Reset to Default Set
If you don’t know
the passcode,
Keep Pushing Switch,
Return to Normal mode
0044
Rotate
Dial
0045
Short
Push
Correct PassCode!
If you don’t know
the password,
Keep Pushing Switch,
Return to Normal mode
0045
Reset to Default Set
If you don’t know
the passcode,
Keep Pushing Switch,
Return to Normal mode
DN 1715
Passcode
Stroke Learning
Yes No
Ac vate Passcode
Figure 7 Enter Passcode

10 of 35
Opus Control Wiring and Programming Installaon Manual www.NabcoEntrances.com
P/N C-00139 Rev 3-9-18
8.2.2 Cancel Passcode or Reset to Default
Passcode
Stroke Learning
Yes No Short
Push
Reset to Default Set
LEVEL 2Reset to Default Set
If you don’t know
the passcode,
Keep Pushing Switch,
Return to Normal mode
0
Short
Push
Reset to Default Set
If you don’t know
the passcode,
Keep Pushing Switch,
Return to Normal mode
00
Short
Push
Reset to Default Set
If you don’t know
the passcode,
Keep Pushing Switch,
Return to Normal mode
000
Rotate
Dial
Reset to Default Set
If you don’t know
the passcode,
Keep Pushing Switch,
Return to Normal mode
004
Short
Push
Reset to Default Set
If you don’t know
the passcode,
Keep Pushing Switch,
Return to Normal mode
0044
Rotate
Dial
0045
Short
Push
Correct PassCode!
If you don’t know
the password,
Keep Pushing Switch,
Return to Normal mode
0045
Reset to Default Set
If you don’t know
the passcode,
Keep Pushing Switch,
Return to Normal mode DN 1712
Figure 8 
8.2.3 Stroke Learning
Stroke Learning is used to measure from Fully Closed to Fully Open points in eort to determine where Check Points should happen.
Stroke Learning is also used to determine if an exisng Operator Type is correct, and/or to determine if Handing is correct.
1. Briey press down on the Rotary Dial to select:
XYes
• 
• 
XNo
• 

• 

screens.
SECTION 8.3: Level Three and Four: Seng Category and Menu Items
Short
Push
DN 1716
Passcode
Stroke Learning
Yes No
Go to Seng menu Seng Category
Base Seng
Movement Seng
Oponal Seng
Output Seng
Input Seng
History Data
LEVEL 3
Low Energy or Full
Low Full
Rotate
Dial
LEVEL 4
LEVEL 2
Long Push
Long Push
Figure 9 

11 of 35
www.NabcoEntrances.com OpusControlWiringandProgrammingInstallaonManual
Rev. 3-9-18 P/N C-00139
CHAPTER 9: PROGRAMMING MENUS
SECTION 9.1: Base Sengs
Base Setting
Setting Category Menu Item Default Action
Operator Type ►
►
►
GT-710
Swing
►
►
Swing
Low or Full Energy
(For Swing Doors)
►Low
►Full
Low ►
►
Door Hand
(for Swing Doors)
►Left
►Right
Le From the Exterior Side of Building, determine which Handing to
enter: Le or Right
RIGHT HANDING
DN 1308
LEFT HANDING
Pivot Sle on Swing Door
Swing Door
EXTERIOR SIDE OF BUILDING
Door Hand
(for Fold Doors)
►Left
►Right
Le From the Exterior Side of Building, determine which Handing to
enter: Le or Right
DN 0833
EXTERIOR BREAKOUT SIDE
LEFT HAND RIGHT HAND
Door Hand
(for Slide Doors)
►Left
►Right
Le From the Exterior Side of Building, determine which Handing to
enter: Le or Right
RIGHT HANDING
DN 1326
LEFT HANDING
EXTERIOR SIDE OF BUILDING
Encoder
(For Swing Doors)
►Yes
►No
Yes ►
Reduced Stroke
(for Slide Doors)
►Yes
►No
No ►
SECTION 9.2: Movement Sengs
Movement Setting
Parameter Range Default Description
Open Speed 0 - 7 3The higher the number the faster the Door opens
Back Check Speed 0 - 7 3Sets door speed during Back Check
Back Check Range 0 - 7 3►°to 35°
►
Close Speed 0 - 7 3The higher the number the faster the Door closes
Latch Check Speed 0 - 7 3Sets door speed during latch check
Latch Check Range 0 - 7 3►°to 45°
►

