Nanfone NF-368 User manual

Index
Introduction……………………………………2
Including…………………………………………3
NF-368 Diagram………………………………4
Main Features……………………………………5
LCD Indication ……………………………7
Preparation for Using…………………………9
Operation Guide ………………………………14
Functions Setting………………………………15
Key Combination…………………………………17
Menus…………………………………………19
Menu Description and Function
Setting ……………………………………………20
Other Features and Setting………………………28
Maintenance……………………………………31
Troubleshooting………………………………32
1
Introduction to NF-368
Thanks for purchasing NANFONE UHF FM
transceiver NF-368. Please read this manual
carefully to learn its functions and operations before
using.
With mini compact size, large LCD display, stable
performance, and easy-to-use feature, transceiver
NF-368 will be your best choice.
Including
Please take the radio out carefully from the package,
and check again before disposing of the packing to
make sure that all the following items are contained
in the packaging. If any of them are missing or
damaged during transportation, please contact with
the vendor for service.
2

Accessories List:
Description Unit Quantity
Antenna pc 1
Belt clip pc 1
Hand strap pc 1
Lithium battery
pack
pc 1
Charger pc 1
User Manual pc 1
Earphone pc 1
Warranty card pc 1
pc
QC passed card 1
3
ĉ
.NF-368 Diagram


ƻ

ƻ
ƻ 
ƻ

ƻ
ƻ ƻ 
ƻ

ƻ
ƻ
 ƻ  
ƻ
 ƻ  
ƻ
 
ƻ
 
ƻ
 
1. Battery snap; 2.Antenna; 3.Volume knob;
4.Coded selector; 5.PTT button; 6.Power supply jack;
7.Indicator light; 8.Monitor/FM radio; 9.FUN key;
10.MENU key; 11.MR key; 12.Power control button;
13.MIC jack; 14.Speaker; 15.Hand strap hole;
16.Earphone jack
4

Ċ
.Main Features
1.Easy operation following menus with clear LCD
display
2.Battery: 3.7V 1200mAh rechargeable Lithium
battery
3.Frequency: 400MHz470MHz
4.Wide/Narrow band selectable˖25KHz/12.5KHz
5.TX output power˖High˖2W,Low˖0.5W
6.CTCSS˄40˅and DCS˄82˅
7.Memory channels˖99 memory channels˄1
emergency channel˅
8.TOT (Time-Out-Timer)˄OFF, 30s, 60s, 90s,
120s, 150s, 180s˅
9.VOX function˄OFF/1/2/3˅
10.Audio-call ˄1750KHz˅function
11.Emergency channel operating ˄Emergency
Alarm˅
12.Busy channel lockout˄BCLO˅
5
13.Dual-frequency standby
14.CTCSS
15.DCS
16.Code
17.Scan˖VFO scan/channel scan
18.Squelch level setting˄level 0-4˅
19.Signal/power indicator table
20.Background light ON/OFF
21.Power-save function
22.Monitor function
23.Automatically check when powered on and
then display voltage
24.Low battery alert
25.Keypad indicate tone
26.Keypad locked
27. APO˄Automatically Power Off˅
28. FM radio function ˄frequency range: 87.500 
108.000MHz˅
6

ċ
. LCD Indication
No. Icon Description Operation
Memorize the
using memory
channel No. in
call-out state
[MR]1
Use menu 02 and
03
CTCSS2
Use menu 02 and
03
DCS3
Activate another
function [F]5
7
Dual
frequency
standby
6 Use menu 01
7 High/Low power Use menu 13
Power save
function Use menu 88
9 APO Use menu 10
10 Keypad locked [F]+[MODE]
Keypad indicate
tone Menu 911
12 Low battery alert
Wide/Narrow
band setting
WMenu 1413
Č
.Preparation Before Using
Install belt clip overlay
Install the belt clip overlay on the back of NF-368
8

rechargeable battery case as following (Usually, it
has been installed well in factory.).
Install Lithium battery pack
Put the original Lithium battery pack into the
transceiver correctly as following picture shows.
9
Install rear case
Install the battery rear case properly as following
picture.
Fix the rear case
As picture, pull up the button in “lock” direction to
avoid the rear case sliding.
10

Install the belt clip
Install the belt clip as picture.
Install the antenna
Install the antenna as picture and rotate it clockwise
till tight.
11
Charge
The battery pack is without power when finished,
and please charges it before using.
When used for the first time after purchased or
stored over two months, the capacity of battery
pack is less than normal. However, it will return
normal after charged and discharged for five times.
Please connect charger to the transceiver
properly as following picture.
12

