Namron GLASSOVN PANEL WBL0636-600 User manual

Elektronisk termostat med spareprogram. Lysende LCD display
øverst på ovnen for enkel betjening.
Electronic thermostat with program setting. Bright LCD display
placed at the top of the heater for easy operation.
LCD LCD
220-240V~50-60Hz
600W/800W/1000W
25cm min
600W/800W/1000W
220-240V~50-60Hz
220-240V~50-60Hz IP24
6
Min.10cm
Min.15cm
2.19cm min
15cm
a
13cm
26cm
32cm
1. 2. 3.
Min.30cm

PROG
1
Oh 2 4 6 8 10 12 14 16 18 20 22 24
1
Oh 2 4 6 8 10 12 14 16 18 20 22 24
3
Oh 2 4 6 8 10 12 14 16 18 20 22 24
3
Oh 2 4 6 8 10 12 14 16 18 20 22 24
BRUK UTEN PROGRAM
1.Slå på "STRØMBRYTER", displayet vil vise temperatur og dagsymbol (FIG. 1).
2.Trykk på "AV/PÅ", ovnen vil være i standby-modus. Trykk på "AV/PÅ" igjen, ovnen vil begynne å varme og varmesymbolet vil vises.
3.Trykk "+" eller "-" for å stille inn ønsket temperatur. Temperaturen kan justeres mellom 5°C ~ 35°C.Fabrikkinstilling er 20°C.
BRUK MED UKENTLIG PROGRAM
1.Slå på "STRØMBRYTER", displayet vil vise temperatur og dagsymbol (FIG. 1).
2.Trykk på "AV/PÅ", ovnen vil være i standby-modus. Trykk på "AV/PÅ" igjen, ovnen vil begynne å varme og varmesymbolet vil vises.
3.Trykk "PROG" for å stille inn dag-/klokkeinnstilling (FIG.2). Trykk på "PROG", dagen i uken vil blinke , 1 er mandag - 7 er søndag. Trykk "+" eller "-" for å stille inn
gjeldende dag. Trykk på "PROG" igjen, tiden på dagen blinker, trykk "+" eller "-" for å stille inn gjeldende tid. Trykk "PROG" for å avslutte dag-/klokkeinnstilling.
MERK: Hvis du ikke trykker på noen tast under prosessen, vil blinkingen stoppe etter 10 sekunder, og dag-/klokkeinnstillingen vil bli satt til fabrikkinnstilling som er 00:00.
4.Trykk "PROG" i 3 sekunder under arbeidsmodus, displayet viser den ukentlige programinnstillingen (FIG.3)
5.Trykk "+" eller "-" for å velge dagen du vil sette programmet, dagssymbolet blinker for den relevante dagen.
6.Trykk på "PROG" igjen, klokkeslett symbolet blinker, trykk "+" eller "-" for å velge de timene du vil stille inn programmet. 07:16 betyr 07:00 til 16:00. Det vil bli angitt
som streker over de timene på døgnet som er satt, se (FIG. 4).
7.Trykk på "PROG" igjen, temperaturen blinker, trykk "+" eller "-" for å velge temperaturen du vil stille inn i programmet. 25:17 betyr 25°C i arbeidstiden du har satt, 17°C
utenfor arbeidstiden du har satt.
8.Trykk på "PROG", dagsymbolet blinker, for å fortsette til de øvrige dagene i uken du vil angi et spareprogram. Trykke på "MÅNE" -tasten for å velge
standardinnstilling for timene du ikke har programmert. Standard innstillinger 15°C.
9.Trykk på "TIMER" -tasten etter programinnstilling, ovnen starter da den ukentlige programmeringsmodusen (FIG.4), klokkesymbolet vil vises på displayet.
MERK: Hvis ovnen skal fungere med riktig tidssyklus, må du sette klokkeinnstillingen før programinnstillingen.
(FIG.1) (FIG.2)
PROG /
PROG
(FIG.3) (FIG.4)
USE WITHOUT PROGRAM
1.Turn on the "POWER SWITCH", the display will show the temperature and day symbol (FIG. 1).
2.Press “ON/OFF”,the heater will be in standby mode. Press “ON/OFF” again to start heating, and the heating symbol will appear.
3.Press “+” or “-” to set the temperature you want. The temperature can be adjusted between 5°C~35°C. Factory default setting is 20°C.
USE WITH WEEKLY PROGRAM
1.Turn on the "POWER SWITCH", the display will show the temperature and day symbol (FIG. 1).
2.Press “ON/OFF”, the heater will be in standby mode. Press“ON/OFF” again to start heating, and the heating symbol will appear.
3.Press “PROG” , to adjust the day and clock setting (FIG.2). Press “PROG” the day symbol will blink , press “+”or “-“ to set the day of the week ,1 is Monday -7 is
Sunday . Press “PROG” again and the time will blink, press “+” or “-” to set the time of the day. Press “PROG” when finished to end the clock setting.
NOTE: If you don`t press any key during the process, the blinking will be stopped in 10seconds. The heater will work in the wrong program period.
4.Press “PROG” for 3 seconds under working mode, the display will show the weekly program setting(FIG.3).
5.Press “+” or “-” to choose the day you want to set the program, the day symbol will blink for the relevant day.
6.Press “PROG” again and the hour will blink, press “+” or “-” to choose the hours you want to set the program ,7:16 means 7am to 4pm.The time zone symbol will appear.
(FIG4.)
7.Press “PROG” again and the temperature will blink, press “+” or “-”to choose the temperature you want to set the program, 25:17 means 25°C in the program period and
17°C outside the program period.
8.Press “PROG” and the day symbol will blink, to continue the rest of the days in the week you want to set the program. Press “MOON” to choose default setting temperature
for the hours you have not programed, default setting temperature is 15°C.
9.Press “TIMER” button after program setting, the heater will directly start the weekly program working mode (FIG.4), the clock symbol will appear on the display.
NOTE:The time setting should be done before the program setting, so the heater can work under correct program period.

