NAD C 446 User manual

®
C446
Digital Media Tuner
ENGLISHPORTUGUÊS FRANÇAISESPAÑOLITALIANODEUTSCHNEDERLANDSSVENSKAРУССКИЙ
Owner’s Manual
NAD

SAVE THESE INSTRUCTIONS FOR LATER USE.
FOLLOW ALL WARNINGS AND INSTRUCTIONS MARKED ON THE AUDIO
EQUIPMENT.
1 Read instructions - All the safety and operating instructions should be read
before the product is operated.
2 Retain instructions - The safety and operating instructions should be retained
for future reference.
3 Heed Warnings - All warnings on the product and in the operating instructions
should be adhered to.
4 Follow Instructions - All operating and use instructions should be followed.
5 Cleaning - Unplug this product from the wall outlet before cleaning. Do not use
liquid cleaners or aerosol cleaners. Clean only with a dry cloth.
6 Attachments - Do not use attachments not recommended by the product
manufacturer as they may cause hazards.
7 Water and Moisture - Do not use this product near water-for example, near a
bath tub, wash bowl, kitchen sink, or laundry tub; in a wet basement; or near a
swimming pool; and the like.
8 Accessories - Do not place this product on an unstable cart, stand, tripod,
bracket, or table. The product may fall, causing serious injury to a child or adult,
and serious damage to the product. Use only with a cart, stand, tripod, bracket, or
table recommended by the manufacturer, or sold with the product. Any mounting
of the product should follow the manufacturer’s instructions, and should use a
mounting accessory recommended by the manufacturer.
9 A product and cart combination should be moved with care. Quick
stops, excessive force, and uneven surfaces may cause the product and
cart combination to overturn.
10 Ventilation - Slots and openings in the cabinet are provided for ventilation and
to ensure reliable operation of the product and to protect it from overheating, and
these openings must not be blocked or covered. The openings should never be
blocked by placing the product on a bed, sofa, rug, or other similar surface. This
product should not be placed in a built-in installation such as a bookcase or rack
unless proper ventilation is provided or the manufacturer’s instructions have been
adhered to.
11 Power Sources - This product should be operated only from the type of power
source indicated on the marking label. If you are not sure of the type of power
supply to your home, consult your product dealer or local power company. The
primary method of isolating the amplier from the mains supply is to disconnect
the mains plug. Ensure that the mains plug remains accessible at all times. Unplug
the AC power cord from the AC outlet if the unit will not be used for several
months or more.
12 Grounding or Polarization - This product may be equipped with a polarized
alternating current line plug (a plug having one blade wider than the other). This
plug will t into the power outlet only one way. This is a safety feature. If you are
unable to insert the plug fully into the outlet, try reversing the plug. If the plug
should still fail to t, contact your electrician to replace your obsolete outlet. Do
not defeat the safety purpose of the polarized plug.
13 Power Cord Protection - Power supply cords should be routed so that they
are not likely to be walked on or pinched by items placed upon or against them,
paying particular attention to cords at plugs, convenience receptacles, and the
point where they exit from the product.
14 Outdoor Antenna Grounding - If an outside antenna or cable system is
connected to the product, be sure the antenna or cable system is grounded so
as to provide some protection against voltage surges and built-up static charges.
Article 810 of the National Electrical Code, ANSI/NFPA 70, provides information
with regard to proper grounding of the mast and supporting structure, grounding
of the lead-in wire to an antenna discharge unit, size of grounding conductors,
location of antenna discharge unit, connection to grounding electrodes, and
requirements for the grounding electrode.
NOTE TO CATV SYSTEM INSTALLER
This reminder is provided to call the CATV system installer’s attention to Section 820-40 of
the NEC which provides guidelines for proper grounding and, in particular, species that
the cable ground shall be connected to the grounding system of the building, as close to
the point of cable entry as practical.
15 Lightning - For added protection for this product during a lightning storm, or
when it is left unattended and unused for long periods of time, unplug it from the
wall outlet and disconnect the antenna or cable system. This will prevent damage
to the product due to lightning and power line surges.
16 Power Lines - An outside antenna system should not be located in the vicinity
of overhead power lines or other electric light or power circuits, or where it can
fall into such power lines or circuits. When installing an outside antenna system,
extreme care should be taken to keep from touching such power lines or circuits
as contact with them might be fatal.
17 Overloading - Do not overload wall outlets, extension cords, or integral
convenience receptacles as this can result in a risk of re or electric shock.
18 Object and Liquid Entry - Never push objects of any kind into this product
through openings as they may touch dangerous voltage points or short-out parts
that could result in a re or electric shock. Never spill liquid of any kind on the
product.
WARNING: THE APPARATUS SHOULD NOT BE EXPOSED TO DRIPPING
OR SPLASHING, AND OBJECTS FILLED WITH LIQUIDS, SUCH AS VASES,
SHOULD NOT BE PLACED ON THE APPARATUS. AS WITH ANY ELECTRONIC
PRODUCTS, USE CARE NOT TO SPILL LIQUIDS INTO ANY PART OF THE
SYSTEM. LIQUIDS CAN CAUSE A FAILURE AND/OR A FIRE HAZARD.
19 Damage Requiring Service - Unplug this product from the wall outlet and refer
servicing to qualied service personnel under the following conditions:
a) When the power supply cord or plug is damaged.
b) If liquid has been spilled, or objects have fallen into the product.
c) If the product has been exposed to rain or water.
d) If the product does not operate normally by following the operating
instructions. Adjust only those controls that are covered by the operating
instructions as an improper adjustment of other controls may result in
damage and will often require extensive work by a qualied technician to
restore the product to its normal operation.
e) If the product has been dropped or damaged in any way.
f) when the product exhibits a distinct change in performance-this indicates a
need for service.
20 Replacement Parts - When replacement parts are required, be sure the
service technician has used replacement parts specified by the manufacturer
or have the same characteristics as the original part. Unauthorized
substitutions may result in fire, electric shock, or other hazards.
21 Safety Check - Upon completion of any service or repairs to this product, ask the
service technician to perform safety checks to determine that the product is in
proper operating condition.
IMPORTANT SAFETY INSTRUCTIONS
2
ENGLISH PORTUGUÊSFRANÇAIS ESPAÑOL ITALIANO DEUTSCH NEDERLANDS SVENSKA РУССКИЙ

