1. INTRODUCTION
KN6 and KN10S are stainless steel, self-powered, 2-way full range speaker systems. Tey
are compact and powerful with multiple D class amplier channels dedicated to each of their
transducer elements. KN6 has a wide 130° vertical coverage pattern and the ability to
select the horizontal coverage from 10° to 130°, making it usable as both a point source and
as a line array element.
The system is ideal for medium throw applications in theatres, concert halls, houses of worship
and AV installations. KN6 uses two 6” Neodymium cone speakers with 2.5” voice coils for
low-mid frequencies. The mid-high frequency section employs three 1” voice coil Neodymium
compression drivers. The transducers are optimized with on-board DSP pre-sets. KN6 is
designed to easily integrate with KN10s selfpowered subwoofer.
The KN10s subwoofer module employs two 10” transducers with Neodymium magnet
structure and suspensions engineered for maximum linear excursion.
All KN6 and KN10S components are designed by the K-array R&D department and custom
made under the K-array quality control system.
KN6 - KN10S
• Background music systems in restaurants and clubs
• High-quality distributed systems for paging and music
• Exhibit audio for museum displays
• Space-sensitive ll for theatres

8rev.A
KN6 - KN10S
3. KEY FEATURES
• Ultra strong stainless steel enclosure
• For stand-alone use or as line array element
• Flat amplitude and phase response
• Selectable point/line source emission
• Self powered
• Integrated 35mm pole adapter
• Unique performance-to-size ratio
4. UNPACKING
Each K-array loudspeaker is built to the highest standard and thoroughly inspected
before leaving the factory. Carefully inspect the shipping carton, then examine and test
your new loudspeaker. If you nd any damage immediately notify the shipping company.
Only the consignee may institute a claim stages in the system’s electronic equipment.
5. WARRANTY
K-array systems are warranted against manufacturing defects in materials or craftsmanship
over a period of 2 years from the date of original purchase. During the warranty period
K-array will, at it’s discretion, either repair or replace products which prove to be defective
provided that the product is returned in its original packaging, shipping prepaid, to an
authorized K-array service agent or distributor. K-array cannot be held responsible for
defects caused by unauthorized modications, improper use, negligence, exposure to
inclement weather conditions, act of God or accident, or any use of this product that
is not in accordance with the instructions provided by K-array. K-array is not liable for
consequential damages. This warranty is exclusive and no other warranty is expressed
or implied. This warranty does not affect your statutory rights.

9
rev.A
KN6 - KN10S
6. SAFETY
• It is important that loudspeaker systems are used in a safe manner.
• Professional loudspeakers are capable of producing extremely high sound levels
and should be used with care. Hearing loss is cumulative and can result from levels
above 90dB if people are exposed for an extended period.
• Never stand close to loudspeakers driven at high level.
• Suspending the system should only be done by qualied personnel following safe
rigging practices. Secure xings to the building structure are vital. Seek help from
architects, structural engineers or other specialists if in any doubt.
• Do not operate the speaker for an extended period of time with the sound distorting.
This is an indication of malfunction, which in turn can cause heat to generate and
result in a re.
• Connect the power supply only to an appropriate power adapter.
• Do not install the speaker in wet or humid locations without using weather protection.
• Do not allow water or any foreign object to get inside the speaker. Do not put objects
containing liquid on, or near, the unit.
• To reduce the risk of overheating the amplier, avoid exposing it to direct sunlight.
Do not install the unit near heat emitting appliances, such as a room heater or stove.
• No naked ame sources such as lighted candles should be placed near the device.
• The speaker should be placed so that its location does not interfere with its proper
cooling.
• Do not attempt to disassemble the unit. The unit contains no user serviceable parts.
Repairs should be performed only by factory trained service personnel.
• Be sure that the adapter has the correct voltage value.
WARNING

10 rev.A
KN6 - KN10S
7. PHYSICAL
50.5 cm
50.5 cm
19 cm
19 cm
17.5 cm
17.5 cm
3.5 cm
3.5 cm
19.88”
19.88”
7.48”
7.48”
6.89”
6.89”
1.38”
1.38”
weight: 9 kg (19.84 lbs)
KN6

11
rev.A
KN6 - KN10S
50.5 cm
50.5 cm
28 cm
33.5 cm
33.5 cm
33.5 cm
3.5 cm
3.5 cm
3.5 cm
19.88”
19.88”
11.02”
13.19”
13.19”
13.19”
1.38”
1.38”
1.38”
weight: 17 kg (37.48 lbs)
KN10S

