NAPCO GEM-SMK User manual

Description. The GEM-SMK is a high-quality photoelec-
tric smoke detector with built-in supervised digitally-coded
radio transmitter. It is compatible with Napco’s GEM-
RECV Series supervised security receivers that monitor
alarms, restores, low battery and status.
The GEM-SMK sounds a local alarm as soon as smoke is
detected and the transmitter will send an alarm signal to
the supervised receiver. The alarm signal will be repeated
every 10 seconds thereafter as long as smoke is still pre-
sent. A restore report will be sent when the smoke detec-
tion chamber clears. Supervisory status reports are sent
from the GEM-SMK every hour.
Coding switches are not required or used in the GEM-
SMK. Each transmitter is assigned a unique identification
code number at the factory.
REMOVE MOUNTING
PLATE
Step 1. Remove the mounting plate. Remove the
GEM-SMK mounting plate by turning the plate
counter-clockwise and pulling it up.
TWIST
MOUNTING
PLATE TO
UNLOCK
Step 3. Install batteries. Connect the two 9-
volt alkaline batteries and place them into
the battery holding clips.
CONNECT AND
INSTALL TWO 9-
VOLT ALKALINE
BATTERIES
Step 2. Identify components. Examine the GEM-
SMK to identify the component locations.
TRANSMITTER
BOARD
BATTERY
HOLDING
CLIPS
R
333 Bayview Avenue
Amityville, New York 11701
For Sales and Repairs, [phone]
For Technical Service, [phone]
Publicly traded on NASDAQ Symbol: NSSC
© NAPCO 2005
GEM-SMK
SUPERVISED
DIGITAL SMOKE DETECTOR
INSTALLATION INSTRUCTIONS
WI750B 2/05
The smoke detector and transmitter are powered by two
9-volt alkaline batteries (supplied) which can power the
unit for up to two years. If the battery voltage drops be-
low normal, a low-battery report will be sent to the re-
ceiver with any status or alarm transmission. If a low-
battery condition is indicated, replace both batteries.
NOTE: Temperature and humidity extremes may reduce
the life of the battery.
continued

NOTE: Smoke alarms are not to be used with detector guards unless the combina-
tion has been evaluated and found suitable for that purpose.
Step 4. Pick smoke-detector location. Referring to
the NFPA standard on page 3, select a good location to
mount the GEM-SMK. Mounting the GEM-SMK on foil-
backed wallpaper or on metal single-gang electrical box
is NOT recommended because the radio range will be
reduced.
Step 5. Install mounting plate. Use the two screws and
anchors provided to attach the mounting plate to the wall
or ceiling. Alternatively, the mounting plate may be at-
tached to a plastic single-gang electrical outlet box.
SCREW
ANCHORS
FOR
WALLBOARD
OR PLASTIC
SINGLE-GANG
ELECTRICAL
BOX
Step 6. Map the GEM-SMK Transmitter. Referring to
the instructions for the panel and keypad in use, enter
the following:
•the zone to which the transmitter will be mapped;
•the 6-digit identification number/1-digit checksum
number printed on the transmitter (include all num-
bers and/or letters and leading zeros, if any); and
•the transmitter point number ("1").
NOTE: In fire alarm installations, the control panel
must be programmed to activate the fire alarm bells or
horns upon detection of a fire.
Maintenance. To clean the smoke detector, vacuum
the outside of the unit at least once a year (preferably
every six months) using a soft brush attachment. Do
not attempt to clean the unit in any other way.
Step 8. Test system with unit mounted. If the sys-
tem is monitored, notify central station of impending
test. Press and hold the test button. Keep the button
depressed for 30 seconds after the local alarm
sounds. Verify that the GEM-SMK triggers the correct
zone on the control panel and that the correct report
is sent to the central station.
HOLD BUTTON FOR AT
LEAST 30 SECONDS
AFTER LOCAL ALARM
SOUNDS TO SEND AN
ALARM TRANSMISSION
PRESS AND HOLD
DETECTOR TEST
BUTTON
Step 7. Attach the GEM-SMK to mounting plate.
Match up alignment tabs on detector and plate. Turn
detector clockwise until it locks into place.
MATCH UP
ALIGNMENT
TABS
TWIST DETECTOR
CLOCKWISE TO
LOCK TO MOUNTING
PLATE

NFPA STANDARD FOR SMOKE-DETECTOR LOCATION
The GEM-SMK should be installed in accordance with the Na-
tional Fire Protection Association (NFPA) Standard 72, which is
summarized below.