22 Wall or Ceiling Mounting - The product should be mounted to a wall or ceiling
only as recommended by the manufacturer.
23 Heat - The product should be situated away from heat sources such as radiators,
heat registers, stoves or other products (including ampliers) that produce heat.
24 Headphones - Excessive sound pressure form earphones and headphones can
cause hearing loss.
25 Battery Disposal - When disposing of used batteries, please comply with
governmental regulations or environmental public instruction’s rules that apply
in your country or area. Batteries (battery pack or batteries installed) must not be
exposed to excessive heat such as sunshine, re or the like.
CAUTION
Danger of explosion if battery is incorrectly replaced.
Replace only with the same or equivalent type.
WARNING
TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS PRODUCT TO
RAIN OR MOISTURE.
CAUTION
TO PREVENT ELECTRIC SHOCK, MATCH WIDE BLADE OF PLUG TO WIDE SLOT, FULLY
INSERT.
THE LIGHTNING FLASH WITH ARROWHEAD SYMBOL, WITHIN AN
EQUILATERAL TRIANGLE, IS INTENDED TO ALERT THE USER TO THE
PRESENCE OF UNINSULATED “DANGEROUS VOLTAGE”WITHIN THE
PRODUCT’S ENCLOSURE THAT MAYBE OF SUFFICIENT MAGNITUDE TO
CONSTITUTE A RISK OF ELECTRIC SHOCK TO PERSONS.
THE EXCLAMATION POINT WITHIN AN EQUILATERAL TRIANGLE IS INTENDED
TO ALERT THE USER TO THE PRESENCE OF IMPORTANT OPERATING
AND MAINTENANCE (SERVICING) INSTRUCTIONS IN THE LITERATURE
ACCOMPANYING THE APPLIANCE.
THE EQUIPMENT MUST BE CONNECTED TO AN EARTHED MAINS SOCKET-OUTLET.
The mains plug of the apparatus should be easily accessible or free from any
obstruction during intended use.
RF EXPOSURE STATEMENT
The antenna(s) used for this transmitter must be installed to provide a separation
distance of at least 20 cm from all persons and must not be located or operated in
conjunction with any antenna or transmitter other than those contained in this device.
CAUTION
Changes or modications to this equipment not expressly approved by NAD
Electronics for compliance could void the user’s authority to operate this equipment.
CAUTION REGARDING PLACEMENT
To maintain proper ventilation, be sure to leave a space around the unit (from the largest
outer dimensions including projections) that is equal to or greater than shown below.
Left and Right Panels: 10 cm
Rear Panel: 10 cm
Top Panel: 50 cm
NOTES ON ENVIRONMENTAL PROTECTION
At the end of its useful life, this product must not be disposed of with
regular household waste but must be returned to a collection point for
the recycling of electrical and electronic equipment. The symbol on the
product, user’s manual and packaging, point this out.
The materials can be reused in accordance with their markings.
Through re-use, recycling of raw materials or other forms of recycling of old products,
you are making an important contribution to the protection of our environment. Your
local administrative oce can advise you of the responsible waste disposal point.
INFORMATION ABOUT COLLECTION AND DISPOSAL OF WASTE BATTERIES
DIRECTIVE 2006/66/EC OF THE EUROPEAN PARLIAMENT AND THE COUNCIL
OF EUROPEAN UNION FOR EUROPEAN CUSTOMERS ONLY
Batteries bearing any of these symbols indicate that
they should be treated as“separate collection”and not
as municipal waste. It is encouraged that necessary
measures are implemented to maximize the separate
collection of waste batteries and to minimize the disposal
of batteries as mixed municipal waste.
End-users are exhorted not to dispose waste batteries
as unsorted municipal waste. In order to achieve a high
level of recycling waste batteries, discard waste batteries
separately and properly through an accessible collection point in your vicinity. For
more information about collection and recycling of waste batteries, please contact
your local municipality, your waste disposal service or the point of sale where you
purchased the items.
By ensuring compliance and conformance to proper disposal of waste batteries,
potential hazardous eects on human health is prevented and the negative impact of
batteries and waste batteries on the environment is minimized, thus contributing to
the protection, preservation and quality improvement of the environment.
NOTE: THE C 446 IS NOT AN AUTO VOLTAGE UNIT. CONNECT ONLY TO THE
PRESCRIBED AC OUTLET, I.E., 120V 60HZ OR 230V 50HZ.
RECORD YOUR MODEL NUMBER NOW, WHILE YOU CAN SEE IT
The model and serial number of your new C 446 are located on the back of the
cabinet. For your future convenience, we suggest that you record these numbers here:
Model no: ......................................
Serial no.: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
IMPORTANT SAFETY INSTRUCTIONS
NAD is a trademark of NAD Electronics International, a division of Lenbrook Industries Limited
Copyright 2011, NAD Electronics International, a division of Lenbrook Industries Limited
3
ENGLISHPORTUGUÊS FRANÇAISESPAÑOLITALIANODEUTSCHNEDERLANDSSVENSKAРУССКИЙ

THANK YOU FOR CHOOSING NAD.
The C 446 Digital Media Tuner is NAD’s answer to connecting the past,
present and future by combining the best of analog and digital broadcast
technology. Along with NAD’s tried and true high performance analog
tuner for the FM and AM bands, the C 446 takes advantage of the latest
frontier in music broadcasting by allowing connection to thousands of free
audio broadcast service transmitted over the internet.
Through C 446, you get to enjoy various available radio stations from
dierent parts of the world in real time and without the use of a computer.
The C 446 takes the computer out of the equation and can be connected
directly to the internet using wireless or wired connection.
Aside from Internet radio and FM and AM radio in their native analog
format or as a decoded S/PDIF digital output, the C 446 also features the
following
•built-in DAB+ radio (230V version model only)
•support for the music recommendation streaming service Last.fm
•browse and playback audio content from your computer via uPnP
(Universal Plug and Play) media sharing
•USB connectivity to playback music les in AAC, MP3, WMA, WAV and
FLAC format
•NAD IPD Dock for iPod (NAD IPD) control and connectivity
•analog stereo line level output or S/PDIF digital audio output
As with all our products, NAD’s “Music First”design philosophy guided the
C 446’s design, such that it can condently promise you both state-of-the-
art and audiophile-quality music listening for years to come.
We encourage you to take a few minutes now to read right through this
manual. Investing a little time here at the outset might save you a good
deal of time later, and is by far the best way to ensure that you make the
most of your investment in the C 446.
One more thing: We urge you to register your C 446 ownership on the NAD
Worldwide Web site:
http://NADelectronics.com
For warranty information contact your local distributor.
INTRODUCTION
TABLE OF CONTENTS
IMPORTANT SAFETY INSTRUCTIONS .........................2
INTRODUCTION
GETTING STARTED ...............................................5
WHAT’S IN THE BOX ..................................................5
CHOOSING A LOCATION .............................................5
RESTORING C 446 TO ITS FACTORY DEFAULT SETTINGS...............5
NOTICE TO EUROPEAN CUSTOMERS .................................5
IDENTIFICATION OF CONTROLS
FRONT PANEL....................................................6
REAR PANEL .....................................................7
TNR 2 REMOTE CONTROL.........................................9
SETUP
SETTING UP THE C 446 ..........................................10
OUT OF THE BOX ................................................... 10
NETWORK SETUP .................................................. 10
TEXT/CHARACTER ENTRY .......................................... 11
SELECTING SOURCES............................................... 11
SETTINGS MENU ................................................... 11
OPERATION
USING THE C 446 – INTERNET RADIO.............................12
MY FAVOURITES .................................................... 12
LOCAL AREA ....................................................... 12
STATIONS........................................................... 12
PODCASTS ......................................................... 12
MY ADDED STATIONS .............................................. 12
HELP ............................................................... 12
USING THE C 446 – OTHER SOURCES.............................13
UPnP CLIENT ....................................................... 13
UPnP RECEIVER ..................................................... 13
LAST.FM ............................................................ 13
USB................................................................. 14
IPOD ............................................................... 14
LISTENING TO AM/FM RADIO ....................................15
STORING PRESETS AM/FM/DAB................................... 15
CHOOSING THE TUNER MODE...................................... 15
ABOUT USER NAMES ............................................... 15
ABOUT RDS ........................................................ 16
LISTENING TO DAB RADIO.......................................17
DAB OPERATION ................................................... 17
DAB SETUP MENU.................................................. 17
STATION ORDER .................................................... 17
MANUAL SCAN..................................................... 18
PRUNE LIST......................................................... 18
RESET SETTINGS.................................................... 18
INFORMATION SETTINGS........................................... 18
REFERENCE
TROUBLESHOOTING ............................................19
SPECIFICATIONS ................................................20
NAD SHALL NOT BE HELD LIABLE FOR ANY TECHNICAL OR USER INTERFACE DISCREPANCIES IN THIS MANUAL.
THE C 446 OWNER’S MANUAL MAY BE SUBJECT TO CHANGE WITHOUT PRIOR NOTICE. CHECK OUT THE NAD WEBSITE FOR THE LATEST
VERSION OF THE C 446 OWNER’S MANUAL.
4
ENGLISH PORTUGUÊSFRANÇAIS ESPAÑOL ITALIANO DEUTSCH NEDERLANDS SVENSKA РУССКИЙ