12 rev.A
KN6 - KN10S
8. AMPLIFIER
8.1 AC POWER CONNECTOR
8.2 VOLTAGE REQUIREMENT
8.3 CURRENT REQUIREMENT
The amplier module and the rest of the audio equipment connected to it (mixing
consoles, processors, etc.) must be connected to the AC power distribution in a
proper way, preserving AC line polarity and connecting earth ground such that all
grounding points are connected to a single node or common point using the same
cable gauge as the neutral and line(s) cables. Bad grounding connections between
speakers and the rest of the audio system may produce noise, hum and/or serious
damage to the input/output stages in the system’s electronic equipment.
Before applying AC to any K-array self-powered speaker, be sure
that the voltage potential difference between neutral and earth
ground is less than 5 VAC.
KN6/KN10S operates safely and without audio discontinuity if the AC voltage
stays within a operating window from 90 V to 260 V.
Check the voltage before connecting the amplier to the AC power.
A higher voltage could seriously damage the device.
The KN6/KN10S presents a dynamic load to the AC mains, which causes the amount
of current to uctuate between quiet and loud operating levels. Since different cables
and circuit breakers heat up at varying rates, it is essential to understand the types of
current ratings and how they correspond to circuit breaker and cable specications.
The maximum continuous RMS current is the maximum RMS current in a period of
at least ten seconds. It is used to calculate the temperature increase in cables, which
is used to select cables that conform to electrical code standards. It is also used to
select the cable size and gauge and the rating for slow-reacting thermal breakers.
The maximum burst RMS current is the maximum RMS current in a period of ap-
proximately one second. It is used to select the rating for magnetic breakers. The
maximum instantaneous peak current during burst is used to select the rating for fast
reacting magnetic breakers.

13
rev.A
KN6 - KN10S
For best performance, the AC Cable voltage drop should not exceed 10% at 115V
and 5% at 230V.
The minimum electrical service amperage required by a K-array Skin system is
the sum of their maximum continuous RMS current. We recommend allowing an
additional 30% above the minimum amperage to prevent peak voltage drops at the
service entry.
140VA(>10 sec) - 700VA (<1 sec) autorange
KN6/KN10S max continuous apparent power (VA)
8.4 REAR PANEL
1
2
5
6
7
8
9
10
14
13
12
11
3
4
1. Power connector IN
2. Power connector OUT (max 15A)
3. Preset selector,
press one to change, 10 sec. to store
4. Audio INPUT
5. Parallel audio OUTPUT
6. Indicator of proper operating
7. Indicator of signal/clip INPUT
8. Indicator of temperature protection
9. Indicator of clip limiter
10. Audio Input level PAD
11,12, 13, 14 Preset in use

14 rev.A
KN6 - KN10S
8.5 POWER CONNECTORS WIRING
8.6 AUDIO INPUT CONNECTORS WIRING
The KN6/KN10S’s ampliers receives DC power from the 3-pin blue PowerCon
connector on their back panel. The white PowerCon connector is a parallel OUTPUT
for supplying power to other devices (max 16A supported). When AC power is
applied to the speaker, the auto-range power supply selects automatically the correct
operating voltage.
For creating your power cables, please use the following wiring diagrams:
The Audio section includes a female balanced XLR connector and a male XLR
connector wired in parallel. Thanks to these connectors it is possible to feed a
module and to send the same signal to another one through the LINK connector. It
is possible to connect till 30 different modules in parallel on the same balanced line
(with a source of 600 ohm output impedance). A Level Control potentiometer (PAD)
allows different set levels. For creating your signal cables, please use the following
wiring diagrams:
brown = hot
blue = neutral
yellow/green =
earth ground
hot
XLR connector
grd
cold
hot grd
cold
21
3
2
1
3
INPUT PARALLEL
OUTPUT

15
rev.A
KN6 - KN10S
The KN6 and KN10S are powered by the a multi channel high power digital amplier.
KN6: 2 x 250W class D amplier channel + 2 x 20W class A/B amplier channel
KN10S: 2 x 250W class D amplier channel
All the specic functions for the KN6 or KN10S such as crossovers, frequency, phase
response, and driver protection are determined by a DSP processor installed inside
the amplier.
The devices have three different type of audio signal limiter. The Clip limiter, the
average Power limiter and the High Frequency limiter reduce the risk of damaging
the components of the speakers.
A Peak Current Shut Down acts as output stage switching process inhibition that
resets itself after 2 seconds. The tripping point is at 35A.
A temperature protection acts reducing the output stage gain above temperature
level of 85° (temperature on output power devices proximity).
The internal DSP allows to choice between four different default presets.
8.7 AMPLIFICATION AND PROTECTION CIRCUITRY
8.8 DSP
SLOT KN6 KN10S
1 KN6 narrow KN10S
2 KN6 wide KN10S EXT
3 KN6 narrow MH KN10S 150 Hz
4 KN6 wide MH KN10S 150 Hz EXT

