Nasta KS-86PR001FK User manual

Operating instructions
Indoor ventilation Passive air register with pollen filter
Please read carefully before installation
Nasta KS-86PR001FK
Body dimensions: 200mm square
Compatible with 150mm duct
Wind direction control
Freely change the orientation of the surface cover for comfort, and to protect
against dust on curtains or furniture
Air volume adjustment
By rotating the disk on the back side of the front cover, the air volume can be
adjusted between Sealed, 1, or 2
Seal can be used to protect against strong/harsh winds, or when ventilation is not
required - not for typical use
Features:
Parts List
Body
Body cover
Rubber Seal
Filter frame
Filter
Filter cartridge
Cover Volume
control disc
Please note that the product design and specifications are subject to change without notice
www.universalfans.com.au
Please retain this manual
Manufactured by
Nasta Co, Ltd

Cleaning and maintenance
Remove the cover
Remove the filter cartridge by pinching the arms of cartridge, rotating
counter-clockwise, and pull gently
To replace, reverse the process ensuring the water guard is at the bottom
1.
2.
3.
If the rubber ring is removed, reattach with firm side facing out Filter cartridge
Water guard
Rubber ring
Turn counter-
clockwise
Pull
Removing and installing the filter
The filter can be removed by lifting the
clips on the top and bottom of the filter
frame
Pull
Filter frame
Filter cartridge
Filter
Clip
Insert the filter into the back of the filter
cartridge, with the firmer side facing the
room
Insert the filter frame into the cartridge
Filter cartridge
Socket
Clip
Filter frame
Pollen filter
Changing the orientation
Depending on the environment (walls, ceilings, curtains, furniture etc.) the direction of the
openings can be changed by removing and replacing the cover of the register
Bedroom Living room
Removing and installing the cover
Push
Push
Cover
Pull Push
Push
Push
Cover
Push in the two opposite open sides of the cover
Pull lightly away from the body
1.
2.
To reattach the cover, perform these actions in reverse
Removing Installing
Adjusting the volume
Cover (reverse)
The disc on the back of the cover allows you to control the amount of air allowed into the room:
S
1
2
Sealed
Level 1 - half
Level 2 - full
Control dial
(enlarged)
Volume control disc
Current setting
Control dial
(enlarged)
Push
Turn
Care Instructions
Wipe off any dirt and dust with a soft cloth, and a neutral detergent (if required)
Do NOT use turpentine, benzine, acids, or alkaline cleaners such as bleach
How to clean the cover and body cover:
Remove dust, and wash with water once every 3 months
Replace every 6 months or as required
How to care for and replace the filter:
