USER MANUAL
2 . 3
2 . 1
eARC
Enhanced Audio Return Channel
HELLO

2222
Your Unit is designed and manufactured to operate within defined design limits, and misuse may result in electric shock or fire. To prevent your Unit
from being damaged, the following rules should be observed for its installation, use and maintenance. Please read the following safety instructions
before operating your unit. Keep these instructions in a safe place for future reference.
WARNING: To reduce the risk of fire or electric shock, do not expose this apparatus to rain or moisture.
IMPORTANT SAFETY INSTRUCTIONS
This lightning flash with arrowhead symbol within an equilateral
triangle is intended to alert user to the presence of not isolated
dangerous voltage within the product that may be sufficient
magnitude to constitute a risk of shock to persons.
The exclamation point within the equilateral
triangle is to alert the user to the presence of
important operating and servicing instructions
in the literature accompanying the appliance.
Warning: This equipment is a Class II or
double insulated electrical appliances. It has
been designed in such way that it does not
require a safety connection to electrical earth.
Read, keep and follow all instructions.
Heed all warnings.
Do not use apparatus near water.
Clean only with a dry cloth.
Do not block any ventilation openings. Install in accordance with the
manufacturer’s instructions.
Do not install near any heat sources such as radiators, heat registers,
stoves, or other apparatus (including amplifiers) that produce heat.
Do not defeat the safety purpose of the polarized or grounding-type
plug. A polarized plug has two blades with one wider than the other. A
grounding type plug has two blades and a third grounding prong. The
wide blade or the third prong are provided for your safety. If the
provided plug does not fit into your outlet, consult an electrician for
replacement of the obsolete outlet.
Protect the power cord from being walked on or pinched, particularly
at plugs, convenience receptacles, and the point where they exit from
the apparatus.
Only use attachments / accessories specified by the manufacturer.
Use only with the cart, stand, tripod, bracket, or table specified by the
manufacturer, or sold with the apparatus. When a cart is used, use
caution when moving the cart / apparatus combination to avoid injury
from tipover.
Unplug this apparatus during lightning storms or when unused for long
periods of time.
Refer all servicing to qualified service personnel. Servicing is required
when the apparatus has been damaged in any way, such as when the
power supply cord or plug is damaged, liquid has been spilled or
objects have fallen into the apparatus, the apparatus has been
exposed to rain or moisture, does not operate normally, or has been
dropped.
To reduce the risk of electric shock or component damage, switch off
the power before connecting other components to your Unit.
Unplug the power cord before cleaning your Unit. A damp cloth is
sufficient for cleaning. Do not use a liquid or a spray cleaner on your
Unit. Do not use abrasive cleaners.
Always use the accessories recommended by the manufacturer to
ensure compatibility.
When moving your Unit from an area of low temperature to an area of
high temperature, condensation may form in the housing. Wait before
turning on your Unit to avoid causing fire, electric shock, or component
damage.
Slots and openings in the back and bottom of the cabinet are provided
for ventilation. To ensure reliable operation of your Unit and to protect
it from overheating, be sure these openings are not blocked or
covered. Do not place your Unit in a bookcase or cabinet unless proper
ventilation is provided.
Never push any objects into the slots and openings on your Unit
enclosure. Do not place any objects on the top of your Unit. Doing so
could short circuit parts causing a fire or electric shock. Never spill
liquids on your Unit.
When connected to a power outlet, power is always flowing into your
Unit. To totally disconnect power, unplug the power cord.
Do not overload power strips and extension cords. Overloading can
result in fire or electric shock.
The wall socket should be located near your Unit and be easily
accessible.
Keep your Unit away from moisture. Do not expose your Unit to rain
or moisture. If water penetrates into your Unit, unplug the power
cord and contact your dealer. Continuous use in this case may result
in fire or electric shock.
Do not use your Unit if an abnormality occurs. If any smoke or odor
becomes apparent, unplug the power cord and contact your dealer
immediately. Do not try to repair your unit yourself.
Avoid using dropped or damaged appliances. If your Unit is dropped
and the housing is damaged, the internal components may function
abnormally. Unplug the power cord immediately and contact your
dealer for repair.
Continued use of your Unit may cause fire or electric shock.
Do not install your Unit in an area with heavy dust or high humidity.
Operating your Unit in environments with heavy dust or high humidity
may cause fire or electric shock.
Ensure that the power cord and any other cables are unplugged
before moving your Unit.
When unplugging your Unit, hold the power plug, not the cord.
Pulling on the power cord may damage the wires inside the cord and
cause fire or electric shock. When your Unit will not be used for an
extended period of time, unplug the power cord.
To reduce risk of electric shock, do not touch the connector with wet
hands.
Insert the remote control batteries in accordance with instructions.
Incorrect polarity may cause the battery to leak which can damage
the remote control or injure the operator.
The marking label of the subwoofer was located on the external
bottom enclosure of the product.
The equipment shall be used at maximum 95F ambient temperature.
See the important note and rating located on the back of the unit.
WARNING - This equipment is not waterproof. To prevent a fire or
shock hazard, do not place any container filled with liquid near the
equipment (such as a vase or flower pot) or expose it to dripping,
splashing, rain or moisture.
To prevent injury, this apparatus must be securely attached to the
floor / wall in accordance with the installation instructions.
CAUTION - Danger of explosion or fire if batteries are mistreated.
Replace only with the same or specified type.
Do not leave the batteries exposed to direct sunlight for a long
period of time with doors and windows closed. Do not disassemble
the batteries or dispose of it in fire.
Where the MAINS plug or appliance coupler is used as the
disconnect device, the disconnect device shall remain readily
operable.