V. Operation Instruction
Key functions:
䱰⹡ TX key. Hold this key to transmit and
release after transmission finished.
377EXWWRQ
Key for powering ON/OFF,
transceiver will be turned on or turned off by pressing and
holding this key for 2 seconds.
POWER key
Quickly press to monitor, and hold it to
turn on or turn off the FM radio.
021,725)0
Thisknobisformaintuning,whichisfor
operating frequency setting, function menu selecting and
other adjustment.
',$/NQRE
Volume control knob. Rotate it clockwise to
turn up.
92/NQRE
Quickly press it to activate another function,
and hold it to make emergency call.
)NH\
Setting functions via MODE key.
02'(NH\
13
Quickly press it to select VFO mode or
channel mode, and hold it to memorize channels.
05NH\
VI. Functions Setting
˄1˅Press [MODE] key to enter [01]DW dual
frequency standby selecting.
˄2˅Press [MODE] key and then rotate the “DIAL”
knob clockwise or withershins to enter [02] CODE
selecting.
˄3˅Press [MODE] key and then rotate the “DIAL”
knob clockwise or withershins to enter [03] CTCSS
setting.
˄4˅Press [MODE] key and then rotate the “DIAL”
knob clockwise or withershins to enter [04] DCS
setting.
˄5˅Press [MODE] key and then rotate the “DIAL”
14

knob clockwise or withershins to enter [05] SQL
level setting.
˄6˅Press [MODE] key and then rotate the “DIAL”
knob clockwise or withershins to enter [06] BCLO
busy channel lockout setting.
˄7˅Press [MODE] key and then rotate the “DIAL”
knob clockwise or withershins to enter [07] LIGHT
turn on or turn off the background light.
˄8˅Press [MODE] key and then rotate the “DIAL”
knob clockwise or withershins to enter [08] SAVE to
activate power-save function.
˄9˅Press [MODE] key and then rotate the “DIAL”
knob clockwise or withershins to enter [09]K TONE
to turn on or turn off the keypad tone.
˄10 ˅Press [MODE] key and then rotate the
“DIAL” knob clockwise or withershins to enter
15
[10]APO to set the automatically power off function.
˄11 ˅Press [MODE] key and then rotate the
“DIAL” knob clockwise or withershins to enter
[11]TOT to set the TX time limit.
˄12 ˅Press [MODE] key and then rotate the
“DIAL” knob clockwise or withershins to enter
[12]VOX to adjust the VOX function.
˄13 ˅Press [MODE] key and then rotate the
“DIAL” knob clockwise or withershins to enter
[13]POWER to select high or low power output.
˄14 ˅Press [MODE] key and then rotate the
“DIAL” knob clockwise or withershins to enter
[14]HLF DEV to select wide or narrow band.
16

VII. Functions of Key Combination
1
ˊ
[F]+[MODE] for keypad locked
Press [F] key and the icon will be showed on
the bottom-left corner of LCD, and then press
[MODE] to lock the keypad. Repeat above steps to
unlock the keypad. icon will display on the
LCD when keypad locked.( Operation of MODE key,
MR key and DIAL key will be invalid after keypad
locked. )
2
ˊ
[F]+[MR] for scanning
Frequency scanning in VFO mode
˖
Press [F] key
and then press [MR] button to start scanning
(channel spacing is 12.5KHZ)when there is a
icon on bottom left corner of the LCD; short press
[MR],[MODE]or [PTT] button to stop scanning
(the frequency will stay at current frequency).
Channel scanning in channel mode: Press [F] key
and then press [MR] button to start scanning when
there is a icon on bottom left corner of the
17
LCD. Rotate the code selector clockwise to scan in
ascending order, and rotate the code selector
withershins to scan channels in descending order. To
stop scanning, please press [MR],[MODE]or [PTT]
button to stop scanning (the channel will stay at
current channel).
3
ˊ
[F]+[DIAL] Wide Range Frequency Tuning
Press [F] key and then rotate the [DIAL] knob to
start tuning at 1MHz space when there is a
icon on bottom left corner of the LCD. Rotate the
code selector clockwise to tune in ascending order,
and rotate it withershins to adjust in descending
order.
4. [PTT] + [MON / FM] for Audio Call
Press [PTT] and then [MONITOR / FM] buttons to
start Audio Call (1750 KHz) function: The
[MONITOR / FM] key to exit.
18

