Nat 3110-000 Owner's manual

INSTALLATION AND OPERATION
MANUAL SUPPLEMENT
NAT Part #: 3110-000 Description: Audio Control Panel
Document #: SM3110\3110-000\810-0 Rev: 1.00
This supplement contains installation and operation information that is unique to the
3110-000 Audio Control Panel. Installation and operation information common to the
3110-100 base unit can be found in the Installation and Operation section of the
SM3110 Installation and Service Manual.
1 Description
The 3110-000 is identical to the 3110-100 with the following exceptions.
a) Changes to the faceplate can be found by comparing figure 1 to figure 2.
PAHF CAB
HDPH
VOX MUTE SPKR
MKR ADF2ADF1
COM3
COM2
COM1
ST
VBOTH ID
INPH
NAV1 NAV2 DME1 DME2
PA
HDPHVOX MUTE SPKR
MKR ADF1
COM2COM1
ST
VBOTH ID
INPH
NAV1 NAV2 DME1 DME2
Figure 1: 3110-100 Figure 2: 3110-000
b) The COM3, HF, and CAB knobs, push-button switches, and indicators are
not installed on the front panel.
c) The ADF2 knob is not installed on the front panel.
Sep 16, 2005 Page 1 of 2
ENG-FORM: 810-0105.DOT
CONFIDENTIAL AND PROPRIETARY TO NORTHERN AIRBORNE TECHNOLOGY LTD.

3110-000 Audio Control Panel Manual Supplement Rev. 1.00
2 Installation
For general Installation information and drawings, see Service Manual SM3110 Section
2. Select the appropriate revision of the drawing for the serial number of the unit under
consideration. The drawings specific to this derivative are listed below, and can be
found at the end of this supplement.
2.1 Installation Drawings
DRAWING REV. DESCRIPTION TYPE SERIAL #
3110\000\403-0 1.00 Audio Control Panel Interconnect All
3110\000\403-1 1.00 Audio Control Panel Interconnect All
3110\000\403-2 1.00 Audio Control Panel Interconnect All
3110\000\403-3 1.00 Audio Control Panel Interconnect All
3110\000\403-4 1.00 Audio Control Panel Interconnect All
3110\000\403-5 1.00 Audio Control Panel Interconnect All
3110\000\405-0 1.00 Audio Control Panel Connector Map All
3110\000\905-0 1.00 Audio Control Panel Faceplate All
3 Operation
For general Operation information, see Service Manual SM3110 Section 3.
End of Installation and Operation Manual Supplement
Page 2 of 2 Sep 16, 2005
ENG-FORM: 810-0105.DOT
CONFIDENTIAL AND PROPRIETARY TO NORTHERN AIRBORNE TECHNOLOGY LTD.

PA
HDPHVOX MUTE SPKR
MKR ADF1
COM2COM1
ST
VBOTH ID
INPH
NAV1 NAV2 DME1 DME2