INTRODUCTION
GETTING STARTED
WHAT’S IN THE BOX
Packed with your C 446 you will nd
•AM loop antenna
•FM ribbon-wire antenna with balun
•Wireless antenna
•DAB antenna (230V version model only)
•Detachable mains power cord
•TNR 2 remote control with 2 AA batteries
•Quick Start guide
SAVE THE PACKAGING
Please save the box and all of the packaging in which your C 446 arrived.
Should you move or otherwise need to transport your C 446, this is by far
the safest container in which to do so. We’ve seen too many otherwise
perfect components damaged in transit for lack of a proper shipping
carton, so please: Save that box!
CHOOSING A LOCATION
Choose a location that is well ventilated (with at least several inches to both
sides and behind), and that will provide a clear line of sight, within 25 feet/8
meters, between the C 446’s front panel and your primary listening/viewing
position - this will ensure reliable infrared remote control communications.
The C 446 generates a modest amount of heat, but nothing that should
trouble adjacent components. It is especially important that sucient
ventilation be provided.
RESTORING C 446TO ITS FACTORY DEFAULT SETTINGS
Sometimes power spikes and drop-outs may from time to time cause some
inadvertent functionality. The procedure below will reset the C 446 to its
factory default settings.
For 120V version model only (AH version)
•At any Source modes, press and hold front panel [3 SOURCE] button
rst and then followed by the [BACK] button. The VFD shows
For 230V version model only (C version)
•At any Source modes, press and hold front panel [3 SOURCE] button
rst and then followed by the [SETUP] button. The VFD shows
IMPORTANT NOTES
• TheC446willautomaticallygotostandbymodeafterthe“reset”
display.
• RestoringtheC446toitsfactorydefaultsettingswilldeleteallAM,
FMandDABpresetsaswellasallsetupsettingsdoneviathe“Settings
Menu”.
NOTICETO EUROPEAN CUSTOMERS
The C 446 may be operated in the following countries:
Armenia Greece Portugal
Austria Hungary Romania
Belarus Iceland Russia
Belgium Ireland Serbia & Montenegro
Bulgaria Italy Slovakia
Croatia Latvia Slovenia
Cyprus Lithuania Spain
Czech Republic Luxembourg Sweden
Denmark Macedonia Switzerland
Estonia Malta Turkey
Finland Moldova Ukraine
France The Netherlands United Kingdom
Georgia Norway
Germany Poland
EU COUNTRY RESTRICTION IN 2.4GHZ BAND
This device may be used indoors or outdoors in all countries of the
European Community using the 2.4GHz band: Channel 1-13, except where
noted below.
• In France, the output power is restricted to 10 mW EIRP when the
product is used outdoors in the band 2454 - 2483.5 MHz. There are no
restrictions when used in other parts of the 2.4 GHz band.
AH Reset...
complete.
C Reset...
complete.
5
ENGLISHPORTUGUÊS FRANÇAISESPAÑOLITALIANODEUTSCHNEDERLANDSSVENSKAРУССКИЙ

IDENTIFICATION OF CONTROLS
FRONT PANEL
1 STANDBY BUTTON
•The rear panel POWER switch must be at ON position for the
Standby button to activate.
•Press this button to switch ON the C 446 from standby mode. The
Standby LED indicator will turn from amber to blue and illuminate
the VFD. Pressing the STANDBY button again turns the unit back to
standby mode.
•The C 446 will wake up to the last Source used prior to standby
mode.
2 STANDBY LED
•This indicator will light up amber when the C 446 is at standby
mode.
•When the C 446 is powered up from standby mode, this indicator
will illuminate blue.
3 tSOURCE u
•Select through Source modes.
•Press these buttons to toggle through the Source selections -
Internet Radio, UPnP Client, UPnP Receiver, Last.FM, USB, iPod, AM,
FM and DAB (230V version model only).
4 PLAY/PAUSE
• Toggle to activate playback or pause of applicable source.
• PLAY/PAUSE is applicable only for playback or pause of USB les, the
docked iPod player and UPnP media.
• Pressing [PLAY/PAUSE] while at Internet Radio mode will cause the
broadcast to stop. Press [PLAY/PAUSE] again to resume broadcast at
current time.
5 INFO
•Show information as supplied by the applicable source.
•INFO feature is applicable only for USB, DAB and Internet Radio.
Toggle [INFO] button to display supplied information.
6 REMOTE SENSOR
•Point the TNR 2 remote control at the remote sensor and press the
buttons.
•Do not expose the remote sensor of the C 446 to a strong light
source such as direct sunlight or illumination. If you do so, you may
not be able to operate the C 446 with the remote control.
Distance: About 23ft (7m) from the front of the remote sensor.
Angle: About 30° in each direction of the front of the remote sensor.
7 VACUUM FLUORESCENT DISPLAY (VFD)
Display visual information about the current Source. Information
supplied is generated by the Source.
8 USB
•Connect a USB memory stick to this input.
•Refer also to the item about USB at the USING THE C 446 – OTHER
SOURCES section of the OPERATION page.
9 SETUP
•Activate and display“Settings Menu”.
•SETUP button can be pressed at any Source mode;“Settings Menu”
is activated each time.
10 BACK
• Return to previous display.
• Repeatedly press [BACK] to return back to a“page” or menu one at a
time.
• During character entry of password or user name, press [BACK] to
delete current character.
11 CONTROL/ENTER
• Dual-function control knob.
• Rotate to select through menu or item list.
• Rotate to select alphanumeric characters for text/character entry as
required by a menu item.
• Press to select item, start playback of a le or complete character
entry (for password and user name).
Internet Radio
Magic 89.9
Playing
© NAD C 446
Digital Media Tuner C 446
SOURCE PLAY/PAUSE INFO SETUP BACK
CONTROL/ENTER
3 4 5 6 7 8 9 101 2 11
6
ENGLISH PORTUGUÊSFRANÇAIS ESPAÑOL ITALIANO DEUTSCH NEDERLANDS SVENSKA РУССКИЙ

