NANLITE PavoTube II 6C User manual

USER MANUAL
PavoTube $6C
RGBWW LED Tube Light
Guangdong NanGuang Photo&Video Systems Co., Ltd

1
Color Temperature: 2700K-7500K + G/M Adjustment
CRI: Average 95
TLCI: Average 97
Number of LEDs: 166 pcs
LED Power: 6W x 5
Rated Input: 5V 2A
Lithium Battery: 3.7V/2200mAh, 8.14Wh
Technical Data
Product Diagram
PavoTube $6C RGBWW LED Tube Light

2
77
1 2 3 4
Product Details
1. Display: Menu and option display.
2. Mode: Switch between modes CCT, HSI, Effects and Menu.
3. " " & " " : Increase or decrease settings, supports long/short press.
4. Power: Power on/off.
5. Switch: Switch selected options.
6. USB Type C port: DC input & firmware updates.
7. 1/4-20 mount: Standard mounting fixture.
Detail Description
65

3
②Buiilt in battery automatically powers unit once charged and unplugged from a power source.
#1 - Lay flat #2 - Standing #3 - Handheld #4 - Hanging
Connecting with USB adapter. Connecting with power bank.
1. Powering the unit.
2. Installation.
①Horizontal & Vertial standing options. (see #1 and #2)
②Handheld option. (installing provided safety strap advised see #3)
③Hanging solution. (see #4)
①Connecting the fixture with a USB cable, then connect with a USB adapter or powerbank (recommended 5V 2A
or above - not included).
Usage

4
Irony Surface Attach the fixture on it.
Use gaffer tape to stick iron plates on the
nonferrous surface
Attach the fixture on iron plates
④There are built-in magnets in both ends, allows you to simply attach the fixture on irony surface, or using iron
plates to attach the fixture on other nonferrous surface .
Note: Please use gaffer tape to stick iron plates on the nonferrous sureface before attaching the fixture.

5
Mounting to tripod. Mounting to a light stand. Mounting to a ball head.Mounting to a clamp.
1. Long press 'power' button to turn on, 'NANLITE' logo will be displayed on start up.
How to Operate
3. 2.4Ghz wireless control and bluetooth control.
With a Built-in 2.4Ghz receiver, the PavoTube $6C is able to be controlled remotely by using the optional WiFi
controller (sold seperately). The PavoTube $6C also has built-in bluetooth module for more control option.
⑤1/4-20 mounting options （Note: Tripod, light stand, clamp and ball head are not included.）
⑥Waterproof bag is an optional accessory, fixture must be setup before placed in bag or controlled via remote options.

6
CCT
DIM: 100%
CCT: 5700K G/M:0
Note: In effect mode, the adjustable range of DIM, CCT and G/M are the same as CCT mode.
CCT
CCT: 5600K G/M:0
DIM: 100%
Battery indicator Time remaining
CCT
HSI
EFFECT
MENU
Press "Switch" button to select from DIM, CCT and G/M.
Press " " " " to choose needed value.
2700K
.
.
.
.
.
7500K
CCT
CCT: 5600K G/M:0
DIM: 100%
CCT
DIM: 100%
CCT: 5600K G/M:0
CCT
DIM: 100%
CCT: 5600K G/M:0
2. "Mode" button: Press to switch between modes - CCT, HSI, Effect and Menu.
①In CCT mode, press “Switch” button to select from DIM, CCT and G/M, press" " and " " to adjust the value
of DIM, CCT and G/M.
DIM range: 0% --- 100% CCT range: 2700K --- 7500K G/M range: -50 --- +50.
6.0h
6.0h 6.0h
6.0h 6.0h

7
EFFECT
DIM: 000%-100%
FX: WELDING
HSI
HUE: 001 SAT:100
DIM: 100%
Press "Switch" button to select from DIM, HUE and SAT.
000
.
.
.
.
.
360
HUE LOOP
.
.
.
.
WELDING
HSI
HUE: 000 SAT:100
DIM: 100%
HSI
HUE: 000 SAT:100
DIM: 100%
HSI
HUE: 000 SAT:100
DIM: 100%
EFFECT
FX: HUE LOOP
DIM: 100%
②In HSI mode, press "Switch" button to select from DIM, HUE and SAT, press" " and " " to adjust the value of
DIM, HUE and SAT.
DIM range: 0% --- 100% HUE range: 0 --- 360 SAT range: 0 --- 100.
③In Effect mode, pres " " " " to select special effect that needed, Pavotube $6C has built-in effects including
Hue Loop, CCT Loop, INT Loop, CCT Flash, HUE Flash, CCT Pulse, Hue Pulse, Storm, Police Car, TV,
Paparazzi, Candle/Fire, Disco, Bad Bulb, Firework, Explosion and Welding.
Note: In effect mode, the adjustable range of DIM, CCT and G/M are the same as HSI mode.
Press " " " " to choose needed value.
Press " " " " to choose needed special effect.
6.0h 6.0h
6.0h6.0h
6.0h6.0h