12 of 35
Opus Control Wiring and Programming Installaon Manual www.NabcoEntrances.com
P/N C-00139 Rev 3-9-18
Movement Setting
Parameter Range Default Description
Open Timer 0-10, 12, 15, 20, 25, 30 2 Amount of Hold Open me aer deacvaon in seconds
Reaction Power 0 - 7 3Determines how fast the door reacts to a reacvaon when closing
Open Recycle Sens 0 - 7 3Determines how hard the door will push against an obstrucon
during opening
Close Recycle Sens 0 - 7 3►

►

Aer Open Recycle Slow Open, Stop Slow Open Determines what happens aer a recycle during Opening cycle.
Close Recycle
Reopen
Yes Yes Determines what happens aer a recycle while closing cycle.
No
SECTION 9.3: Oponal Sengs
Optional Setting
Parameter Range Default Description
Hold Close Force 0 - 3 0 0 OFF
3Strongest Hold Close force
Power Close Range  No Power
Close
Closing assisted by Motor to ght wind or stack pressure


Latch and Back
Manual Open Function No Acon No Acon Does nothing
Push and Go P & G Enables push and go
Stop and Close S & C Door pauses at open angle then closes
Open Assist ►
►
►
►

Manual Open Sensitivity 0 - 3 1Angle/force to acvate Push and Go
Manual Open Timer 0-10, 12, 15, 20, 25, 30 4Hold Open me for Manual Opening

BCHK Lockout Angle 0 - 9
A
0►
►Range is from 0°to 30°
►
0Narrow
A Wide
LCHK Lockout Angle 0 - 9
A
0►
►Range is from 0°to 30°
►
0Narrow
A Wide

13 of 35
www.NabcoEntrances.com OpusControlWiringandProgrammingInstallaonManual
Rev. 3-9-18 P/N C-00139
Optional Setting
Parameter Range Default Description
DN 1309
Latch Check (LCHK)
Lockout Angle
Back Check (BCHK)
Lockout Angle Available Angle
Connuous Safety
Available Angle
for Low Energy
Door Mount
Approach Side
Sensor
Available Angle Safety
with lockout
Available Angle Safety
with Lockout
SAFETY WITH LOCKOUT AREASLOCKOUT PARAMETERS
Stop Force Adjustment 0 - 7 3Determines how the door reacts to a connuous safety signal:
Slow Open, Stop, or Slow Close
Anti-Slam Open? Yes No Choose Yes if the door slams open
No
Sim Pair Setting Single Door Single Door Select type of Door
Normal Sim Pair If selected; before returning to last screen, opon to copy
sengs to other Control is given.
Double Egress The Acvaon signal (only) is shared between doors. All other
signals are independent.
Overlap Sim Pair ►
►

1. Have acvaon signals connected to it
2. Be set to “Overlap Sim Pair”
►
►
►

DN 1558
Open fi rst,
Latch check is wide
Overlap Sim Pair
Opus Se ngs
Normal Sim Pair
Ac va on No Ac va on
Connec on

14 of 35
Opus Control Wiring and Programming Installaon Manual www.NabcoEntrances.com
P/N C-00139 Rev 3-9-18
SECTION 9.4: Output Sengs
Output Setting
Parameter Terminal Default Range Description
Output 1 Terminal 7 Full Open  
Output 2 Terminal 13 Full Close  
Relay Output 3 Electric
Lock
Terminals
— —  
 
 
 
Electric Strike Lock 
Electric Magnetic Lock 
Air lock 
Breakout Pass through 
Door Sequencing 
Sensor Monitoring (N.O.) 
 