1 FM ANTENNA TERMINAL
•Connect the supplied wire“dipole”FM antenna to the FM antenna
terminal using the supplied “balun”adapter. It will usually work best
when mounted on a vertical surface such as a wall, with arms fully
outstretched forming a horizontal“T” perpendicular to the origin
point of the signal.
AM ANTENNA TERMINAL
The AM loop antenna supplied with the C 446 (or a suitable
replacement) is required for AM reception.
•Connect the supplied AM loop antenna to these terminals. If an
external AM antenna is used, make connections to the AM and GND
terminals in accordance with the instructions supplied with the
antenna.
•Testing dierent positions for the antenna may improve reception;
vertical orientation will usually produce the best results. Antenna
proximity to large metal objects (appliances, radiators) may impair
reception, as well as attempts to lengthen the wire to the loop.
•Refer also to the item about ASSEMBLING THE LOOP ANTENNA at
the LISTENING TO AM/FM RADIO section of the OPERATION page.
2 DAB ANTENNA TERMINAL (230V version model only)
•Install the supplied DAB antenna into this DAB terminal.
•With DAB, you can receive CD-like quality programs without any
annoying interference and signal distortion.
•Refer also to the“LISTENING TO DAB RADIO”segment of the
“OPERATION” section.
3 AUDIO OUT
Connect to the corresponding analog audio input of an amplier,
receiver or stereo system.
4 DIGITAL OUT
Using an optical cable (TOSLINK connector), connect DIGITAL OUT to
the corresponding digital audio input of receivers or digital processors.
5 LOCAL AREA NETWORK (LAN) PORT
•LAN connection must be setup for Wired connection to be
established. Set up a Wired Ethernet broadband router with
broadband internet connection.
•Using a standard straight-through Ethernet cable (not supplied),
connect one end of the Ethernet cable to the LAN port of your wired
Ethernet broadband router and the other end to C 446’s LAN port.
NOTES
•NADisnotresponsibleforanymalfunctionoftheC446and/orthe
internetconnectionduetocommunicationerrorsormalfunctions
associatedwithyourbroadbandinternetconnectionorotherconnected
equipment.ContactyourInternetServiceProvider(ISP)forassistanceor
theservicebureauofyourotherequipment.
•ContactyourISPforpolicies,charges,contentrestrictions,service
limitations,bandwidth,repairandotherrelatedissuespertinentto
internetconnectivity.
6 WIRELESS (WIFI) ANTENNA TERMINAL
•Install the supplied wireless antenna into this wireless antenna
terminal (WiFi).
•Wireless (WiFi) broadband router with broadband internet
connection is required for wireless connection to be established.
7 RS 232
NAD is a certied partner of AMX and Crestron and fully supports
these external devices. Check out the NAD website for information
about AMX and Crestron compatibility with NAD. See your NAD audio
specialist for more information.
•Connect this interface using RS-232 serial cable (not supplied) to
any Windows compatible PC to allow remote control of the C 446
via compatible external controllers.
8 MP DOCK
The C 446 is equipped with a data port in the rear panel where an
optional NAD IPD (NAD IPD Dock for iPod) 1, NAD IPD 2 and later
variants can be plugged in.
•Connect the “MP DOCK (DATA PORT)” jack of the C 446 to the
corresponding“DATA PORT” socket of the optional NAD IPD model.
•Connection between the C 446 and NAD IPD is only via their
respective DATA PORT. NAD IPD audio and S-Video port connections
should be directed to the external device’s corresponding input
ports (assigned for NAD IPD).
NOTE
TheNADIPDDockforiPodisnotsuppliedwithyourC446.
IDENTIFICATION OF CONTROLS
REAR PANEL
© NAD C 446
FM
ANTENNA
GND AM
DAB
AUDIO OUT
DIGITAL OUT
LAN RS232
MP DOCK
+12V
TRIGGER
IN
POWER
100~240V – 50/60Hz
ON
IR IN
DATA PORT
L
R
WIFI
3 4 5 6 7 8 9 11101 2 12
ATTENTION!
PleasemakesurethattheC446ispoweredoorunpluggedfromthemainspowersourcebeforemakinganyconnections.Itisalsoadvisabletopowerdown
orunplugallassociatedcomponentswhilemakingorbreakinganysignalorACpowerconnections.
7
ENGLISHPORTUGUÊS FRANÇAISESPAÑOLITALIANODEUTSCHNEDERLANDSSVENSKAРУССКИЙ

9 +12V TRIGGER IN
This input allows the C 446 to be switched remotely to standby mode
and ON by ancillary equipment, such as an amplier, preamplier,
receiver, etc. The controlling device must be equipped with a +12V
trigger output to use this feature. Connect this +12V Trigger input to
the remote device’s corresponding +12V DC output jack using a mono
cable with 3.5mm male plug.
10 IR IN
•This input is connected to the output of an IR (infrared) repeater
(Xantech or similar) or the IR output of another component to allow
control of the C 446 from a remote location.
11 POWER
•Supply the AC mains power to the C 446.
•When the POWER switch is set to ON position, the C 446 goes to
standby mode as shown by the amber status condition of the
Standby LED. Press the front panel Standby button or TNR 2 remote
control’s [ON] button to switch ON the C 446 from standby mode.
•If you intend not to use the C 446 for long periods of time (such as
when on vacation), switch o the POWER switch.
•With POWER switched o, neither the front panel Standby button
nor TNR 2 remote control’s [ON] button can activate the C 446.
12 AC MAINS INPUT
The C 446 comes supplied with a separate detachable mains power
cord. Before connecting the plug to the mains power source, ensure
that it is rmly connected to the C 446’s AC Mains input socket rst.
•Connect only to the prescribed AC outlet, i.e., 120V 60 Hz (120V
version model only) or 230V 50 Hz (230V version model only).
•Always disconnect the mains power plug from the mains power
source rst, before disconnecting the cable from the C 446’s AC
Mains input socket.
IDENTIFICATION OF CONTROLS
REAR PANEL
8
ENGLISH PORTUGUÊSFRANÇAIS ESPAÑOL ITALIANO DEUTSCH NEDERLANDS SVENSKA РУССКИЙ

1 ON: Switch ON C 446 from standby mode.
OFF: Switch C 446 to standby mode.
2 FM MUTE: Activate or deactivate FM Mute Stereo at FM mode.
MEM: Save current station to a Preset number.
DEL: Delete selected Preset number.
SETUP: Bring up Settings Menu.
3 SHUF: Play les, folders, songs and albums in random order, as applicable.
RPT: Repeat playback of les, folders, songs and albums, as applicable.
l:At Last.fm mode,“Love”or recommend current track.
4 INFO: Show information as supplied by the applicable source.
SLEEP: Switch o C 446 and go to standby mode after a preset number of minutes.
x:At Last.fm mode,“Ban” or do not recommend current track.
5 3SOURCE 4: Select through Source modes.
6 A/S/D/F, ENTER: Use to navigate and select a menu or item in a menu. Use [D/F]for text
or character entry in user name or password setup. Use [A/S/D/F] for text or character entry in
renaming of AM/FM Presets. Use [A/S] to move back to the previous menu/item or forward to the
next menu/item.
7 MENU: Bring up menu in Last.fm, USB or iPod source. Use [MENU] button also to bring up previous
menu.
8 [g]: Stop playback.
[;]: Pause playback temporarily.
[0]: Go to next le.
[9]: Go to the beginning of current or previous le.
[u]: Start playback.
[7/8]: Fast reverse/forward search.
9 NUMERIC KEYS: Use for direct entry of le number, frequency or preset number.
IDENTIFICATION OF CONTROLS
TNR 2 REMOTE CONTROL
1
4
5
6
8
7
9
2
3
9
ENGLISHPORTUGUÊS FRANÇAISESPAÑOLITALIANODEUTSCHNEDERLANDSSVENSKAРУССКИЙ

