Owner’s Manual
T517
DVD / CD / MP Player

SAVE THESE INSTRUCTIONS FOR LATER USE.
FOLLOW ALL WARNINGS AND INSTRUCTIONS MARKED ON THE
AUDIO EQUIPMENT.
1 Read instructions - All the safety and operating instructions should be
read before the product is operated.
2 Retain instructions - The safety and operating instructions should be
retained for future reference.
3 Heed Warnings - All warnings on the product and in the operating
instructions should be adhered to.
4 Follow Instructions - All operating and use instructions should be
followed.
5 Cleaning - Unplug this product from the wall outlet before cleaning.
Do not use liquid cleaners or aerosol cleaners. Use a damp cloth for
cleaning.
6 Attachments - Do not use attachments not recommended by the
product manufacturer as they may cause hazards.
7 Water and Moisture - Do not use this product near water-for example,
near a bath tub, wash bowl, kitchen sink, or laundry tub; in a wet
basement; or near a swimming pool; and the like.
8 Accessories - Do not place this product on an unstable cart, stand,
tripod, bracket, or table. The product may fall, causing serious injury to
a child or adult, and serious damage to the product. Use only with a
cart, stand, tripod, bracket, or table recommended by the manufacturer,
or sold with the product. Any mounting of the product should follow
the manufacturer’s instructions, and should use a mounting accessory
recommended by the manufacturer.
9 A product and cart combination should be moved with
care. Quick stops, excessive force, and uneven surfaces may
cause the product and cart combination to overturn.
10 Ventilation - Slots and openings in the cabinet are provided for
ventilation and to ensure reliable operation of the product and to
protect it from overheating, and these openings must not be blocked
or covered. The openings should never be blocked by placing the
product on a bed, sofa, rug, or other similar surface. This product should
not be placed in a built-in installation such as a bookcase or rack unless
proper ventilation is provided or the manufacturer’s instructions have
been adhered to.
11 Power Sources - This product should be operated only from the type
of power source indicated on the marking label. If you are not sure of
the type of power supply to your home, consult your product dealer or
local power company.
The primary method of isolating the amplier from the mains supply
is to disconnect the mains plug. Ensure that the mains plug remains
accessible at all times. Unplug the AC power cord from the AC outlet if
the unit will not be used for several months or more.
12 Grounding or Polarization - This product may be equipped with a
polarized alternating-current line plug (a plug having one blade wider
than the other). This plug will t into the power outlet only one way.
This is a safety feature. If you are unable to insert the plug fully into the
outlet, try reversing the plug. If the plug should still fail to t, contact
your electrician to replace your obsolete outlet. Do not defeat the safety
purpose of the polarized plug.
13 Power - Cord Protection - Power-supply cords should be routed so that
they are not likely to be walked on or pinched by items placed upon or
against them, paying particular attention to cords at plugs, convenience
receptacles, and the point where they exit from the product.
14 Outdoor Antenna Grounding - If an outside antenna or cable system
is connected to the product, be sure the antenna or cable system is
grounded so as to provide some protection against voltage surges
and built-up static charges. Article 810 of the National Electrical Code,
ANSI/NFPA 70, provides information with regard to proper grounding
of the mast and supporting structure, grounding of the lead-in wire
to an antenna discharge unit, size of grounding conductors, location
of antenna discharge unit, connection to grounding electrodes, and
requirements for the grounding electrode.
NOTE TO CATV SYSTEM INSTALLER
This reminder is provided to call the CATV system installer’s attention to Section
820-40 of the NEC which provides guidelines for proper grounding and, in
particular, species that the cable ground shall be connected to the grounding
system of the building, as close to the point of cable entry as practical.
15 Lightning - For added protection for this product during a lightning
storm, or when it is left unattended and unused for long periods of
time, unplug it from the wall outlet and disconnect the antenna or
cable system. This will prevent damage to the product due to lightning
and power-line surges.
16 Power Lines - An outside antenna system should not be located in the
vicinity of overhead power lines or other electric light or power circuits,
or where it can fall into such power lines or circuits. When installing an
outside antenna system, extreme care should be taken to keep from
touching such power lines or circuits as contact with them might be
fatal.
17 Overloading - Do not overload wall outlets, extension cords, or
integral convenience receptacles as this can result in a risk of re or
electric shock.
18 Object and Liquid Entry - Never push objects of any kind into this
product through openings as they may touch dangerous voltage points
or short-out parts that could result in a re or electric shock. Never spill
liquid of any kind on the product.
WARNING: THE APPARATUS SHOULD NOT BE EXPOSED TO
DRIPPING OR SPLASHING, AND OBJECTS FILLED WITH LIQUIDS,
SUCH AS VASES, SHOULD NOT BE PLACED ON THE APPARATUS.
AS WITH ANY ELECTRONIC PRODUCTS, USE CARE NOT TO SPILL
LIQUIDS INTO ANY PART OF THE SYSTEM. LIQUIDS CAN CAUSE A
FAILURE AND/OR A FIRE HAZARD.
IMPORTANT SAFETY INSTRUCTIONS
2
ENGLISH FRANÇAIS ESPAÑOL ITALIANO DEUTSCH NEDERLANDS SVENSKA РУССКИЙ

19 Damage Requiring Service - Unplug this product from the wall outlet
and refer servicing to qualied service personnel under the following
conditions:
a) When the power-supply cord or plug is damaged.
b) If liquid has been spilled, or objects have fallen into the product.
c) If the product has been exposed to rain or water.
d) If the product does not operate normally by following the operating
instructions. Adjust only those controls that are covered by the
operating instructions as an improper adjustment of other controls
may result in damage and will often require extensive work by a
qualied technician to restore the product to its normal operation.
e) If the product has been dropped or damaged in any way.
f) when the product exhibits a distinct change in performance-this
indicates a need for service.
20 Replacement Parts - When replacement parts are required, be
sure the service technician has used replacement parts specified
by the manufacturer or have the same characteristics as the
original part. Unauthorized substitutions may result in fire, electric
shock, or other hazards.
21 Safety Check - Upon completion of any service or repairs to this
product, ask the service technician to perform safety checks to
determine that the product is in proper operating condition.
22 Wall or Ceiling Mounting - The product should be mounted to a wall
or ceiling only as recommended by the manufacturer.
23 Heat - The product should be situated away from heat sources such as
radiators, heat registers, stoves or other products (including ampliers)
that produce heat.
WARNING
TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS
PRODUCT TO RAIN OR MOISTURE.
CAUTION
TO PREVENT ELECTRIC SHOCK, MATCH WIDE BLADE OF PLUG TO WIDE SLOT,
FULLY INSERT.
CAUTION
The T 517 employs a Laser System. To ensure proper use of this product,
please read this owner’s manual carefully and retain for future reference.
Should the unit require maintenance, contact an authorized service
location. Use of controls, adjustments or the performance of procedures
other than those specied may result in exposure to laser radiation. To
prevent direct exposure to laser beam, do not try to open the enclosure.
Visible laser radiation when the enclosure is opened.
DO NOT STARE INTO BEAM.
FCC NOTICE
This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation.
This equipment generates, uses and can radiate radio frequency energy and if
not installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be
determined by turning the equipment o and on, the user is encouraged to try
to correct the interference by one or more of the following measures
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit dierent from
that to which the receiver is connected
• Consult the dealer or an experienced radio/TV technician for help.
FCC WARNING
Changes or modications not expressly approved by the party responsible
for compliance could void the user’s authority to operate the equipment.
INDUSTRY CANADA REQUIREMENT
This Class B digital apparatus meets all requirements of the Canadian
Interference-Causing Equipment Regulations.
THE LIGHTNING FLASH WITH ARROWHEAD SYMBOL, WITHIN
AN EQUILATERAL TRIANGLE, IS INTENDED TO ALERT THE USER
TO THE PRESENCE OF UNINSULATED “DANGEROUS VOLTAGE”
WITHIN THE PRODUCT’S ENCLOSURE THAT MAYBE OF
SUFFICIENT MAGNITUDE TO CONSTITUTE A RISK OF ELECTRIC
SHOCK TO PERSONS.
THE EXCLAMATION POINTWITHIN AN EQUILATERALTRIANGLE IS
INTENDEDTO ALERTTHE USERTO THE PRESENCE OF IMPORTANT
OPERATING AND MAINTENANCE (SERVICING) INSTRUCTIONS IN
THE LITERATURE ACCOMPANYINGTHE APPLIANCE.
CAUTION
Changes or modications to this equipment not expressly approved by
NAD Electronics for compliance could void the user’s authority to operate
this equipment.
CAUTION REGARDING PLACEMENT
To maintain proper ventilation, be sure to leave a space around the unit
(from the largest outer dimensions including projections) that is equal to or
greater than shown below.
Left and Right Panels: 10 cm
Rear Panel: 10 cm
Top Panel: 50 cm
IMPORTANT SAFETY INSTRUCTIONS
3
ENGLISHFRANÇAISESPAÑOLITALIANODEUTSCHNEDERLANDSSVENSKAРУССКИЙ