3333
TABLE OF CONTENTS
1 Understanding your Soundbar System
Package Contents
Controls & Connections
2 Setting up your Home Theater
Speaker Placements
Connecting Surround Speakers to Subwoofers
Turning on your Soundbar System
Connecting your TV
Listening to your Soundbar
Setting up your TV
Connecting your Content Devices
Setting up your Content Devices
3 Understanding your Remote Control
Overview
Selecting Different Input Sources
Accessing Audio Presets
Accessing Channel Mapping / Upmixing
Accessing Setup Button
Accessing Room Size
Accessing SSE Max Mode
Accessing Info Mode
Saving Audio Settings to System Memory
4 Bluetooth Audio Streaming
5 Re-pairing Subwoofers with the System
6 Installing the Wall Mount
Mounting your Soundbar
Mounting your Surround Speakers
7 Firmware Upgrade
8 Specifications
9 Warranty Information & Support
10 Glossary
11 Legal & Compliance
12 Help & Troubleshooting
4
----------- 4
----------- 5
8
----------- 8
----------- 11
----------- 12
----------- 13
----------- 15
----------- 16
----------- 17
----------- 22
23
----------- 24
----------- 25
----------- 26
----------- 27
----------- 29
----------- 30
----------- 31
----------- 32
----------- 33
34
35
36
----------- 36
----------- 37
38
39
40
41
42
43

4444
1 PACKAGE CONTENTS
Soundbar Main Unit x 1 10” Wireless Subwoofers x 2 Surround Speakers x 4
BASS VOL
ALL CH
STEREO SURROUND
TV HDMI2 HDMI 3
COAX
HDMI4 OPT
USBAUX
BLUETOOTH/USB MODE ONLY
CR SB
SS
TR
SB
SS
TR
CR
SYSTEMMEMORY
32
1
RETURN
INFO
SETUP
ENTER
Remote Control w/
Batteries x 1
Soundbar Power Cable x 1
Subwoofer Power Cables x 2
(Length: 5 ft. each)
Satellite Speaker Audio Cables x 4
(Length: 32.8 ft. each)
HDMI 2.1 Cable x 1
(Length: 5 ft.)
Optical Cable x 1
(Length: 5 ft.)
3.5mm Audio Cable x 1
(Length: 4 ft.)
Soundbar Power Adapter
(Length: 5 ft.)
Wall Screws &
Brackets x 20
Satellite Speaker Mounting
Brackets (Dipole) x 2
Mounting Screws
(Soundbar) x 2
Mounting Screws
(Satellite Speakers) x 8
Soundbar & Satellite Wall
Mount Brackets x 10
Soundbar Mounting Guide
Surround Speakers Backplate
Screws (Dipole) x 8
Speakers Connectors (Dipole) x 4 +
Silver Flathead Screws x 8