OUT OF THE BOX
Unpack all the contents of the C 446 package. Refer to the previous section
“What’s in the box” to conrm the contents. For a quick guide on how to set
up your C 446, refer to the enclosed “C 446 Digital Media Tuner Quick Start
Guide”.
It is important that you check out rst the C 446 Quick Start Guide;
follow the guidelines as the details are necessary to start up your
C 446. A video presentation of the C 446 Setup procedure is also available
from the NAD website.
Make the connections as per detailed in the Quick Start guide. Upon
completing all the requisite connections, undertake the necessary setup
procedure for each of the Source modes.
NETWORK SETUP
When you switch ON the C 446 for the rst time, the VFD will show
This is the default mode when there is no network connection set up.
Press [SETUP] to bring up“Settings Menu”. Press [ENTER] or [S] to select
“Network Setup”.
There are ve menu items under NETWORK SETUP.
WIRELESS SETUP
•View Networks: List available wireless network in your area of
coverage.
•Connect WPS: Congure wireless security automatically. If your
wireless router supports WPS (WiFi Protected Setup), press your router’s
WPS button within 2 minutes of selecting“Connect WPS”.
•Set Region: Select the region where wireless connection is setup.
INTERFACE
Before setting up your network connection, ensure that the following are
already established and available
•broadband internet connection
•wireless (WiFi) broadband router
•wired Ethernet broadband router
Wired
Network connection using Ethernet broadband connection. The C 446
is defaulted to“Wired”setup. It is advisable that wired connection is
utilized when possible. Wired connection is less likely to have“drop-out”
or range problem and not vulnerable to interference or eavesdropping.
Using a standard straight-through Ethernet cable (not supplied),
connect one end of the Ethernet cable to the LAN port of your wired
Ethernet broadband router and the other end to C 446’s LAN port.
Wireless
Network connection using WiFi broadband connection. Ensure that
the supplied wireless antenna is installed in the C 446 rear panel’s
wireless antenna terminal (WiFi) before setting up the wireless network
connection of your C 446.
If you prefer“Wireless”connection instead of“Wired”, follow the steps
provided in the“INTERNET RADIO – WIRELESS SETUP” section of the C 446
Digital Media Tuner Quick Start Guide.
STATUS
Display status of current network connection. The following are the status
information.
Wireless connection: Network name, IP (Internet Protocol) address and
RSSI (Received Signal Strength Indicator).
Wired connection: IP (Internet Protocol) address
If the connection is failed or not available, “Setup Failed”or “Link Down”is
shown.
WIRELESS MAC
Display your C 446’s MAC wireless address.
WIRED MAC
Display your C 446’s MAC local area network address.
Internet Radio
Check Network Setup
Network Setup
Wireless Setup
}Interface
Status
Network Interface
`Wireless
}~Wired
SETUP
SETTING UP THE C 446
10
ENGLISH PORTUGUÊSFRANÇAIS ESPAÑOL ITALIANO DEUTSCH NEDERLANDS SVENSKA РУССКИЙ

TEXT/CHARACTER ENTRY
When entering a text or character as required by a menu item, the
following buttons can be used.
FRONT PANEL BUTTONS OR KNOB
CONTROL/ENTER: Rotate to select alphanumeric characters for text/
character entry.
CONTROL/ENTER: Press to end and complete text/character entry.
[SOURCE4]: Press to select text/character and move on to the next
text/character entry.
[3SOURCE]: Press to go back to previous text/character.
TNR 2 REMOTE CONTROL BUTTONS
[D/F]: Toggle to select alphanumeric characters for text/character entry.
ENTER: Press to end and complete text/character entry.
[S]: Press to select text/character and move on to the next text/
character entry.
[A]: Press to go back to previous text/character.
IMPORTANT NOTE ABOUT PASSWORD/USER NAME ENTRY
 Rightafterenteringthelastcharacterofyourpasswordorusername,press
[ENTER]buttonimmediatelytocompletepasswordorusernameentry.
SELECTING SOURCES
Toggle TNR 2 or front panel’s [3SOURCE 4] buttons to step through the
following Source modes. Stop (release button) when your desired Source
comes up.
Internet Radio $ UPnP Client $ UPnP Receiver $ Last.fm $ USB $ iPod
$ AM $ FM $ DAB (230V version model only) $ then back to Internet
Radio
SETTINGS MENU
At any source mode, [SETUP] button can be pressed to bring up the
“Settings Menu”. Aside from Network Setup, DAB Setup and Last.FM Setup
which are discussed separately in their respective associated source modes,
the“Settings Menu”also features the following
· Display Brightness
· Digital Level
· System Info
DISPLAY BRIGHTNESS
Select “Dimmed” to reduce brightness of the display or “Bright” for normal
display brightness.
DIGITAL LEVEL APPLICABLE ONLY AT INTERNET RADIO MODE
Select “Digital Level”to attenuate output level by -3dB or -6dB. The default
level is 0dB.
SYSTEM INFO
Select to display current C446 system information.
Enter Password
_
{Source} = Next/Prev
{Scroll} = Edit Char
Settings Menu
}Display Brightness
Digital Level
System Info
Display Brightness
}~Bright
`Dimmed
Settings Menu
Display Brightness
}Digital Level
System Info
Digital Level
}~ 0dB
` -3dB
` -6dB
Settings Menu
Display Brightness
Digital Level
}System Info
SETUP
SETTING UP THE C 446
11
ENGLISHPORTUGUÊS FRANÇAISESPAÑOLITALIANODEUTSCHNEDERLANDSSVENSKAРУССКИЙ

Internet Radio is the default Source mode of the C 446. With an established
network connection, the C 446 paves the way for you to tune in and listen
to internet radio services across various parts of the world. Internet Radio
allows you to search and browse your favourite music station, genres
among others categories.
When Internet Radio is selected rst time, the following menu options are
displayed
•My Favourites
•Local area
•Stations
•Podcasts
•My Added Stations
•Help
MY FAVOURITES
Internet Radio stations can be stored in the menu item “My Favourites”.
There are two ways on how to store your desired internet radio stations –
via the NAD Electronics WiFi Radio Portal or using the TNR 2 remote control.
NAD ELECTRONICS WIFI RADIO PORTAL
The Internet Radio section of the C 446 is linked to the NAD Electronics WiFi
Radio Portal at
http://vtuner.nadelectronics.com.
The NAD Radio Portal will help organize your listening by creating a list
of your favourite internet radio stations. The stations you pick will be
immediately displayed in the“My Favourites”area of the home page and
accessible through your C 446.

The NAD radio portal also allows you to suggest a station that is not
currently promoted. Click“Suggest a station”and enter the requisite
information like Station name, Station Website, Location, Station URL
among others.
The NAD radio portal provides also a communication channel for your
questions and comments.
Create an Account
•Create an account at http://vtuner.nadelectronics.com. Click“Register
here” to start o your registration.
•An access code is required to register at the NAD radio portal.
•Your C 446 access code can be found at the“Get access code”item in
the“Help”menu.
Add or remove station at “My Favourites”via NAD Radio Portal
Once an account is created, you can start browsing for internet radio
stations as you would do with a C 446.
•To add a station in “My Favourites”, click the“l+”icon beside the Station
Name. A new window will open where one can either create a new
favourites group or add to an existing favourites group.
•To remove a station in “My Favourites”, click the “l-” icon beside the
Station Name.
USING TNR 2 REMOTE CONTROL
The [MEM] and [DEL] buttons of the TNR 2 can also be used to add or
remove a station from “My Favourites”menu.
Add or remove station at “My Favourites”
•To add a station in “My Favourites”, press [MEM] while playing a station
or during a display list of stations.“Favourite Added”is shown in the
lower line of the display upon successful addition of desired station.
•To remove a station in “My Favourites”, select the station from the “My
Favourites”list and then press and hold [DEL] until “Favourite Removed”
is shown in the lower line of the display.
LOCAL AREA
Normally,“Local Area” should be displayed as “Local Canada”, “Local Australia”
or any other applicable country, state, province or locality. Local area is
determined by the IP address of your network connection. This allows faster
access to stations local to your area thus avoiding going through searching
by Location.
STATIONS
Search radio stations by Location, Genre, Search stations, Popular stations or
New stations.
Location: Search stations by geographical location including selection
by country.
Genre: Select stations by type of programming like Blues, Classical,
Country and other classes.
Search stations: Direct input of desired station name.
Popular stations: Search from a list of most popular stations.
New stations: Select newly listed stations.
PODCASTS
Podcasts are recordings of a various media like audio broadcasts that are
made available in the internet for download or listening. It allows you to
selectively listen to a program at any given time.
Just like in “Stations”above, Podcast program can be selected by Location,
Genre and Search podcasts.
MY ADDED STATIONS
List stations that you have requested via the NAD radio portal. These are
the stations successfully added in the NAD radio portal using the “Suggest
a station” option.
HELP
Select to nd your C 446 access code needed in registering at http://
vtuner.nadelectronics.com. The Help section also shows a couple of FAQ
(Frequently Asked Questions). Listen to the audio explanation of the
selected FAQ.
OPERATION
USING THE C 446  INTERNET RADIO
12
ENGLISH PORTUGUÊSFRANÇAIS ESPAÑOL ITALIANO DEUTSCH NEDERLANDS SVENSKA РУССКИЙ