IMPORTANT INFORMATION FOR UK CUSTOMERS
DO NOT cut o the mains plug from this equipment. If the plug tted is not
suitable for the power points in your home or the cable is too short to reach
a power point, then obtain an appropriate safety approved extension lead
or consult your dealer. If, nonetheless, the mains plug is cut o, REMOVE
THE FUSE and dispose of the PLUG immediately, to avoid possible shock
hazard by inadvertent connection to the mains supply. If this product is
not provided with a mains plug, or one has to be tted, then follow the
instructions given below:
IMPORTANT
DO NOT make any connection to the larger terminal which is marked with
the letter‘E’or by the safety earth symbol or colored GREEN or GREEN AND
YELLOW.
The wires in the mains lead on this product are colored in accordance with
the following code:
BLUE – NEUTRAL
BROWN – LIVE
As these colors may not correspond with the colored markings identifying
the terminals in your plug, proceed as follows:
The BLUE wire must be connected to the terminal marked with the
letter‘N’or colored BLACK.
The BROWN wire must be connected to the terminal marked with the
letter‘L’or colored RED.
When replacing the fuse, only a correctly rated and approved type should
be used, and be sure to re-t the fuse cover.
IF IN DOUBT CONSULT A COMPETENT ELECTRICIAN.
NOTES ON ENVIRONMENTAL PROTECTION
At the end of its useful life, this product must not be disposed
of with regular household waste but must be returned to a
collection point for the recycling of electrical and electronic
equipment. The symbol on the product, user’s manual and
packaging, point this out.
The materials can be reused in accordance with their markings. Through
re-use, recycling of raw materials or other forms of recycling of old
products, you are making an important contribution to the protection of
our environment. Your local administrative oce can advise you of the
responsible waste disposal point.
NOTE: THE T 517 IS NOT AN AUTO VOLTAGE DVD PLAYER.
CONNECT ONLY TO THE PRESCRIBED AC OUTLET, I.E., 120V 60HZ
OR 230V 50HZ.
RECORDYOUR MODEL NUMBER NOW, WHILE YOU CAN SEE IT
The model and serial number of your new T 517 are located on the back of
the cabinet. For your future convenience, we suggest that you record these
numbers here:
Model no. : . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Serial no. : . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
IMPORTANT SAFETY INSTRUCTIONS
NAD is a trademark of NAD Electronics International, a division of Lenbrook Industries Limited
Copyright 2008, NAD Electronics International, a division of Lenbrook Industries Limited
4
ENGLISH FRANÇAIS ESPAÑOL ITALIANO DEUTSCH NEDERLANDS SVENSKA РУССКИЙ

INTRODUCTION
TABLE OF CONTENTS
THANK YOU FOR CHOOSING NAD.
The T 517 DVD/CD/MP Player is a technologically advanced and highly
capable product — yet we have invested great eort in making it
simple and easy to use. We have been careful to ensure that the T 517
is as musically transparent, faithful to every video detail and spatially
accurate as possible, incorporating much of what we’ve learned from a
quarter-century’s experience designing audio, video and home-theater
components.
As with all our products, NAD’s“Music First”design philosophy guided the
T 517’s design in such a way that it can condently promise you state-of-
the-art visual delity and audiophile-quality music listening for years to
come.
We encourage you to take a few minutes now to read right through this
manual. Investing a little time here at the outset might save you a good
deal of time later, and is by far the best way to ensure that you make the
most of your investment in the T 517, and get the most from this powerful
and exible component.
One more thing: We urge you to register your T 517 ownership on the NAD
Worldwide Web site:
http://NADelectronics.com/warranty
For warranty information contact your local distributor.
IMPORTANT SAFETY INSTRUCTIONS ...........................2
INTRODUCTION
GETTINGSTARTED...............................................6
UNPACKINGANDSETUP .............................................6
CHOOSINGALOCATION.............................................6
QUICKSTART.........................................................6
ABOUTTHET517.....................................................6
IDENTIFICATION OF CONTROLS
FRONTPANEL....................................................7
REARPANEL .....................................................8
DVD8REMOTECONTROL........................................9
SETUP
USINGTHET517................................................10
REGION MANAGEMENT INFORMATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
PLAYABLEDISCS.................................................... 10
DISCLOADINGANDPLAYBACK .................................... 10
ABOUT THE ONSCREEN DISPLAY OSD. . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
NAVIGATING THE SETUP MENU OSD AND MAKING CHANGES. . . . . . 10
DISPLAYDISCOSD................................................. 10
ABOUTTHE SYMBOLDISPLAY................................... 10
FACTORYDEFAULTSETTINGS ...................................... 10
OPERATION
USINGTHET517–SETUPMENU.................................11
LANGUAGESETUPMENU .......................................... 11
DISPLAYSETUPMENU.............................................. 11
AUDIOSETUPMENU............................................... 11
LOCKSETUPMENU................................................. 12
OTHERSSETUPMENU.............................................. 13
USINGTHET517-FEATURES....................................14
USBMODE......................................................... 14
ABOUTHDMI ...................................................... 14
PROGRAMMING.................................................... 14
PLAYINGMP3/WMA/JPEG.......................................... 15
VIEWINGAJPEGDISC.............................................. 15
DIVXPLAYBACK.................................................... 16
LASTSCENEMEMORY.............................................. 16
SCREENSAVER...................................................... 16
SYSTEM SELECT 230V VERSION ONLY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
USING THE T 517 – FUNCTION CONTROL . . . . . . . . . . . . . . . . . . . . . . . . . 17
AUDIO ............................................................. 17
SUBTITLE........................................................... 17
ANGLE. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
REPEAT............................................................. 17
REPEATAB......................................................... 17
RANDOM........................................................... 17
ZOOM.............................................................. 18
MARKER, SEARCH. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
RESOLUTION....................................................... 18
SLOW............................................................... 18
TITLEANDMENU .................................................. 19
REFERENCE
LANGUAGECODELIST ..........................................20
AREACODE.....................................................21
TROUBLESHOOTING ............................................22
NOTESONDISCS................................................22
SPECIFICATIONS................................................23
5
ENGLISHFRANÇAISESPAÑOLITALIANODEUTSCHNEDERLANDSSVENSKAРУССКИЙ

