NAPCO NP-DMOD-8OUT User manual

DESCRIPTION
A Power Distribution Unit, the NP-DMOD-8OUT easily
converts a single AC or DC output power supply into
eight (8) individually fused outputs.
FEATURES
•Handles up to 28VAC/VDC.
•Converts a single AC or DC input into eight (8) indi-
vidually fused outputs (fuses rated @ 3 Amps may be
used).
•Power output LED indicator.
•Surge protected outputs.
•Board dimensions: 131.83mm(L) x 85.34mm(W) x
24.6mm(H)
INSTALLATION INSTRUCTIONS
1. Mount NP-DMOD-8OUT in desired location/
enclosure.
2. Connect the desired power supply output to termi-
nals marked [INPUT].
Note: If using DC voltage, right terminal is NEG. (-)
and left terminal is POS. (+).
3. Connect each device camera to terminal pairs 1 to 8,
marked [+ thru -].
Note: It is important to measure output voltage be-
fore connecting devices. This helps avoid potential
damage.
All terminals with common suffix “+” are same polar-
ity.
4. Fuses rated at 3 Amps VAC.
R
333 Bayview Avenue
Amityville, New York 11701
For Sales and Repairs, [phone]
For Technical Service, [phone]
NP-DMOD-8OUT
8 OUTPUT
POWER DISTRIBUTION MODULE
WI1338B 12/05
© NAPCO 2005
APPENDIX LIST
Item Description Dimension Volume Memo
1 Instruction Sheet A4 1
2 Double Stick Foam Tape 60*20*7mm 2