UPnP CLIENT
The C446 utilizes UPnP (Universal Plug and Play) client to allow playback of
audio les stored in a home network such as a computer, NAS (network-
attached storage), Apple iOS device or Android phone.
The C 446 browses your UPnP server audio content over the local network.
It includes MP3, FLAC, WMA, WAV, and AAC codecs. The computer, NAS
or mobile devices on the network are all potential servers. In order to use
them as such, they each need to be set up to act as a UPnP server.
WINDOWS 7
Windows 7 has a built-in UPnP server. To enable it and other related
information, visit the following websites:
http://windows.microsoft.com/en-CA/windows7/Getting-started-with-
media-streaming
http://windows.microsoft.com/en-CA/windows7/Stream-your-media-to-
devices-and-computers-using-Windows-Media-Player
OTHER DEVICES AND OPERATING SYSTEMS
For other Windows versions, Linux or Mac computers, server software such
as“Twonky Server” can be downloaded and installed. Visit twonky.com for
more information.
For applicable Apple and Android devices, visit their stores or website for
information about applicable apps needed for them to act as UPnP servers.
The always-on NAS is an ideal device for storing and accessing music les.
When selecting a NAS, look for DLNA-certied unit that can also serve as a
Digital Media Server (DMS).
UPnP RECEIVER
Browsing one’s media collection is not limited anymore to the C 446. The
connection between the mobile device or computer and the C 446 is
more than accessing and browsing of media. In a local network, the UPnP
Receiver allows the streaming of your media collection from your computer
or handheld device to your C 446. The UPnP Receiver eectively transfers
control of the media to the user’s computer or handheld device.
With the C 446’s UPnP Digital Audio Renderer, browsing, creating playlists
and changing of songs are possible anywhere at home using a variety of
networked devices.
WINDOWS 7
Windows 7 Media player has a feature called “Play To”that allows users
to play media on their computer to other devices on their local network
including the NAD C446.
To enable it and other related information, visit the following websites:
http://windows.microsoft.com/en-CA/windows7/using-the-play-to-feature-
to-stream-media
http://windows.microsoft.com/en-CA/windows7/Stream-your-media-to-
devices-and-computers-using-Windows-Media-Player
OTHER DEVICES
For applicable Apple and Android devices, visit their stores or website for
information about applicable apps needed for them to allow control of
your media. Once the app is installed on the device, simply follow the setup
instructions.
LAST.FM
Last.fm is a music recommendation streaming service supported by C 446.
Last.fm oers a large number of music options. Go to www.last.fm to see
the programming available.
Last.fm is a pay per use service. An account must be setup at Last.fm to use the
service with the C 446. Once an account is set up, a user name and password
are provided. Use this information to set up Last.fm with the C 446.
UPnP Client
}NAD: LAB:
Twonky Server [HOME]
UPnP Receiver
Listening
Last.FM
Settings Menu
Network Setup
}Last.FM Setup
Display Brightness
Last.FM Setup
}User Name
Password
OPERATION
USING THE C 446  OTHER SOURCES
13
ENGLISHPORTUGUÊS FRANÇAISESPAÑOLITALIANODEUTSCHNEDERLANDSSVENSKAРУССКИЙ

USB
The C 446 can play back AAC, MP3, WMA, WAV or FLAC les stored on a USB
(Universal Serial Bus) memory stick. Connect the USB memory stick into the
front panel USB port.
When connected, the following keys on the TNR 2 remote control are
active:
[4], [j], [g], [7/8], [9/0], [MENU], [SHUF], [RPT]
Playback the les in your USB memory stick as prompted in the VFD or as
you would in normal USB playback.
The following are the C 446’s capabilities with respect to USB device
playability.
USB SUPPLEMENTARY INFORMATION
Maximum number of folders supported 128
Maximum le in one folder 511
Maximum le in device 65408
Maximum number of sub-directory 8
Maximum number of bytes supported for Folder/File name 64
Maximum number of bytes supported for ID3 Title/Artist/
Album 60
Maximum bit rate supported VBR, 320K
HDD handling capacity (additional power adapter maybe
required for some HDD models) FAT 16/32
USB version supported 1.1
iPod
The C 446 has a MP DOCK DATA PORT where a corresponding DATA PORT
from a NAD IPD Dock for iPod (NAD IPD) can be connected and interfaced.
This allows control of the NAD IPD via C 446.
Playback the les from your docked iPod as prompted in the VFD or as you
would when operating your iPod player independently.
When connected, the following keys on the TNR 2 remote control are
active:
[4], [j], [g], [7/8], [9/0], [MENU], [SHUF], [RPT]
These TNR 2 keys operate like their corresponding iPod player buttons or
function.
NOTES
•NADIPDandiPodplayerarenotsuppliedwithyourC446.
•iPodplayerfunctions,featuresandplaybackcapabilitiesaccessible
throughC446mayvarydependingonyouriPodplayermodel.
USB
Attached
iPod Display
iPod Connected
OPERATION
USING THE C 446  OTHER SOURCES
14
ENGLISH PORTUGUÊSFRANÇAIS ESPAÑOL ITALIANO DEUTSCH NEDERLANDS SVENSKA РУССКИЙ