 
 
 

 
Open Delay Timer N/A 0.4 0.1, 0.4, 1.5 sec




Sequence
Delay Timer
N/A 00-10, 12, 15, 20, 25


seconds
Lock Condition N/A Every Fully
Closed


Determines when the electric lock engages

15 of 35
www.NabcoEntrances.com OpusControlWiringandProgrammingInstallaonManual
Rev. 3-9-18 P/N C-00139
SECTION 9.5: Input Sengs
Input Setting
Parameter Terminal Default Range Description
Input 62 Terminal 4 Exterior
Activation
— — No input
All Mode Acvaon Activates in all modes but OFF
Interior Acvaon Activation on interior for One Way mode
Exterior Acvaon Activation on exterior
Beam Sensor Beam input
LE Approach Sensor LE door mounted sensor
Unlock Input Receives unlocked signal from elec Lock
Spring Close Only Turns off power close and hold close
Sequenal Input Takes on activation to open then another to close door
Open Slow Causes slow opening of the door
Safety with Lockout Swing side header mounted sensor input
Connuous Safety Swing side door mounted sensor input
Reduced Opening Causes unit to change to reduced open
Emergency Close Forces the door to slowly close and lock (if equipped)
Hold Open Mode Causes the door to hold open forever
Asia Only AsiaSpec_IntActSwgSd ►ANSI does not allow
mounted on the Swing side of Door.
►

►ASIAN market ONLY.
AsiaSpec_ExtActSwgSd
Input 62
Open Timer
N/A Same as Open
mer
Same as Open Timer
0 thru 10, 12,15, 20,25 sec
Hold open time for Input 62
Input H
Setting
Terminal
10
— — — — No input
All Mode Acvaon Acvates in all modes but OFF
Interior Acvaon Acvaon on interior for One Way mode
Exterior Acvaon Acvaon on exterior
Beam Sensor Beam input
LE Approach Sensor LE door mounted sensor
Unlock Input Receives unlocked signal from elec Lock
Spring Close Only Turns o power close and hold close
Sequenal Input Takes on acvaon to open then another to close door
Open Slow Causes slow opening of the door
Safety with Lockout Swing side header mounted sensor input
Connuous Safety Swing side door mounted sensor input
Reduced Opening Causes unit to change to reduced open
Emergency Close Forces the door to slowly close and lock (if equipped)
Hold Open Mode Causes the door to hold open forever
Asia Only AsiaSpec_IntActSwgSd ►ANSI does not allow
mounted on the Swing side of Door.
►

►ASIAN market ONLY.
AsiaSpec_ExtActSwgSd

16 of 35
Opus Control Wiring and Programming Installaon Manual www.NabcoEntrances.com
P/N C-00139 Rev 3-9-18
Input Setting
Parameter Terminal Default Range Description
Input H
Open Timer
N/A Same as
Open Timer
Same as Open Timer,
0 thru 10, 12,15, 20,25 sec
Open Timer Seng for this Terminal only
Input 61
Circuit
N/A 

►
►
Circuit logic for Input 61
Input 62
Circuit
N/A 

►
►
Circuit logic for Input 62
Input 6B
Circuit
N/A 

►
►
Circuit logic for Input 6B
Input
SWL Circuit
N/A 

►
►
Circuit logic for Input SWL
Input BA
Circuit
N/A 

►
►
Circuit logic for Input BA
6B Stop
Closing
N/A No ►Yes Determines door movement stop or close, when 6B is ON
at latch check while closing cycle.
►No
After 6B
Open?
N/A Yes ►Yes Determines door movement open or close, aer 6B.
►No
61
Monitoring
N/A  ►
►
Sensor monitoring function *
62
Monitoring
N/A  ►
►
Sensor monitoring function *
6B
Monitoring
N/A  ►
►
Sensor monitoring function *
SWL
Monitoring
N/A  ►
►
Sensor monitoring function *
* If Monitoring is enabled for any input then the sensor MUST be connected to Output 1 or 2.
Output 1 or 2 must then be programmed to “Sensor Health Check”. If an error occurs, the door will hold open until the error clears
or the power is cycled. Monitoring is controlled by the U30 Microprocessor Control for SLIDE doors only.
SECTION 9.6: History Seng
History Data
Parameter Description
Operation Cnt ►
►
Open Recycle Cnt Indicates number of mes the Door reversed direcon during Opening cycle aer sensing:
►
►
Close Recycle Cnt Indicates number of mes the Door reversed direcon during Closing cycle aer sensing:
►
►
Latest Recycle Position ►
►

SECTION 9.7: Test Open
<= Test Open =>
Tests Open/Close door cycle while ignoring Safety Signals.