INTRODUCTION
GETTING STARTED
UNPACKING AND SETUP
WHAT’S IN THE BOX
Packed with your T 517 you will nd:
• An audio/video cable connector
• The DVD 8 remote control with 2 (two) AAA batteries
• This owner’s manual
SAVE THE PACKAGING
Please save the box and all of the packaging in which your T 517 arrived.
Should you move or otherwise need to transport your T 517, this is by far
the safest container in which to do so. We’ve seen too many otherwise
perfect components damaged in transit for lack of a proper shipping
carton, so please: Save that box!
CHOOSING A LOCATION
Choose a location that is well ventilated (with at least several inches to both
sides and behind), and that will provide a clear line of sight, within 23 feet/7
meters, between the T 517’s front panel and your primary listening/viewing
position - this will ensure reliable infrared remote control communications.
The T 517 generates a modest amount of heat, but nothing that should
trouble adjacent components. It is perfectly possible to stack the T 517 on
top of other components.
QUICK START
In case you simply cannot wait to experience the performance of your new
NAD T 517, we provide the following“Quick Start” instructions to get you
underway.
Please make all the connections to your T 517 with the unit unplugged. It is
also advisable to power-down or unplug all associated components while
making or breaking any signal or AC power connections.
PLAY A CD OR DVD MOVIE
1 Using the supplied audio/video cable connector, connect the
T 517’s composite VIDEO OUT to your TV/monitor’s corresponding
input. Connect likewise the T 517’s AUDIO OUT to your TV/monitor’s
applicable AUDIO input.
2 Plug the AC mains plug into the AC outlet.
3 Press the STANDBY button to switch ON the T 517.
4 To start playback of the T 517; press the [OPEN/CLOSE] button.
5 Insert the media and press [ PLAY] button to start playback. You
should hear audio and see an image on the TV/monitor (If one or the
other fails to appear, check your TV/monitor’s input settings or the T 517
audio/video connections).
Enjoy the movie or music, but be sure to set aside time to read this
manual thoroughly to set up and congure your T 517 according to your
preference.
ABOUT THE T 517
Though the T 517 is among the most technically sophisticated DVD/CD/MP
players, we worked hard to make it one of the most musically transparent
components available as well - this is what we mean by NAD’s“Music First”
design philosophy. Here are just a few examples
• The T 517 includes the High Denition Digital Interface (HDMI) with
HDCP encryption, allowing high denition audio and video signals
to be transferred among applicable components, processors and TV
Displays in a purely digital format.
• HDMI digital video output with upscaling up to 720p, 1080i and 1080p
depending upon your TV’s compatibility.
• Using the high quality 12-bit 148-MHz video DAC, the T 517 ensures
highly accurate playback of delicate, low-level video signals as well as
produce vivid picture that is faithful in every detail. On the other hand,
the audiophile quality 24-bit, 192-kHz audio D/A converters make the
T 517 well protected from noise caused by even minute uctuations
in current from the power supply. This high performance audio D/A
converter ensures that all the sound you hear is as clear and noise free
as possible thereby maintaining the delivery of dynamic, smooth and
expansive audio sound.
• The T 517 has exceptional playability. It has support for DVD video,
DVD±R, DVD±RW, VCD/SVCD with playback control (PBC), Audio CD
and CD-R/CD-RW that contains audio titles, DivX, MP3, WMA and JPEG
les.
6
ENGLISH FRANÇAIS ESPAÑOL ITALIANO DEUTSCH NEDERLANDS SVENSKA РУССКИЙ

IDENTIFICATION OF CONTROLS
FRONT PANEL
1 STANDBY: Press this button to switch ON the T 517. The display
window will illuminate. If there is disc loaded, the display window will
show the playback time status of the disc. If there is no disc inside, the
display window will show“NOdSC” (No Disc).
Pressing the [OPEN/CLOSE] button of the DVD 8 will switch ON the
T 517 from standby mode and at the same time open the disc tray. The
T 517 can also be switched ON by pressing the [ON] or [PLAY] buttons
of the remote control. Pressing the standby switch again turns the unit
back to standby mode. Unplug the AC power cord from the AC wall
socket to completely shut down the T 517.
2 DISC TRAY: With the DISC TRAY open, insert a DVD, VCD, CD or other
compatible media disc face down onto the tray.
“Disc Error”appears at the On-Screen Display (OSD) (“Err”at the display
window), if the disc is placed upside down (and it is a single sided disc).
3 DISPLAY WINDOW: If there is disc loaded, the display window will
show the playback time status of the disc. If there is no disc inside, the
display window will show“NOdSC” (No Disc).
4 REMOTE SENSOR: Point the DVD 8 at the remote sensor and press
the buttons. Do not expose the remote sensor of the DVD 8 to a strong
light source such as direct sunlight or illumination. If you do so, you may
not be able to operate T 517 with the remote control.
Distance: About 23 ft (7 m) from the front of the remote sensor
Angle: About 30° in each direction of the front of the remote sensor
5 USB PORT: Connect an external USB device into this input. Refer also
to the“USB MODE”section of “USING THE T 517 – FEATURES” under the
“OPERATION”main heading.
6 OPEN/CLOSE: Press this button to open and close the disc tray.
7 PLAY: Press this button to start playback. If the disc tray is open, press
this button to automatically close the tray and start playback if a disc is
loaded. Use also this button for USB le playback.
8 PAUSE: Toggle [PAUSE] button to switch between PLAY and PAUSE
mode if a disc is loaded or if a USB le is at playback mode.
9 STOP: During disc playback, press this button to STOP and at the same
time PAUSE disc playback. Press [PLAY] button to resume play from the
spot it was stopped. If [STOP] button is pressed consecutively during
playback, disc or le playback will fully stop.
10 SKIP [ ]: Press [ ] to skip forward or [ ] to skip
backward a track, le or chapter.
SCAN [ ]: Press and hold these buttons to scan at fast-forward
or fast-reverse during playback. Each time the button is pressed, the
speed increases until the maximum level is reached. The scanning
speeding is shown in the OSD and may vary by disc type. The speed
will be retained even after the button is released, but normal playback
will resume once the next track, le or chapter is reached. To return to
normal playback, press [PLAY].
NOTE
Not all media support maximum speeds for scanning.
4 5 6 7 8 9 102 31
7
ENGLISHFRANÇAISESPAÑOLITALIANODEUTSCHNEDERLANDSSVENSKAРУССКИЙ