5555
1.2 CONTROLS & CONNECTIONS
A. SOUNDBAR
HELLO
FRONT VIEW
Top View
POWER
Power ON soundbar or
goes to STANDBY mode
INPUT
Switches audio source
DEMO
Plays a Demo track, followed by
Diagnostic Tones on each channel
VOLUME - / +
Decreases or increases volume
LED PANEL
Displays system information
BACK VIEW
OPTICAL
USB
COAXIAL
AUX
AVIS:
RISQUEDE CHOC ELECTRIQUE /
NEPAS OUVRIR
WARNING:To avoid electrical shock,
pleasedo not open the back cover of
thisunit. Please contact authorized
professionalpersonnel for
maintenanceor repair.
ForDTS patents, see http://patents.dts.com
Thisdevice complies with Part 15 of the FCC Rules.
Operationis subject to the following two conditions:
(1)This device may not cause harmful interference, and
(2)This device must accept any interference received,
includinginterference that may cause
undesiredoperation.
CANICES-3 (B)/NMB-3(B)
FCCID: XXXX-XXXX
IC:XXXXX-XXXXX
Manufacturedunder license from Dolby Laboratories.
Dolby,Dolby Atmos, Dolby Vision Compatible and the
double-Dsymbol are trademarks of Dolby Laboratories.
Designedby SHOCKWAFE LABS
ModelNo.: ULTRA 9.2 eARC MadeIn China


DC IN
Power Supply
OPTICAL
USB
OPTICAL
Digital Optical
Audio Input
USB
For Firmware
Upgrade only
COAXIAL
AUX
COAXIAL
Digital Coaxial
Audio Input
AUX
3.5mm Stereo
Analog Audio
Input
HDMI IN [2]
(HDCP 2.3, Dolby Vision,
4K HDR Pass-thru)
HDMI IN [3]
(HDCP 2.3, Dolby Vision,
4K HDR Pass-thru)

 HDMI OUT (TV) [1]
(ARC/eARC,
HDCP 2.3, Dolby Vision,
4K HDR Pass-thru)
HDMI IN [4]
(HDCP 2.3, Dolby Vision,
4K HDR Pass-thru)

6666
B. SUBWOOFERS & SURROUND SPEAKERS
BACK SURRBACK SURR
Pairing Button
Pairing LED Indicator
RED LED Indicator
(For Firmware
Upgrade only)
USB IN (For Firmware
Upgrade Only)
Power Switch
Power Port
Connect to
LEFT BACK
Surround
Speaker
Connect to
LEFT SURR
Surround
Speaker
Back of LEFT Subwoofer Back of RIGHT Subwoofer
Connect to
RIGHT SURR
Surround
Speaker
Connect to
RIGHT BACK
Surround
Speaker
Back of LEFT Surround Speakers Back of RIGHT Surround Speakers
RIGHT BACK
Speaker Port
(Connect to
RIGHT Subwoofer)
LEFT BACK
Speaker Port
(Connect to LEFT
Subwoofer)
LEFT SURR
Speaker Port
(Connect to LEFT
Subwoofer)
RIGHT SURR
Speaker Port
(Connect to
RIGHT Subwoofer)
DIPOLE
Satellite Speaker Switch
(See Pg 9 for more details)
1.2 CONTROLS & CONNECTIONS