8
EFFECT
FX: HUE LOOP
DIM: 100%
EFFECT
HUE1: 000 HUE2:360
SPD: 08S
EFFECT
HUE1: 000 HUE2:360
SPD: 08S
EFFECT
HUE1: 360 HUE2:360
SPD: 08S
000
.
.
.
.
.
360
EFFECT
FX: CCT LOOP
DIM: 100%
EFFECT
SPD: 08S
CCT: 3200K-5600K
(1) HUE LOOP
Press "Switch" button to select from DIM, HUE 1, HUE 2 and Speed(SPD), press " " and " " to adjust the
value of DIM, HUE 1, HUE 2, and Speed(SPD).
Speed range: 02S...30S.
Press "Switch" button to select from DIM, HUE 1, HUE 2 and SPD.
Press " " " " to choose needed value.
(2) CCT LOOP
Press “Switch”button to select from DIM, CCT 1, CCT 2, and Speed (SPD), press " " and " " to adjust the
value of DIM, CCT 1, CCT 2, and Speed (SPD).
Speed range: 02S...30S.
Press "Switch" button to select from DIM, CCT 1, CCT 2 and SPD.
6.0h 6.0h
6.0h 6.0h
6.0h 6.0h

9
EFFECT
SPD: 09S
CCT: 3200K-5600K
EFFECT
SPD: 08S
CCT: 3200K-5600K
02S
.
.
.
.
.
30S
EFFECT
FX: INT LOOP
DIM: 000%-100%
EFFECT
CLR: CCT CCT:5600K
SPD: 08S
EFFECT
CLR: CCT CCT:5600K
SPD: 08S
EFFECT
CLR: HUE HUE:000
SPD: 08S
HUE
CCT
(3) INT LOOP
Press "Switch" button to select from DIM 1, DIM 2, speed(SPD) and color(CLR), press " " and " " to adjust
the value of DIM 1, DIM 2 , speed(SPD) and color(CLR).
Speed range: 02S...30S. Color includes CCT and HUE.
Press " " " " to choose needed value.
Press "Switch" button to select from DIM 1, DIM 2, SPD and CLR.
Press " " " " to choose needed value.
6.0h 6.0h
6.0h 6.0h
6.0h 6.0h

10
EFFECT
FX: CCT FLASH
DIM: 100%
EFFECT
CCT: 5600K G/M:0
INTVL: 1.0S
EFFECT
CCT: 5600K G/M:0
INTVL: 1.0S
EFFECT
CCT: 5600K G/M:0
INTVL: 1.1S
0.1S
.
.
.
.
.
10.0S
EFFECT
FX: HUE FLASH
DIM: 100%
EFFECT
HUE: 000 SAT: 100
INTVL: 1.0S
(4) CCT FLASH
Press "Switch" button to select from DIM, CCT, G/M and INTVL, press " " and " " to adjust the value of DIM,
CCT, G/M, INTVL.
INTVL range: 0.1S....10.0S.
(5) HUE FLASH
Press "Switch" button to select from DIM, HUE, SAT, INTVL, press " " and " " to adjust the value of DIM ,
HUE, SAT, INTVL.
INTVL range: 0.1S....10.0S.
Press "Switch" button to select from DIM, CCT, G/M and INTVL.
Press " " " " to choose needed value.
Press "Switch" button to select from DIM, HUE, SAT, INTVL.
6.0h 6.0h
6.0h 6.0h
6.0h 6.0h

11
Press "Switch" button to select from DIM, CCT, G/M, PULSES/M.
EFFECT
HUE: 000 SAT: 100
INTVL: 1.0S
EFFECT
HUE: 000 SAT: 100
INTVL: 1.1S
0.1S
.
.
.
.
.
10.0S
EFFECT
FX: CCT PULSE
DIM: 100%
EFFECT
PULSES/M: 040
CCT: 6500K G/M: 0
EFFECT
PULSES/M: 040
CCT: 6500K G/M: 0
EFFECT
PULSES/M: 041
CCT: 6500K G/M: 0
001
.
.
.
.
.
240
(6) CCT PULSE
Press "Switch" button to select from DIM, CCT, G/M, PULSES/M(minute), press " " and " " to adjust the
value of DIM, CCT, G/M, PULSES/M(minute).
PULSES/M range: 001...240.
Press " " " " to choose needed value.
Press " " " " to choose needed value.
6.0h 6.0h
6.0h 6.0h
6.0h 6.0h