16 rev.A
KN6 - KN10S
0
20 50 1K 2K 5K 10K 20K100 200 500
3
-3
-6
-9
-12
6
9
12
KN6 narrow
KN6 wide
0
20 50 1K 2K 5K 10K 20K100 200 500
3
-3
-6
-9
-12
6
9
12
KN6 narrow MD
KN6 wide MD
10° 130°
LINE ARRAY POINT SOURCE
Spot Flood

17
rev.A
KN6 - KN10S
0
20 50 1K 2K 5K 10K 20K100 200 500
3
-3
-6
-9
-12
6
9
12
KN10S
0
3
-3
-6
-9
-12
6
9
12
KN10S 150Hz
KN10S 150Hz EXT
KN10S EXT
0
20 50 1K 2K 5K 10K 20K100 200 500
3
-3
-6
-9
-12
6
9
12
0
20
20
50
50
1K
1K
2K
2K
5K
5K
10K
10K
20
20
K
K
100
100
200
200
500
500
3
-3
-6
-9
-12
6
9
12

18 rev.A
KN6 - KN10S
9. SERVICE
To obtain service:
1) Contact the ofcial K-array distributor in your country. They will direct you to the service
centre.
2) If you are calling for service, have the serial number(s) of the unit(s) at hand for refe-
rence. Ask for Customer Service, and be prepared to describe the problem clearly and
completely.
3) If the problem cannot be resolved over the phone, you must return the unit for service.
4) You will be given an RA (Return Authorization) number for job tracking. Refer to this
number on shipping materials and in all correspondence concerning the repair. Shipping
charges are the responsibility of the purchaser.
Any attempt to modify or replace components of the device will invalidate your warranty.
Service must be performed by an authorized K-array service center.
Cleaning:
Clean the product enclosures using a soft, dry cloth only. Do not use
any solvents, chemicals, or cleaning solutions containing alcohol,
ammonia, or abrasives. Do not use any sprays near the product or allow
liquids to spill into any openings.

19
rev.A
KN6 - KN10S
HORIZONTAL VERTICAL
KN6 KN6 - WIDE mode
8 KHz
4 KHz
1 KHz
500 Hz
250 Hz
8 KHz
4 KHz
1 KHz
500 Hz
250 Hz
10. DISPERSION GRAPHS
IN HORIZONTAL POSITION
90°
120° 60°
30°
-30°
-60°
150°
-90°
180°
-150°
-120°
0° frontback
90°
120° 60°
30°
-30°
-60°
150°
-90°
180°
-150°
-120°
0° frontback

11. KN6 TECHNICAL DETAILS
KN6
Acoustics
Power handling 2x250 + 3x20 w(AES)
Maximum
amplier power 2x500 + 3x40 w(EIAJ)
Impedance 2x4Ω + 3x16Ω
Operating
frequency range 45Hz - 19 KHz +/- 3dB (preset dependent)
SPL 1W/1mt 96 dB (low) 104 dB (high)
Maximum SPL 125 dB continuous - 131 dB peak
Coverage (in horizontal position)
Horizontal 130°
Vertical selectable from 10° to 130°
Crossover
Type DSP controlled
Frequency 1.8 KHz minimum (preset dependent)
Transducers
Low - Mid frequency 2 x 6” Neodymium speakers with 2.5” voice coil
High frequency 3 x 0.5” Neodymium compression driver with 1” voice coil
Audio Input
Connectors male + female parallel 3-pin balanced XLR
Wiring PIN1= ground PIN2 = hot (+) PIN3 = cold (-)
Power Input
Connectors 1 x 3-pin PowerCon
Ampliers
Type 2 x 250W class D amplier channel - DSP controlled
+ 2 x 20W class A/B amplier channel
Power (woofer) 350 + 350 Watt1
Power (driver) 2 x 40 Watt1
Protection Dynamic limiter, over current, over temp, short circuits
AC power
Operating range 85 - 270 Vac 50/60Hz autorange
Max continuous
and burst current 140VA(>10 sec) - 700VA (<1 sec) autorange
Physical
Dimensions 19 x 50.5 x 17.5 cm (7.48”x 19.88”x 6.89”)
Weight 9 Kg (19.84 lbs)
Notes for data
1. Amplier wattage rating is based on the maximum unclipped burst sine wave RMS
voltage that the amplier will produce into the nominal load impedance .
New materials and design are introduced into existing products without previous
notice. Present systems may differ in some respects from those presented in this
brochure.
rev.A