VIII. Menu Description
No. Display & Description Setting Contents
DW ˄Dual-frequency
standby setting˅OFF--ON1
2 CODE˄Code setting˅OFF/CTCSS/DCS
3 CTCSS˄CTCSS setting˅67Hz—254.1HZ
4DCS˄DCS setting˅023N---754N
SQL ˄Squelch level
setting˅0---45
BCLO˄Busy channel lockout
setting˅OFF--ON6
LIGHT˄Background light
setting˅OFF--ON7
SAVE ˄Power-save
function setting˅OFF--ON8
KTONG˄Keypad locked
or unlocked setting˅OFF--ON9
APO ˄Automatically
power off function setting˅OFF—ON(30 minutes)
10
OFF-15/30/45/60/75/
90/......./600S
11 TOT ˄TX time limit˅
19
VOX ˄VOX function
setting˅OFF, level 1-312
POWER (High/Low power
setting˅HIGH--LOW13
HLFDEV˄Wide/Narrow band
selection˅OFF--ON14

đ
. Menu Function Description and
Setting
1. Dual-frequency function (DW)
It is dual channels monitor scanning function, via
which it can inspect a custom monitoring channel
(channel 00) at VFO mode and channel mode
operation. Namely: monitor and scan the current
channel frequency and 00-channel frequency. If
there is signal received at monitor channel, the scan
stop at that frequency.
Following is process to start dual-channel
monitoring function:
1) Press [MODE] key, and then tune [DIAL] knob to
enter the menu 01. And DW is displayed.
20

2) Press [MODE] key again to enter the menu.
3) Clockwise or counterclockwise rotate [DIAL]
knob to select: OFF to turn off dual-frequency
standby, and ON to activate dual-frequency standby
function.
4) After selected, press [MODE] key to confirm.
5) Press [PTT] key to save the new settings and exit
to normal operating mode.
2. CODE selection
This feature allows your radio keeping quiet when
there is no specific call. Please set it as following
steps:
1) Press [MODE] key, and then tune [DIAL] knob to
enter menu 02. And CODE is showed.
2) Press [MODE] key again to enter the menu.
3) Clockwise or counterclockwise rotate [DIAL]
knob to select: OFF / CTCSS / DCS.
4) Press [MODE] key to confirm after selected.
5) Press [PTT] key to save the new settings and exit
to normal operating mode.
3. CTCSS code selection
The audio system called "consecutive single-audio
squelch system ". Please set the CTCSS as following
steps:
21
1) Press [MODE] key, and then tune [DIAL] knob to
enter menu 03. And CTCSS displays.
2) Press [MODE] key again to enter the menu.
3) Clockwise or counterclockwise rotate [DIAL]
knob to select: 67Hz--254.1Hz (40 groups totally).
4) Press [MODE] key again to confirm after
selected.
5) Press [PTT] key to save the new settings and exit
to normal operating mode.
4. DCS code setting
This is a relatively new anti-jamming advanced
audio system which is better than CTCSS. Please set
the DCS as following steps:
1) Press [MODE] key, and then tune [DIAL] knob to
enter menu 04. And DCS displays.
2) Press [MODE] key again to enter the menu.
3) Clockwise or counterclockwise to rotate [DIAL]
knob to select: 023N-754N (totally 82 groups).
5. SQL level setting
Squelch system can eliminate background noise
when there is no signal received, which not only
make it more comfortable at standby mode, but also
significantly reduces the standby power
consumption. Please set the squelch level following
22

steps below:
1) Press [MODE] key and then tune [DIAL] knob to
enter menu 05. And SQL is showed.
2) Press [MODE] key again to enter the menu.
3) Clockwise or counterclockwise rotate [DIAL]
knob to select: 0/1/2/3/4 (usually set as 1, which is
the best sensitivity point).
4) Press [MODE] key again to confirm after
selected.
5) Press [PTT] key to save the new settings and exit
to normal operating mode.
6. Busy channel lockout setting (BCLO)
BCLO function is for prohibiting transmitter when
there are other signals to prevent breaking other
people's communications inadvertently. Please set it
as following steps:
1) Press [MODE] key and then tune [DIAL] knob to
enter menu 06. And BCLO is displayed.
2) Press [MODE] key again to enter the menu.
3) Clockwise or counterclockwise rotate [DIAL]
knob to select: ON or OFF.
4) After selected, press [MODE] key again to
confirm.
5) Press [PTT] key to save the new settings and exit
23
to normal operating mode.
7. LIGHT--Background Light ON / OFF
Selection
1) Press [MODE] key and then tune [DIAL] knob to
enter menu 07. And LIGHT displays.
2) Press [MODE] key again to enter the menu.
3) Clockwise or counterclockwise rotate [DIAL]
knob to select: ON / OFF.
4) Press [MODE] key again to confirm after
selected.
5) Press [PTT] key to save the new settings and exit
to normal operating mode.
When "OFF" is selected, the backlight will
automatically turn off as the transceiver is at Sleep
mode.
8.SAVE -- Power-saving function
The transceiver has a very important automatic
power-saving receive function, which allows the
radio to enter sleep state and wake up periodically to
check and receive signal. If there is call in the
channel, NF368 will stay at active status and then
get back to sleep state after call finished. This
feature can reduce battery consumption effectively.
Following is the steps to activate the power-saving
24