6
I tilfelle et vindu åpnes i rommet, har ovnen en åpen vindu minnefunksjon. Hvis temperaturen faller med mer enn
5°C innen 10 minutter, vil termostaten pipe 3 ganger.
In case of a window is open in the room, the heater has a window opening remind function. If the temperature drops
more than 5°C within 10 minutes, the buzzer will ring 3 time .
Ved et strømbrudd begynner termostaten å pipe 10 ganger hvert 30 minutt, noe som indikerer at det har vært et
strømbrudd. Trykk på hvilken som helst knapp på termostaten for å stoppe varslingen. Trykk på "PROG" for å starte
klokkeinnstillingen på nytt med gjeldende tid og trykk "TIMER". Ovnen vil da starte samme program som før
strømbruddet.
Merk: Ovnen har minnefunksjon, brukeren bør alltid sjekke klokkeinnstillingen med gjeldende tid når det har vært et
strømbrudd, ellers vil ovnen fungere i samme program, men til feil tid.
In case of a power outage, the buzzer will start to ring 10 times every 30 minutes indicating that a power outage
has occurred. Press any key on the thermostat to stop the ringing. Press“PROG”to start the clock setting with
current time and press “TIMER”, the heater will start the same program setting as before power outage .
Note: The heater has a memory function, user should always re-check the clock setting with current time when there
is power outage occurred, otherwise, the heater will work in the same program, but wrong time.
Termostaten kan låses ved å holde inne både "+" og "-" knappene i 3 sekunder. Gjenta samme fremgangsmåte for
å låse opp termostaten igjen.
The thermostat could be locked by holding down both “+”and “-“ buttons for 3 seconds. Repeat the same procedure
to unlock the thermostat again.
Trykk på "AV/PÅ" i 5 sekunder, ovnen vil gå tilbake til standardinnstillingen.
Press “ON/OFF” for 5 seconds, the heater will revert to default setting.
Ovnen bør settes på maksimal temperatur 30 minutter for å brenne elementet rent. Noe lukt kan oppstå når dette gjøres.
The heater should be set to maximal temperature for 30 minutes to burn the element clean. Some smell may occur.
Åpentvinduminne
Window open remind
Strømbruddpåminnelse
Power cut remind
Barnesikring
Child Lock
Tilbakestill termostaten til
standardinnstillingen
Reset thethermostat to
default setting
Informasjon første gangs bruk
Information for first time use
680mm
360mm
480mm
360mm
580mm
360mm

