Napa Carlyle Tools 791-5260A User manual

791-5260A 12/19/18
Capacity ............................................................ 1,250 lbs.
Base size ...................................................... 17.5" x 14.6"
Height.............................................................................7"
Product Weight.................................................... 48.4 lbs.
Shipping Weight .................................................. 50.6 lbs.
SPECIFICATIONS
1,250 LBS. CAR DOLLIES (PAIR)
791-5260A791-5260A
S
A
F
E
T
Y
S
T
A
N
D
A
R
D
C
O
M
P
L
I
E
S
I
T
H
W
ASME PASE-2014

791-5260A 2 12/19/18
OPERATING MANUAL FOR 791-5260A
WARNING INFORMATION
This is the safety alert symbol. It is used to alert you
to potential personal injury hazards. Obey all safety
messages that follow this symbol to avoid possible
injury or death.
IMPORTANT: READ THESE INSTRUCTIONS BEFORE OPERATING
BEFORE USING THIS DEVICE, READ THIS MANUAL COMPLETELY AND THOROUGHLY, UNDERSTAND ITS OPERATING
PROCEDURES, SAFETY WARNINGS AND MAINTENANCE REQUIREMENTS.
It is the responsibility of the device owner to make sure all personnel read this manual prior to using the device. It is also the responsibility
of device owner to keep this manual intact and in a convenient location for all to see and read. If the manual or product labels are lost or
not legible, contact NAPA for replacements. If the operator is not uent in English, the product and safety instructions shall be read to
and discussed with the operator in the operator’s native language by the purchaser/owner or his designee, making sure that the operator
comprehends its contents.
THE NATURE OF HAZARDOUS SITUATIONS
The use of car Wheel Dollies is subject to certain hazards that cannot be prevented by mechanical means, but only by the exercise of
intelligence, care, and common sense. It is essential to have personnel involved in the use and operation of the device who are careful,
competent, trained, and qualified in the safe operation of the device and its proper use when servicing motor vehicles and their components.
Examples of hazards are dropping, tipping or slipping of loads caused primarily by improperly securing loads, overloading, off-centered loads,
use on other than hard level surfaces, and using equipment for a purpose for which it was not intended.
METHODS TO AVOID HAZARDOUS SITUATIONS
• Read, study, understand and follow all instructions before operating this device.
• Use of this product is limited to transporting only.
• Dollies must be used in pairs. Dollies are to be used to support vehicles. Do not use to support vehicles without wheels.
 •Inspectthedollybeforeeachuse.Donotuseifdamaged,altered,modied,inpoorcondition,leakinghydraulicuid,orunstabledue
  tolooseormissinghardwareorparts.Takecorrectiveactionbeforeusing.
• Wear eye protection that meets ANSI Z87.1 and OSHA standard.
• Do not exceed rated capacity.
• Use only on a hard, level, dry concrete surface free from expansion joints and all obstructions.
• Do not use with tires that are wider than 12”.
• Before moving vehicle, ensure the vehicle wheels are centered and secure.
• Do not start the vehicle’s engine or drive the vehicle when mounted on Dollies. Dollies are designed for manually moving the vehicle.
 •Activatethewheeland/orcasterlockingdevicesaftermovingavehicle.
• Do not use (or modify) this product for any other purpose than that for which it was designed without consulting the manufacturer’s
authorized representative.
 •Neverworkon,aroundorunderavehiclewhilesupportedbyvehiclemovingdollies.
• Failure to heed these warnings may result in serious or fatal personal injury and/or property damage.
WARNING:Thisproductcanexposeyoutochemicalsincludingnickel,whichisknowntotheStateofCaliforniatocausecancerand 
birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov.
CONSEQUENCES OF NOT AVOIDING HAZARDOUS SITUATIONS
Failure to read this manual completely and thoroughly, failure to understand its OPERATING INSTRUCTIONS, SAFETY WARNINGS,
MAINTENANCE INSTRUCTIONS and comply with them, and failure to comply with the METHODS TO AVOID HAZARDOUS SITUATIONS
could cause accidents resulting in serious or fatal personal injury and/or property damage.
WARNING: Indicates a hazardous situation
which, if not avoided, could result in death
or serious injury.
WARNING
WARNING
WARNING
WARNING

791-5260A 3 12/19/18
OPERATING MANUAL FOR 791-5260A
ASSEMBLY INSTRUCTIONS
1. Attach L-brackets (Ref No. 2) to main frame (Ref No. 1) using hardware provided (Ref No. 5, 6).
2. Attach locking casters (Ref No. 3) to L-brackets on one side of main frame with provided hardware (Ref No. 5, 6, 7).
3. Attach casters (Ref no 4) to L-bracket on the other side of the main frame using hardware provided (Ref no. 5, 6, 7)
OPERATING INSTRUCTIONS
1. Lift the vehicle.
2. Carefully place dolly under center of wheel.
3. Lower the vehicle.
4. Repeat for other dolly.
NOTE: Dollies must ALWAYS be used in pairs.
5. Dollies are for moving vehicle ONLY.
Do NOT walk on or under vehicle while supported
with dollies.
OWNER/USER RESPONSIBILITY
The owner and/or user must have an understanding of the manufacturer’s operating instructions and warnings before using this these car
dollies. Personnel involved in the use and operation of equipment shall be careful, competent, trained, and qualied in the safe operation
of the equipment and its proper use when servicing motor vehicles and their components. Warning information should be emphasized and
understood. If the operator is not uent in English, the manufacturer’s instructions and warning shall be read to and discussed with the
operator in the operator’s native language by the purchaser/owner, making sure that the operator comprehends its contents. Owner and/or
user must study and maintain for future reference the manufacturers’ instructions. Owner and/or user is responsible for keeping all warning
labels and instruction manuals legible and intact. Replacement labels and literature are available from the manufacturer.
WARRANTY
Please contact your local NAPA Auto Parts Store for details on warranty.

791-5260A 4 12/19/18
791-5260A - 1,250 LBS.
CAR DOLLY (PAIR)
REF # PART# DESCRIPTION QTY
1 Main Frame 1
2 RS5260A02 L-Brackets (set of 4) 1
3 RS526003A Locking Caster (each) 2
4 RS526002A Non-Locking Caster (each) 2
5 * Bolt M8 x 20 32
6 * Lock Washer 32
7 * Nut 16
N/S RS7915260APLK Product label kit 1
* RS5260AHK Caster Hardware Kit Includes Ref. No. 5, 6 and 7

791-5260A 5 12/19/18
791-5260A
ESPECIFICACIONES:
791-5260A
PLATAFORMA RODANTE PARA COCHE,
1250 LBS. (EL PAR)
Capacidad......................................................... 1,250 lbs.
Tamaño de la base....................................... 17.5" x 14.6"
Altura .............................................................................7"
Peso del Producto............................................... 48.4 lbs.
Peso del Envío ................................................... 50.6 lbs.
