National Geographic 300X-1200X User manual

Install Batteries
1. Remove button screws and cover.
2. Install batteries with the positive
(+) and negative (-) in the correct
direction indicated by the battery
compartment label.
3. Replace the cover and screws.
Please recycle batteries responsibly.
How Do I Use My Microscope
Before you use your microscope, make sure that the table, desk or surface that you
place it on is stable and is not subject to vibration. If the microscope needs to be moved,
hold it by the arm and base while carefully transferring it. Once the microscope is in a
suitable location and the batteries are installed, check the light source to make sure that
it illuminates. Use a microfiber cleaning cloth to gently wipe the lenses o. If the stage is
dirty with dust or oil, carefully clean it o. Make sure that you only raise and lower the stage
using the focus adjustment knob.
How Do I Operate The Illumination?
Locate the mirror/light on the base of the microscope. Flip the mirror/light to the “on”
position (with the light facing up) and the light will illuminate. This microscope is equipped
with an incandescent light that illuminates the specimen from below. The color filter wheel
is located in the middle of the microscope stage. The filters help you when you observing
very bright or clear specimens. Using these filters, you can choose various brightness
levels and colors. This helps you better recognize the components of colorless or
transparent objects (e.g. sea salt).
How Do I Adjust My Microscope Correctly?
Place the microscope in a suitable location as described above, and sit in a comfortable
viewing position. Always start each observation with the lowest magnification. Adjust the
distance of the microscope stage so that the stage is in the lowest position — farthest
away from the turret head. Turn the objective turret until it clicks into place at the lowest
magnification (Objective: 5x/Magnification: 100x). Note: Before you change the objective
setting, always make sure the microscope stage is farthest away from the turret by
rotating the focus knob. Separating the stage and turret by rotating the focus knob will
avoid causing damage to the specimen slide or microscope. When starting an observation,
always start with the 5x objective in the rotating head.
How Do I Observe The Specimen?
Sitting in your location with adequate illumination, the following basic rules should be
observed. Start with a simple observation at the lowest magnification. Position the object
or specimen in the middle of the stage under the stage clips, center over the lower light.
Focus the image by rotating the focus knob until a clear image appears in the eyepiece.
Place the prepared slide directly under the objective on the microscope stage and secure
it with the stage clips. The prepared slide should be located directly over the lower
illumination. Look through the eyepiece and carefully turn the focus knob until the image
appears clear and sharp. Now you can select a higher magnification by rotating to the
objective turret. Higher levels of magnification can be achieved by turning the objective
turret to a higher setting (400x or 900x). Following this procedure creates a steady
increase of magnification without overpowering the view of the object. The following
magnification order should be used: 100x, 400x then 900x. Each time the magnification
changes (due to the objective change), the image sharpness must be readjusted with the
focus knob. When doing this, be careful because if you move the microscope stage too
quickly, the objective and the slide could come into contact and cause damage to the slide
or microscope.
For transparent objects (e.g. sea salt), light is projected by the lower light traveling from
below the stage, through the objective and eyepiece, and finally into your eye. This process
of light transmission is known as microscopy. Many micro-organisms found in water, plant
components and the smallest animal parts are transparent in nature. Opaque specimens,
on the other hand, will need to be prepared for viewing. Opaque specimens can be made
transparent by a process of treatment and penetration with the correct materials (media),
or by slicing. You can read more about creating specimens in the enclosed microscope
experiments booklet.
MAGNIFICATION GUIDE:
Eyepiece Objective Power
20x 5x 100x
20x 20x 400x
20x 45x 900x
NOTE:
THE HIGHEST MAGNIFICATION IS NOT ALWAYS THE BEST FOR
EVERY SPECIMEN!
TROUBLESHOOTING GUIDE:
Problem Solution
No recognizable image Turn on light, Readjust focus,
Start with the lowest power objective (5x)
No image Center object on slide under
lowest power objective
No light Replace batteries, Check on/o position
©2020 National Geographic Partners LLC. All rights reserved.
NATIONAL GEOGRAPHIC and Yellow Border Design are trademarks of the
National Geographic Society, used under license.