17 of 35
www.NabcoEntrances.com OpusControlWiringandProgrammingInstallaonManual
Rev. 3-9-18 P/N C-00139
CHAPTER 10: COMMON PROGRAM ADJUSTMENTS
SECTION 10.1: Stroke Learning
UNIT SPECS
Passcode
Go to Seng menu
Stroke Learning
Yes No
Push and Hold
Rotary Dial (2 Sec.)
LEVEL 1LEVEL 2
1. Rotate Dial to select
"Yes".
2. Push Rotary Dial
3. Door will Fully Close
DN 1633
SECTION 10.2: Movement Sengs
DN 1635
UNIT SPECS
Passcode
Go to Seng menu
Stroke Learning
Yes No
Push and Hold
Rotary Dial (2 Sec.)
LEVEL 1LEVEL 2
1. Rotate Dial to select
"Go to Seng menu".
2. Push Rotary Dial
Seng Category
LEVEL 3
Movement Seng Push Rotary Dial
Open Speed
0 1 2 3 4 5 6 7
0, 1 = Slow, 7 = Fast
Speed Ajustment
11
20
10
12
1. Rotate Dial to select the
"parameter opon".
2. Push Rotary Dial
1. Rotate Dial to select
"speed in seconds".
2. Push Rotary Dial
LEVEL 4
1. Rotate Dial to select
"Movement Seng".
2. Push Rotary Dial
Back Check Speed
0 1 2 3 4 5 6 7
0, 1 = Slow, 7 = Fast
Speed Ajustment
11
20
10
12
Push and Hold
Rotary Dial (2 Sec.)
SECTION 10.3: Recycle Count “Reset”
Opera on Cnt
0 cnt
Open Recycle Cnt
0 cnt
Close Recycle Cnt
0 cnt
Latest Rcycl Posi on
C1 0 Op 0
Clear Recycle Cnt
0
If you don/t know
the passcode,
Keep Pushing Switch,
Return to Normal mode
11
20
10
12
DN 1630
UNIT SPECS
Passcode
Go to Se ng menu
Stroke Learning
Yes No
Push and Hold
Rotary Dial (2 Sec.)
LEVEL 1LEVEL 2
1. Rotate Dial to select
"Go to Se ng menu".
2. Push Rotary Dial
Se ng Category
LEVEL 3
History Se ngPush Rotary Dial
Opera on Cnt
0 cnt
Open Recycle Cnt
2 cnt
Close Recycle Cnt
0 cnt
Latest Rcycl Posi on
C1 0 Op 0
11
20
10
12
Push and Hold
Rotary Dial (2 Sec.)
11
20
10
12
Enter Passcode
0045
Clear Recycle Cnt
0045
If you don/t know
the passcode,
Keep Pushing Switch,
Return to Normal mode
11
20
10
12
LEVEL 4
1. Rotate Dial to
select "History Se ng".
2. Push Rotary Dial

18 of 35
Opus Control Wiring and Programming Installaon Manual www.NabcoEntrances.com
P/N C-00139 Rev 3-9-18
CHAPTER 11: FOLD DOOR WIRING DIAGRAMS
SECTION 11.1: Switches and Sensors
DN 1341
1 12VDC +12VDC 2 GND Common for 12V and Signals 361Interior Acvaon
462Exterior Acvaon/Programmable Input
56BSwing Door Connuous Safetly (door mounted, swing side Safety Sensor)
Slide Door Holding Beam
6SWL Swing Door Safety with Lockout (overhead, swing side safety sensor)
Slide Door Sidelite Sensor
7 Out1 Programmable Output
8BABreakout Used mainly for sliding doors, can be used for ON/OFF with swing doors. 9SQ Sequenal Sequenal Acvaon signals to open, or signals to close.
10 H Input HProgrammable input
11 M0 Mode 0 When grounded, puts door into One-Way Mode (Hold-Open when grounded with M1)
12 M1 Mode 1 When grounded, puts door into Night Mode (Hold Open when grounded with M0) 13 Out2 Auxillary Output 2Programmable output, closes to GND
14 GND Ground Ground (common) for all above signals
BLUE to pin 11 BLACK to pin 8 on Opus WHITE to pin 12 RED to pin 14
5 4 3 2 1
Approach Side Acusensor
A-00684
RED
WHITE
BLACK
GREEN
RED
BLUE
BROWN
WHITE
RED
WHITE
BLACK
GREEN
1
2
2 3
1
2
2 4
1
2
2 6
To Pin # on Opus Control
7
6
54
321
EXIT
AUTO
ON
OFF
HOLD OPEN
1413121110
98
N.O. Breakout Switches
Rocker Switch
A-01048
Fold Side Acusensor
A-00684
Fold Side Acusensor
V-00202
Acusensor Harness
M-01167
Acusensor Harness
M-01167
Acuvision Harness
M-01730