function:
1) Press [MODE] key and then tune [DIAL] knob to
enter menu 08. And SAVE displays.
2) Press [MODE] key again to enter the menu.
3) Clockwise or counterclockwise rotate [DIAL]
knob to select: ON / OFF.
4) Press [MODE] key again to confirm after
selected.
5) Press [PTT] key to save the new settings and exit
to normal operating mode.
(ON is to activate the power-saving mode: LCD
shows " " power-saving icon and the
transceiver will enter power-saving mode without
signal receiving in 10 seconds at standby state. OFF
is to turn off power-saving feature.)
9. KTONE – Keypad tone setting ON / OFF
If the keypad tone causes inconvenience (especially
operating in the quiet room), it can cancel easily as
following steps:
1) Press [MODE] key and then tune [DIAL] knob to
enter menu 09. And KTONE displays.
2) Press [MODE] key again to enter the menu.
3) Clockwise or counterclockwise rotate [DIAL]
knob to select: ON / OFF.
25
4) Press [MODE] key again to confirm after
selected.
5) Press [PTT] key to save the new settings and exit
to normal operating mode.
(ON is for activating the keypad tone, and LCD
displays icon . OFF is to turn off keypad tone).
10. APO Automatically Power Off setting
Automatically Power OFF (APO) function refers to
the transceiver turns off automatically without any
operation when there is no signal received in 30
minutes, which helps extend the battery life.
Following is steps to start the APO function:
1) Press [MODE] key and then tune [DIAL] knob to
enter menu 10. And APO displays.
2) Press [MODE] key again to enter the menu.
3) Clockwise or counterclockwise rotate [DIAL]
knob to select: ON / OFF.
4) Press [MODE] key again to confirm after
selected.
5) Press [PTT] key to save the new settings and exit
to normal operating mode.
11. TOT – Time Out Timer
Time Out Timer (TOT) feature is to limit the
continuous launching over time by a safety switch.
26

Please follow below steps to activate TOT function:
1) Press [MODE] key and then tune [DIAL] knob to
enter menu 11. And TOT displays.
2) Press [MODE] key again to enter the menu.
3) Clockwise or counterclockwise rotate [DIAL]
knob to select: ON / OFF.
4) Press [MODE] key again to confirm after
selected.
5) Press [PTT] key to save the new settings and exit
to normal operating mode.
12. VOX – Voice-operated Setting
VOX function allows launching by voice only
without pressing PTT key and launching stop
automatically once speak stops. Following is VOX
setting process:
1) Press [MODE] key and then tune [DIAL] knob to
enter menu 12. And VOX displays.
2) Press [MODE] key again to enter the menu.
3) Clockwise or counterclockwise rotate [DIAL]
knob to select: ON / OFF.
4) Press [MODE] key again to confirm after
selected.
5) Press [PTT] key to save the new settings and exit
to normal operating mode.
27
Note: 3 = high sensitivity, which is used when there
is only low background noise.
2 = Medium sensitivity, which is used in most
situations.
1 = low sensitivity, which is used in situation with
high background noise.
13. POWER -- Power Selection
Power of NF-368 can be set as high or low power
according to actual using range and surrounding to
reduce battery consumption. Following is process of
high and low power settings:
1) Press [MODE] key and then tune [DIAL] knob to
enter menu 13. And POWER displays.
2) Press [MODE] key again to enter the menu.
3) Clockwise or counterclockwise rotate [DIAL]
knob to select: ON / OFF.
4) Press [MODE] key again to confirm after
selected.
5) Press [PTT] key to save the new settings and exit
to normal operating mode.
(HIGH refers to high-power 2W, and LOW refers
to low-power 0.5W. When LOW is selected, the
LCD displays icon ).
14. HLF DEV -- Wide / Narrow band selection
28