The C 446’s internal AM/FM tuner oers very high quality sound from
radio broadcasts. You can listen to AM and FM stations either in their
native analog format or as a decoded SPDIF digital output. The reception
and sound quality will always be dependent to the type of antenna(s)
used as well as proximity to the broadcast origin, geography and weather
conditions.
ABOUT ANTENNAS
Connect the supplied wire“dipole”FM antenna to the FM antenna terminal
using the supplied“balun”adapter. It will usually work best when mounted
on a vertical surface such as a wall, with arms fully outstretched forming a
horizontal“T” perpendicular to the origin point of the signal.
In areas of poor FM reception, an exterior FM antenna can improve
performance dramatically. If radio listening is important to you, consider
consulting an antenna installation professional to optimize your system.
The supplied AM“loop”antenna will usually provide adequate reception.
However, an exterior AM antenna can be used to improve reception.
Consult an antenna professional for more information.
NOTE
 Unlessexplicitlyspecied,allcontrolbuttonsmentionedbelowarewith
referencetoTNR2remotecontrol.
ASSEMBLING THE LOOP ANTENNA
1 Rotate the outer frame of the antenna.
2 Insert the bottom edge of the outer frame into the groove on the stand.
3 Extend the antenna cord.
TUNING AM/FM STATIONS
Rotate the front panel [CONTROL/ENTER] or use TNR 2’s [A/S] to tune for
stations.
1 Press [A/S] momentarily to step up or down between AM or FM
frequencies.
2 Press and hold [A/S] for more than 2 seconds to search up or down
- the C 446’s tuner will stop at the next suciently strong signal it
encounters.
3 Pressing the [A/S] during the search process will stop the search.
DIRECT TUNING
If you know your desired station’s frequency allocation, you can tune
directly to the station.
1 Toggle [ENTER] button to switch between “Preset” and “Tune”mode (see
second line of the VFD). Select “Tune” mode.
2 Using the numeric keys of the remote control, key-in the frequency
allocation of the station. For example, to enter 104.50MHz, press “1”, “0”,
“4”, “5”and “0”.
STORING PRESETS (AM/FM/DAB)
The C 446 can store a mix of your 40 favorite AM, FM and DAB radio stations
for immediate recall.
1 To store a desired AM/FM station to a preset, rst tune to the desired
frequency (see above), then press TNR 2’s [MEM] button. The VFD will
show the next available Preset number – for example, “Preset 04 Free”.
If there is no more vacant Preset number, you can overwrite an existing
Preset number by pressing the [D/F] buttons to select the Preset
number you want to overwrite.
2 Press the [MEM] button again to store the desired frequency on the
Preset number shown. Your desired frequency is now stored in the
assigned preset.
DIRECT RECALL OF A PRESET NUMBER
You can directly recall a desired Preset number.
1 Toggle [ENTER] button to switch between “Preset” and “Tune”mode (see
second line of the VFD). Select “Preset”mode.
2 Using the numeric keys of the remote control, directly key-in your
desired Preset number. For example, to enter Preset 5, press “5”.
DELETING A STORED PRESET AM/FM/DAB
You can empty a preset by deleting the stored information.
1 Select the preset number to be deleted. For example,“P04”.
2 Press and hold [DEL] button until the current Preset number shown in
the VFD is extinguished (“P04 becomes “P--”.).
CHOOSING THE TUNER MODE
The TNR 2’s [FM MUTE] key is a dual-purpose control. Toggle [FM MUTE] to
switch between“FM Mute Stereo” and “Tuned”. In the normal position, “FM
Mute Stereo”, only the stations with strong signal can be listened to and the
noise between stations is muted.
Pressing the [FM MUTE] button again (“Tuned”) allows distant and
potentially noisy stations to be received. Noise is reduced if the FM
station signal level is less than the FM Stereo threshold (since mono FM is
inherently less noise-prone) though at the sacrice of the stereo eect.
ABOUT USER NAMES
A particular Preset number can be assigned a twelve-character“User
Name”. The assigned“User Name”will be shown in the VFD whenever the
associated Preset number is recalled.
ENTERING USER NAMES
To assign a Preset number with the user name“NEWS”, follow the procedure
as below.
1 Recall the desired Preset number to be assigned a “User Name”.
2 Then, press the [MEM] button once and within ve (5) seconds, press
the [INFO] button - the readout shows a blinking box.
3 Use the [D/F] buttons to select the rst character of the name (“N”
from the alphabetical list).
4 Press [S] button to select the character and correspondingly move
forward to the next position. (Press [A] to go back to the previous
character). Repeat this process for each character in sequence.
5 Press the [MEM] key again to store the User Name and exit the text-
entry mode.
OPERATION
LISTENING TO AM/FM RADIO
15
ENGLISHPORTUGUÊS FRANÇAISESPAÑOLITALIANODEUTSCHNEDERLANDSSVENSKAРУССКИЙ

ABOUT RDS
The Radio Data System (RDS) permits sending small amounts of digital
information using conventional FM radio broadcasts. The C 446 supports
two RDS modes, program-service name (PS mode) and radio-text (RT
mode). Not every FM station incorporates RDS in its broadcast signal. In
most areas you will nd from one to several RDS-enabled stations, but it is
by no means impossible that your favorite stations will not be broadcasting
RDS data.
When an RDS-enabled FM broadcast is tuned, the VFD will show its
program-service name (PS) text and the station’s radio-text (RT) readout,
if any, which might scroll song- or artist-name, or any other text of the
station’s choosing.
FM 103.50M P02
Stereo FM Mute
NAD Music First
High Performance
OPERATION
LISTENING TO AM/FM RADIO
16
ENGLISH PORTUGUÊSFRANÇAIS ESPAÑOL ITALIANO DEUTSCH NEDERLANDS SVENSKA РУССКИЙ

Until now, analogue radio signals such as FM or AM have been subject to
numerous kinds of interference on their way from the transmitter to your
radio. These problems were caused by mountains, high-rise buildings
and weather conditions. With Digital Audio Broadcast (DAB), you can now
receive CD-like quality radio programs without any annoying interference
and signal distortion. DAB broadcasts use digital signals rather than
traditional analogue transmissions, thus providing clear high quality
reception. You getfar more robust reception andvirtually hiss or crackle
freesound with DAB as long as you are withina good coverage area.
With DAB, the listener can scroll through a list of available stations - then
instantly tune to the station of his choice. There is no need either to
remember channel frequencies. All broadcasts are selected by simply
selecting the service name.
The C 446 makes it possible for you to enjoy listening to DAB+ broadcasts.
Connect the other end of the supplied DAB antenna into the DAB antenna
terminal and start enjoying the CD-like quality sound and expansive
content selection available with DAB.
IMPORTANT NOTES
•DABisapplicableonlyto230VversionmodelsofC446.
•Unlessexplicitlyspecied,allcontrolbuttonsmentionedbelowarewith
referencetoTNR2remotecontrol.
DAB OPERATION
With the supplied DAB antenna already connected, you can now carry out
the C 446 to receive DAB broadcasts.
1 Toggle [3SOURCE 4] button until DAB mode. When DAB mode is
selected, VFD will show
The above display indicates that there are no scanned DAB broadcast
services yet. This is the DAB default mode.
2 To tune to DAB broadcast services, press [SETUP] to bring up “Settings
Menu”and then use [D/F] to scroll to “DAB Setup”. Press [ENTER] or [S]
to select “DAB Setup”.
3 At“DAB Setup” menu, use [D/F] to scroll to“Full Scan”. Press [ENTER] or
[S] to select “Full Scan”.
Upon selecting “Full Scan”, automatic scanning will immediately ensue.
When scanning is completed, the total number of stations found will be
displayed.
4 Toggle [A] until the list of DAB stations is shown. Use [D/F] to scroll to
desired DAB station. Press [ENTER] or [S] to select desired DAB station.
NOTE
 “NoItems”willbeshownintheVFDwhennoDABstationsarefound
afterthescanningprocess.Ifthisoccurs,checktheconnectionand
positionoftheDABantennaorcallyourlocalDABbroadcastproviders
forcoverageinformation.
DAB SETUP MENU
Aside from“Full Scan”as already described above,“DAB Setup” menu will
also present you with other options namely - Station Order, Manual Scan,
Prune List and Reset Settings.
STATION ORDER
Use“Station Order”to sort the sequence of the listed stations. There are
three orders – Alphanumeric, Ensemble and Active.
1 While listening to a DAB broadcast, select“Station Order”from“DAB
Setup”menu.
2 At“Station Order” menu, use [D/F] to select “Alphanumeric”,
“Ensemble”or “Active”.
3 Press [ENTER] to select desired station order.
ALPHANUMERIC
This is the default setting. Stations are arranged by numbers rst and then
alphabetically by letters.
ENSEMBLE
Digital radio is broadcast as groups of data called ensemble. Each ensemble
contains a number of stations, transmitted at a set frequency. When
“Ensemble”is selected as the mode of station order, the radio stations are
arranged in the order of their ensemble names.
NOTE
 Ensembleisalsointerchangeablytermedas“multiplex”byother
broadcastproviders.
ACTIVE
Active stations are listed at the top of the broadcast list. DAB broadcasts
that are in the list but have no service in the area will be displayed last in
the broadcast list.
DAB
No Items
Settings Menu
Network Setup
}DAB Setup
Last.FM Setup
DAB Setup
Station Order
}Full Scan
Manual Scan
Station Order
}~Alphanumeric
`Ensemble
`Active
OPERATION
LISTENING TO DAB RADIO
17
ENGLISHPORTUGUÊS FRANÇAISESPAÑOLITALIANODEUTSCHNEDERLANDSSVENSKAРУССКИЙ