IDENTIFICATION OF CONTROLS
REAR PANEL
1 AC LINE CORD: Plug the AC power cord into a live AC wall socket.
Make sure all connections have been made before connecting to mains.
2 HDMI OUT: Using a HDMI cable (not supplied), connect the HDMI OUT
jack to the corresponding HDMI input jack of a compatible equipment
like a HDTV, a projector or an A/V Receiver.
WARNING
Before connecting and disconnecting any HDMI cables, both the T 517
and the ancillary source must be powered OFF and unplugged from the
AC outlet. Failure to observe this practice may cause permanent damage
to all equipment connected via HDMI sockets.
IMPORTANT NOTICE
If your HDMI equipped TV is not capable of decoding DTS or Dolby
Digital Bitstream, set the T 517’s Dolby Digital or DTS setting at the
“Audio Setup Menu” to “PCM”. There may be a rushing noise heard if
your TV is not capable of decoding the DTS (or Dolby Digital) Bitstream;
most TVs do not have this capability.
3 S-VIDEO OUT (120V version only): In general, the S-Video
connection is superior to composite video and should be used if
your TV/monitor provides the corresponding input. Connect to the
corresponding S-Video input of a compatible monitor/television,
projector, A/V receiver or processor using quality S-Video cable
designed for video signals.
4 COMPONENT VIDEO OUT: Connect to the corresponding component
video input of a compatible equipment like a monitor/television,
projector, A/V receiver or processor. Be sure to observe consistency in
connecting the appropriate Y, Cb/Pb, Cr/Pr jacks to the corresponding
sources/inputs. Do not rely purely on the color coding of the jacks,
which may not always be consistent among brands.
NOTES
• Only non-copy protected discs can be played back at 720p, 1080i and
1080p resolution. If the disc is copy protected, it will be only displayed at
480i/576i or 480p/576p resolution.
• For 230V version only: Make sure to set the “TV Output Select” to “YPbPr”
for component video output to be available.
5 DIGITAL OUT (OPTICAL): Connect to the corresponding optical
digital input of a compatible device such as CD recorders, receivers,
computer soundcard or other digital processors.
6 IR IN: This input is connected to the output of an IR (infrared) repeater
(Xantech or similar) or the IR output of another component to allow
control of the T 517 from a remote location. Most NAD products with IR
OUT are fully compatible with the T 517.
7 SCART/RGB OUT (230V version only): Using a SCART connector
(not supplied), connect to the corresponding SCART/RGB video input
of a compatible video monitor/TV. Be sure to observe the correct
orientation of the SCART/RGB plug.
8 VIDEO OUT: Connect to the corresponding composite video input of
a compatible monitor/television, projector, A/V receiver or processor
using quality dual-RCA cable designed for video signals.
9 AUDIO OUT: This analog audio output can be connected to the
corresponding analog audio input of a compatible equipment like an
amplier, receiver, TV or stereo system.
10 DIGITAL OUT (COAXIAL): Connect to the corresponding coaxial
digital input of a compatible device such as CD recorders, receivers,
computer soundcard or other digital processors.
3 4 5 6
7810
1 2
ATTENTION!
Please make sure that the T 517 is powered o or unplugged before making any connections. It is also advisable to power-down or unplug all associated
components while making or breaking any signal or AC power connections.
9
8
ENGLISH FRANÇAIS ESPAÑOL ITALIANO DEUTSCH NEDERLANDS SVENSKA РУССКИЙ

IDENTIFICATION OF CONTROLS
DVD 8 REMOTE CONTROL
1 ON : Switch T 517 ON.
2 OFF : Switch T 517 OFF.
3 AUDIO : Select an audio language.
SUBTITLE : Select a subtitle language
ANGLE : Select a DVD camera angle if
available.
4 REPEAT : Repeat track, all, chapter, title, le,
folder.
RPT A-B : Repeat sequence.
RANDOM : Play tracks or les in random
mode.
5 PROGRAM : Enter or exit program mode.
CLEAR : Remove a track or le number on
the program list.
ZOOM : Enlarge video image.
6 MARKER : Mark any point during playback.
SEARCH : Display MARKER SEARCH menu.
RESOLUTION : Change video resolution
via HDMI or component video output (for
non-copyright protected discs only) port.
7 0-9 number buttons : Select numbered
items in a menu.
8 SKIP [ ] : Go to next chapter, track or
le.
SKIP [ ] : Go to beginning of current
chapter, track, or le/ go to previous chapter,
track, or le.
9 SCAN [ ] : Fast reverse or forward
search.
10 SETUP : Access or remove setup menu.
TITLE : Display the disc Title menu, if
available.
MENU : Access menu on a DVD disc.
11 [ ] : Select an item in a menu.
ENTER : Acknowledge menu selection.
12 DISP : Access on-screen display.
RTN : Exit from a menu window.
13 OPEN/CLOSE : Opens and closes the disc
tray.
SLOW [ ] : Slow forward playback.
14 STOP : Stop playback.
BATTERY ASSEMBLY
Press in and lift tab to remove battery cover out
of recess.
Place batteries into opening. Ensure the correct
tting is observed.
Replace battery cover by aligning and inserting
the two tabs into the holes. Press battery cover
into place until it‘clicks’closed.
1
3
4
5
6
7
8
10
11
12
13
14
12
10
9
2
9
ENGLISHFRANÇAISESPAÑOLITALIANODEUTSCHNEDERLANDSSVENSKAРУССКИЙ
pauSe/Step : Pause playback temporarily/
press repeatedly for frame-by-frame
playback.
plaY : Start playback.

