SCXI-1342 PC-LPM-16
Cable Assembly
Installation Guide
Part Number 320623-01
This guide describes how to install the SCXI-1342 PC-LPM-16 cable assembly between an
SCXI module and a data acquisition board. In addition to the SCXI-1342 kit contents, you will
need an SCXI chassis, an SCXI module, a computer, a data acquisition board, and a small
flathead screwdriver.
Introduction
With the SCXI-1342 PC-LPM-16 cable assembly, you can connect your PC-LPM-16 data
acquisition board to the following SCXI modules: the SCXI-1100, SCXI-1120, SCXI-1121,
SCXI-1140, SCXI-1160, SCXI-1161, SCXI-1162, and SCXI-1163. If you have a newly released
module that is not in this list, contact National Instruments for information on your cable needs.
The SCXI-1342 cable assembly consists of a 50-conductor NB1 ribbon cable and an adapter
board. Use the ribbon cable to connect the I/O connector of the PC-LPM-16 to the adapter board
rear connector, which has latches. The adapter board also has a female right-angle module
connector that plugs into the rear of the SCXI module. In addition, the adapter board has an
extra male breakout connector that provides the unmodified signals of the PC-LPM-16 for use
with other accessories. For example, you can connect this male breakout connector to an
SCXI-1180 feedthrough panel to bring the PC-LPM-16 pinout to the front of your SCXI chassis.
What Your Kit Should Contain
The contents of the SCXI-1342 PC-LPM-16 cable assembly kit (part number 776574-42) are as
follows:
Kit Component Part Number
1.0 m NB1 cable
Two small screws
Adapter board
SCXI-1342 PC-LPM-16 Cable Assembly Installation Guide
180524-10
742413-01
181760-01
320623-01
If your kit is missing any of the components, contact National Instruments.
371182A-01

SCXI-1342 Cable Assembly Installation Guide 2 © National Instruments Corporation
Installation Procedure
Figure 1 illustrates the components of your SCXI system.
SCXI 1140
SCXI Module
NB1 Ribbon Cable
Extra Male
Breakout Connector
(Optional Connection)
PC-LPM-16 Board
SCXI-1342
Adapter Board
Figure 1. Connecting the SCXI-1342 to Your Data Acquisition Board and SCXI Module
Perform the following steps to install the SCXI-1342 cable:
1. Turn off the power to your computer and the SCXI chassis.
2. Install your SCXI module in the SCXI chassis, following the instructions in your module
user manual.
3. Set jumper W1 on the SCXI-1342 adapter board to the correct position for your system, as
shown in Figure 2. When set to position A, the factory-default position, jumper W1 connects
pin 46 of the PC-LPM-16 to pin 46 of the module connector. Position B breaks this
connection. Leave jumper W1 in position A unless you are using an SCXI-1140 module and
are not supplying the HOLDTRIG signal to the module from the PC-LPM-16. See your
SCXI-1140 User Manual for an explanation of the HOLDTRIG signal.
A
B
Position A
HOLDTRIG Connected
BA
Position B
HOLDTRIG Disconnected
Figure 2. Jumper W1 Settings
4. Plug the female right-angle module connector of the SCXI-1342 adapter board into the rear
signal connector of the SCXI module.

© National Instruments Corporation 3 SCXI-1342 Cable Assembly Installation Guide
5. Secure the SCXI-1342 adapter board by screwing the two screws through the rear panel of
the adapter board and into the threaded strips in the rear of the SCXI chassis.
6. Install your data acquisition board in a slot in your computer, following the instructions in
your data acquisition board user manual.
7. Connect one end of the NB1 cable to the rear connector of the adapter board.
8. Connect the loose end of the NB1 cable to the I/O connector on the PC-LPM-16 as shown in
the detail in Figure 3.
The finished installation should look like Figure 3.
SCXI
Chassis
SCXI-1342
Cable Assembly
Computer
NB1 Ribbon Cable
PC-LPM-16 Board
Figure 3. Installed Cable
SCXI-1342 Pin Translations
The following table lists the way that the SCXI-1342 translates pins from the PC-LPM-16 to the
SCXI module.

SCXI-1342 Cable Assembly Installation Guide 4 © National Instruments Corporation
Rear
Connector Pin
PC-LPM-16
Signal Name
Male Breakout
Connector Pin
SCXI Module
Connector Pin
1 ACH0 1 3
2 ACH1 2 5
3 ACH2 3 7
4 ACH3 4 9
5 ACH4 5 11
6 ACH5 6 13
7 ACH6 7 15
8 ACH7 8 17
9 AIGND 9 1, 2
10 DAC0 OUT 10 20
11 AOGND 11 23
12 DAC1 OUT 12 21
13 DGND 13 24, 33
14 PA0 14 Not connected
15 PA1 15 Not connected
16 PA2 16 Not connected
17 PA3 17 Not connected
18 PA4 18 Not connected
19 PA5 19 Not connected
20 PA6 20 Not connected
21 PA7 21 Not connected
22 PB0 22 Not connected
23 PB1 23 Not connected
24 PB2 24 Not connected
25 PB3 25 Not connected
26 PB4 26 25
27 PB5 27 27
28 PB6 28 29
29 PB7 29 37
30 PC0 30 Not connected
31 PC1 31 26
32 PC2 32 28
33 PC3 33 Not connected
34 PC4 34 Not connected
35 PC5 35 Not connected
36 PC6 36 Not connected
37 PC7 37 Not connected
38 EXTTRIG 38 Not connected
39 EXTUPDATE* 39 Not connected
40 EXTCONV* 40 36
41 OUTB0 41 Not connected
42 GATB0 42 Not connected
43 OUTB1 43 46
44 GATB1 44 Not connected
45 CLKB1 45 Not connected
46 OUTB2 46 Not connected
47 GATB2 47 Not connected
48 CLKB2 48 Not connected
49 +5V 49 34, 35
50 DGND 50 24, 33