In many areas, the required channel spacing is very
small, which need to reduce the modulation
bandwidth of launching to avoid interference to
adjacent channels. Please adjust settings following
steps below:
1) Press [MODE] key and then tune [DIAL] knob to
enter menu 14. And HLF DEV displays.
2) Press [MODE] key again to enter the menu.
3) Clockwise or counterclockwise rotate [DIAL]
knob to select: ON / OFF.
4) Press [MODE] key again to confirm after
selected.
5) Press [PTT] key to save the new settings and exit
to normal operating mode.
(ON is to turn on narrowband 12.5KHz, and OFF is
to activate wideband 25KHz. When OFF is selected,
there is a Wicon display on the bottom left corner of
the LCD.)
X. Other features and settings
1. Channel memorization:
A) Conventional channels memorization, numbered
from 01-99.
B) One special memorized channel (emergency
29
channel), No. 00.
Channel memorizing steps are as follow:
1) At VFO mode, select the required frequency, as
well as setting the required CTCSS and DCS.
2) Hold the [MR] key for 2 seconds till display
channel 00-99 flashes on the LCD. And then rotate
[DIAL] knob and select a channel among 00-99
channels.
3) Press [MR] key again to store frequency and other
data into the channel.
4) It is still working at the frequency mode (VFO) at
this time. Meanwhile, repeating above steps to input
another frequency and save it to other channels.
(Note: To launch and receive different frequency
needs to programmed with Frequency Programmed
Software)
2. Emergency channel operations (emergency
calling function)
NF-368 is built-in a very useful “emergency call"
feature. Hold the [F] key for over 1 second and the
30

"emergency call" function can be activated. At this
time:
A) The radio switch to the most commonly used
channel (OO-channel) to launch.
B) The red indicator light flashes.
C) The radio releases loud alarm sound.
D) This function can be turned off by pressing
launch button.
When come across danger while walking
outdoors, this function allows alarming to the
family quickly. Loud alarm sound may set back
attack from gangster and avoid hurt.
3. FM Radio (FM)
1) Hold [MONITOR / FM] button once for over 2
seconds to enter FM radio receiving mode.
2) Rotate [DIAL] knob to tune the frequency (the
frequency range is among 87.5 ~ 108.0MHz, and
step is 100KHZ).
3˅Hold the [MONITOR/FM] key for over 2
seconds again or press [PTT] button to exit FM
31
radio mode.
ƾAt FM radio state, walkie-talkie function retains
priority always, which means FM radio function
exits automatically and turns to transceiver
communication once there is same frequency signal
received at FM radio receiving mode.
ƾAt FM radio frequency mode: FM radio channel
memorizing mode can be entered by pressing [MR]
key (there is 15 stored channels)
ƾFM Radio Scanner
ķScanning frequency: at FM radio frequency mode,
press [F] key and then [V / M] key is for whole
frequency scanning: start from the current frequency
to scan the whole frequency range. Clockwise rotate
the encoder to scan from low to high and
anti-clockwise rotate to scan in descending order. It
stays when there is signal scanned. Rotate the
encoder to continue to scan up or down, and press
any key to exit.
ĸChannel scanning: at FM radio frequency mode,
32

press [V / M] key once to enter channel state. And
press [F] and [MR] keys to enter channel scanning.
Clockwise rotate the encoder to scan channels from
low to high and anti-clockwise rotate to scan in
descending order. It stays when there is signal
scanned. Rotate the encoder to continue to scan up
or down, and press any key to exit.
radio
ƾ
-channel memorizing (The same as
transceiver channel memorization)
ƹ
Maintenance
Transceiver NF-368 you purchased is an exactitude
design electronic products and please use it carefully.
Following maintenance ways may help extend its
lifetime.
1. Please don’t try to disassemble the transceiver
because non-technicians’ processing may cause
damage to the device.
2. To use stable power supply, please connect the
specified USB cable to the DC jack of the
transceiver.
33
3. Please don’t put the transceiver in sun or hot place
for long time, because the high temperature will
shorten use life of electronic parts and cause
distortion to plastic parts.
4. Please keep the transceiver dry, because rain and
moisture will erode the electronic circuits.
5. Please power off the transceiver and remove its
battery pack immediately once there is peculiar
smell or smog emit from the device.
ƹ
Troubleshooting
Trouble Solution
zThe battery pack has
been exhausted. Please
change a new battery or
recharge the battery.
No power
zThe battery pack may be
not installed correctly.
Please install it again.
The battery used
out soon after
recharged.
zThe use-life of the battery
is over, please change new
battery.
Unable to talk with zPlease check the
34

other members in
the same group.
frequency and CTCSS/DCS
you use are the same as
other members use in the
same group.
zThe distance between you
and other group members
may be too far. Please
check if you are in the
cover range of other group
transceivers.
zPlease change your
CTCSS/DCS NO. And it
has to change all signal
sound of the group
transceivers.
Other (not from
group members)
sound heard in
channels.
35
