nanometer lighting nanoflex Operating and safety instructions

Installation & Maintenance Guide
This guide provides instruction and tips for installing and caring for your
NanoFlex flexible linear luminaires, including diagrams and steps for the
various surface and pendant mounts available.
1/24/2024

YOU WILL NEED:
Screwdrivers
Pencil
Level
Tape measure
Utility knife
Depending on the location of the install site, a ladder or scissor lift
may be required for the product and the installers.
1/24/2024
CLEANING NANOFLEX
NanoFlex fixtures are low-maintenance and easy to clean.
Simply use a soft cloth or tissue and glass cleaner to remove
dust and scuff marks from the NanoFlex lens.
Installation & Maintenance Guide

FIELD CUTTING
1/24/2024
ATTACHING OVERLAP CAPS
Installation & Maintenance Guide
Measure the NanoFlex fixture to the desired length and cut using a utility
knife.
Attach provided overlap caps using silcone glue. Follow the glue
instructions for bonding and setting times.
When cutting NanoFlex fixtures in the field, please first refer to
the spec sheetto ensure correct cut increments to avoid damaging
the LEDs and wiring.
Please also note that some NanoFlex fixtures are only cuttable at exact
locations indicated with a dashed line. Consult manufacturer for additional
information if needed.

1/24/2024
SURFACE MOUNT
Installation & Maintenance Guide - Dual Bend
11.8”
TECHNICAL SPECS
Minimum Bending Diameter
Input Voltage 120-277AC -Remote Power Required
Maximum Twist Degree 360° / 39.4 in.
Beam Angle 120°
Ambient Temperature IP67 -4°F to 113°F
10
16
20
23
4.72”
11.8”
11.0”
11.0”
4.72”
7.87”
4.72”
Type TOP BEND SIDE BEND
MOUNTING ACCESSORIES
FLEXIBLE CHANNEL
CONTINUOUS CHANNEL
METAL CLIP
CONTINUOUS CONCEALED
WIRE CHANNEL
Recommended 12” spacing
between clips.
16
0.89”
0.94” 1.00”
0.89”
YX
20
23
0.49”
0.83” 0.71”
0.47”10
16
0.94”
1.04” 1.48”
1.39”
YX
20
23
0.49”
0.75” 1.21”
0.97”10
16
0.87”
0.98” 1.04”
0.83”
YX
20
23
0.49”
0.67” 0.69”
0.47”10
16
0.94”
1.04” 0.98”
0.89”
YX
20
23
0.49”
0.75” 0.71”
0.47”10
Recommended for back
feed.

Attach clips to mounting surface. We recommend using a clip every 12”
Press Dual Bend fixture firmly into the clips.
1/24/2024
SURFACE MOUNT
SURFACE MOUNTING
Installation & Maintenance Guide - Dual Bend
METAL CLIP
FLEXIBLE CHANNEL
If required, route into mounting surface per profile channel dimensions.
Secure channel with mounting screws. Attach flexible channel to the
mounting surface, bending to the desired pattern. Press Dual Bend fixture
firmly into the channel.
When arranging clips or flexible channel for
mounting, be sure not to exceed the minimum bend
radius of the fixture. Doing so may damage the LEDs.

Cut aluminum channel to desired length and attach to mounting surface.
Press Dual Bend fixture into the channel.
1/24/2024
SURFACE MOUNT
SURFACE MOUNTING
Installation & Maintenance Guide - Dual Bend
CONTINUOUS CONCEALED WIRE CHANNEL
CONTINUOUS CHANNEL
Cut aluminum channel to desired length and attach to mounting surface.
Press Dual Bend fixture into the channel. The concealed wire channel is
recommended for fixtures with back feeds.

1/24/2024
Installation & Maintenance Guide
POWERBOX DIAGRAM
Provided standard 10’ 18 AWG leader.
Driver can be remoted at various
maximum distance.
Distance will vary with load; please
verify before release.
14
Distance (ft.)
Wire Size (AWG)
18 25
50
10 100
Data based on a Class 2 load.
REMOTE WIRING DIAGRAMS
STATIC WHITE
TUNABLE WHITE
RGBW
Refer to NanoControls Spec Sheets for Pixel Controlled wiring diagrams.