You may operate the T 517 from its front panel or via the DVD 8 remote
control. Since the remote will be the primary controller for most cases, we
will focus on remote-controlled operations. Be sure also to read the section,
“IDENTIFICATION OF CONTROLS - FRONT PANEL”.
REGION MANAGEMENT INFORMATION
The T 517 is designed and manufactured to respond to the Region
Management Information that is recorded on a DVD disc. If the Region
number described on the DVD disc does not correspond to the Region
number shown on the back of the T 517, the T517 cannot play that disc. The
OSD will display“Check Regional Code”(“Err”in the display window) when
an incompatible region disc is loaded.
PLAYABLE DISCS
The T 517 has exceptional playability. It has support for DVD video, DVD±R,
DVD±RW, VCD/SVCD with playback control (PBC), Audio CD and CD-R/CD-
RW that contains audio titles, DivX, MP3, WMA and JPEG les.
NOTE
You cannot playback discs other than those listed above. To do so may
render the T 517 permanently inoperable.
DISC LOADING AND PLAYBACK
There are two dierent disc sizes. Place the disc in the correct guide on the
disc tray. If the disc is out of the guide, it may damage the disc and cause
the T 517 to malfunction. “Disc Error” appears at the On-Screen Display
(OSD) (“Err”at the display window), if the disc is placed upside down (and it
is a single sided disc).
The following are important tips when loading a disc
• Do not push the disc tray while it is moving. Doing so may cause the
T 517 to malfunction.
• Do not push up the disc tray or put any objects other than discs on the
disc tray. Doing so may cause the T 517 to malfunction.
• Keep your ngers well clear of the disc tray as it is closing. Be especially
careful with children’s ngers around the closing disc tray, as there is a
risk of personal injury.
Press [PLAY], the disc tray is automatically closed. Playback of the rst
track starts if a CD is loaded. For DVD, USB or other disc media, playback
operation is accessible through their menu screen.
NOTE
Do not move the T 517 during playback. Doing so may damage the disc
and the T 517.
ABOUT THE ON-SCREEN DISPLAY (OSD)
The T 517 employs a self-explanatory on-screen display“menu”that will
appear on the connected video monitor/TV. These are required during
the setup process (and are useful in day-to-day operation), so be sure to
connect the monitor/TV before proceeding with the setup.
DISPLAY THE T 517 SETUP MENU
Press the DVD 8’s [SETUP] button for the Setup Menu OSD to appear. With
the use of the DVD 8’s navigation buttons, you may select various menus. If
the Setup Menu does not appear, check your applicable video connections.
NAVIGATING THE SETUP MENU OSD AND MAKING CHANGES
To navigate through the Setup Menu OSD options, please do the following
using the DVD 8 remote control:
1 Use [ ] keys to move up or down the menu selections.
2 Press [ ] to select a menu item.
3 Use [ ] keys to select through the options of a particular menu
item.
4 Press [ENTER] to select a desired setting/selection.
5 Press [SETUP] or [PLAY] to exit the Setup menu.
To exit from a menu option, press repeatedly DVD 8’s [ ] key as applicable.
DISPLAY DISC OSD
You can display the general disc playback status on the TV screen. Some
items can be changed using the menu. To use the on-screen display:
1 Press the DVD 8’s [DISP] during playback.
2 Press [ ] to select an item. The selected item is highlighted.
3 Key-in the desired the number button, press [ ] or [ENTER] as
applicable.
NOTES
• The display feature may not be available for all disc media and is media
dependent.
• Display disc OSD does not apply to audio only discs like CD and MP3/
WMA/JPEG les as they are already presented in their respective menu
screens.
• If no button is pressed for about 10 seconds, the on-screen display
disappears.
ABOUT THE SYMBOL DISPLAY
“ ”may appear on your TV display during operation. This indicates that the
function you entered or try to execute is not available on that specic disc
or le.
FACTORY DEFAULT SETTINGS
The procedure below will restore the T 517 to its factory default settings.
1 The T 517 must be in a “No Disc”status. Press [SETUP] key of the DVD 8
and the Setup Menu OSD will appear.
2 Use [ ] to highlight DISPLAY setup menu. Press [ ] to go to “TV
Aspect” option.
3 Press [ ] again to highlight “16:9”. Using the number buttons of the
DVD 8, input in quick succession the following numbers – 1397139,
then [ENTER].
4 The“SYSTEM INFORMATION” OSD will be shown. Press [ENTER].
5 Switch OFF the T 517. The T 517 is now restored to its factory default
settings.
When you turn back ON the T 517, the “Menu Language”OSD will appear.
Use [ ] to select your preferred language. Press [ENTER]. You will again
be prompted to press [ENTER] to conrm your selection.
SETUP
USING THE T 517
10
ENGLISH FRANÇAIS ESPAÑOL ITALIANO DEUTSCH NEDERLANDS SVENSKA РУССКИЙ

The Setup Menu allows one to customize the operation of the T 517. If the
factory defaults do not suit your taste, you will need to use the setup menu
to congure the T 517 yourself.
To access and navigate through the Setup Menu selections, please refer to
and follow the directions stated in the above section about “NAVIGATING
THE SETUP MENU OSD AND MAKING CHANGES.”
LANGUAGE SETUP MENU
MENU LANGUAGE
Select a language for the SETUP menu and on-screen display.
DISC AUDIO/SUBTITLE/MENU
Select the language you prefer for the audio track (disc audio), subtitles
and the disc menu. Depending on the DVD media, only those Disc Audio,
Disc Subtitle and Disc Menu languages recorded on the DVD media are
available. When a language is chosen, it will become the default setting
unless the DVD media overrides the settings.
Original: Refers to the original language in which the disc was
recorded.
Other: Select “Other”if the desired language is not on the list.
Use [ ] to highlight “Others”and then input the 4-digit language
code using the number keys of the remote control. Press [ENTER]. If
you enter the wrong language code, press [CLEAR]. See “LANGUAGE
CODE LIST” under the main heading “REFERENCE”for a list of applicable
language codes.
O: If you choose for the disc subtitle not to come up, select “O”.
DISPLAY SETUP MENU
TV ASPECT
4:3 : Select when a standard 4:3 TV is connected.
16:9 : Select when a 16:9 wide TV is connected.
DISPLAY MODE
Display Mode setting works only when the TV Aspect mode is set to 4:3.
Letterbox: Displays a wide picture with bands on the upper and lower
portions of the screen.
Panscan: Automatically displays the wide picture on the entire screen
and cuts o the portions that do not t.
TV OUTPUT SELECT 230V VERSION ONLY
Set the player’sTV Output Select options according to theTV connection type.
RGB: Select when you connect the SCART OUT port with the use of a
SCART connector (not supplied) to the corresponding SCART input of a
compatible TV. There is no component video output when“TV Output
Select”is set to “RGB”.
YPbPr: Select this option for component video output to be available.
AUDIO SETUP MENU
Each DVD disc has a variety of audio output options. Set the T 517’s AUDIO
options according to the type of audio system you use.
DOLBY DIGITAL/DTS/MPEG
Set the type of digital audio signal.
Bitstream: Select “Bitstream”if you connect the T 517’s digital OUT jack
to an amplier or other equipment with a Dolby Digital, DTS or MPEG
decoder.
PCM: Select when connected to a two-channel digital stereo
amplier. DVDs encoded in Dolby Digital or MPEG will be automatically
downmixed to two-channel PCM audio.
O (for DTS only): Select“O”when you connect the digital audio out
jack to an equipment that has no DTS decoder.
SAMPLE FREQ. FREQUENCY
Set the sampling frequency of the audio signal.
48KHz: If your receiver or amplier is not capable of handling 96 kHz
signals, select 48 kHz. When this choice is made, this unit automatically
converts any 96 kHz signals to 48 kHz so your system can decode them.
96KHz: If your receiver or amplier is capable of handling 96 kHz
signals, select 96 kHz. When this choice is made, this unit passes each
type of signal through without any further processing.
Check the documentation of your amplier to verify its capabilities.
DRC DYNAMIC RANGE CONTROL
You can select the eective dynamic range (subjective range from soft
to loud) for playback of Dolby Digital soundtracks. It is useful when you
watch your favorite action movie without disturbing others at night.
On: The “On”setting is for late-night sessions or other times when you
wish to retain maximum dialog intelligibility while minimizing overall
volume levels. This is applicable only for Dolby Digital soundtracks.
O: To maintain full dynamic range, set to “O”.
OPERATION
USING THE T 517 SETUP MENU
11
ENGLISHFRANÇAISESPAÑOLITALIANODEUTSCHNEDERLANDSSVENSKAРУССКИЙ