Smoke detectors shall be installed outside of each separate
area in the immediate vicinity of the bedrooms and on each addi-
tional story of the family living unit including basements and exclud-
ing crawl spaces and unfinished attics. This represents the mini-
mum number of detectors required. It is recommended that the
householder consider the use of additional smoke or heat detectors
for increased protection for those areas separated by a door from
areas protected by the required smoke detectors. The recom-
mended additional areas are: living room, dining room, bedroom(s),
kitchen, attic (finished or unfinished), furnace room, utility room,
basement, integral or attached garage and hallways. However, the
use of additional detectors remains the option of the householder.
For family living units with one or more split levels (i.e., adjacent
levels with less than one full story separation between levels), a
smoke detector required as above shall suffice for an adjacent
lower level, including basements.
Exception: Where there is an intervening door between one
level and the adjacent lower level, a smoke detector shall be in-
stalled on the lower level.
•Ceiling-mounted smoke alarms should be located in the center
of the room or hall, or not less than 4 inches from any wall.
When the detector is mounted on a wall, the top of the detector
should be 4 to 12 inches from the ceiling.
•Do not install smoke alarms where normal ambient tempera-
tures are above 100°F (37.8°C), or below 40°F (4°C). Also, do
not locate alarm in front of air conditioners, heating registers, or
other locations where normal air circulation will keep smoke
from entering the detector.
FIRE PREVENTION AND ESCAPE
The purpose of an early warning smoke alarm is to detect the
presence of fire in its early stages, and sound an alarm giving the
occupants more time to exit the premise before the smoke reaches
a dangerous concentration level.
Fires start even with the best of housekeeping and fire-
prevention procedures. Fire is an unexpected event. Early warning
detection alerts occupants in time to act.
KNOW FIRE HAZARDS. No detection device can protect life in
all situations. Therefore, safeguards should be taken to avoid such
potentially dangerous situations as smoking in bed, leaving children
home alone, cleaning with flammable liquids such as gasoline.
The best fire protection is minimizing fire hazards through
proper storage of materials and general good housekeeping tech-
niques. A cluttered basement, attic, or other storage area is an
open invitation to fire.
Careless use of combustible materials and electrical appliances,
or overloading of electrical outlets are other prime causes in starting
fires.
It is most important that explosive and/or fast-burning materials
be eliminated from the home if at all possible.
Even after proper precautions have been taken, fires can start.
Be prepared.
IN CASE OF FIRE. Leave immediately. Don’t stop to pack or
search for valuables. In heavy smoke, hold your breath and stay
low -- crawl if necessary. The clearest air is usually at the floor.
If you have to go through a closed door, carefully feel the door
and door knob to see if undue heat is present. If they seem rela-
tively cool, brace your foot against the bottom of the door with your
hip against the door and one hand against the top edge. Open it
slightly. If a rush of hot air is felt, slam the door quickly and latch it.
Unvented fire tends to build up considerable pressure. Be sure all
the household realizes and understands this danger.
Use your neighbor’s phone or a street fire alarm box. The job of
extinguishing the fire should be left to the professionals. Too many
unforeseen things can occur when inexperienced people try to ex-
tinguish afire.
BE PREPARED. Perform fire drills regularly. Use them to as-
sure recognition of an alarm signal. For your protection, simulate
different circumstances (smoke in hall, in living room, etc.). Then
have everyone react to the situation.
Draw a floor plan and show two exits from each room. Fre-
quently, a knotted rope or ladder from a window will serve this pur-
pose. It is important that children be instructed carefully, because
they tend to hide in times of crisis.
It is imperative that one meeting place outside the home be es-
tablished. You should insist that everyone meet there during an
alarm. This will eliminate the tragedy of someone reentering the
house for a missing member who is actually safe.
If you have children and/or invalids residing in your household, you
can help your fire department. Most fire departments have window
decals available for use in children’s or invalid’s bedrooms. Properly
used, these decals will quickly identify sleeping quarters of these
individuals and show the department where to look first for mem-
bers of your household.
Additional information on Household Fire Warning is available at
nominal cost from The National Fire Protection Agency, Battery-
march Park, Quincy, MA 02269. Request Standard No. NFPA 72.
A smoke alarm should be
located between the sleeping
area and the rest of the family
living unit.
In family living units with more
than one sleeping area, a smoke
alarm should be provided for
each separate sleeping area.
Indicates required smoke detector
Indicates optional smoke detector if
door is not provided between Living
and Recreation rooms.

NAPCO SECURITY SYSTEMS, INC. (NAPCO) warrants
its products to be free from manufacturing defects in
materials and workmanship for thirty-six months following
the date of manufacture. NAPCO will, within said period,
at its option, repair or replace any product failing to
operate correctly without charge to the original purchaser
or user.