7777
C. USING YOUR REMOTE CONTROL
1.2 CONTROLS & CONNECTIONS
Remote Angle
Tilt the remote downwards by 15-25 degrees for best response.
(As if you are aiming the remote slightly towards the ground)
Once HDMI-CEC is set up, use your TV / content device’s remote
control to power ON the entire system.
Always use your TV’s remote control to power OFF the entire
system.
Inserting Batteries before using the Remote Control
(AAA Batteries x 2)
Slide the back cover in the direction of the arrow until it is
completely removed. Insert 2 x AAA Batteries and gently
push the cover back into place.
Infrared Transmitter

8888
A. BEST SURROUND: SIGNATURE PLACEMENT (4 INDIVIDUAL SPEAKERS SETUP)
2 SETTING UP YOUR HOME THEATER
Note: Illustration is not to scale. Speaker stands are not included.
135 150 135 150
Sub
Right
Sub
Left
5 ft 5 ft
3.2 ft 3.2 ft
6.5 ft 6.5 ft
6.5 ft 6.5 ft
3.2 ft min
clearance
3.2 ft min
clearance
9 ft min
clearance
SURROUND
RIGHT
SURROUND
BACK RIGHT
SURROUND
BACK LEFT
SURROUND
LEFT
The bottom speaker driver of the surround speakers
should be at ear level and pointing directly at the
listener's sitting area for optimal performance.
9CH
Tip:
Toggle the surround speaker switch to
9CH mode.
For recommended speaker stands, scan QR code
or visit: bit.ly/shockwafe-speaker-stands
The soundbar system features modular surround speakers, giving you placement flexibility to suit your listening environment. The
diagram below illustrates the recommended speaker placement. Actual distance can vary based on actual room layout.

9999
For recommended speaker stands,
scan QR code or visit:
bit.ly/shockwafe-speaker-stands
B. BETTER SURROUND: DIPOLE CONFIGURATION (SPEAKERS ARE ATTACHED TO FORM TWO PAIRS)
2 SETTING UP YOUR HOME THEATER
Attaching the speakers for dipole setup
Secure the dipole mounting
bracket with screws
Attach the L-shaped silver connectors
onto the slots of the right speaker.
Secure the connectors using silver
flathead screws.
3
Attach left and right
speaker
45
12
Remove the rubber stoppers from the slots
Left Speaker Right Speaker
Tip:
The bottom speaker driver of the surround speakers should be at ear
level. The silver seam in between the speakers should be pointing
directly at the listening area for optimal performance.
Toggle the surround speaker switch to DIPOLE mode.
DIPOLE
The diagram below illustrates the recommended speaker placement. Actual distance can vary based on actual room layout.
135 150 135 150
Sub
Right
Sub
Left
5 ft 5 ft
3.2 ft 3.2 ft
6.5 ft 6.5 ft
6.5 ft 6.5 ft
3.2 ft min
clearance
3.2 ft min
clearance
9 ft min
clearance
OPTION A OPTION A
OPTION BOPTION B