MANUAL SCAN
This option allows you to manually tune to a desired DAB broadcast and
include it in the service list (if not yet available at the time). You can also
use MANUAL SCAN to assist you in positioning the DAB antenna for best
reception of the desired DAB broadcast.
1 While listening to a DAB broadcast, select“Manual Scan”from “DAB
Setup”menu.
2 To select other channels, toggle [A/S] to step through the channel list.
Release [A/S] when you have arrived at your desired channel.
NOTE
 Thenumberofensemblesandstationsthatcouldbescannedwillvary
dependinguponyourlocation.
PRUNE LIST
There maybe situations wherein certain stations become inactive. The
“Prune list”option enables the deletion of these inactive stations in the
service list.
1 While listening to a DAB broadcast, select“Prune List” from“DAB Setup”
menu.
2 At“Prune List”menu, use [D/F] to select between “Cancel” and
“Conrm Prune”. Any inactive stations (normally preceded by a “?”mark)
are automatically deleted when“Conrm Prune”is selected. Otherwise,
select “Cancel”.
RESET SETTINGS
The“Reset Settings”allows the DAB section of the C 446 to be reset to its
factory default settings.
1 While listening to a DAB broadcast, select“Reset Settings”from“DAB
Setup”menu.
2 At“DAB Factory Reset” menu, use [D/F] to select between“Cancel”
and“Conrm Reset”. Selecting “Conrm Reset” will cause the DAB
section to be reset to its factory default settings. Otherwise, select
“Cancel”.
INFORMATION SETTINGS
While listening to a DAB broadcast, the type of information displayed in the
second line of the VFD can be varied. Toggle TNR 2’s [INFO] button to step
through the following display options
•station name
•program type
•ensemble name
•time and date
•audio signal information
•others
Above information may not always be available and are dependent upon
the DAB station’s supplied information.
The scrolling text (if available) at the bottom line of the VFD is the Dynamic
Label Segment (DLS). It may contain information on music titles or details
regarding the program or station.
Manual Scan
6A 181.936M
Status: Tuning
Signal Strength 10%
Prune List
Cancel
}Confirm Prune
DAB Factory Reset
Cancel
}Confirm Reset
OPERATION
LISTENING TO DAB RADIO
18
ENGLISH PORTUGUÊSFRANÇAIS ESPAÑOL ITALIANO DEUTSCH NEDERLANDS SVENSKA РУССКИЙ

CONDITION POSSIBLE CAUSES POSSIBLE SOLUTIONS
No power. • The power cord is disconnected. • Plug the power cord into the wall outlet
securely.
• Rear panel POWER switched o. • Set rear panel POWER switch to ON.
No sound. • Faulty/missing cables. • Check cables.
No RDS information. • Station signal too weak. • Check station tuning. Adjust or replace antenna.
• Station not transmitting RDS data. • Tune to an RDS station that supports program-
service name (PS mode) and radio-text (RT
mode).
Display shows“No Items”. • DAB antenna not connected properly. • Check the connection and position of DAB
antenna.
• No DAB coverage in the area. • Call your local DAB broadcast service provider
for coverage information.
Display shows“Action Failed”at
Internet Radio mode.
• Tuning error or unintended misuse. • Toggle [3 SOURCE 4] to cycle through the
sources and back to Internet Radio mode.
• Check network connection.
• Restore C 446 to its factory default settings.
Display shows“Operation Failed” at
Internet Radio mode.
• Weak or unstable broadcast. • Select again the internet radio station from your
list until it stabilizes and broadcasts properly.
• Check network connection.
C 446 does not respond to remote
control commands.
• Batteries are at or incorrectly inserted. • Check batteries.
• Infrared receiver (IR) window of C 446 or IR
transmitter of the remote control is obstructed.
• Check IR windows and ensure clear line-of-sight
from remote to C 446.
• C 446 front panel is in very bright sunlight or
ambient light.
• Reduce sunlight/room lighting.
REFERENCE
TROUBLESHOOTING
19
ENGLISHPORTUGUÊS FRANÇAISESPAÑOLITALIANODEUTSCHNEDERLANDSSVENSKAРУССКИЙ

FM SECTION
Usable Sensitivity (98 MHz) 10 dB
Signal/Noise Ratio 65 dB (60 dB IHF-WTD Mono)
60 dB (60 dB IHF-WTD Stereo)
Frequency Response ±1.5 dB (20 Hz - 15 kHz, 60 dB)
Channel Separation (60 dB) - 30 Hz 33 dB
1 kHz 40 dB
10 kHz 32 dB
Capture Ratio (40 dB) 3 dB
AM Suppression 50 dB (60 dB, 100% Mod. FM, 30% Mod. AM)
Image Rejection (119.4 MHz) 70 dB
I.F. Rejection (10.7 MHz) 70 dB
Pilot Suppression (60 dB) 60 dB
Total Harmonic Distortion* - Mono 0.4%
Stereo 0.8%
Auto Search Sensitivity 24 dB
RDS Decode Sensitivity 26 dB
AM SECTION
Usable Sensitivity (999/1000 Hz) 55 dB
Signal/Noise Ratio (5 mV in) 42 dB
Total Harmonic Distortion (5 mV in) 1.5%
IF Rejection (450 kHz) 40 dB
Image Rejection (F+2xIF) 28 dB
Selectivity 20 dB
Loop Sensitivity (20dB S/N) - 999/1000 Hz 66 dB
603/600 Hz 66 dB
1404/1400 Hz 66 dB
Frequency response (100 - 2.3 kHz, 5 mV) ±6 dB
DAB SECTION
BAND 3
Tuning range 175.280 – 240.000 MHz
Large signal handling capacity 0 dBm
Sensitivity -97 dBm
Far o selectivity 40 dB
Adjacent channel rejection 40 dB
PLAYABLE MEDIA FORMAT
WAV up to 1.536 mbit/s
FLAC up to 1.5 mbit/s
AAC up to 320 kbit/s
MP3 up to 320 kbit/s
WMA up to 320 kbit/s
INTERFACE
Wired 10/100 Ethernet
Wireless (Wi-Fi) 802.11/b/g
GENERAL SPECIFICATIONS
Standby power <0.5W
Analog audio output 2 Vrms
S/PDIF audio output 3.3 V
Unit Dimension (W x H x D) - Gross 435 x 99 x 341 mm
17 / x 3 / x 13 / inches
Net weight 4.8 kg (10.6 lbs)
Shipping weight 6.5 kg (14.3 lbs)
* 60 dB, L=R 75 kHz for 120V version; 40 kHz Dev for 230V version)
Specications are subject to change without notice. For updated documentation and features, please log onto www.NADelectronics.com for the latest
information about C 446.
REFERENCE
SPECIFICATIONS
20
ENGLISH PORTUGUÊSFRANÇAIS ESPAÑOL ITALIANO DEUTSCH NEDERLANDS SVENSKA РУССКИЙ
