Installation Guide
_____________________________
Product and company names are trademarks or trade names of their respective companies.
320815A-01 © Copyright 1994 National Instruments Corporation. All rights reserved. October 1994
DAQ Board Accessories Rack-Mount Kit
This guide describes how to assemble the rack-mount hardware for the AMUX-64T analog
multiplexer board and the SC-205X, SC-206X, SC-207X, and BNC-208X Series signal
conditioning boards in a standard 19-in. rack-mount cabinet.
Introduction
There are four versions of the rack-mount kit—single- and double-height kits with an acrylic
plastic cover, and single- and double-height kits with a metal wraparound cover. The metal
wraparound cover kits are ideal for high-voltage applications. However, we do not recommend
the metal wraparound cover kits for use with the BNC-208X Series boards.
What You Need to Get Started
You will need the following parts from your DAQ board accessories rack-mount kit, depending
on the version you have:
Plexiglas cover kit
Item Component Quantity
2 Cover, rack-mount, Plexiglas 1
4 Washer, flat, #4, nylon 4
Metal wraparound cover kit
Item Component Quantity
2 Cover, rack-mount, metal wraparound 1
4 Washer, flat, #4, SS 4

Double-height kits
Item Component Quantity
5 Support bracket, AMUX, type 2 2
6 Screw, 6-32 x 1/4, FLHD, PHIL, SS 4
You will also need the following items from your kit, regardless of which version you have.
All of the DAQ board accessories rack-mount kits have the following items:
Item Component Quantity
1 Bracket, rack-mount, 5.25 in., type DA 1
3 Screw, 4-40 x 1/4, PHN, SS 4
7 Foot, rubber adhesive 4
DAQ Board Accessories Rack-Mount Kit
Installation Guide 1
In addition, you will need:
1-point Phillips-head screwdriver for assembling the rack-mount kit
flathead screwdriver for installing the kit into a cabinet
circuit card assemblies.
Mounting Space
The following table shows how much space each accessory requires in a single-height
rack-mount kit. Three SC-205X (except for the SC-2054) or SC-206X boards fit into one
rack-mount kit. You can mix SC Series accessories in one rack-mount kit. For example, you
can use one SC-2051 with two SC-206X units, or one SC-2051 with one SC-207X.
Accessory Width Required
AMUX-64T Two-thirds
SC-2050, SC-2051, SC-2052, SC-2053 One-third
SC-2054 One-half
SC-206X Series One-third
SC-207X Series One-half
BNC-208X Series One-half

3
Installation Procedure
Refer to the preceding figure and perform the following steps:
1. Attach the rubber adhesive feet (item 7) onto the bottom of the rack-mount bracket (item 1).
2. If you are building a double-height kit, install the support brackets (item 5) using the
6-32 x 1/4 screws (item 6).
3. Install the circuit card assemblies. You purchase the assemblies separately. Mounting
screws and hardware are supplied with the assemblies.
4. Install the cover (item 2) using the 4-40 x 1/4 screws (item 3) and the #4 flat washer (item 4).
5. Place the completed rack-mount kit into a standard 19-in. rack-mount cabinet and secure the
assembly.