10101010
B. BETTER SURROUND: DIPOLE CONFIGURATION (SPEAKERS ARE ATTACHED TO FORM TWO PAIRS) C. HYBRID ELEVATION
2 SETTING UP YOUR HOME THEATER
Lay the surround speakers down (drivers tilted upward in 2 modes, see
illustration on the right) to enable vertical effects to bounce off the
ceiling of your room.
Elevation 2:
Hybrid 360oSurround
with Vertical Effects
Elevation 1:
Vertical Effects-Centric
Mode
135 150 135 150
Surround Right
(Vertical Effects)
Surround Right
(Vertical Effects)
SURROUND
BACK LEFT
SURROUND
BACK RIGHT
Sub
Right
Sub
Left
5 ft 5 ft
3.2 ft 3.2 ft
6.5 ft 6.5 ft
6.5 ft 6.5 ft
3.2 ft min
clearance
3.2 ft min
clearance
9 ft min
clearance
OPTION C1: 9.2CH SIDE ELEVATION
For added perceptibility of height effects from both
sides of the room
SURROUND LEFT SURROUND RIGHT
Surround Back Left
(Vertical Effects)
Surround Back Right
(Vertical Effects)
Sub
Right
Sub
Left
5 ft 5 ft
3.2 ft 3.2 ft
6.5 ft 6.5 ft
6.5 ft 6.5 ft
3.2 ft min
clearance
3.2 ft min
clearance
9 ft min
clearance
OPTION C2: 9.2CH REAR ELEVATION
For added perceptibility of height effects from the back
of the room
Surround Left
(Vertical Effects)
Surround Left
(Vertical Effects)
Surround Back Left
(Vertical Effects)
Surround Back Right
(Vertical Effects)
Sub
Right
Sub
Left
5 ft 5 ft
3.2 ft 3.2 ft
6.5 ft 6.5 ft
6.5 ft6.5 ft
3.2 ft min
clearance
3.2 ft min
clearance
9 ft min
clearance
OPTION C3: 9.2CH ALL ELEVATION
For added perceptibility of height effects from sides
and back of room
Note: The diagrams above illustrate the recommended speaker placements. Actual distances can vary based on actual room layout.
Tip:
Find a video clip, invest the time to play the clip with
different speaker placements and audition to see what
works best for your room.

11111111
BACK SURR
LEFT SUBWOOFER
BACK SURR
RIGHT SUBWOOFER
2.2 CONNECTING SURROUND SPEAKERS TO
SUBWOOFERS

12121212
c
d
AC IN
e
POWER
f
PAIRING
Blinking Blue Light:
Subwoofer is on standby mode.
Rapid Blinking Blue Light:
Subwoofer is on pairing mode.
Solid Blue Light:
Subwoofer successfully paired.
2.3 TURNING ON YOUR SOUndbar SYSTEM
Tip: Once soundbar is powered off, the blue LED lights on the subwoofers will continue blinking for 10 minutes before
going into standby mode. You do not need to turn off the subwoofers after each use.
g
Top of Soundbar
SOUNDBAR
a
b

13131313
BACK OF SOUNDBAR
Manufactured under license from Dolby Laboratories.
Dolby, Dolby Atmos, Dolby Vision Compatible and the
double-D symbol are trademarks of Dolby Laboratories.
Designed by SHOCKWAFE LABS
Model No.: ULTRA 9.2 eARC Made In China

 
HDMI CABLE
2.4 Connecting your TV
1. Connect one end of the HDMI cable to the HDMI (ARC / eARC) port at the back of your TV
2. Connect the other end to the HDMI OUT (TV) [1] port of your Nakamichi soundbar
Tip: HDMI Audio Return Channel (ARC) / enhanced Audio Return Channel (eARC)
offers two-way communication between your soundbar and TV over a single HDMI
connection. Essentially, the HDMI ARC port lets you use HDMI as both an input and
an audio output. For more information, please refer to Pg 16.
BACK OF TV
* HDMI ARC / eARC port location may differ based on TV brand.
See your TV’s user manual for more information
A. VIA HDMI ARC / EARC

14141414
B. DIGITAL OPTICAL , COAXIAL , AUX
2.4 Connecting your TV
OPTICAL
USB
COAXIAL
AUX
AVIS:
RISQUE DE CHOC ELECTRIQUE /
NE PAS OUVRIR
WARNING: To avoid electrical shock,
please do not open the back cover of
this unit. Please contact authorized
professional personnel for
maintenance or repair.
For DTS patents, see http://patents.dts.com
BACK OF SOUNDBAR
3.5MM AUDIO
CABLE
COAXIAL CABLEDIGITAL OPTICAL
CABLE
Note: Be sure to connect to a TV's audio output port, not an audio input port.
Not all TVs have the audio outputs shown above. To connect the soundbar directly
to your other devices (Blu-ray player, game consoles, etc). See Pg 21, CONNECTING
YOUR CONTENT DEVICES
Cable appearance may differ from the ones supplied.
If there is no audio during the setup, see Pg 43 for Help & Troubleshooting
Cable not included
*
*
!

