INTRODUCTION
Veri-Phone is a programmable two-way voice module that allows on-line (live) communication between a central
station and the premises. To simplify installation, the Veri-Speaker consists of a siren, microphone and speaker in
one compact unit. With only 4 wires, hookup is easy and convenient. See WI783 for more information regarding
the operation and triggering methods for your control panel.
WIRING THE VERI-SPEAKER TO THE VERI-PHONE MODULE
Connect the Veri-Speaker wires as shown in the table below and diagram on the following page.
R
333 Bayview Avenue
Amityville, New York 11701
For Sales and Repairs, [phone]
For Technical Service, [phone]
VERI-SPEAKER
AUDIO SUPPORT UNIT
VERI-PHONE WIRING INSTRUCTIONS
WI1197A 4/03
VERI-SPEAKER WIRING DESCRIPTION
Veri-
Speaker
Wire Color
Veri-
Phone
Terminal
Veri-Phone
Terminal
Number
Comments
Black 12V (-)
(GND)
2 System Ground
Red 12V (+) 1 +12 Volt power input. Requires 350mA for siren, and 20mA for micro-
phone and speaker.
Green SPKR (+) 4 8 ohm speaker input and siren trigger input. Speaker automatically
connected, unless +12 volts or ground activates siren.
Yellow Mic 6, 7, 8 Pre-amplifier driven microphone output, rated 600 ohm maximum.
Gain adjustment located at upper right of opened Veri-Speaker unit.
RECOMMENDED INITIAL SETTINGS
1. Please note there are two microphone gain potentiometers, one on the Veri-Phone, and one on the Veri-
Speaker. For initial setup, it is recommend to set the microphone gain potentiometer on the Veri-Phone to the
full counter-clockwise position. Set gain potentiometer as per the Veri-Speaker wiring scenarios (a) or (b) below:
(a) Under normal conditions with the Veri-Speaker yellow microphone wire connected to a single microphone
channel (terminals 6 or 7 or 8), the initial position for the Veri-Speaker microphone gain potentiometer
should be at the full clockwise position.
(b) In the example shown on the following page (with the yellow microphone wire connected to all three termi-
nals 6, 7 and 8), the initial setting for the Veri-Speaker microphone gain potentiometer should be set to the
"one-half" position (see comment 2 below).
2. When using only one microphone, it is advisable to connect microphone inputs 1,2, and 3 together. When doing
so, avoid VOX feedback by reducing the Veri-Speaker microphone gain potentiometer to the "one-half" position.
3. Set the speaker volume potentiometer on the Veri-Phone module to the full clockwise position.
continued on reverse

1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25
12V
+ –
SPKR
– +
IN MICROPHONES
SPKR 1 2 3 + –
INH LOC TRGL TRGH CTRL INHO
NO NC COM
TELCO IN
T R
TELCO OUT
T R
SENSE
IN OUT
DS1
STATUS
E1
VERI-PHONE
R37
CUT FOR BOOST
T1
RED
GREEN
RED
BLACK
GREEN
YELLOW
NOTE: As compared to page 6 of the Veri-Phone manual (WI783), this draw- ing displays Telco wired to the control panel before the Veri-Phone to avoid tripping the control panel's line fault sensor while Veri-Phone audio is on line.
VERI-SPEAKER
TYPICAL
CONTROL
PANEL
1 5
2 874 6 3
16VAC IN BELL
POS NEG
AUX PWR
POS NEG PGM1 PGM2
2928
26 27
TELCO IN
T R
TELCO OUT
T R
E5
E19
GRAY
NOTE: For negative (–) trigger, use terminal 13; for positive (+) 12v trig- ger, use terminal 14.
NOTE: Siren Trigger com- patible with (+)12v or (–) trigger alarm outputs.
RJ31X
BROWN
MIC
GAIN
SPKR
VOL
Napco GEM-P1632 control panel shown.
