NAPCO NP-DMOD-4OUT User manual

DESCRIPTION
A Power Distribution Module, the NP-DMOD-4OUT
easily converts a single AC or DC output power supply
into four (4) individually fused outputs.
FEATURES
•Surge protected outputs.
•Conveniently converts a single AC or DC input into
four (4) individually fused outputs (fuses are rated @
3 Amps fuses may be used).
•Handles up to 28VAC/VDC.
•Power output LED indicator.
•Board dimensions: 131.83mm(H) x 85.34mm(W) x
28mm(D)
INSTALLATION INSTRUCTIONS
1. Mount the NP-DMOD-4OUT in desired location/
enclosure.
2. Connect the desired power supply output to termi-
nals marked [INPUT].
Note: If using DC voltage, left terminal is NEG. (-)
and right terminal is POS. (+).
3. Connect each device to terminal pairs 1 to 4, marked
[1+ 1- thru 4+ 4-].
Note: It is important to measure output voltage be-
fore connecting devices. This helps avoid potential
damage.
All terminals with common suffix P 1+, 2+...” are
same polarity.
4. Fuses rated at 3 Amps.
R
333 Bayview Avenue
Amityville, New York 11701
For Sales and Repairs, [phone]
For Technical Service, [phone]
NP-DMOD-4OUT
4 OUTPUT
POWER DISTRIBUTION MODULE
WI1337A 12/05
© NAPCO 2005
APPENDIX LIST
Item Description Dimension Volume Memo
1 Instruction Sheet A4 1
2 Double Stick Foam Tape 60*20*7mm 2
