NanoCam Plus NCP-MIRDVR522 User manual

3
CONTENTS
1.0 CAUTION ............................................................................................................................. 7
1.1 Battery Warning..........................................................................................................................8
2.0 INTRODUCTION ................................................................................................................... 8
3.0 PACKAGE CONTENTS.......................................................................................................... 9
4.0 PRODUCT OVERVIEW ........................................................................................................ 10
5.0 GETTING STARTED............................................................................................................ 11
5.1 Inserting/Removing a Micro SD Card ......................................................................................11
5.2 Installing the NCP-MIRDVR552................................................................................................12
6.0 CONNECTING THE NCP-MIRDVR552 TO POWER............................................................... 12
7.0 CONNECTING THE REVERSE CAMERA.............................................................................. 14
7.1 Installation Guide......................................................................................................................14
8.0 REVERSE CAMERA WIRING DIAGRAM .............................................................................. 15
9.0 POWERING THE MIRROR DVR ON/OFF ............................................................................. 15
10.0 PLAYING BACK RECORDED VIDEO ON A PC ...................................................................... 17
11.0 INTERFACE NAVIGATION................................................................................................... 18

4
11.1 Main Menu ................................................................................................................................18
11.2 Playback Interface ....................................................................................................................19
11.3 System Setting Menu................................................................................................................20
12.0 FREQUENTLY ASKED QUESTIONS .................................................................................... 23
13.0 WARRANTY TERMS & CONDITIONS .................................................................................. 25
14.0 NOTES ............................................................................................................................... 28

5

6

7
1.0 CAUTION
• Ensure you are using your Car DVR within your countries’ road laws. Please make sure you
are familiar with your local road legislation before use.
• Avoid leaving your Car DVR in direct sunlight for extended periods of time in an unventilated
space.
• Please set time and date before you use this device to record.
• The notifications given by the Car DVR are suggestions only, please drive to the actual
conditions.
• The system is to be used only for non-commercial use, within the limits permitted by the
relevant laws.
• Avoid using the Car DVR in the vicinity of any devices that emit radio interference (eg.
Microwave Ovens).
• It is considered normal operation for the Car DVR to get warm during use.

8
1.1 BATTERY WARNING
• Always power and charge the Car DVR using the provided 12/24V adapter. Improper
charging of the Car DVR may result in failure of the internal battery.
• Never dismantle the Car DVR or expose the internal battery.
• Do not dispose of the Car DVR in fire.
• Dispose of the Car DVR observing local regulations being mindful of the internal battery.
• Do not attempt to replace or expose the internal battery.
2.0 INTRODUCTION
Thank you for purchasing a NanoCam Plus Car Mirror DVR. We are certain that our product
will give you trouble free operation while providing you with a safety feature that enhances
your driving experience. Our products, like most after-market safety enhanced devices,
are designed to assist and aid the driver, not to replace the manual function of the person
operating the vehicle. Please read through these instructions before attempting to install this
product.
For the latest manual and product updates, please visit our website at
www.nanocamplus.com.au or www.nanocamplus.co.nz

9
3.0 PACKAGE CONTENTS
Rubber Fasteners 8M Rear Camera Cable 3M VHB Adhesive
Rear Camera
Mounting Screws
User Guide
DVR Mirror Rear Camera 12/24V Adapter

10
4.0 PRODUCT OVERVIEW
1. Power/Display Off Key
2. Touch Panel/Display
Screen
3. MIC
4. GPS Port (Not applicable
in this model)
5. Micro SD Card Slot
6. AV In (Rear Camera)
7. Power USB Port
8. Camera Lens
9. Speaker
10.Reset Key
*Note: Micro SD is not included and
must be purchased seperately.
18
2
4567
3
910

17
10.0 PLAYING BACK RECORDED VIDEO ON A PC
To playback video files on your PC it is recommended to connect the Micro SD card (not
included) directly to your PC using either a USB Micro SD card reader (not included) or if your
PC has a SD card slot, a Micro SD/SD Card converter (not included). Once the Micro SD card
is connected it should appear as a removable storage device. It is recommended that you
transfer video files that you want to playback to a folder on your computer before attempting
to playback. This will reduce any delay in playback.