12
Press "Switch" button to select from DIM, HUE, SAT, PULSES/M.
Press "Switch" button to select from DIM, CCT, INTVL.
EFFECT
FX: HUE PULSE
DIM: 100%
EFFECT
PULSES/M: 040
HUE: 000 SAT: 100
EFFECT
PULSES/M: 040
HUE: 000 SAT: 100
EFFECT
PULSES/M: 041
HUE: 000 SAT: 100
001
.
.
.
.
.
240
EFFECT
FX: STORM
DIM: 100%
EFFECT
CCT: 5600K
INTVL: 02S-06S
(7) HUE PULSE
Press "Switch" button to select from DIM, HUE, SAT, PULSES/M(minute), press " " and " " to adjust the
value of DIM, HUE, SAT,PULSES/M(minute).
PULSES/M(minute) range: 001...240.
(8) STORM
Press "Switch" button to select from DIM, CCT, INTVL, press " " and " " to adjust the value of DIM, CCT
and INTVL .
INTVL range: 01S...60S.
Press " " " " to choose needed value.
6.0h 6.0h
6.0h 6.0h
6.0h 6.0h

13
Press "Switch" button to select from DIM, COLOR and SPD.
EFFECT
CCT: 5600K
INTVL: 02S-06S
EFFECT
CCT: 5600K
INTVL: 03S-06S
01S
.
.
.
.
.
60S
EFFECT
FX: POLICE CAR
DIM: 100%
EFFECT
COLOR: RB
SPD: 050
EFFECT
COLOR: RB
SPD: 050
EFFECT
COLOR: RB
SPD: 051
001
.
.
.
.
.
100
(9) POLICE CAR
Press "Switch" button to select from DIM, COLOR and Speed(SPD), press " " and " " to adjust the value of
DIM, COLOR (B/RB/BW/RBW) and Speed (SPD).
Speed range: 001...100.
Press " " " " to choose needed value.
Press " " " " to choose needed value.
6.0h 6.0h
6.0h 6.0h
6.0h 6.0h

14
Press "Switch" button to select from DIM, CCT, G/M and SPD.
Press "Switch" button to select from DIM1, DIM2, CCT, G/M and SPD.
EFFECT
FX: TV
DIM: 000%-100%
EFFECT
SPD: 050
CCT: 5600K G/M: 0
EFFECT
SPD: 050
CCT: 5600K G/M: 0
EFFECT
SPD: 051
CCT: 5600K G/M: 0
001
.
.
.
.
.
100
EFFECT
FX: PAPARAZZI
DIM: 100%
EFFECT
SPD: 050
CCT: 5600K G/M: 0
(10) TV
Press "Switch" button to select from DIM 1, DIM 2, CCT, G/M and Speed (SPD), press " " and " " to adjust
the value of DIM 1, DIM 2, CCT, G/M and Speed (SPD).
Speed range: 001...100.
(11) PAPARAZZI
Press "Switch" button to select from DIM, CCT, G/M and Speed(SPD), press " " and " " to adjust the value
of DIM, CCT, G/M and Speed (SPD).
Speed range: 001 …100.
Press " " " " to choose needed value.
6.0h6.0h 6.0h
6.0h 6.0h
6.0h 6.0h

15
Press "Switch" button to select from DIM 1, DIM 2, CCT, G/M and SPD.
EFFECT
SPD: 050
CCT: 5600K G/M: 0
EFFECT
FX: CANDLE/FIRE
DIM: 000%-100%
EFFECT
SPD: 050
CCT: 5600K G/M: 0
EFFECT
SPD: 050
CCT: 5600K G/M: 0
EFFECT
SPD: 051
CCT: 5600K G/M: 0
001
.
.
.
.
.
100
(12) CANDLE/FIRE
Press "Switch" button to select from DIM 1, DIM 2, CCT, G/M and Speed (SPD), press " " and " " to
adjust the value of DIM 1, DIM 2, CCT, G/M and Speed (SPD).
Speed range: 001 …100.
Press " " " " to choose needed value.
Press " " " " to choose needed value.
EFFECT
SPD: 051
CCT: 5600K G/M: 0
001
.
.
.
.
.
100
6.0h 6.0h
6.0h 6.0h
6.0h 6.0h

