INSTALLATION GUIDE
IMAQ A8014 Camera Cable
This guide describes how to use the National Instruments IMAQ A8014
analog camera cable to connect the PCI/PXI-1409 or PCI-1410 image
acquisition (IMAQ) device to a camera.
The IMAQ A8014 cable provides direct connection between the
IMAQ 1409/1410 device and the camera without using a breakout box.
Use the IMAQ A8014 cable with the following Sony and JAI cameras:
• Sony XC-ES Series
• Sony XC-ST Series
• Sony XC-HR Series
• JAI A-Series
Note Refer to the Sony and JAI Web sites and documentation for information about the
functionality of these cameras.
Getting Started
The following items are necessary for connecting the IMAQ A8014 cable:
❑IMAQ A8014 cable
❑IMAQ A8014 Camera Cable Installation Guide
❑IMAQ 1409 device and documentation
or
❑IMAQ PCI-1410 device and documentation
❑Camera and documentation
™

IMAQ A8014 Installation Guide 2 ni.com
Connecting the IMAQ A8014 Cable
Complete the following steps to connect the IMAQ A8014 cable to the
IMAQ 1409/1410 device and camera. Refer to Figure 1 for an illustration
of the IMAQ A8014 cable.
1. Connect the 68-pin male VHDCI connector to the connector on the
IMAQ 1409/1410 device and tighten the thumbscrews.
2. Connect the 12-pin male Hirose connector to the camera power supply.
3. Connect the 12-pin female Hirose connector to the input receptacle on
the camera.
Optional Connections
1. Connect the external trigger to the Ext. Trig 0 BNC.
2. Connect any device requiring general-purpose digital input/output,
such as a strobe light, to the Ext. Trig 1 BNC.
Figure 1. IMAQ A8014 Cable
Connectors
The 68-pin VHDCI connector provides connection to the
IMAQ 1409/1410 device, and the 12-pin Hirose connectors provide
connection to the camera. Figures 2 and 3 show the pinouts for these
connectors.
1 68-Pin Male VHDCI Connector
2 12-Pin Male Hirose Connector
3 12-Pin Female Hirose Connector
4Ext.Trig0
5Ext.Trig1
NATIONAL INSTRUMENTS
1
2
3
4
5

©National Instruments Corporation 3 IMAQ A8014 Installation Guide
Figure 2. 68-Pin VHDCI Connector (Cable)
Figure 3. Hirose Connector (Cable)
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
9
10
4
11
12
1
65
8
7
2
3

National Instruments, NI, ni.com, and LabVIEW are trademarks of National Instruments Corporation.
Refer to the Terms of Use section on ni.com/legal for more information about National
Instruments trademarks. Other product and company names mentioned herein are trademarks or trade
names of their respective companies. For patents covering National Instruments products, refer to the
appropriate location: Help»Patents in your software, the patents.txt file on your CD, or
ni.com/patents.
© 2003–2005 National Instruments Corporation. All rights reserved. 373484B-01 Feb05
Pin Assignments
Table 1 shows the pin assignments for the connectors on the IMAQ A8014
cable.
Triggering
You can use the IMAQ A8014 cable for applications requiring precise
triggering or exposure control. In addition to connecting the video signal
between the camera and the IMAQ 1409/1410 device, the IMAQ A8014
cable also connects the camera control lines on the IMAQ 1409/1410 to the
exposure and trigger inputs on the camera. The IMAQ 1409/1410 can then
be programmed to generate precise timing pulses for controlling the
camera.
Tip Visit the National Instruments Camera Advisor Web site at ni.com/camera for
application notes and sample code for many of the cameras the IMAQ A8014 supports.
Table 1. IMAQ A8014 Connector Pin Assignments
Signal
68-Pin
VHDCI
12-Pin Male Hirose
(to Power Supply)
12-Pin Female Hirose
(to Camera) Ext. BNC 0 Ext. BNC 1
VIDEO(0) + 68 — 4 — —
VIDEO(0) – 67 — 3 — —
HSYNC_IN + 16 — 6 — —
DGND 26 — 5 — —
VSYNC_IN + 15 —10 — —
DGND 2 — 8 — —
PCLK_IN + 3 — 9 — —
DGND 39 — 8 — —
TRIG(3) 5 — 11 — —
DGND 41 —12 — —
TRIG(0) 8 — — Center —
DGND 42 — — Shield —
TRIG(1) 7 — — — Center
DGND 39 — — — Shield
DC +12V — 2 2 — —
DGND — 1 1 — —