LOCK SETUP MENU
Some movies contain scenes that may not be suitable for children to view.
Many of these discs contain parental control information that applies to
the complete disc or to certain scenes on the disc. Movies and scenes are
rated from Level 1 to 8, depending on the country. Some discs oer more
suitable scenes as an alternative.
When you access Lock Setup Menu for the rst time, you will initially be
directed to the“Area Code”menu. This allows you to setup your own
Parental Control Password from the onset. Continue on with the procedure
below (applicable only for rst time use or when the T 517 is restored to its
factory settings).
1 While at “Area Code” line menu, press [ ].
2 Input your desired 4-digit password code. Press [ENTER].
3 Enter it again and press [ENTER] to verify. You have now setup your
Parental Rating password. If you make a mistake before pressing
[ENTER], press [CLEAR].
4 You can now setup your Area Code as described below (from step
number 3).
NOTE
Given that this is your rst time accessing the Lock setup menu, after
setting up the Area Code, you will be redirected to the “Rating” menu for
you to set up your parental rating. Follow the “Rating” setup procedure
below.
AREA CODE
Enter the code of the country/area whose standards were used to rate the
DVD video disc. See “AREA CODE LIST”under the main heading “REFERENCE”
for a list of applicable area codes.
1 While at “Area Code” line menu, press [ ].
2 Input the password you have setup. Press [ENTER].
3 Select the rst character using [ ] buttons. Press ENTER.
4 Select the second character using [ ] buttons.
5 Press ENTER to conrm your area code selection.
RATING 120V VERSION ONLY
The parental rating feature allows you to block access to scenes greater
than the rating you set up, thereby preventing your children from being
able to view material you believe is unsuitable. To activate“Rating”, please
be guided by the following:
1 While at “Rating”line menu, press [ ]. Press [ENTER].
2 Input the password you have setup.
3 Upon entering the password, you can now set the parental rating level
you prefer. Use [ ] to step through the rating levels.
4 Press [ENTER] to conrm your rating selection.
RATING 18
Rating one (1) has the most restrictions and Rating“8” is the least restrictive.
UNLOCK
If you select unlock, parental lock is not active and the disc plays in full.
NOTE
If you set a rating level for the player, all disc scenes with the same rating
level or lower are played. Higher rated scenes are not played unless an
alternate scene is available on the disc. The alternative must have a
lower rating. If no suitable alternative is found, playback stops. You must
enter the 4-digit password in order to play the disc. Should you forget
your password, restore the T 517 to its factory default settings. Refer to
the “Factory Default Settings” section under the main heading “Setup
– Using the T 517”.
PASSWORD
You can change the password for parental control. Enter your four-digit
password when prompted on the screen.
1 Scroll to [Password]. Press [ ] to select “Change”. Press [ENTER].
2 Enter your old four-digit password using the numeric buttons (0-9).
Press [ENTER].
3 You will be prompted to enter your new password. Enter the new four-
digit password using the numeric buttons (0-9). Press [ENTER].
4 You will be prompted to verify your new password. Enter the new four-
digit password again. Press [ENTER]. The new four-digit password is now
valid.
OPERATION
USING THE T 517 SETUP MENU
12
ENGLISH FRANÇAIS ESPAÑOL ITALIANO DEUTSCH NEDERLANDS SVENSKA РУССКИЙ

OTHERS SETUP MENU
PBC
Set Playback Control (PBC) to On or O. This function is available only on
Video CD and SVCD with playback control (PBC) feature.
On : Video CDs with PBC are played according to the PBC.
O : Video CDs with PBC are played the same way as Audio CDs.
B.L.E.  BLACK LEVEL EXPANSION 120V VERSION ONLY
Black level determines the amount of light a picture display emits for the
darkest areas of an image.
On : Select to enhance the black level.
O : Select for the standard black level setting.
NOTE
Black level is only available for CVBS (composite video) and S-video
output. For component video output, black level is only applicable at a
480i resolution setting.
DIVX ®VOD DIVX REGISTRATION
DivX is the name of a revolutionary new video codec which is based on the
new MPEG-4 compression standard for video. You will be able to play DivX
discs using the T 517.
The Registration code details necessary for VOD (Video-On- Demand)
service can be shown by pressing [ENTER] while at “Select” menu option.
OPERATION
USING THE T 517 SETUP MENU
13
ENGLISHFRANÇAISESPAÑOLITALIANODEUTSCHNEDERLANDSSVENSKAРУССКИЙ

USB MODE
The T 517 can play back MP3/WMA/JPEG/DivX les stored in external USB
(Universal Serial bus) devices. The following are the T 517’s capabilities with
respect to USB device playability.
• Support USB 1.1 full speed (12Mbps).
• When more than 650 les are recorded in the USB device, the T 517 may
not be able to play the les correctly.
• Digital camera & mobile phone are not supported.
USB PLAYBACK
1 Connect the external USB device to the front panel’s USB input.
2 At STOP mode, press [RTN] button of the DVD 8 to switch from DISC
mode to USB mode and vice-versa.
3 For details of operations on applicable le type, refer to the relevant
sections about MP3/WMA/JPEG/DivX playback.
ABOUT HDMI
HDMI (High Denition Multimedia Interface) supports both video and
audio on a single digital connection for use with DVD Players, Set-Top Boxes
and other AV devices.
HDMI was developed to provide the technologies of HDCP (High Denition
Contents Protection). HDCP is used to protect digital content transmitted
and received.
HDMI has the capability to support standard, enhanced or high-denition
video plus standard to multi-channel surround-sound audio, HDMI features
include uncompressed digital video, a bandwidth of up to 5 gigabytes per
second, one connector (instead of several cables and connectors), and
communication between the AV source and AV devices such as DTVs.
HDMI CONNECTION
If you have a HDMI TV or monitor, you can connect it to this player using a
HDMI cable (not supplied).
1 Connect the HDMI OUT jack on the player to the HDMI jack on a HDMI
compatible TV/monitor.
2
image will be displayed if your 1080p-capable TV doesn’t accept
images in 60Hz.
IMPORTANT NOTICE
If your HDMI equipped TV is not capable of decoding DTS or Dolby
Digital Bitstream, set the T 517’s Dolby Digital or DTS setting at the
“Audio Setup Menu” to “PCM”. There maybe a rushing noise heard if your
TV is not capable of decoding such formats.
PROGRAMMING
The program function enables you to store your favorite tracks from any
disc in the player memory. A program can contain 30 tracks. To program the
sequence
1 Insert a disc. Audio CD or MP3/WMA discs: Audio CD or MP3/WMA
menu screen appears.
2 Press DVD 8’s [PROGRAM] button. An“E” icon will appear to the right of
the word“Program”on the right side of the menu screen.
3 Use [ ] to select a track/le that will be included on the“Program”
list. Press [ENTER]. Repeat to place additional tracks/les on the list.
4 Press [Program] again to nish or exit program mode.
PROGRAM PLAYBACK
1 Select the track/le you want to start playing from the “Program”list
(right side of the menu screen).
2 To begin playback, press [ ] or [ENTER]. Playback follows the order in
which you programmed the tracks/les. Playback stops after all of the
tracks/les on the “Program”list have been played once.
3 To resume normal playback from programmed playback, select a track/
le on the left side of the menu screen and then press [PLAY].
ERASING A TRACK FROM PROGRAM LIST
1 Press [ ] to move to the“Program”list.
2 Use [ ] to select the track/le that you wish to erase from the
Program list.
3 Press [CLEAR] button of DVD 8. Repeat to erase additional tracks on the
list.
ERASING THE COMPLETE PROGRAM LIST
1 Press [ ] to move to the“Program”list.
2 Use [ ] to select “Clear All”, then, press ENTER.
NOTE
The programs are also cleared when the disc is removed.
OPERATION
USING THE T 517  FEATURES
14
ENGLISH FRANÇAIS ESPAÑOL ITALIANO DEUTSCH NEDERLANDS SVENSKA РУССКИЙ
Set the TV’s source to HDMI (refer to your TV/monitor’s Owner’s
manual).
When you use HDMI connection, you can change the resolution (480i/576i,
480p/576p, 720p, 1080i, 1080p) for the HDMI output by pressing
RESOLUTION. You can only change the resolution within your TV/Monitor’s
resolution capabilities.
NOTE
No

