NASAB CM3060 User manual

Installation Guide
Model: CM3060
LoRaWANTM
MULTICAL READER

2LoRaWAN™ MULTICAL READER CM3060
1. Register the unit to the LoRa network
• Details needed for registering the device with your LoRa service
provider are included in a separate sticker.
2. Open Multical meter housing
3. Install Multical Reader into the expansion module slot.
 •Terminalblocksiderst
• Lock it in place
4. Connect external antenna
5. Close Multical meter housing
• Use dedicated wire outlets
6. Apply DC voltage (optional)
INSTALLATION GUIDE
Prerequisites
Installation procedure
• Free expansion module slot
2.
3.
4.
5.
Connect external DC power supply (optional)
• +3,7V - positve
• GND - negative
• Do not remove battery if present
• Set switch to EXT position

3LoRaWAN™ MULTICAL READER CM3060
VISUAL GUIDE
+-+--
PULSE A PULSE B
+
U.Antennaconnection
SAFETY NOTICE
1. Read, follow, and keep these instructions.
2. Heed all warnings.
3.Onlyuseattachments/accessoriesspeciedbythemanufacturer.
Electrostatically sensitive device, hold PCB only fom it edges, do not touch
components on the PCB.
Product is delivered in the form of printed cirquit board (PCB) for internal
installation only.
REVISION HISTORY
0.1 - First draft
0.2 - Updated process
All content contained herein is subject to change without notice. Nordic Automation Systems reserves the right
to change or modify the content at any time.
WARNING:
WARNING:
Do not apply power before connecting the antenna!WARNING:
POWER