©2020 Explore Scientic, LLC.
1010 S. 48th Street, Springdale AR 72762
All rights reserved. explorescienticusa.com | 866.252.3811
Made in China
CONTENTS AND COLORS MAY VARY
CONFORMS TO THE SAFETY REQUIREMENTS OF ASTM F963
V042020

CHOKING HAZARD — Small parts.
Not for children under 8 years.
WARNING:
FUNCTIONAL SHARP POINT — Not for
children under 8 years.
WARNING:
900X MICROSCOPE SET
INSTRUCTION MANUAL
*Not suitable for children under 8 years of age. Contains functional sharp points.
Microscope Parts:
01. Eyepiece
02. Focus Knob
03. Stage with Color Filters
04. Stage Clips
05. Objective Turret (5x, 20x, 45x)
06. Illumination On/O Switch and Mirror
07. Rubber Base and Battery Case
08. Microscope Arm
09. (5) Prepared Slides and (7) Blank Slides with Slide Case
10. (7) Slide Covers/Labels
11. (2) Collection Vials
12. Test Tube
13. Petri Dish
14. Scalpel / Needle* / Tweezers / Stirring Rod
15. Slicer
16. Blue Dye / Red Dye / Sea Salt / Brine Shrimp Eggs
17. Hatchery
NOT INCLUDED
X2
Do not mix old and new batteries. Do not mix alkaline,
standard (carbon-zinc), or rechargeable (ni-cad, ni-mh, etc.) batteries.
Non-rechargeable batteries are not to be recharged.
Please recycle batteries responsibly.
01
02
03
06
07
08
12
13
14
15
16
17
80-50101
EN
8+
• THIS MICROSCOPE SET IS INTENDED FOR CHILDREN OLDER THAN AGE 7. CHILDREN SHOULD ONLY USE THIS DEVICE UNDER
ADULT SUPERVISION. NEVER LEAVE A CHILD UNSUPERVISED WITH THIS DEVICE. ACCESSORIES IN THE EXPERIMENT KIT MAY
HAVE SHARP EDGES AND TIPS. PLEASE STORE THE DEVICE AND ALL OF ITS ACCESSORIES AND AIDS OUT OF THE REACH OF
YOUNG CHILDREN WHEN NOT BEING USED DUE TO A RISK OF INJURY.
• CHEMICALS: ANY CHEMICALS AND LIQUIDS USED IN CONJUNCTION WITH THE DEVICE SHOULD BE KEPT OUT OF REACH OF
CHILDREN. DO NOT DRINK ANY OF THE CHEMICALS CONTAINED IN THIS SET. HANDS SHOULD BE WASHED THOROUGHLY UNDER
RUNNING WATER AFTER WORKING WITH THESE CHEMICALS. IN CASE OF ACCIDENTAL CONTACT WITH EYES OR MOUTH, RINSE
THE AFFECTED AREA WITH WATER. SEEK MEDICAL TREATMENT FOR AILMENTS ARISING FROM CONTACT WITH THE CHEMICAL
SUBSTANCE, AND TAKE THE CHEMICALS WITH YOU TO THE DOCTOR.
• CHOKING HAZARD: CHILDREN SHOULD ONLY USE DEVICE UNDER ADULT SUPERVISION. KEEP PACKAGING
MATERIALS LIKE PLASTIC BAGS AND RUBBER BANDS OUT OF THE REACH OF CHILDREN AS THESE MATERIALS
POSE A CHOKING HAZARD.
• BATTERY GUIDELINES: THIS DEVICE CONTAINS ELECTRONIC COMPONENTS THAT ARE POWERED BY BATTERIES.
BATTERIES SHOULD BE KEPT OUT OF CHILDREN’S REACH. WHEN INSERTING BATTERIES, PLEASE ENSURE THE POLARITY IS
CORRECT. INSERT THE BATTERIES ACCORDING TO THE DISPLAYED +/- INFORMATION. NEVER MIX OLD AND NEW BATTERIES.