PLAYING MP3/WMA/JPEG
The T 517 can play MP3/WMA formatted recordings on CD-R, or CD-RW
discs as well as view discs with JPEG les. You may mix any of the le types
on the disc.
1 Load the applicable disc. The OSD will display the folders or les as a list.
Use the DVD 8’s [ ] keys to navigate through the folders or les.
2 Press [ ] to select a folder, and press ENTER to see the folder
contents.
3 Press [ ] to select a le.
4 Press [ENTER] or [PLAY] to start playback. Toggle [DISP] to show
information about the current music le if any - Title, Artist, Album, Year,
Comment. If there is no information,“No ID3 Tag”will be instead shown.
NOTES
• If you are in a le list and want to return to the previous Folder list, use
the [ ] buttons on the remote to highlight “ ” and press [ENTER].
• Press [MENU] button of the DVD 8 to scroll up and down the le list one
page or at least 8 les at a time.
• On a disc with MP3/WMA and JPEG you can switch between MUSCI
and PHOTO menu. Press TITLE and MUSIC or PHOTO word on top of the
menu is highlighted.
• The total number of les on the disc should be less than 650.
IMPORTANT NOTICE
Customers should note that permission is required in order to download
MP3/WMA les and music from the Internet. NAD ELECTRONICS
INTERNATIONAL has no right to grant such permission. Permission
should always be sought from the copyright owner.
VIEWING A JPEG DISC
Using the T 517, you can view discs with JPEG les.
1 Insert a disc and close the tray. The PHOTO menu appears on the TV
screen.
2 Press [ ] to select a folder.
3 Press ENTER. A list of les in the folder appears. Press [ ] to select a
le.
4 Press ENTER or PLAY to start playback. While viewing a le, you can press
STOP to return to the previous menu (PHOTO menu).
NOTES
• If you are in a le list and want to return to the previous Folder list, use
the [ ] buttons on the remote to highlight “ ” and press [ENTER].
• Press [MENU] button of the DVD 8 to scroll up and down the le list one
page or at least 8 les at a time.
• On a disc with MP3/WMA and JPEG you can switch between MUSIC
and PHOTO menu. Press TITLE and MUSIC or PHOTO word on top of the
menu is highlighted.
• To hide/unhide the navigation options below the photo being displayed,
press [DISP] or [RTN] button of the DVD 8.
• The total number of les on the disc should be less than 650.
SLIDE SHOW
Highlight “ ”and use [ ] to setup the speed of the slide show. Use
[ ] to highlight“ ”or“ ” and then press [ENTER] to start slide
show.
LISTENING TO MUSIC DURING SLIDE SHOW
If the disc contain music and photo les together, you can listen to music
during slide show by selecting “ ”. Use [ ] to highlight“ ” and
then press [ENTER] to start slide show.
STILL PICTURE
Press [PAUSE/STEP] during slide show. The player will now go into PAUSE
mode. To return to the slide show, press PLAY or press [PAUSE/STEP] again.
MOVING TO ANOTHER FILE
Press [ ] once while viewing a picture to advance to the next or
previous le.
OPERATION
USING THE T 517  FEATURES
15
ENGLISHFRANÇAISESPAÑOLITALIANODEUTSCHNEDERLANDSSVENSKAРУССКИЙ

DIVX PLAYBACK
Using the T 517, you can play DivX discs.
1 Insert a disc and close the disc tray. The MOVIE menu appears on the TV
screen.
2 Press [ ] to select a folder. Press [ENTER]. A list of les in the folder
appears.
3 Press [ ] to select a le. If you are in a le list and want to return
to the previous Folder list, use the [ ] buttons on the remote to
highlight “ ”and press [ENTER].
4 Press ENTER or PLAY to start playback.
5 Press [STOP] to exit.
NOTES
• Playable DivX les- .avi, .mpg, .mpeg
• The total number of les on the disc should be less than 650.
LAST SCENE MEMORY
This player memorizes the last scene from the last disc that is viewed. The
last scene remains in memory even if you remove the disc from the player
or switch o the player. If you load a disc that has the scene memorized, the
scene is automatically recalled.
NOTE
This player does not memorize the scene of a disc if you switch o the
player before commencing to play the disc.
SCREENSAVER
The screensaver appears when you leave the T 517 in Stop mode for about
ve minutes. If the Screensaver is displayed for ve minutes, the T 517
automatically turns itself o.
SYSTEM SELECT (230V VERSION ONLY)
You can select either Auto, PAL or NTSC to force the output of the T 517 to
the desired format. For example one can load a PAL media and display it
in the NTSC format. Similarly one can load an NTSC media and display it in
the PAL format. The Auto setting will detect automatically the media being
played and display it. Depending on the type of TV set you own, select the
signal mode you wish to watch your disc.
Press the [OPEN/CLOSE] button. To toggle through the system selection,
press and hold [PAUSE/STEP] key of the remote control for more than 5
seconds to select a system – Auto, PAL or NTSC.
OPERATION
USING THE T 517  FEATURES
16
ENGLISH FRANÇAIS ESPAÑOL ITALIANO DEUTSCH NEDERLANDS SVENSKA РУССКИЙ

Depending on the media, the following basic function controls of the T 517
can be accessed directly using the DVD 8.
AUDIO
The AUDIO button will allow one to switch the audio language or format of
the DVD media only if the DVD media supports the AUDIO button feature.
Press [AUDIO] repeatedly to select desired audio language or format.
SUBTITLE
It is possible to change the subtitle language to a dierent language from
the one selected at the initial settings. This operation works only with discs
on which multiple subtitle languages are recorded.
1 Press [SUBTITLE] during playback. When no subtitles are recorded,“OFF”
will be displayed.
2 Press [SUBTITLE] repeatedly until the desired language is selected.
When the desired language is not selected even after pressing the button
several times, it means that the language is not available on the disc.
To eliminate the On Screen Subtitles, press [SUBTITLE] repeatedly to select
“OFF”.
ANGLE
Some DVDs may contain scenes that have been shot simultaneously from a
number of dierent angles. For these discs, the same scene can be viewed
from each of these dierent angles using the [ANGLE] button. This function
only works for discs having scenes recorded at dierent angles.
1 Press [ANGLE] during playback. Angle number will be displayed.
2 Press [ANGLE] repeatedly until the desired angle is selected.
REPEAT
To repeat the playback of a particular track or chapter, press the T 517’s
[REPEAT] key once. Pressing the same [REPEAT] key a second time will
repeat all the tracks or title. Turn o repeat mode by pressing [REPEAT]
button a third time.
NOTE
REPEAT feature does not apply to JPEG les.
RPT A-B
To repeat a sequence, implement the following procedures:
1 Press [RPT A-B] at your chosen starting point -“A” appears on the TV
screen.
2 Press [RPT A-B] again at your chosen end point -“A -B”appears on the
TV screen. The repeat sequence begins.
3 Press [RPT A-B] again to cancel the sequence.
NOTE
REPEAT A-B feature does not apply to MP3/WMA/JPEG les.
RANDOM
Press DVD 8’s [RANDOM] key during playback. Random Playback begins
immediately and“RANDOM”appears on the menu screen. Press [ ]
for random playback of audio tracks. Press [RANDOM] again to return to
normal playback.
OPERATION
USING THE T 517  FUNCTION CONTROL
17
ENGLISHFRANÇAISESPAÑOLITALIANODEUTSCHNEDERLANDSSVENSKAРУССКИЙ