16
Press "Switch" button to select from DIM, COLOR and SPD.
Press "Switch" button to select from DIM, CCT , G/M and SPD.
EFFECT
FX: DISCO
DIM: 100%
EFFECT
COLOR: 03
SPD: 050
EFFECT
COLOR: 03
SPD: 050
EFFECT
COLOR: 03
SPD: 051
001
.
.
.
.
.
100
EFFECT
FX: BAD BULB
DIM: 100%
EFFECT
SPD: 050
CCT: 5600K G/M: 0
(13) DISCO
Press "Switch" button to select from DIM, Color and Speed (SPD), press " " and " " to adjust the value of
DIM, Color and Speed (SPD).
Color range: 03, 06, 09, 12, 15, 18, 21, 24. Speed range: 001 …100.
(14) BAD BULB
Press "Switch" button to select from DIM, CCT , G/M and Speed (SPD), press " " and " " to adjust the
value of DIM, CCT, G/M and Speed (SPD).
Speed range: 001 …100.
Press " " " " to choose needed value.
6.0h 6.0h
6.0h 6.0h
6.0h 6.0h

17
Press "Switch" button to select from DIM, COLOR, SPD and DECAY.
EFFECT
SPD: 050
CCT: 5600K G/M: 0
EFFECT
SPD: 051
CCT: 5600K G/M: 0
001
.
.
.
.
.
100
EFFECT
FX: FIREWORK
DIM: 100%
EFFECT
COLOR: 03
SPD: 050 DECAY: 050
EFFECT
COLOR: 03
SPD: 050 DECAY: 050
EFFECT
COLOR: 03
SPD: 051 DECAY: 050
001
.
.
.
.
.
100
(15) FIREWORK
Press "Switch" button to select from DIM, Color, Speed (SPD) and Decay, press " " and " " to adjust the
value of DIM, Color, Speed (SPD) and Decay.
Color range: 03, 06, 09, 12, 15, 18, 21, 24. Speed range: 001 …100. Decay range: 001 …100.
Press " " " " to choose needed value.
Press " " " " to choose needed value.
6.0h 6.0h
6.0h6.0h
6.0h 6.0h

18
Press "Switch" button to select from DIM, CCT, G/M, SPD and DECAY.
Press "Switch" button to select from DIM 1, DIM 2, CCT, G/M, SPD and PAUSE.
EFFECT
FX: EXPLOSION
DIM: 100%
EFFECT
CCT: 5600K G/M: 0
SPD: 050 DECAY: 050
EFFECT
CCT: 5600K G/M: 0
SPD: 050 DECAY: 050
EFFECT
CCT: 5600K G/M: 0
SPD: 051 DECAY: 050
001
.
.
.
.
.
100
EFFECT
FX: WELDING
DIM: 000%-100%
EFFECT
CCT: 5600K G/M: 0
SPD: 050 PAUSE: OFF
(16) EXPLOSION
Press "Switch" button to select from DIM, CCT, G/M, Speed (SPD) and Decay, press " " and " " to adjust
the value of DIM, CCT, G/M, Speed (SPD) and Decay.
Speed range: 001 …100. Decay range: 001 …100.
(17) WELDING
Press "Switch" button to select from DIM 1, DIM 2, CCT, G/M, SPD and Pause, press " " and " " to adjust
the value of DIM 1, DIM 2, CCT, G/M, SPD and Pause.
Speed range: 001 …100. The Pause includes "OFF" and "ON". When the status is "ON", the fixture will go out.
Press " " " " to choose needed value.
6.0h 6.0h
6.0h6.0h
6.0h 6.0h

19
3. Long press the "Power" button to turn off the light.
·Lighting effects and additional functionality maybe added with future firmware releases, for details of these please
see www.nanlite.com.
Press "Switch" button to select from CH, LANGUAGE and VERSION.
EFFECT 6.0h
CCT: 5600K G/M: 0
SPD: 050 PAUSE: OFF
EFFECT
CCT: 5600K G/M: 0
SPD: 051 PAUSE: OFF
001
.
.
.
.
.
100
MENU
LANGUAGE: ENG
CH: 512
MENU
CH: 512
LANGUAGE: ENG
④Menu
Press "Switch" button to select from Channel, Language and Version, press " " and " " to set the Channel
(001…512), set the language (Chinese and English) and check the firmware version of your fixture.
Press " " " " to choose needed value.
Press " " " " to adjust needed option.
6.0h
6.0h6.0h
MENU
CH: 512
LANGUAGE: ENG
6.0h 菜单
通道：512
语言：中文
6.0h
中文
ENG