may
pos-
-sible
5401373
5401373

Information requirment for the electric local space heaters
Model identifier(s): 5401370 / WBL0636-600
ItemSymbolValue Unit Item Unit
lacolegarotscirtcelerof,tupnitaehfoepyTtuptuotaeH
space heaters only (select one)
Nominal heat output Pnom 0.5-0.6 kW manual heat charge control, with
integrated thermostat No
Minimum heat output
(indicative)Pmin 0.50 kW manual heat charge control with room and/or outdoor temperature feedbackNo
Maximum continuous heat
output Pmax,c 0.60 kW electronic heat charge control with room and/or outdoor temperature feedbackNo
Auxiliary electricity
consumption
fan assisted heat output No
At nominal heat output elmax N/A kW
Type of heat output/room temperature control
(select one)
At minimum heat outputelmin N/A kW single stage heat output and no room
temperature controlNo
In standby modeelSB0.00016 kW Two or more manual stages, no room
temperature controlNo
with mechanic thermostat room
temperature controlNo
with electronic room temperature control No
electronic room temperature control plus
day timer No
electronic room temperature control plus
week timerYes
Other control options (multiple selections
possible)
room temperature control, with presence
detection No
room temperature control, with open
window detection Yes
with distance control option No
with adaptive start control No
with working time limitation No
with black bulb sensor No
Contact detailsNAMRON AS
Nedre Kalbakkvei 88B 1081 Oslo Norway

Information requirment for the electric local space heaters
Model identifier(s): 5401371 / WBL0636-800
ItemSymbolValue Unit Item Unit
lacolegarotscirtcelerof,tupnitaehfoepyTtuptuotaeH
space heaters only (select one)
Nominal heat output Pnom0.67-0.8 kW manual heat charge control, with
integrated thermostat No
Minimum heat output
(indicative)Pmin 0.67 kW manual heat charge control with room and/or outdoor temperature feedbackNo
Maximum continuous heat
output Pmax,c 0.80 kW electronic heat charge control with room and/or outdoor temperature feedbackNo
Auxiliary electricity
consumption
fan assisted heat output No
At nominal heat output elmax N/A kW
Type of heat output/room temperature control
(select one)
At minimum heat outputelmin N/A kW single stage heat output and no room
temperature controlNo
In standby modeelSB0.00016 kW Two or more manual stages, no room
temperature controlNo
with mechanic thermostat room
temperature controlNo
with electronic room temperature control No
electronic room temperature control plus
day timer No
electronic room temperature control plus
week timerYes
Other control options (multiple selections
possible)
room temperature control, with presence
detection No
room temperature control, with open
window detection Yes
with distance control option No
with adaptive start control No
with working time limitation No
with black bulb sensor No
Contact detailsNAMRON AS
Nedre Kalbakkvei 88B 1081 Oslo Norway

Information requirment for the electric local space heaters
Model identifier(s): 5401372 / WBL0636-1000
ItemSymbolValue Unit Item Unit
lacolegarotscirtcelerof,tupnitaehfoepyTtuptuotaeH
space heaters only (select one)
Nominal heat output Pnom0.85-1.0 kW manual heat charge control, with
integrated thermostat No
Minimum heat output
(indicative)Pmin 0.85 kW manual heat charge control with room and/or outdoor temperature feedbackNo
Maximum continuous heat
output Pmax,c 1.00 kW electronic heat charge control with room and/or outdoor temperature feedbackNo
Auxiliary electricity
consumption
fan assisted heat output No
At nominal heat output elmax N/A kW
Type of heat output/room temperature control
(select one)
At minimum heat outputelmin N/A kW single stage heat output and no room
temperature controlNo
In standby modeelSB0.00016 kW Two or more manual stages, no room
temperature controlNo
with mechanic thermostat room
temperature controlNo
with electronic room temperature control No
electronic room temperature control plus
day timer No
electronic room temperature control plus
week timerYes
Other control options (multiple selections
possible)
room temperature control, with presence
detection No
room temperature control, with open
window detection Yes
with distance control option No
with adaptive start control No
with working time limitation No
with black bulb sensor No
Contact detailsNAMRON AS
Nedre Kalbakkvei 88B 1081 Oslo Norway