ZOOM
Use [ZOOM] to enlarge the video image. Press [ZOOM] during playback or
still playback to activate the Zoom function.
Depending on the media, each press of the ZOOM button changes the TV
screen in the following sequence: 100%, 200%, 300% and 400%.
Use the DVD 8’s [ ] keys to move through the zoomed picture. To
resume normal playback, press [ZOOM] repeatedly until “100%”.
NOTE
Zoom may not work on some DVDs.
MARKER, SEARCH
Storing a MARKER in the T517’s memory is similar to marking your page in a
book. It allows you to quickly return to any point on the disc.
Press [MARKER] during play at the starting point to be viewed again. Up to 9
markers can be stored in the memory.
RECALLING/CLEARING A MARKER
1 Press SEARCH during playback.
2 Use the [ ] buttons to select the marker to be recalled/cleared.
3 Press [ENTER] to recall a marker. Or press [CLEAR] to clear a marker.
4 Play resumes from the point corresponding to the selected marker, or
the selected marker is cleared.
NOTES
• These operations work only with discs for which the elapsed playing
time appears in the DVD display window during playback or stop mode.
• Some subtitles recorded around the marker may fail to appear (DVD).
• All the markers are cleared when the power is turned o or the disc is
removed.
• A marker is not stored when the DVD or title menu is displayed on the TV
screen.
RESOLUTION
The T 517 has the excellent ability to up-convert standard video denition
contents to high denition video signal. The best possible video resolution
is ensured by the sophisticated video processor of the T
] to select the desired
speed. To exit Slow Motion mode, press [PLAY].
OPERATION
USING THE T 517  FUNCTION CONTROL
18
ENGLISH FRANÇAIS ESPAÑOL ITALIANO DEUTSCH NEDERLANDS SVENSKA РУССКИЙ
517.
Toggle [RESOLUTION] button to step through the possible resolution
settings. You can only change the resolution within your TV/Monitor’s
resolution capabilities.
NOTE
Component Video output - Only
back at 720p, 1080i and 1080p
will be only displayed at 480i/576i
non-copy protected discs can be played
resolution. If the disc is copy protected, it
or 480p/576p resolution.
SLOW
Slow forward playback. Repeatedly press [SLOW

TITLE AND MENU
The [TITLE] and [MENU] buttons are used to display via OSD, the title
headings and menus of the DVD and other applicable media. Some movie
discs may contain two or more titles. If the disc has a title menu recorded
on it, the [TITLE] button can be used to select the movie title. (The details of
operation dier depending on the disc used.)
Press [TITLE] and a list of the titles on the disc are displayed. Depending
on the disc, pressing [TITLE] again will resume play from the scene when
[TITLE] was rst pressed.
Press [ENTER], [PLAY] or the numeric button(s) to select desired title. The
selected title now starts playing.
Some DVDs have unique menu structures called DVD menus. For example,
DVDs programmed with complex contents provide guide menus, and
those recorded with various languages provide menus for audio and
subtitle language.
Press [MENU] during play; the DVD menu available on the disc is now
displayed. Pressing [MENU] again resumes play from the scene when MENU
was rst pressed.
OPERATION
USING THE T 517  FUNCTION CONTROL
19
ENGLISHFRANÇAISESPAÑOLITALIANODEUTSCHNEDERLANDSSVENSKAРУССКИЙ

Use this list to input your desired language for the following settings: DISC AUDIO/DISC SUBTITLE/DISC Menu language.
REFERENCE
LANGUAGE CODE LIST
Language Code
Abkhazian 6566
Afar 6565
Afrikaans 6570
Albanian 8381
Ameharic 6577
Arabic 6582
Armenian 7289
Assamese 6583
Aymara 6588
Azerbaijani 6590
Bashkir 6665
Basque 6985
Bengali; Bangla 6678
Bhutani 6890
Bihari 6672
Breton 6682
Bulgarian 6671
Burmese 7789
Byelorussian 6669
Cambodian 7577
Catalan 6765
Chinese 9072
Corsican 6779
Croatian 7282
Czech 6783
Danish 6865
Dutch 7876
English 6978
Esperanto 6979
Estonian 6984
Faroese 7079
Language Code
Fiji 7074
Finnish 7073
French 7082
Frisian 7089
Galician 7176
Georgian 7565
German 6869
Greek 6976
Greenlandic 7576
Guarani 7178
Gujarati 7185
Hausa 7265
Hebrew 7387
Hindi 7273
Hungarian 7285
Icelandic 7383
Indonesian 7378
Interlingua 7365
Irish 7165
Italian 7384
Japanese 7465
Javanese 7487
Kannada 7578
Kashmiri 7583
Kazakh 7575
Kirghiz 7589
Korean 7579
Kurdish 7585
Laothian 7679
Latin 7665
Latvian, Lettish 7686
Language Code
Lingala 7678
Lithuanian 7684
Macedonian 7775
Malagasy 7771
Malay 7783
Malayalam 7776
Maltese 7784
Maori 7773
Marathi 7782
Moldavian 7779
Mongolian 7778
Nauru 7865
Nepali 7869
Norwegian 7879
Oriya 7982
Panjabi 8065
Pashto, Pushto 8083
Persian 7065
Polish 8076
Portuguese 8084
Quechua 8185
Rhaeto-Romance 8277
Rumanian 8279
Russian 8285
Samoan 8377
Sanskrit 8365
Scots Gaelic 7168
Serbian 8382
Serbo-Croatian 8372
Shona 8378
Sindhi 8368
Language Code
Singhalese 8373
Slovak 8375
Slovenian 8376
Somali 8379
Spanish 6983
Sudanese 8385
Swahili 8387
Swedish 8386
Tagalog 8476
Tajik 8471
Tamil 8465
Tatar 8484
Telugu 8469
Thai 8472
Tibetan 6679
Tigrinya 8473
Tonga 8479
Turkish 8482
Turkmen 8475
Twi 8487
Ukrainian 8575
Urdu 8582
Uzbek 8590
Vietnamese 8673
Volapük 8679
Welsh 6789
Wolof 8779
Xhosa 8872
Yiddish 7473
Yoruba 8979
Zulu 9085
20
ENGLISH FRANÇAIS ESPAÑOL ITALIANO DEUTSCH NEDERLANDS SVENSKA РУССКИЙ