19 of 35
www.NabcoEntrances.com OpusControlWiringandProgrammingInstallaonManual
Rev. 3-9-18 P/N C-00139
SECTION 11.2: Switches and Sensors with Monitoring
DN 1895
5
1
BROWN (power +)
RED (power-)
234 67
BLACK (signal common)
Acusensor M Harness
P.N. A-01292
GREY (test +)
GREEN (signal N.O.)
YELLOW (test-)GREY AND YELLOW NOT
NEEDED ON THIS SENSOR
Approach Side Acvaon/Safety
Acusensor M
P.N. V-00741
To Terminal # on Opus Control
Fold Side Acvaon
Acusensor M
P.N. V-00741 GREY AND YELLOW NOT NEEDED
ON THIS SENSOR
YELLOW
GREEN
GREY
BROWN
RED
BLACK
Fold Side Safety
Acusensor M
P.N. V-00741
Acusensor M Harness
P.N. A-01292
YELLOW
GREEN
GREY
BROWN
RED
BLACK
2 1 2
4
1
2 2 2
6
7
8BABreakout Used mainly for sliding doors, can be used for ON/OFF with swing doors. 9SQ Sequenal Sequenal Acvaon signals to open, or signals to close.
10 H Input HProgrammable input
11 M0 Mode 0 When grounded, puts door into One-Way Mode (Hold-Open when grounded with M1)
12 M1 Mode 1 When grounded, puts door into Night Mode (Hold Open when grounded with M0) 13 Out2 Auxillary Output 2Programmable output, closes to GND
14 GND Ground Ground (common) for all above signals
BLUE to pin 8 BLACK to pin 11 on Opus WHITE to pin 12 RED to pin 14
5 4 3 2 1
EXIT
AUTO
ON
OFF
HOLD OPEN
1413121110
98
N.O. Breakout Switches
Rocker Switch
A-01048
1 12VDC +12VDC 2 GND Common for 12V and Signals 361Interior Acvaon
462Exterior Acvaon/Programmable Input
56BSwing Door Connuous Safetly (door mounted, swing side Safety Sensor)
Slide Door Holding Beam
6SWL Swing Door Safety with Lockout (overhead, swing side safety sensor)
Slide Door Sidelite Sensor
7 Out1 Programmable Output
(may be used with sensors equipped with monitor input)
2
1
3 2
BLACK
BLUE
WHITE
RED

20 of 35
Opus Control Wiring and Programming Installaon Manual www.NabcoEntrances.com
P/N C-00139 Rev 3-9-18
CHAPTER 12: SWING DOOR WIRING DIAGRAMS
SECTION 12.1: Acvaon
DN 1329
1 12VDC +12VDC
2 GND Common for 12V and Signals
361Interior Acvaon
462Exterior Acvaon/Programmable Input
56BSwing Door Connuous Safety (door mounted, swing side Safety Sensor)
Slide Door Holding Beam
6SWL Swing Door Safety with Lockout (overhead, swing side safety sensor)
Slide Door Sidelite Sensor
7 Out1 Programmable Output
5 67
2
812 14
11 13
910
1 2 3 4567
3
4
1 2 3 4 5 671 2 3 4
2
3
4
1
N.O.
COMN.O.
COM
Exterior Push-Plate
Interior Push-Plate
ALL DEVICES MUST BE
N.O. DRY CONTACT
812 14
11 13
910
1 2 3 4567
N.O.COM
Interior Acvaon Exterior Acvaon
PWR–PWR+ N.O.COMPWR–PWR+
ALL DEVICES MUST BE
N.O. DRY CONTACT
POWERED ACTIVATION DEVICES
SENSOR, CARD READER, RADIO RECEIVER, ETC.
!!!WARNING!!!
TOTAL POWER OF ALL SENSORS AND POWERED
ACTIVATION DEVICES MUST NOT EXCEED 750 MA
Non-Powered Acvaon Devices
Powered Acvaon Devices
Radio
Receiver