This warranty shall not apply to any equipment, or any part
thereof, which has been repaired by others, improperly
installed, improperly used, abused, altered, damaged,
subjected to acts of God, or on which any serial numbers
have been altered, defaced or removed. Seller will not be
responsible for any dismantling or reinstallation charges.
THERE ARE NO WARRANTIES, EXPRESS OR
IMPLIED, WHICH EXTEND BEYOND THE
DESCRIPTION ON THE FACE HEREOF. THERE IS NO
EXPRESS OR IMPLIED WARRANTY OF MERCHANT
ABILITY OR A WARRANTY OF FITNESS FOR A
PARTICULAR PURPOSE. ADDITIONALLY, THIS
WARRANTY IS IN LIEU OF ALL OTHER OBLIGATIONS
OR LIABILITIES ON THE PART OF NAPCO.
Any action for breach of warranty, including but not limited
to any implied warranty of merchant ability, must be
brought within the six months following the end of the
warranty period.
IN NO CASE SHALL NAPCO BE LIABLE TO ANYONE
FOR ANY CONSEQUENTIAL OR INCIDENTAL
DAMAGES FOR BREACH OF THIS OR ANY OTHER
WARRANTY, EXPRESS OR IMPLIED, EVEN IF THE
LOSS OR DAMAGE IS CAUSED BY THE SELLER'S
OWN NEGLIGENCE OR FAULT.
In case of defect, contact the security professional who
installed and maintains your security system. In order to
exercise the warranty, the product must be returned by the
security professional, shipping costs prepaid and insured
to NAPCO. After repair or replacement, NAPCO assumes
the cost of returning products under warranty. NAPCO
shall have no obligation under this warranty, or otherwise,
if the product has been repaired by others, improperly
installed, improperly used, abused, altered, damaged,
subjected to accident, nuisance, flood, fire or acts of God,
or on which any serial numbers have been altered,
defaced or removed. NAPCO will not be responsible for
any dismantling, reassembly or reinstallation charges.
This warranty contains the entire warranty. It is the sole
warranty and any prior agreements or representations,
whether oral or written, are either merged herein or are
expressly canceled. NAPCO neither assumes, nor
authorizes any other person purporting to act on its behalf
to modify, to change, or to assume for it, any other
warranty or liability concerning its products. In no event
shall NAPCO be liable for an amount in excess of
NAPCO's original selling price of the product, for any loss
or damage, whether direct, indirect, incidental,
consequential, or otherwise arising out of any failure of the
product. Seller's warranty, as herein above set forth, shall
not be enlarged, diminished or affected by and no
obligation or liability shall arise or grow out of Seller's
rendering of technical advice or service in connection with
Buyer's order of the goods furnished thereunder.
NAPCO RECOMMENDS THAT THE ENTIRE SYSTEM
BE COMPLETELY TESTED WEEKLY.
Warning: Despite frequent testing, and due to, but not
limited to, any or all of the following; criminal tampering,
electrical or communications disruption, it is possible for
the system to fail to perform as expected. NAPCO does
not represent that the product/system may not be
compromised or circumvented; or that the product or
system will prevent any personal injury or property loss by
burglary, robbery, fire or otherwise; nor that the product or
system will in all cases provide adequate warning or
protection. A properly installed and maintained alarm may
only reduce risk of burglary, robbery, fire or otherwise but
it is not insurance or a guarantee that these events will not
occur. CONSEQUENTLY, SELLER SHALL HAVE NO
LIABILITY FOR ANY PERSONAL INJURY, PROPERTY
DAMAGE, OR OTHER LOSS BASED ON A CLAIM THE
PRODUCT FAILED TO GIVE WARNING. Therefore, the
installer should in turn advise the consumer to take any
and all precautions for his or her safety including, but not
limited to, fleeing the premises and calling police or fire
department, in order to mitigate the possibilities of harm
and/or damage.
NAPCO is not an insurer of either the property or safety of
the user's family or employees, and limits its liability for
any loss or damage including incidental or consequential
damages to NAPCO's original selling price of the product
regardless of the cause of such loss or damage.
Some states do not allow limitations on how long an
implied warranty lasts or do not allow the exclusion or
limitation of incidental or consequential damages, or
differentiate in their treatment of limitations of liability for
ordinary or gross negligence, so the above limitations or
exclusions may not apply to you. This Warranty gives you
specific legal rights and you may also have other rights
which vary from state to state.
NAPCO LIMITED WARRANTY
NAPCO SECURITY GROUP
333 Bayview Avenue, Amityville, New York 11701 For Sales and Repairs, [phone] For Technical Service, [phone]
Publicly traded on NASDAQ Symbol: NSSC