15151515
Press to power on / off the soundbar
Important: Once HDMI CEC is set up, always
power on the soundbar by using your TV or
content device’s remote control power ON
button.
Always use your TV’s remote control to power
OFF the entire system.
For more about HDMI CEC, visit:
nakamichi-usa.com/what-is-hdmi-cec/
Press TV button to listen to TV audio (ARC /
eARC).
Press HDMI 2 / 3 / 4 / Optical / Coaxial button
to listen to content from other devices
TV HDMI 2 HDMI 3
OPT COAX HDMI 4
Dolby Atmos is Dolby’s latest object-based 3D surround sound format. It is
encoded into Dolby TrueHD or Dolby Digital Plus stream with meta-data to
extract and place the objects in relevant positions of a surround environment.
2.5 Listening to your soundbar
TV HDMI 2 HDMI 3
OPT COAX HDMI 4
USBAUX
ALL CH
STEREO SURROUND
RETURN
INFO
SETUP
ENTER
BASS VOL
CR SB
SS
TR
SS
CR TR SB
SYSTEM MEMORY
3
2
1
BLUETOOTH MODE ONLY
All Channel Stereo / Stereo Only
All Channel Stereo (Recommended) =
Enables Stereo playback on surround
speakers. Best for music, YouTubeTM and
content with minimal rear surround effects.
Stereo Only = Enables playback with
soundbar + subwoofers only (no surround)
ALL CH
STEREO
Access to advanced system settings.
(See Pg 27 for more information)
SETUP
Set SURROUND to Default for the best
experience.
For Dolby/PCM content:
DOLBY SURR (Default) = Dolby Full Surround
+ Height
DOLBY UPMIX = Dolby Full Surround Upmix
NATIVE = Direct decode 2.1 / 5.1 / 7.1
channels based on how content was recorded.
For DTS content:
Neural X (Default) = DTS Full Surround +
Height
DTS Direct = DTS Full Surround Upmix
Native = Direct decode 2.1 / 5.1 / 7.1 channels
based on how content was recorded.
Above modes are for DTS content only. Cannot
enable when Dolby or PCM content is playing.
(See Pg 26 for detailed information on
channel mapping and upmixing)
SURROUND
Press INFO button once to see the source
audio format on the soundbar’s LED display:
DOLBY ATMOS TRUEHD
(Dolby Atmos encoded Dolby TrueHD)
DOLBY ATMOS D PLUS
(Dolby Atmos encoded Dolby Digital Plus)
DOLBY ATMOS MAT**
(Dolby Atmos meta-data into lossless pulse-code
modulation)
DOLBY TRUEHD
DOLBY D PLUS (Dolby Digital Plus)
DOLBY DIGITAL
DTS X, DTS-HD MA (DTS HD Master Audio)
DTS HD (DTS High Definition Audio)
DTS DIGITAL (DTS Digital Surround)
LPCM 7.1 (Linear Pulse Code Modulation 7.1)
LPCM 5.1 (Linear Pulse Code Modulation 5.1)
PCM 2.0 (Pulse Code Modulation)
** XBOX SERIES X / One X/S and Apple TV 4K come with
a Dolby Atmos MAT encoder, which is designed to
encode, decode and incorporate Dolby Atmos meta-data
into lossless pulse-code modulation (LPCM) audio.
INFO
For expanded remote control guide,
scan QR code or visit:
bit.ly/92earc-shockwafe-remote