REPLACE ALL BATTERIES AT THE SAME TIME. NEVER MIX ALKALINE, STANDARD CARBON-ZINC AND RECHARGEABLE
NICKEL-CADMIUM BATTERIES. NEVER SHORT CIRCUIT THE DEVICE OR BATTERIES OR THROW EITHER INTO A FIRE. LEAKING
OR DAMAGED BATTERIES CAN CAUSE INJURY IF THEY COME INTO CONTACT WITH THE SKIN. IF YOU NEED TO HANDLE
SUCH BATTERIES, PLEASE WEAR SUITABLE SAFETY GLOVES. REMOVE BATTERIES FROM THE PRODUCT BEFORE EXTENDED
STORAGE TO PREVENT LEAKING. DO NOT IMMERSE THE BATTERY COMPARTMENT IN WATER. NON-RECHARGEABLE BATTERIES
ARE NOT TO BE RECHARGED. RECHARGEABLE BATTERIES ARE TO BE REMOVED FROM THE TOY BEFORE BEING CHARGED.
RECHARGEABLE BATTERIES ARE ONLY TO BE CHARGED UNDER ADULT SUPERVISION. EXHAUSTED BATTERIES ARE TO BE
REMOVED FROM TOY. THE SUPPLY TERMINALS ARE NOT TO BE SHORT-CIRCUITED. PLEASE RECYCLE BATTERIES RESPONSIBLY.
• RISK OF FIRE: DO NOT PLACE DEVICE, PARTICULARLY THE LENSES, IN DIRECT SUNLIGHT. THE CONCENTRATION OF LIGHT
RAYS COULD CAUSE A FIRE.
• DO NOT DISASSEMBLE THIS DEVICE. IN THE EVENT OF A DEFECT, PLEASE CONTACT YOUR DEALER. THE DEALER WILL
CONTACT THE CUSTOMER SERVICE DEPARTMENT AND CAN SEND THE DEVICE IN TO BE REPAIRED IF NECESSARY.
• DO NOT SUBJECT THE DEVICE TO TEMPERATURES EXCEEDING 60 °C (140 °F).
• DISPOSAL: KEEP PACKAGING MATERIALS, LIKE PLASTIC BAGS AND RUBBER BANDS, AWAY FROM CHILDREN AS
THEY POSE A RISK OF SUFFOCATION. DISPOSE OF PACKAGING MATERIALS AS LEGALLY REQUIRED. CONSULT THE
LOCAL AUTHORITY ON THE MATTER IF NECESSARY AND RECYCLE MATERIALS WHEN POSSIBLE.
• THE WEEE SYMBOL IF PRESENT INDICATES THAT THIS ITEM CONTAINS ELECTRICAL OR ELECTRONIC
COMPONENTS WHICH MUST BE COLLECTED AND DISPOSED OF SEPARATELY.
• NEVER DISPOSE OF ELECTRICAL OR ELECTRONIC WASTE IN GENERAL MUNICIPAL WASTE. COLLECT AND DISPOSE
OF SUCH WASTE SEPARATELY.
• MAKE USE OF THE RETURN AND COLLECTION SYSTEMS AVAILABLE TO YOU, OR YOUR LOCAL RECYCLING
PROGRAM. CONTACT YOUR LOCAL AUTHORITY OR PLACE OF PURCHASE TO FIND OUT WHAT SCHEMES ARE AVAILABLE.
• ELECTRICAL AND ELECTRONIC EQUIPMENT CONTAINS HAZARDOUS SUBSTANCE WHICH, WHEN DISPOSED OF INCORRECTLY,
MAY LEAK INTO THE GROUND. THIS CAN CONTRIBUTE TO SOIL AND WATER POLLUTION WHICH IS HAZARDOUS TO HUMAN
HEALTH, AND ENDANGER WILDLIFE.
• IT IS ESSENTIAL THAT CONSUMERS LOOK TO RE-USE OR RECYCLE ELECTRICAL OR ELECTRONIC WASTE TO AVOID IT GOING TO
LANDFILL SITES OR INCINERATION WITHOUT TREATMENT.