16161616
A. What is Enhanced Audio Return Channel (ARC / eARC)?
HDMI Audio Return Channel (ARC) / enhanced Audio Return Channel (eARC) offers two-way communication between your soundbar
and TV over a single HDMI connection. Essentially, the HDMI ARC port lets you use HDMI as both an input and an audio output. An
eARC-compatible TV can send original, full resolution (lossless) audio signals to the soundbar. For eARC, you will need to connect
your soundbar to the TV's HDMI eARC port using a high speed HDMI 2.1 cable.
The soundbar's eARC port is backwards-compatible with ARC and can also accept audio signals from HDMI ARC Equipped TV's.
Audio Settings for TV*
Setting the audio output:
1. Go to Settings > Sound
2. Select Speaker Settings
3. Set as HDMI Audio Out
4. For eARC equipped TV’s only:
Please also check your TV settings and turn on eARC mode if available.
This option might be found under the advanced/expert options on your TV.
Setting the audio format:
A) Go to Settings > Sound > Additional Settings
B) Select Speaker Audio Format
C) Set as Dolby Digital / DTS / Bitstream (whichever is available)
B. What is CEC?
CEC is an HDMI protocol that is only available when:
1. Your TV is CEC enabled. (Check with your TV manufacturer for more information)
2. The soundbar and TV is connected via a HDMI cable through the ARC ports.
By doing so, you are able to control the soundbar’s volume and power functions with the TV remote.
Enabling CEC^
From the SYSTEM menu, enable CEC and ARC^ functions.
From the CEC menu, select Device Discovery to register the soundbar with the TV.
Enable CEC for TV only. Do not enable CEC for other source devices or inputs may switch randomly.
To disable CEC on the soundbar, see Pg 28.
* Steps may differ based on TV brand. See your TV’s user manual for more information.
^ HDMI-CEC TV Trade names: Samsung (Anynet+), Sharp (Aquos Link), Sony (Bravia Sync), LG (SIMPLINK), Panasonic (HDAVI Control / EZ Sync / Viera
Link) , Philips (EasyLink), Vizio (CEC), TCL (CEC), Hisense (CEC). Naming may differ based on TV brand. See your TV’s user manual for more information.
Visit www.nakamichi-usa.com/best-sound for expanded list of TVs’ audio
settings instructions. Visit bit.ly/hdmi-cec-settings or scan QR Code for
HDMI-CEC setup instructions by device
If your devices are not listed on our website, please check with the device
manufacturer’s manual
2.6 SETTING UP YOUR TV
For brand specific TV audio settings,
scan QR code or visit:
www.nakamichi-usa.com/best-sound

17171717
TV
Satellites
Set-Top Boxes
PS4, XBOX ONE, Switch &
Older Consoles
Streaming Devices
Connect these devices directly to
Soundbar Via HDMI
Connect TV HDMI ARC / eARC to
Soundbar HDMI 1 eARC
Connect these devices directly to
your TV via HDMI
Blu-ray Players
HELLO
A. CONNECTIONS CENTRAL - RECOMMENDED CONNECTION BASED ON DEVICES
*Connect XBOX Series X and PS5 directly to TV’s HDMI inputs if TV is equipped with eARC
2.7 CONNECTING YOUR CONTENT DEVICES
XBOX Series X / PS5*
Use our Perfect Device Matching Tool
to create a custom setup guide based on your TV and
devices. Scan QR code or visit bit.ly/device-matching-tool

18181818
2.7 CONNECTING YOUR CONTENT DEVICES
B. HDMI CONNECTION SETUP
HDMI cables transmit both audio and video content. To view video from these devices, turn the soundbar on, then set the
soundbar input to HDMI IN [2], HDMI IN [3] or HDMI IN [4]. Set your TV input to the HDMI ARC / eARC port which the soundbar
is connected.
* Connect XBOX Series X and PS5 directly to TV’s HDMI inputs if TV is equipped with eARC.
Note 1: Cables may appear differently from the ones supplied.
Note 2: Connect devices with the same HDCP standards for seamless switching between sources. If there are devices with different HDCP
standards, connect all HDCP 2.3 devices to soundbar while connecting HDCP 1.4 / 2.0 / 2.1 devices to TV to avoid audio and video instability.
HDMI OUT (TV) [1]
(ARC / eARC,
HDCP 2.3, Dolby Vision,
4K HDR Pass-thru)
HDMI IN [4]
(HDCP 2.3, Dolby Vision,
4K HDR Pass-thru)
TV
HDMI OUT (TV) [3]
(HDCP 2.3, Dolby Vision,
4K HDR Pass-thru)
HDMI IN [2]
(HDCP 2.3, Dolby Vision,
4K HDR Pass-thru)
Blu-ray / DVD Player Streaming Devices Gaming Consoles* TV with eARC / ARC
BACK OF SOUNDBAR
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received,
including interference that may cause
undesired operation.
CAN ICES-3 (B)/NMB-3(B)
FCC ID: XXXX-XXXX
IC: XXXXX-XXXXX
Manufactured under license from Dolby Laboratories.
Dolby, Dolby Atmos, Dolby Vision Compatible and the
double-D symbol are trademarks of Dolby Laboratories.
Designed by SHOCKWAFE LABS
Model No.: ULTRA 9.2 eARC Made In China



19191919
OPTICAL
USB
COAXIAL
AUX
AVIS:
RISQUE DE CHOC ELECTRIQUE /
NE PAS OUVRIR
WARNING: To avoid electrical shock,
please do not open the back cover of
this unit. Please contact authorized
professional personnel for
maintenance or repair.
For DTS patents, see http://patents.dts.com
BACK OF SOUNDBAR
3.5MM AUDIO
CABLE
COAXIAL CABLE*DIGITAL OPTICAL
CABLE
Gaming Consoles Network Media Player Tablet / MP3 Player / PC
Note: Dolby Digital Plus, Dolby True HD, Dolby Atmos, DTS HD MA, DTS HD and DTS:X are not supported on Optical, Coaxial and Aux connections
*Cable not included
2.7 CONNECTING YOUR CONTENT DEVICES
C. NON-HDMI CONNECTION SETUP

20202020
2.7 CONNECTING YOUR CONTENT DEVICES
D. ADVANCED SETUP - FOUR DEVICE SETUP FOR HDTV
Thisdevice complies with Part 15 of the FCC Rules.
Operationis subject to the following two conditions:
(1)This device may not cause harmful interference, and
(2)This device must accept any interference received,
includinginterference that may cause
undesiredoperation.
CANICES-3 (B)/NMB-3(B)
FCCID: XXXX-XXXX
IC:XXXXX-XXXXX
Manufacturedunder license from Dolby Laboratories.
Dolby,Dolby Atmos, Dolby Vision Compatible and the
double-Dsymbol are trademarks of Dolby Laboratories.
Designedby SHOCKWAFE LABS
ModelNo.: ULTRA 9.2 eARC MadeIn China

HDMI IN (eARC / ARC)
HDMI OUT (TV) [1]
Switch the soundbar’s source to TV for playing
Device’s 4 audio. (Via TV’s ARC / eARC
connection. Dolby Atmos and DTS:X audio are
not supported on ARC connection)
HDMI IN*
HDMI OUT
(Dolby Atmos / DTS:X
devices supported)
HDMI IN [4]
HDMI OUT
HDMI IN [3]
HDMI OUT
HDMI IN [2]
HDMI OUT
Note: If the device is not equipped with a HDMI port, use an Optical or Coaxial output.
* Compatible HDMI eARC TVs can pass original, full resolution audio (with Dolby Atmos and DTS:X support) to the Soundbar. Selected HDMI
ARC-equipped TVs can send compressed Dolby Atmos audio to the soundbar.


TV
Device 4
Device 3
Use our Perfect Device Matching Tool
to create a custom setup guide based on your TV
and devices. Scan QR code or visit
bit.ly/device-matching-tool
(Dolby Atmos / DTS:X
devices supported)
Device 2
(Dolby Atmos / DTS:X
devices supported)
Device 1
Dolby Atmos / DTS:X
supported if TV is
equipped with eARC
Video & Audio
